MP-8
1110307
2010+ Dodge 6.7L
Installation Manual
Thank you for buying the MP-8 for the 07.5 Dodge 6.7L. Here you will learn how to
install this MP-8 into your truck, and we guarantee that you will be satisfied with
our product. Before you get started check to make sure that you have everything
below in the contents that came in the box.
Contents:
MP-8 Module Harness (TSP01BO)
Velcro (1) (2) Zip Ties
Shim Kit
HP increase of up to 100hp
Decrease Fuel Consumption
When removed leaves no trace of modification or foot prints

Continued
Installation of the TS Performance Power Play Mp-8
2011+ Dodge 6.7L
Read all instructions and fully understand them before installing you TS Performance MP-8 module.
Disconnect the battery terminals and remove keys from ignition before installation.
Place Di-Electric Grease onto every electrical connection.
1. Disconnect the positive
terminals on both
batteries.Failure to do this will
cause a Check Engine Light and it
will have to be cleared with a code
reader. (Any time the module is
installed or removed, the batteries
must be disconnected.)
2. Remove the dipstick and 4 bolts
holding the plastic cover plate on top
of the engine.
3. Using an 11mm wrench remove the 2
clamps holding the EGR tube that
crosses in front of the valve cover.
You do not have to remove the tube
only tilt the tube up towards the front
of the truck.
4. Using a 10mm socket and wrench,
remove the bolt that holds the dipstick
tube to the bracket and the 6 bolts that
hold the air horn to the manifold.
Making sure not to damage the gasket,
slide the air horn forward so that you
can access the front of the fuel rail.
5. Remove the 18mm fuel rail valve located
on the front of the fuel rail.
6. Take valve and thread supplied nut tool
onto valve. Then place valve in a vice,
clamping down on sides of valve cap.

Continued
7. Use a wrench to unscrew supplied nut in
order to remove valve cap. Be careful to
hold end of valve while doing this! It is
spring loaded and you don’t want to lose
parts!
8. Removing metal spring, then insert the 3
supplied metal shims into valve.
9. Replace valve spring and then cap. Note
that there are 3 holes in a triangle
position on the inside of the valve cap
that does not need to be removed from
cap and should face towards spring as it
did when it was removed, hole
alignment is not necessary.
10. Place valve back in vice, now with a
thick piece of cardboard or piece of
wood behind valve cap to prevent
damage to the valve seal surface.
Tighten vice so that the valve cap
reenters valve until fully seated. No need
to over-tighten; just tighten until snug.

Continued
11. Take a small punch and small hammer
and re-apply the 3 factory indentations
along the lip where the valve casing
covers the valve cap. You may need to
loosen the vice slightly to rotate the
valve to access all 3 indentations, but do
not let the spring push the cap out any!
Make sure that the cap stays fully seated
in valve while rotating. After doing so
loosen the vice and make sure that the
valve cap is held by the indentations.
12. Re-install the fuel valve and tighten it down to 100 ft. lbs.
13. Now you can re-install the air horn, make sure to line up the six holes in the
gasket with the bolt holes for the air horn. Also connect the dipstick tube to the
bracket on the air horn.
14. Line the EGR tube back up. For easier installation line up one side to its
connection, install the clamp but leave it loose enough so you have a little
movement to connect the other side. Then fully tighten both sides, once you have
both sides lined up correctly.
15. Locate the fuel pressure sensor on the back of the fuel rail close to the fire wall.
Plug the factory connector into our harness and our harness into the fuel pressure
sensor.
16. Connect our harness to the MP-8 module and mount the MP-8 in a location of
your choice.

Continued
TS Performance
851 Lovers Ln
Bowling Green, KY 42103
270-746-9999
www.tsperformance.com
READ CAREFULLY BEFORE INSTALLING ANY TS PERFORMANCE PRODUCT
REMEMBER THIS IS A HIGH PERFORMANCE PRODUCT. USE AT YOUR OWN RISK. FOR OFF ROAD USE ONLY.
Do not use this product until you have carefully read the following agreement. This agreement sets forth the terms
and conditions for the use of the TS Performance product. The installation of this product indicates that the buyer has
read and fully understands this agreement and accepts its terms and conditions.
DISCLAIMER OF LIABILITY
TS Performance, its distributors or dealers shall in no way be responsible for the product’s proper use and service. The
buyer of this system hereby waives all liability claims. The buyer acknowledges that he is not relying on the sellers
skill or judgment to select or furnish goods suitable for any particular purpose and that there are no liabilities which
extend beyond the description on the face hereof, and the buyer hereby waives all remedies or liabilities, expressed or
implied arising by law or otherwise, (including without obligations of the seller with respect fitness, merchantability
and consequential damages) or whether or not occasioned by the seller’s negligence.
The seller disclaims any warranty and expressly disclaims any liability for personal injury or damages. The buyer
acknowledges and agrees that the disclaimer of any liability for personal injury is a material term for this agreement
and the buyer agrees to indemnify the seller and to hold the seller harmless from any claim related to the item of the
equipment purchased. Under no circumstances will the seller be liable for any damages or expenses by reason of use or
sales of any such equipment.
The seller assumes no liability regarding the improper installation or misapplication of its products. It is the installer’s
responsibility to check for proper installation and if in doubt the manufacturer is to be contacted.
LIMITED LIFETIME WARRANTY
STATEMENT POLICY
The warranty policy is the best warranty within the high performance diesel industry.
All TS Performance products have been inspected, tested and trial in the factory laboratories and on the
field.
Nothing in this Statement of Policy shall alter or enlarge the terms of warranties, obligation or liabilities of
these products.
TS Performance is not responsible or liable for any products damaged or destroyed due to improper
installation.
TERMS OF WARRANTY
The defective product must be freight prepaid and returned to TS Performance for further investigation,
otherwise this warranty shall be deemed null and voided and of no effect.
This warranty is void on any products that show evidence of misapplication, negligence, and improper
installation, and abuse, lack of proper maintenance or alternation from its original design.
In no event will TS Performance be liable for any consequential or incidental damages for breach of any
express or implied warranty on the product.
This warranty is not transferable or assignable.
TS Performance is not responsible or liable for any products damaged or destroyed due to improper
installation
.IN THE EVENT THAT THE BUYER DOES NOT AGREE WITH THIS AGREEMENT: THE
BUYER MAY PROMPTLY RETURN THIS PRODUCT IN A NEW ANDN UNUSED
CONDITION WITH A DATED PROOF OF PURCHASE TO THE PLACE OF PURCHASE
WITHIN TEN (10) DAYS FROM DATE OF PURCHASE FOR A FULL REFUND.
