Perle C-100MM Series User manual

P/N 5500313-10
Perle Fast Ethernet Fiber to
Fiber
Media Converter
Module
Installation Guide
C-100MM-XXXXX Unmanaged Module
CM-100MM-XXXXX Managed Module

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 2
Overview
This document contains instructions necessary for the installation
and operation of the Perle Fast Ethernet Fiber to Fiber Media
Converter Module(s) (C-100MM and CM-100MM) that are used in
conjunction with a Perle MCR chassis. The C-100MM are the
unmanaged media converter modules, and the CM-100MM are
the managed versions. These products allow dissimilar 100Base-X
fiber interfaces to connect to each other.
These are the fiber to fiber conversion models:
•Multimode to Multimode (MM)
•Multimode to Single Mode (SM)
•Multimode to Single Mode Single Strand (SM)
These media converter modules operate over different
wavelengths and distances, depending on the model selected
(See tables below). For information on the management options of
the CM-100MM converter module, refer to the MCR-MGT Module
User’s Guide.
Fiber port 1 – MM1
Model Connector Mode Distance Wavelength
(TX/RX)
All models SC/ST/LC MM. 2 km/1.2 mi. 1310 nm
Fiber port 2 – MM2/SM2
Model Connector Mode Distance Wavelength
(TX/RX)
C-100MM-M2xx2
CM-100MM-M2xx2 SC/ST/LC MM 2 km/1.2 mi. 1310 nm
C-100MM-S2xx20
CM-100MM-S2xx20 SC/ST/LC SM 20 km/12.4 mi 1310 nm
C-100MM-S2xx40
CM-100MM-S2xx40 SC/ST/LC SM 40 km/24.9 mi 1310 nm
C-100MM-S2xx80
CM-100MM-S2xx80 SC/ST/LC SM 80 km/49.7 mi 1550 nm
C-100MM-S2xx120
CM-100MM-S2xx120 SC/ST/LC SM 120 km/74.6mi 1550 nm
C-100MM-S1SC20U
CM-100MM-S1SC20U SC SM 20 km/12.4 mi. 1310/1550 nm

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 3
C-100MM-S1SC20D
CM-100MM-S1SC20D SC SM 20 km/12.4 mi. 1550/1310 nm
C-100MM-S1SC40U
CM-100MM-S1SC40U SC SM 40 km/24.9 mi. 1550/1310 nm
C-100MM-S1SC40D
CM-100MM-S1SC40D SC SM 40 km/24.9 mi. 1550/1310 nm
Note: Please refer to Perle’s web site for the most up to date
Installation guides, models and specifications
http://www.perle.com/

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 4
Installation
The media module comes equipped with a bank of DIP switches
and jumpers for setting configuration. The default DIP switch
settings (all switches in the UP position) and jumper settings will
work for most installations.
The following steps are used to configure the Perle Fast Media
Converter Module:
•Set the Auto-Config jumper. (CM-100MM only) (optional)
•Set the DIP switch settings. (optional).
•Insert the media module into the chassis.
•Connect fiber cable 1 to port MM1.
•Connect fiber cable 2 to port MM2/SM2.
Auto-Config Jumper (CM-100MM only)
The Auto-Config jumper is J5.
Refer to the diagram below for labelling. This jumper only applies
to the CM-100MM converter module.
Auto (Pin 2 and Pin 3 are strapped): When set to Auto. At power
up the media module will, check its internal flash memory to see if
configuration information has been downloaded to it from a
management module. If so, the media module will use this
configuration as its running configuration. If there is no
configuration in flash, the media module will read the settings of
the DIP switches and use those settings as its running
configuration.
SW (Pin 1 and Pin 2 are strapped): When set to SW (Switch). At
power up, the media module will read the settings of the DIP
switches and use those settings as its running configuration. The
media module will ignore any configuration information in its flash
memory.
Note: The default jumper setting is Auto

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 5
DIP Switch Settings
Note: All switch changes take effect immediately and will result in
a link reset on both fiber ports.
Link Mode (Switch 1)
Switch
Position Mode
Up (default) Link Pass-Through Mode
Down Standard Mode
Link Pass-Through: In this mode, the link state on one fiber
connection is directly reflected through the media module to the
other fiber connection.
Standard Mode: In this mode, each fiber link can be brought up
and down independently of each other. A loss of link on either fiber
connection can occur without affecting the other fiber connection.

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 6
Far End Fault (Switch 2)
Switch
Position Mode
Up (default) Enabled
Down Disabled
Enabled: If the media module detects a loss of fiber signal on the
fiber receiver, the media module will immediately send a FEF on
the transmitter of its fiber link to the remote end module. This, in
effect, notifies the fiber link partner that an error condition exists on
the fiber connection.
Note: This switch needs to be set to either generate or detect the
Far-End Fault signal.
Disabled: The media module will not monitor for, or generate Far
End Fault.
Illustration of the FEF feature
Media Converter A Configuration
Link Mode–Standard Mode
Far-End Fault–Enabled
Media Converter B Configuration
Link Mode–Link Pass Through Mode
Far-End Fault–Enabled

Fast Ethernet Fiber to Fiber Media Module – Installation Guide
Sequence of Events
1. Media module Aloses fiber connection (RX) on MM2/SM2.
2. Media module Asends FEF on transmitter (TX) MM2/SM2.
3. Media module Bdetects loss of fiber link on receiver RX –
MM2/SM2.
4. Media module Bturns off transmitter (TX) on MM1.
5. Media module AMM1 is not affected.
Remote Loopback Fiber 1 (Switch 3)
Switch
Position Mode
Up (default) Disabled
Down Enabled
Disabled: This is the normal position for regular operation. The
switch must be set to this position in order for data to pass through
the media module.
Enabled: This is a test mode. All data received on the receive
(RX) fiber connection is looped back to the transmit (TX) fiber
connection.
Note: Only one fiber interface can be in loopback at a time.
Remote Loopback Fiber 2 (Switch 4)
Switch
Position Mode
Up (default) Disabled
Down Enabled
Disabled: This is the normal position for regular operation. The
switch must be set to this position in order for data to pass through
the media module.
Enabled: This is a test mode. All data received on the receive
(RX) fiber connection is looped back to the transmit (TX) fiber
connection.
Note: Only one fiber interface can be in loopback at a time.

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 8
Installing Media Converter Modules
Caution: Observe electrostatic discharge precautions when
installing the media module(s) into the chassis. Failure to observe
this caution could result in damage to the module(s) and/or
chassis.
The Perle media module can be installed in any available slot and
in any order within the MCR chassis.
•Remove the media module from its packaging.
•Using a cross-head screwdriver, remove the screw holding the
face plate to the chassis to reveal the slot opening.
•Set the jumpers and DIP switches on the media module to the
desired operating mode. (optional)
•Locate the top and bottom alignment guides inside the MCR
chassis.
•Using the module alignment guides gently slide the module
into the slot until it becomes flush with the front of the chassis.
Light pressure may be needed to seat the module. Do not
force the module as you might cause damage. If there is
resistance, remove the module and check the module
connector for damaged or incorrectly aligned pins. If these are
not damaged, retry to insert the module.
•Tighten the captive retainer screw to ensure the media module
is locked in place.
•Remove the dust caps from the fiber connectors and connect
the fiber cables.

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 9
Removing Media Convert Modules
Loosen the captive retainer screw on the front of the media
module and gently pull the module towards you.
If not inserting a replacement media module cover the opened slot
with a face plate and secure the screw.
Installing the Duplex Fiber Cable
Locate a 100Base-X compliant duplex (2 strands) fiber cable with
the appropriate connectors.
Connect the fiber cables from the media module to the other
media module/switch/fiber device ensuring that the RX and TX are
reversed at the opposite end.
Installing the Simplex Fiber Cable
Locate a 100Base-X compliant simplex (1 strand) fiber cable with
appropriate connectors.
Connect the fiber cable from one media module to another media
module/converter/switch/fiber device.

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 10
Operation
Status LED
The Perle Fast Ethernet Media Converter modules have three
single colored status LEDs located on the face plate of the
module.
PWR - Power/Test
•On- Power is on, the module is operating normally.
•Blinking- slowly: the module is in loopback mode.
•Blinking- quickly: the module has a hardware error.
LK1 – MM1 (Fiber Link 1) Activity
•On- Fiber link present.
•Blinking- quickly: Fiber link present and receiving data.
•Off- No fiber link present.
LK2 – MM2/SM2 (Fiber Link 2) Activity
•On- Fiber link present.
•Blinking- quickly: Fiber link present and receiving data.
•Off- No fiber link present

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 11
Troubleshooting
General
•Ensure the module is correctly seated to the backplane in the
MCR chassis. The PWR LED should be on solid.
•Ensure all cabling is of the correct type and is in good working
order.
•Ensure both devices on either end of the fiber are compatible.
If using a simplex fiber connection, ensure that you have both
an Upstream (U) and Downstream (D) media module.
•For duplex fiber connections, ensure the RX and TX has been
reversed between the two media converter module.
No connectivity
If unable to get full connectivity with all DIP switches in the UP
position, these methods are recommended for troubleshooting.
Note: If troubleshooting a CM-100, setting the Auto-Config jumper
(J5) to SW will ensure the DIP switches are being read.
Method 1
1. Set the Link mode to Standard (SW1 – Down) on both media
converter module. Leave all other switches in the Up position.
2. Connect the near end device to the MM1 port. The LK1 should
be lit to indicate a good fiber connection. If the LK1 LED is not
lit, then check the fiber cable and the attached device.
3. Repeat step 2 for the MM2/SM2 port
4. Return the media module to the desired configuration.
Method 2:
The fiber connection can also be verified by configuring the remote
media module for loopback mode. The LEDs on both media
converter module should be lit. Data should pass through the local
module, over the fiber connection to the remote media module. At
the remote media module, the data will be looped back and
passed through MM2/SM2 transmit fiber link.

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 12
Technical Specifications
The following applies to all C-100MM and CM-100MM media
converter modules:
Power Input/Consumption 12V DC /3.5 W
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -25°C to 0°C (-13°F to 158°F)
Operating Humidity: 5% to 90% non-condensing
Storage Humidity: 5% to 95% non-condensing
Operating Altitude: Up to 3,048 m (10,000 ft)
Weight: 0.15 kg (0.33 lbs)
MTBF: (C-100MM) 484,202 hours
(CM-100MM) 489,076 hours
Dimensions: 203 mm by 38 mm by 152 mm
(8 in. By 1.5 in by 6 in
Fiber Optic Specifications
Fiber port 1 – MM1
Model Mode Wave length
(nm)
TX Power
(dB) RX Power (dB) Budget (dB)
C-100MM-M2SC2
CM-100MM-M2SC2 MM TX: 1310
RX: 1310 Min: -20 Max: -12 Min: -31 Max: -14 11
Fiber port 2 – MM2/SM2
Model Mode Wave length
(nm)
TX Power
(dB) RX Power (dB) Budget (dB)
C-100MM-M2SC2
CM-100MM-M2SC2 MM TX: 1310
RX: 1310 Min: -20 Max: -12 Min: -31 Max: -14 11
C-100MM-M2ST2
CM-100MM-M2ST2 MM TX: 1310
RX: 1310 Min: -20 Max: -12 Min: -31 Max: -14 11
C-100MM-M2LC2
CM-100MM-M2LC2 MM TX: 1310
RX: 1310 Min: -20 Max: -12 Min: -30 Max: -14 10
C-100MM-S2SC20
CM-100MM-S2SC20 SM TX: 1310
RX: 1310 Min: -18 Max: -7 Min: -32 Max: -3 14
C-100MM-S2ST20
CM-100MM-S2ST20 SM TX: 1310
RX: 1310 Min: -15 Max: -8 Min: -32 Max: -3 17

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 13
Model Mode Wave length
(nm)
TX Power
(dB) RX Power (dB) Budget (dB)
C-100MM-S2LC20
CM-100MM-S2LC20 SM TX: 1310
RX :1310 Min: -15 Max: 0 Min: -34 Max: -5 19
C-100MM-S2SC40
CM-100MM-S2SC40 SM TX: 1310
RX :1310 Min: -5 Max: 0 Min: -34 Max: -3 29
C-100MM-S2ST40
CM-100MM-S2T40 SM TX: 1310
RX :1310 Min: -5 Max: 0 Min: -34 Max: -3 29
C-100MM-S2LC40
CM-100MM-S2LC40 SM TX: 1310
RX :1310 Min: -5 Max: 0 Min: -34 Max: -3 29
C-100MM-S2SC80
CM-100MM-S2SC80 SM TX: 1550
RX: 1550 Min: -5 Max: 0 Min: -34 Max: -3 29
C-100MM-S2ST80
CM-100MM-S2ST80 SM TX: 1550
RX: 1550 Min: -5 Max: 5 Min: -34 Max: -3 29
C-100MM-S2LC80
CM-100MM-S2LC80 SM TX: 1550
RX: 1550 Min: -5 Max: 0 Min: -34 Max: -3 29
C-100MM-S2SC120
CM-100MM-S2SC120 SM TX: 1550
RX: 1550 Min: 0 Max: 5 Min: -35 Max: -3 35
C-100MM-S2ST120
CM-100MM-S2ST120 SM TX: 1550
RX: 1550 Min: 0 Max: 5 Min: -35 Max: 0 35
C-100MM-S2LC120
CM-100MM-S2LC120 SM TX: 1550
RX: 1550 Min: 0 Max: 5 Min: -35 Max: -3 35
C-100MM-S1SC20U
CM-100MM-S1SC20U SM TX: 1310
RX: 1550 Min: -14 Max: -8 Min: -32 Max: -3 18
C-100MM-S1SC20D
CM-100MM-S1SC20D SM TX: 1550
RX:1310 Min: -14 Max: -8 Min: -32 Max: -3 18
C-100MM-S1SC40U
CM-100MM-S1SC40U SM TX: 1310
RX:1550 Min: -8 Max: -3 Min: -33 Max: -3 25
C-100MM-S1SC40D
CM-100MM-S1SC40D SM TX: 1550
RX:1310 Min: -8 Max: -3 Min: -33 Max: -3 25
Fiber Cabling Requirements :
MM: 50/125 microns or 62.5/125 microns
SM: 9/125 microns
Note: Please refer the product page on the Perle website for the
most up to date specifications.
http://www.perle.com/

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 14
Compliance Information
FCC
This product has been found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions in this Guide, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at
his/her own expense.
EN 55022, Class A,
WARNING This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.
EN 55024, Class A
Laser Safety – IEC 60825-1:2007
This product meets Class I Laser safety requirements per IEC-60825-1:2007
standard and complies with FDA/CDRH 21 CFR1040.10 and 21 CFR1040.11.
WARNING: Visible and invisible laser radiation may be present when cables are
not connected. Do not stare into the beam or view the beam directly with optical
instruments. Failure to observe this warning could result in an eye injury or
blindness.
WARNING: Use of controls, adjustments or the performance of procedures other
than those specified herein may result in hazardous radiation exposure.

Fast Ethernet Fiber to Fiber Media Module – Installation Guide 15
Warranty / Registration
Perle’s standard Lifetime Warranty provides customers with return
to factory repairs for Perle products that fail under the conditions of
the warranty coverage. Details can be found at:
http://www.perle.com/support_services/warranty.shtml
Contacting Technical Support
Contact information for the Perle Technical Assistance Center
(PTAC) can be found at the link below. A Technical Support Query
may be made via this web page.
www.perle.com/support_services/support_request.shtml
Copyright
© 2011 Perle Systems Limited
All rights reserved. No part of this document may be reproduced or used in any
form without written permission from Perle Systems Limited.
