PetAirapy PA - 777 User manual

PA - 777 / PA-PRO PORTABLE AIR PURIFIER
Instruction Manual
Residential / Light Commercial Air Purication Unit
Thank you for selecting PetAirapy for your pets, your family and your home
Please keep the instruction manual for reference
PA-777 Model Shown PA-PRO Model Shown

Finally, an innovative, natural solution to your pet’s allergies
Breathe easy with your new PetAirapy PA-777 / PA-PRO unit
We know just how important the comfort and health of your pets and family are. Our air purication units have
been carefully and meticulously designed to keep pets and people more comfortable - reducing allergens that
cause asthma, colds and respiratory infections. Treatment that lasts a lifetime, not just a season!
PA-777 / PA-PRO Features:
o Targets allergens and other microorganisms including mold, viruses and bacteria. Protect your pets
and family from odor, environmental allergens and illnesses.
o SIX LAYERS of purifying power; UVC light, ULPA (Super HEPA) Filter, Aluminum Electric Static Plasma
Filter, Photo Catalyst Filter, Activated Carbon Filter, Anions (Ions).
o Kills, disinfects and lters up to 1,000 square feet
o UVC light has a robust 8000 hour lifespan
o Particle sensor allows the unit to be self-sufcient (PA-PRO model only)
o Color LED alerts you of your air quality with a red, purple or blue light
o Stylish, sleek, portable and easy to clean and maintain
PA-PRO Model Shown

PA - 777 / PA PRO | 3
PA-777 / PA-PRO Portable Air Purifier
Technical innovation for convenience
Diagram of the outer unit
Sensor switch settings
ULPA or Aluminum Electric Static Plasma Filter RESET button
Operating while in sensor mode
Maintenance and cleaning instructions
Cleaning the carbon fiber of ion generator
Cleaning the Aluminum Electric Static Plasma Filter
Cleaning the ULPA Filter
Cleaning and replacement of the UVC light
Technical parameters of the UVC light
Technical parameters of the Aluminum Electric Static Plasma Filter
Technical parameters of the ULPA Filter
Diagram of the inner unit
Diagram of the filters and UVC Light
Technical innovation for convenience
Specifications of the air sensor
4-5
4
5
6
6
6
6
7
7
7
8
8
8
9
9-10
9
9
10
10
11-12
11
11
11
12
12
12
13-15
13
14
15
15
16
17-18
17
17
17
18
18
18
9

PA - 777 / PA PRO | 4
Misusing or mishandling may cause death
Misusing or mishandling may cause injury
DO NOT
DISASSEMBLE,
REPAIR OR
RECONSTRUCT
THIS UNIT.
It may cause unit damage or fire.
PLUG THE POWER
CORD INTO THE
ELECTRICAL
OUTLET
COMPLETELY.
Failure to do so may cause fire or
electrical shock. Do not use if the
power cord or plug is damaged.
Do not plug the power cord into a
loose socket.
DO NOT USE ON AN
OVERLOADED
SOCKET OR WIRING
CONNECTOR.
ENSURE YOU ARE
USING THE RATED
VOLTAGE.
Failure to do so may cause fire
or electrical shock.
DANGER
DANGER
CLEAN THE POWER
CORD AND PLUG
REGULARLY.
If there is dust or debris on the plug,
it may weaken the insulation or even
cause fire.
Periodically inspect the plug for dust
or debris and clean it with a soft, dry
cloth.
Unplug the unit if it will be unused for
an extended period of time.
DO NOT INSERT
ANY METAL OR
FOREIGN OBJECTS
INTO THE UNIT
It may cause
injury or
electrical shock.
DANGER
DO NOT TOUCH
THE POWER CORD
OR PLUG WITH
WET HANDS.
It may cause electrical shock.
UNPLUG THE UNIT
BEFORE
DISASSEMBLY,
REASSEMBLY,
CLEANING OR
MAINTENANCE.
Failure to do so may cause injury
or electrical shock.
DANGER
DO NOT ATTEMPT TO REPAIR A DAMAGED POWER
CORD OR PLUG. DO NOT ATTEMPT TO REPAIR A
DAMAGED UNIT.
It may cause a short circuit, injury, electrical shock or fire.
THE SURFACE OF THE
UNIT SHOULD NEVER
COME IN CONTACT
WITH WATER
DANGER
It may cause a short circuit, injury or
electrical shock.

PA - 777 / PA PRO | 5
DANGER
DO NOT USE IN A HIGH
MOISTURE AREA.
It may cause injury,
electrical shock or fire.
DANGER
DO NOT USE THIS UNIT AS AN
EXHAUST FAN FOR SMOKE.
THIS UNIT IS NOT MEANT TO
BE USED AS A VENTILATOR.
It may cause injury
DANGER
DO NOT USE THIS UNIT IN AN
ATTEMPT TO CLEAR SMOKE
CAUSED BY FIRE. THIS UNIT IS
NOT MEANT TO BE USED AS A
VENTILATOR.
It may cause Carbon
Monoxide poisoning.
DANGER
DO NOT TURN ON THE UNIT
DURING OR IMMEDIATELY
AFTER USING AN INSECTICIDE
IN THE ROOM.
The insecticide may be stored in the unit and will be
expelled into the air during normal use which is harmful to
your health.
Please ventilate the room completely after having used
insecticide before turning on the unit.
KEEP ALL FLAMES, HOT ASH,
CANDLES, FLAMMABLE
MATERIALS AND
COMBUSTIBLE MATERIALS
AWAY FROM THE UNIT. DANGER
KEEP THE UNIT AWAY FROM
ALCOHOL, AEROSOLS OR
INSECTICIDE.
It may cause unit surface
damage, short circuit,
electric shock, injury or fire.
ALWAYS UNPLUG THE UNIT
USING THE PLUG INSTEAD OF
THE POWER CORD. NEVER TUG
OR PULL ON THE POWER CORD
TO UNPLUG THE UNIT FROM THE
ELECTRICAL OUTLET.
It may cause damage to the
power cord, short circuit, electrical
shock or fire.
Please remove the plug from the electrical
outlet if there are any conditions as below:
● If all buttons on the unit do not work
● If you experience loss of power due to brownout
or blackout
● If you notice any strange odor, noise or vibration
coming from the unit
●Any other abnormality or failure
If the power cord is damaged, please send to a service center or
technician for repairing. Do not change or repair it yourself.

PA - 777 / PA PRO | 6
● ALUMINUM ELECTRIC STATIC PLASMA FILTER: Its purification for dust is more than 99.9%. It will
effectively absorb dust in an area up to 229 square feet.
● ANION (ION): More than 8 million ions are generated per second creating a fresh, clean environment equal
to a 160,000 square foot forest. (Optional on/off feature).
● UVC LIGHT: Its sterilization rate is more than 99.2%, killing a variety of bacteria, mold, viruses and
other microorganisms.
● ULPA (SUPER HEPA) FILTER: Absorbs particulate down to 0.1 micron like pollen, drifting dust and germs
with purification efficiency of 99.999%.
● PHOTO CATALYST FILTER: Restrains the activation of bacteria and viruses with efficiency equal to an
environment of 54,000 °F.
● ACTIVATED CARBON: Absorbs and decomposes harmful gasses, odors and volatile organic compounds (VOC).
Diagram of the filters and UVC light
UVC Light (2 lights in one unit)
ULPA + Activated Carbon + Photo
Catalyst Filter
Aluminum Electric Static Plasma Filter
(with 4 carbon fiber heads
which can be cleaned)

PA - 777 / PA PRO | 7
Six stages of purification power
UVC LIGHTS: Kill a variety of bacteria, mold, viruses and other microorganisms that can trigger allergic
reactions and respiratory illnesses and infections. It effectively kills over 99% of germs. (Optional on/off
feature).
ULPA MICRO ALLERGEN FILTER (SUPER HEPA): Captures particles such as dust mites, dander and
pollen and keeps them from being circulated into the air that your family and pets breathe. This powerful
filter filters out particles as small as 0.1 microns with 99.999% efficiency, making it more effective than even
a HEPA filter.
ALUMINUM ELECTRONIC STATIC PLASMA FILTER: Collects the dust in the air around you with electric
plasma technology that is 99.9% effective. You’ll have cleaner air and less dust on your furniture. Aluminum
filter is washable and reusable. (Optional on/off feature).
PHOTO CATALYST FILTER: Restrains and inactivates reproduction of microorganisms such as mold,
bacteria and viruses with TiO2.
ACTIVATED CARBON FILTER: Absorbs odors, gas, smoke, fumes and VOC’s for cleaner, fresher air.
You’ll be able to tell the difference with every breath!
ANION (IONS): Generates more than 8 million negative ions per second, creating an environment as fresh
and clean as a 160,000 sq. ft. forest! (Optional on/off feature).
Technical innovation for convenience
AIR POLLUTION SENSORS: There are odor sensors and particle sensors* in the unit which will control
its working status when the sensors detect pollutants in the air such as dust, odor and smoke as well as a
multitude of many others.
AIR QUALITY LED: It notifies you of the pollution level of the air according to the color of the LED: Red
(highly polluted), Purple (semi-polluted), Blue (non-polluted).
EXTENDED FILTER LIFE: TheAluminum Electric Static Plasma Filter can reduce large particles in the
air up to 99%, helping to extend the life of the ULPA and Activated Carbon Filters.
AUTO FILTER CLEANING/REPLACEMENT LEDS: The auto filter LEDs notify you when the ULPA Filter,
Aluminum Electric Static Plasma Filter and the UVC Light need cleaning or replacement. An audible alarm
will also sound when cleaning or replacement is necessary.
AUTO MODE: Controlled by the built-in Samsung intelligent chip (IC), the unit will automatically alternate
in 20 minutes on / 40 minutes off cycles for ultimate convenience.
AUDIO AND VISUAL SIMPLICITY: ON/OFF sound settings and LED display technology maximize
convenience and operating simplicity.
Six stages of purification power
UVC LIGHTS: Kill a variety of bacteria, mold, viruses and other microorganisms that can trigger allergic
reactions and respiratory illnesses and infections. It effectively kills over 99% of germs. (Optional on/off
feature).
ULPA MICRO ALLERGEN FILTER (SUPER HEPA): Captures particles such as dust mites, dander and
pollen and keeps them from being circulated into the air that your family and pets breathe. This powerful
filter filters out particles as small as 0.1 microns with 99.999% efficiency, making it more effective than even
a HEPA filter.
ALUMINUM ELECTRONIC STATIC PLASMA FILTER: Collects the dust in the air around you with electric
plasma technology that is 99.9% effective. You’ll have cleaner air and less dust on your furniture. Aluminum
filter is washable and reusable. (Optional on/off feature).
PHOTO CATALYST FILTER: Restrains and inactivates reproduction of microorganisms such as mold,
bacteria and viruses with TiO2.
ACTIVATED CARBON FILTER: Absorbs odors, gas, smoke, fumes and VOC’s for cleaner, fresher air.
You’ll be able to tell the difference with every breath!
ANION (IONS): Generates more than 8 million negative ions per second, creating an environment as fresh
and clean as a 160,000 sq. ft. forest! (Optional on/off feature).
Technical innovation for convenience
AIR POLLUTION SENSORS: There are odor sensors and particle sensors* in the unit which will control
its working status when the sensors detect pollutants in the air such as dust, odor and smoke as well as a
multitude of many others.
AIR QUALITY LED: It notifies you of the pollution level of the air according to the color of the LED: Red
(highly polluted), Purple (semi-polluted), Blue (non-polluted).
EXTENDED FILTER LIFE: TheAluminum Electric Static Plasma Filter can reduce large particles in the
air up to 99%, helping to extend the life of the ULPA and Activated Carbon Filters.
AUTO FILTER CLEANING/REPLACEMENT LEDS: The auto filter LEDs notify you when the ULPA Filter,
Aluminum Electric Static Plasma Filter and the UVC Light need cleaning or replacement. An audible alarm
will also sound when cleaning or replacement is necessary.
AUTO MODE: Controlled by the built-in Samsung intelligent chip (IC), the unit will automatically alternate
in 20 minutes on / 40 minutes off cycles for ultimate convenience.
AUDIO AND VISUAL SIMPLICITY: ON/OFF sound settings and LED display technology maximize
convenience and operating simplicity.
* Model PA-777 has odor sensors only. Model PA-PRO has both odor sensors and particle sensors.

PA - 777 / PA PRO | 8
ULPA
Diagram of the outer unit
PA-777 LED Operating Panel PA-PRO Color LED Operating Panel
Non-
Polluted Semi- Polluted Highly- Polluted
Purple
Operating
Buttons
Air Quality LED
ULPA

PA - 777 / PA PRO | 9

PA - 777 / PA PRO | 10
ULPA
Air sensor power settings
The unit begins to record air quality once it is plugged in. Air quality will continue to be recorded
so that the unit will turn on and off based on changes in the air quality.
The ULPA Filter or Aluminum Electric Static Plasma Filter RESET Button
After cleaning or replacing the ULPA Filter or Aluminum Electric Static Plasma Filter, press the respective reset
button to alert the unit to begin recording the working time of the appropriate filter.
Aluminum Electric Static Plasma
Filter & ULPA Filter RESET buttons
Disassembly and reassembly of the front panel
Use your fingertips to locate the indents on each side of the bottom front panel. With your fingertips in
place, smoothly pull the bottom front panel towards you until it disconnects from the unit. Avoid forced
disassembly with one hand.
*Diagram of reassembly
Insert the top of the front panel to the upside of the unit. Press the bottom and top of the front panel until
it is secured in place. Then use two hands, one on each side of the middle of the front panel, and press
forward firmly until you hear each side of the panel click into place.The front panel should be flush against
the unit, it should not be bowed.
Slip the clips into
the indentations
ULPA
ULPA
ULPA

PA - 777 / PA PRO | 11
Press the POWER button. The POWER LED lights up and the unit powers on.
Power LED
PA - 777
Manual Mode ANION (Ion)
UV
Static
Manual Mode
LOW Fan Speed
Press the ANION (Ion), UV and STATIC buttons to turn these features on and off individually. All three features are
on by default. Their corresponding lights will turn on and off on the LED panel as the feature buttons are toggled.
The ULPA + Activated Carbon + Photo Catalyst combination filter is working whenever the unit is powered on.
The remote control can control the functions separately.
It is recommended that ANION (Ion), UV and STATIC remain on for optimal benefit.
Mode settings (Air sensor function must be off)
Press the MODE button repeatedly to select the preferred mode of operation: MANU (Manual), AUTO
(Automatic), 1H, 2H or 4H function.
The MODE LED will show:
MANU: Manual mode; the unit needs to be turned on and off manually
AUTO:Automatic mode; the unit is set to alternate in 20 minutes on, 40 minutes off cycles
1H: The unit will power off after 1 hour
2H: The unit will power off after 2 hours
4H: The unit will power off after 4 hours.
PA- PRO
The air sensor function must be off to use any
individual MODE settings.

PA - 777 / PA PRO | 12
Fan speed settings (Air sensor function must be off)
Press the SPEED button to select the preferred fan speed; LOW, MEDIUM or HIGH.
The SPEED LED will show:
The air sensor function must be off to use any individual SPEED settings manually.
Automatic air quality sensor settings (Sensor mode)
Press the SENSOR button. The pollution LED strip on the front panel of the unit will light up and the unit will
work in air quality sensor mode.
In this mode, the unit’s function and fan speed will adjust automatically to the air quality in your environment.
There are three main color indicators representing the air quality:
Blue
(Non-Polluted) Purple
(Semi-Polluted) Red (Highly-Polluted)
Hibernation Low fan speed High fan speed
When turning on the Air Sensor mode, the pollution LED strip will always be in red. True air quality
indicator colors will not be available for 3 minutes after entering Air Sensor mode. The unit will need
adequate time to record and adjust to the environment’s air quality.
Operating while in Sensor mode
When the air sensor function is on, the unit has Air Sensor Interception Control (AIC).
It records the pollution of the air every 20 minutes and the unit will work according to the pollution / air quality record.
The pollution / air quality record will be erased after the power is disconnected.
The pollution / air quality record will be replaced everyday.

PA - 777 / PA PRO | 13
MAINTENANCE AND CLEANING INSTRUCTIONS
PLEASE REMOVE THE PLUG
FROM THE WALL OUTLET
BEFORE ATTEMPTING TO
MAINTAIN OR CLEAN THE UNIT.
● Clean the outside of the unit (the panels) with a
damp soft cloth only.
● Do not directly apply water to the unit.
● Do not use any chemicals, solvent, alcohol,
aerosols or any other type of cleaning solution on
the unit.
● Failure to do so may cause damage to surface
and paint
Cautions for cleaning the carbon fiber of the ion generator
Open the cover and clean the carbon fiber head with the soft bristled brush that was
shipped with your unit. Close the cover securely when finished.
Clean the carbon fiber head once per month.
Do not put any metal materials or foreign objects to the carbon fiber head even when the
power is off. There is still a small quantity of high voltage power.
Cautions for cleaning the Aluminum Electric Static Plasma Filter
When the Auto Filter Cleaning/Replacement LED is on for the Aluminum Electric Static Plasma Filter
and/or you hear a sound notification, it is your reminder to clean this filter.
Aluminum Electric Static Plasma Filter
cleaning/replacement LED
Take out the Aluminum Electric Static Plasma filter, rinse it thoroughly with water or clean it with a soft
brush. Dry it thoroughly before putting it back into the unit.
After putting it back into the unit, press the STATIC RESET button. You will hear a sound notification.
The unit is now recording the working time of the filter.

PA - 777 / PA PRO | 14
Diagram of disassembly and installation of the
Aluminum Electric Static Plasma Filter
Diagram of disassembly:
Remove the front panel of the unit.
Slide out the combined ULPA filter by pulling on the fabric loops at the top and bottom of the
filter casing.
With the combined ULPA filter removed, use your fingertips to locate the indentations on the
sides of the Aluminum Electric Static Plasma Filter.
Slide the filter out smoothly.
Diagram of installation:
Use your fingertips to locate the indentations on the sides of the filter.
Line the filter up properly to its entrance into the unit and push it
forward into the unit smoothly.

PA - 777 / PA PRO | 15

PA - 777 / PA PRO | 16
Issue Possible Solution
The unit does not
power on
Ensure the plug has not disconnected from the electrical socket
Ensure the front panel is securely in place in all four corners and in
the middle.
When in air sensor mode,
the unit runs continuously
as though the air quality
never changes. The air
pollution LED is in RED
continuously.
The air quality in your environment may be highly polluted due to
vapor, strong odor, smoke, aerosol, etc. Move the unit to another
room to test it.
The air sensor switch may be set to HIGH. Change to LOW.
Odor in the room is not
being removed by the unit.
The Activated Carbon Filter inside of the unit may need cleaned or
replaced. First, clean the Activated Carbon Filter as is described
previously in this manual. If the cleaned filter does not solve the
problem, replace it with a new filter.
Particles (dust, dirt, etc.) in
the air are not being
removed by the unit and/or
the unit seems to be
running loudly.
The combination ULPA Filter inside of the unit may need replaced.
Contact the retailer for a replacement filter.
When in air sensor
mode, the unit does not
seem to kick on
although the air quality
is noticeably polluted.
The air pollution LED is
in BLUE continuously.
Particles (dust, dirt, etc.) may not be absorbing into the filters.
Move the unit to another room to run continuously in HIGH fan
speed.
The room size may be too large for the unit to control its air
quality appropriately.
The air sensor switch may be set to LOW. Change to HIGH.
If the problem still exists after the above troubleshooting, please
disconnect the power and contact the retailer for repair.
Refer to the below FAQs before contacting the retailer or sending it in for repair.

PA - 777 / PA PRO | 17
100
Residential / Light Commercial Portable Air Purification Unit
PA - 777 / PA -PRO
(2) The consumed power is around 2W when the unit is powered off. It is suggested to unplug the unit from
the electrical outlet if the unit will not be in use for a period of time in order to save energy.
Technical parameters of Aluminum Electric Static Plasma Filter
Description Residential/Light Commercial
Portable Air Purication Unit
Model PA - 777/PA-PRO
Fan Speed LOW MEDIUM HIGH
Air ow volume (m3/h) 400 450 500
Noise level (db) 25 33 42
Power rating (W) 28 35 43
Ions 8x102ions/cm3
Length of power cord 3.0 m
Product size 580x450x240(mm)
Net weight 25 lbs
Voltage supply 110V~120V,
60Hz Applicable area up to 1000 sq. ft.
W

PA - 777 / PA PRO | 18
ULPA
Specifications of the air sensor
Will Work Naturally
smoke, incense, cooking
odors, common household
odors, common pet odors,
alcohol, aerosol, etc.
May Work Abnormally
vapor, cooking smoke, in an
environment where there are
quick flows of air or drafts of
air, in an environment where
there are quick changes in
temperature, etc.
Can Not Work
floating dust, dirt, debris,
bacteria, viruses, pollen, pet
dander, etc.
floating dust, dirt, debris,
pollen, pet dander, etc. smoke, smog, fog, etc. alcohol, bacteria, viruses, etc.
0.1 micron *
* when used under normal conditions as outlined in the manual
Serial #
Technical parameters of the ULPA
Specications of the air sensor

PA - 777 / PA PRO | 19
PA-777 / PA-PRO Portable Air Purification Unit
You will not be notified by the retailer or manufacturer if there are any changes to the parameters or specifications of this
product. Please contact the retailer for any questions or concerns or visit us at www.PetAirapy.com for any product updates,
news or further information.

PA-777 / PA-PRO Portable Air Purification Unit Instruction Manual
PetAirapy LLC
2774 E. Main St. Suite 144
St. Charles, IL 60174
1-866-994-AIRE(2473)
www.PetAirapy.com
