Pfeiffer Vacuum UNO 35 User manual

OPERATING INSTRUCTIONS
EN
Original
UNO 35/65 | DUO 35/65
Rotary Vane Pump

PK0168BEN_Q PK0168 2018-01-31

Table of contents
1 About this manual 5
1.1 Validity 5
1.1.1 Related documents 5
1.1.2 Variants 5
1.2 Target group 5
1.3 Conventions 6
1.3.1 Abbreviations 6
1.3.2 Pictographs 6
1.3.3 Stickers in the product 6
1.3.4 Symbols used 7
1.3.5 Instructions in the text 7
2 Safety 8
2.1 General safety instructions 8
2.2 Safety instructions 8
2.3 Safety precautions 10
2.4 Safety precautions for handling pumps with magnetic coupling 10
2.5 Limits of use of the product 11
2.6 Proper use 11
2.7 Foreseeable improper use 11
3 Product description 12
3.1 Product identification 12
3.2 Scope of delivery 12
3.3 Functional description 12
3.4 Operating principle 14
4 Transportation and Storage 15
4.1 Transport 15
4.2 Storage 15
5 Installation 17
5.1 Installing the pump 17
5.2 Connecting the vacuum side 18
5.3 Connecting the exhaust side 18
5.4 Establishing mains connection 20
5.4.1 Three phase motor with 6-pin terminal board 20
5.4.2 Three phase motor with 9-pin terminal board 21
5.4.3 Checking the direction of rotation 22
5.4.4 Motor protection 22
PTC thermistor temperature sensor (3TF) 22
Motor protection switch 23
5.4.5 Motor control 24
Frequency converter (applies to 3-phase motor) 24
Soft start 24
5.5 Refilling operating fluid 24
5.6 Connecting accessories 25
5.6.1 Solenoid valve for gas ballast valve (standard version) 26
5.6.2 Solenoid valve for gas ballast valve (C version) 27
5.6.3 Process monitoring (option) 27
5.6.4 Gas flushing device 28
6 Operation 31
6.1 Commissioning 31
6.2 Switching on 31
6.3 Operation with gas ballast 32
6.3.1 Gas ballast valve – standard version 32
Table of contents
3/66

6.3.2 Gas ballast valve with flushing gas connection (option) 32
6.3.3 Gas ballast valve with solenoid valve (option) 33
6.4 Operation with flushing gas 34
6.5 Refilling operating fluid 34
6.6 Switching off the pump 35
6.6.1 Venting the vacuum chamber 35
6.6.2 Maintaining the vacuum in the chamber 35
7 Maintenance 36
7.1 Maintenance instructions 36
7.2 Maintenance instructions for M or MC version magnetic coupling 36
7.3 Checklist for inspection and maintenance! 37
7.4 Changing the operating fluid 38
7.4.1 Degree of aging of P3 operating fluid 38
7.4.2 Draining the operating fluid 39
7.4.3 Rinsing and cleaning 40
7.5 Cleaning the gas ballast valve 40
7.5.1 Gas ballast valve – standard version 40
7.5.2 Gas ballast valve – corrosive gas version 41
7.5.3 Adjusting the gas ballast valve silencer 42
7.6 Changing operating fluid type 43
7.7 Checking the oil level in the oiler (C version pumps only) 43
8 Decommissioning 45
8.1 Shutting down for longer periods 45
8.2 Recommissioning 45
8.3 Disposal 45
9 Malfunctions 46
10 Service solutions from Pfeiffer Vacuum 48
11 Spare parts 50
11.1 Spare parts packs 50
11.1.1Set of seals 51
11.1.2Maintenance kit 1 – maintenance level 1 52
11.1.3Overhaul kit and set of seals 52
11.1.4Set of vanes 52
11.1.5Coupling set 53
12 Technical data and dimensions 54
12.1 General 54
12.2 Technical data 54
12.3 Dimensions 59
13 Accessories 62
Declaration of conformity 64
Table of contents
4/66

1 About this manual
IMPORTANT
Read carefully before use.
Keep the manual for future consultation.
1.1 Validity
These operating instructions are for customers of Pfeiffer Vacuum. They describe the function of the
designated product and provide the most important information for a safe usage of the product. The de-
scriptions comply with applicable directives. All information provided in these operating instructions refer
to the current development status of the product. The documentation remains valid as long as the cus-
tomer does not modify the product in any way.
1.1.1 Related documents
Uno 35/65 | Duo 35/65 Operating instructions
Declaration of conformity A component of these instructions
Current documents are available from the Pfeiffer Vacuum Download Center.
1.1.2 Variants
These instructions apply to Uno/DuoLine series vacuum pumps:
Pump type Pump version
Uno 35/65
Duo 35/65
Pump in standard version
Duo 35/65 C C version pump – changes relative to the standard version:
●Operating fluid F5
●Vane material changed
●Hose connection and dosage spindle on gas ballast valve
●Oiler for shaft feedthrough
●Leakage rate ≤ 1 × 10-7 Pa m3/s
Uno 35/65 M
Duo 35/65 M
M version pump – changes relative to the standard version:
●Magnetic coupling
●Leakage rate ≤ 1 × 10-7 Pa m3/s
Duo 35/65 MC MC version pump – changes relative to the standard version:
●Operating fluid F5
●Vane material changed
●Hose connection and dosage spindle on gas ballast valve
●Magnetic coupling
●Leakage rate ≤ 1 × 10-7 Pa m3/s
1.2 Target group
This operating instructions are aimed at all persons performing the following activities on the product:
●transport,
●setup (installation),
●usage and operation,
●decommissioning,
●maintenance and cleaning,
●storage or disposal.
About this manual
5/66

The work described in this document is only permitted to be performed by persons with the appropriate
technical qualifications (expert personnel) or who have received the relevant training from Pfeiffer Vac-
uum.
1.3 Conventions
1.3.1 Abbreviations
Abbreviation Meaning in this document
C version Corrosive gas version
M version Version with magnetic coupling
MC version Corrosive gas version with magnetic coupling
OME Oil mist filter (Oil Mist Eliminator)
RSSR Radial shaft seal ring
3TF PTC thermistor temperature sensor
Tbl. 1: Abbreviations used in this document
1.3.2 Pictographs
Pictographs used in the document indicate useful information.
Note
Tip
1.3.3 Stickers in the product
This section describes all the stickers on the product along with their meaning.
D-35641 Asslar
Mod.: DUO 35
Mod.-Nr.: PK D45 XXX
Ser.- Nr.: 0014440
S : max. 2.5/2.9 m /h
Oil : P3 0.4 l
Mass : 11,2 kg
n : XXXX 1/min
(N )
2
3
max.
Made in Germany 2005/01
Vor Inbetriebnahme..
Fill the pump with ...
Remplir la pompe ...
ACHTUNG!
...
ATTENTION!
...
ATTENTION
●Warning
Hot surface
●Label
Fill pump with oil prior to
commissioning.
●Label
CAUTION! Check the direc-
tion of rotation of the pump
before filling with oil.
●Rating plate
The rating plate is located on
the pump housing next to the
sight glass.
●Motor rating plate
The motor rating plate is lo-
cated on the motor (not
shown).
Tbl. 2: Product stickers
About this manual
6/66

1.3.4 Symbols used
Vacuum connection
Exhaust connection
Gas ballast connection
M
Measurement connection
Electrical connection
Tbl. 3: Symbols used in this document
1.3.5 Instructions in the text
Usage instructions in the document follow a general structure that is complete in itself. The required ac-
tion is indicated by a individual or multi-part action steps.
Individual action step
A horizontal, solid triangle indicates the only step in an action.
►This is an individual action step.
Sequence of multi-part action steps
The numbering indicates an action with multiple action steps required.
1. Action step 1
2. Action step 2
3. ...
About this manual
7/66

2 Safety
2.1 General safety instructions
This document includes the following four risk levels and one information level.
DANGER
Imminent danger
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
►Instructions on avoiding the hazardous situation
WARNING
Possibly imminent danger
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
►Instructions on avoiding the hazardous situation
CAUTION
Possibly imminent danger
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
►Instructions on avoiding the hazardous situation
NOTICE
Danger of property damage
Notice is used to address practices not related to physical inrury.
►Instructions on avoiding property damage
Notes, tips or examples identify important information on the product or on this
document.
2.2 Safety instructions
All safety instructions in this document are based on the results of the risk assessment carried out in
accordance with Machinery Directive 2006/42/EC Annex I and EN ISO 12000 Section 5. Where applica-
ble, all life cycle phases of the product were taken into account.
Risks during transport
WARNING
Danger of serious injury from falling or swinging objects
Falling or swinging objects during transport pose a danger of injuries to limbs, up to and including
bone fractures.
►Prevent people from remaining below the suspended load.
►Secure the danger zone if necessary.
►Avoid diagonal pulling of the crane rope.
►Wear protective equipment, e.g. safety shoes.
Safety
8/66

Risks during installation
WARNING
Danger of injury from electric shock
Contact with live parts causes electric shock.
►Make sure that connection leads are voltage-free.
►Make sure that electrical installations are only carried out by qualified electricians.
►Provide adequate grounding for the device.
WARNING
Danger of poisoning from toxic vapors
Igniting and heating synthetic operating fluid generates toxic vapors. Danger of poisoning if inhaled.
►Observe the application instructions and precautions.
►Do not allow tobacco products to come into contact with the operating fluid.
Risks during operation
WARNING
Danger of poisoning due to emission of toxic process gases from the exhaust
During operation with no exhaust line, the vacuum pump allows exhaust gases and vapors to escape
freely into the air. In processes involving toxic media, there is a risk of injury and danger to life due to
poisoning.
►Observe the relevant regulations for handling toxic substances.
►Safely purge toxic process gases via an exhaust line.
►Use suitable filter equipment to separate toxic substances.
CAUTION
Risk of injury from bursting due to high pressure in the exhaust line
Faulty or insufficient exhaust lines cause hazardous situations, e.g. increase in exhaust pressure.
There is a risk of bursting. It is not possible to rule out the risk of injuries due to broken pieces flying
around, high escaping pressure and damage to the equipment.
►Lay the exhaust line without shut-off units.
►Observe the permissible pressures and pressure differentials of the product.
►Check the exhaust line regularly for correct function.
CAUTION
Danger of burns on hot surfaces
Depending on the operating and ambient conditions, the surface temperature of the pump can rise to
above 70°C.
►Provide suitable touch protection.
Risks during maintenance
WARNING
Danger of injury from strong magnetic field
There is a risk of injury for people with pacemakers and medical implants.
►Make sure that such individuals do not enter the sphere of influence (≤ 2 m) of the magnetic field.
–Identify rooms in which magnetic couplings are openly accessible with the symbol: "No ac-
cess for people with pacemakers"
►Always keep disassembled couplings away from computers, data carriers, and other electronic
components.
Safety
9/66

WARNING
Danger to life from electric shock in the event of a fault
In the event of a fault, parts connected to the mains may be live.
►Always keep the mains connection freely accessible so you can disconnect it at any time.
WARNING
Health risk and environmental damage due to poisoning on toxic contaminated parts or devi-
ces
Toxic process media result in contamination of the devices or parts thereof. During maintenance work
there is a health risk due to contact with these poisonous substances. The non-permitted disposal of
toxic substances results in environmental damage.
►Take appropriate safety precautions and avoid health risks or environmental hazards due to toxic
process media.
►Decontaminate the affected parts before carrying out maintenance work.
►Wear protective equipment.
CAUTION
Scalding from hot operating fluid
Danger of burns when draining operating fluid if it comes into contact with the skin.
►Wear protective equipment.
►Use a suitable collection receptacle.
2.3 Safety precautions
Information requirement on possible hazards
The owner or operator of the product is required to make all operating personnel
aware of hazards arising from the use of this product.
Every person who is involved in the installation, operation or maintenance of the
product must have read and understood the safety-relevant parts of this documen-
tation.
Infringement of EU conformity due to modifications to the product
The Declaration of Conformity from the manufacturer is no longer valid if the opera-
tor changes the original product or installs additional equipment.
●Following installation into a system, the operator is required to check and re-
evaluate as necessary the conformity of the overall system in the context of the
relevant EU Directives before commissioning that system.
General safety precautions when handling the product
►Observe all applicable safety and accident prevention regulations.
►Check that all safety measures are observed at regular intervals.
►Do not expose body parts to the vacuum.
►Always ensure a secure connection to the earthed conductor (PE).
►Never disconnect plug connections during operation.
►Observe the above shutdown procedures.
►Keep lines and cables away from hot surfaces (> 70°C).
►Never fill or operate the unit with cleaning agents or cleaning agent residues.
►Do not carry out your own conversions or modifications on the unit.
►Observe the unit protection class prior to installation or operation in other environments.
►Provide suitable touch protection, if the surface temperature exceeds 70°C.
2.4 Safety precautions for handling pumps with magnetic coupling
The following safety instructions are only valid for the disassembly of the drive system for a vacuum
pump with a magnetic coupling:
Safety
10/66
