Phase Technologies AS-1 Owner's manual

T E C H N O L O G Y






 
 


















Audio For Every Room
Your favorite music in every room
Phase Tech and A-BUS have created a whole-house solution
for audio distribution from your CD player, satellite receiver or
computer media center to any room in your house. With just a
single CAT 5 wire the distributed audio system enables multi-
room audio, infrared system control, system status and power.
MULTI-ROOM Sound Systems
Whole-house audio distribution

T E C H N O L O G Y
All Phase Tech speakers come with a transferable 10-year factory warranty.
Audio For Every Room
MULTI-ROOM Sound Systems
HUB-1
Single-source/four-zone
audio distribution system
Provides system power and converts audio
signal for distribution throughout the home.
Multiple HUB-1s can be linked to expand
your system to any number of rooms.
Built-in infrared (IR) signal repeater system
eliminates the need for adding outboard
controls. On/off control comes from either
auto signal-sensing or 12V trigger. Comes
complete with power supply.
HUB-4
Four-source/four zone
audio distribution system
Provides system power and converts audio
signal for distribution throughout the home.
Offers simultaneous listening capability to
any of four separate sources in any zone.
Multiple HUB-4s and HUB-1s can be linked
to expand your system to any number of
rooms. Built-in infrared (IR) signal repeater
system eliminates the need for adding
outboard controls, and includes IR routing
for controlling multiples of the same type of
source component. On/off control comes
from either auto signal-sensing or 12V trig-
ger. Comes complete with power supply.
TP-4
Infra-red amplified touchpad
volume control
In-wall volume control with integrated
A-BUS stereo amplifier module and infra-
red receiver. TP-4 is packaged with an
RM-1 remote control.
VC-1
Rotary volume control
In-wall rotary volume control with inte-
grated A-BUS amplifier module.
AS-1
Four-source auxiliary selector
Audio selector integrates four sources into
a PT A-BUS HUB-1 system. Outputs can
loop sources back to main home theater
receiver. Sources can be selected through
the RM-1 or LRC-1 remote controls. AS-1 is
packaged with an RM-1 control.
LM-1
Local input module
Local Input Module with stereo (L/R) RCA
inputs for adding a local source to a TP-4 or
VC-1. In normal operation, the house-wide
music is passed to the room’s speakers. As
soon as the local source (e.g, TV, computer
audio, etc.) is activated, house music is
overridden and the local source is amplified
and sent to the room’s speakers.
LCR-1
Learning remote control
Learning Remote Control is pre-loaded
with all A-BUS control commands, and
incorporates many functions of your
sources’ original remotes, controlling up
to eight components. Program by enter-
ing a product code from manual or simply
line up the LRC-1’s window with another
remote’s and initiate function transfer.
RM-1
Remote control
Credit card-sized remote allows volume
control and source selection when used
with an AS-1 or HUB-4 through any A-BUS
IR-equipped receiver.
P#217-1013
