Getting Started
Welcome to the STC1001 user guide! In order to get started, make sure you have the following hardware on hand:
STC1001- 2.5A Stepper Phidget
VINT Hub
Phidget cable
USB cable and computer
Power supply (8-30V DC)
4-wire, 6-wire, or 8-wire bipolar stepper motor
Next, you will need to connect the pieces:
1. Connect the STC1001 to the VINT Hub using the Phidget cable.
2. Connect the stepper motor to the Phidget's output terminals. See your motor's data sheet or product page for wiring
instructions.
3. Connect the VINT Hub to your computer with a USB cable.
4. Connect the power supply to the power terminals on the STC1001.
Now that you have everything together, let's start using the STC1001!
Using the STC1001
Phidget Control Panel
In order to demonstrate the functionality of the STC1001, the Phidget Control Panel running on a Windows machine will be used.

3/8/2018 2.5A Stepper Phidget - STC1001_0 at Phidgets
https://www.phidgets.com/?tier=3&catid=64&pcid=57&prodid=1014 2/3
The Phidget Control Panel is available for use on both macOS and Windows machines. If you would like to follow along, first take
a look at the getting started guide for your operating system:
Getting started with Windows
Getting started with macOS
Linux users can follow the getting started with Linux guide and continue reading here for more information about the STC1001.
First Look
After plugging the STC1001 into your computer and opening the Phidget Control Panel, you will see something like this:
The Phidget Control Panel will list all connected Phidgets and associated objects, as well as the following information:
Serial number: allows you to differentiate between similar Phidgets.
Channel: allows you to differentiate between similar objects on a Phidget.
Version number: corresponds to the firmware version your Phidget is running. If your Phidget is listed in red, your firmware
is out of date. Update the firmware by double-clicking the entry.
The Phidget Control Panel can also be used to test your device. Double-clicking on an object will open an example.
Stepper Motor
Double-click on the Stepper object, labelled Stepper Phidget, in order to run the example:

3/8/2018 2.5A Stepper Phidget - STC1001_0 at Phidgets
https://www.phidgets.com/?tier=3&catid=64&pcid=57&prodid=1014 3/3
General information about the selected object will be displayed at the top of the window. You can also experiment with the
following functionality:
Toggle the Engage button to provide power to the motor coils.
By default, motor position, velocity, and acceleration are measured in sixteenths of a step. If you want to use different units,
change the value in the Rescale Factortextbox.
Use the Target Position slider to set a new target position. Change the Accelerationand Velocity sliders to speed up or slow
down the STC1001's approach.
Select the Velocity (Continuous) Control tab for continuous rotation instead of specifiying a position.
Technical Details
Rescale Factor
Further Reading
For more information, have a look at the Stepper Motor and Controller Primer.
What to do Next
Software Overview - Find your preferred programming language here to learn how to write your own code with Phidgets!
General Phidget Programming - Read this general guide to the various aspects of programming with Phidgets. Learn how
to log data into a spreadsheet, use Phidgets over the network, and much more.
Phidget22 API - The API is a universal library of all functions and definitions for programming with Phidgets. Just select
your language and device and it'll give you a complete list of all properties, methods, events, and enumerations that are at
your disposal.
