Washing Machine
OWNER’S MANUAL
PLD 127 D QTL
PLDI 138 C QTL

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user’s manual.
Copyright © 2020, Fast ČR, a. s. Revision 12/2020

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 1
CONTENTS
PART 1: SAFETY INSTRUCTIONS ......................................................................................................................2
Safety Instructions .............................................................................................................................................................................2
PART 2: INSTALLATION .....................................................................................................................................7
Product Description .......................................................................................................................................................................... 7
Installation............................................................................................................................................................................................ 8
PART 3: OPERATIONS......................................................................................................................................12
Quick Start ..........................................................................................................................................................................................12
Before Each Washing.......................................................................................................................................................................13
Detergent Dispenser.......................................................................................................................................................................14
Control Panel (PLD 127 D QTL)....................................................................................................................................................15
Control Panel (PLDI 138 C QTL)...................................................................................................................................................16
Option ..................................................................................................................................................................................................17
Other Functions................................................................................................................................................................................18
Programmes.......................................................................................................................................................................................20
Washing Programmes Table.........................................................................................................................................................21
Washing Programmes Table.........................................................................................................................................................22
PART 4: MAINTENANCES................................................................................................................................23
Cleaning And Care...........................................................................................................................................................................23
Cleaning The Inlet Filter.................................................................................................................................................................23
Cleaning The Drain Pump Filter ..................................................................................................................................................24
Trouble Shooting..............................................................................................................................................................................26
Technical Specications.................................................................................................................................................................27
PART 5: PRODUCT INFORMATION SHEET....................................................................................................28
Read This Manual
Use all instructions and explanations of the installation before use. Follow the instructions carefully. Keep the
operation instructions handy for later use. If the application is sold or passed on then ensure that the new
owner always receives those operation instructions.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 2
PART 1: SAFETY INSTRUCTIONS
pSafety Instructions
For your safety,the information in this manual must be followed to
minimize the risk of re or explosion, electric shock, or to prevent
property damage, personal injury or loss of life.
Explanation of the symbols:
！
Warning!
This combination of symbol and signal word indicates a potentially
dangerous situation which may result in death or serious injuries
unless it’s avoided.
Caution!
This combination of symbol and signal word indicates a potentially
dangerous situation which may result in slight or minor injuries or
damage to property and the environment.
Note!
This combination of symbol and signal word indicates a potentially
dangerous situation which may result in slight or minor injuries.
！
Warning!
The electric shock!
• Ifthesupplycordisdamaged,itmustbereplacedbythe
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 3
• Thenewhose-setssuppliedwiththeappliancearetobeused
andthatoldhose-setsshouldnotbereused.
• Beforeanymaintenancethedevice,unplugtheappliancefrom
the mains.
• Alwaysunplugthemachineandturnothewatersupplyafter
use. The max. inlet water pressure, in pascals. The min. inlet water
pressure, in pascals.
• Toensureyoursafety,powerplugmustbeinsertedintoan
earthedthree-polesocket.Checkcarefullyandmakesurethat
your socket is properly and reliably earthed.
• Makesurethatthewaterandelectricaldevicesmustbe
connected by a qualied technician in accordance with the
manufacturer’s instructions and local safety regulations.
Risk to children!
• ENcountries:theappliancecanbeusedbychildrenagedfrom8
years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• Childrenoflessthan3yearsshouldbesupervisedtoensurethat
they do not play with appliance.
• Animalsandchildrenmayclimbintothemachine.Checkthe
machine before every operation.
• Kidsshouldbesupervisedthattheydonotplaywiththe
appliance.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 4
• Removeallpackagesandtransportboltsbeforeusingthe
appliance. Otherwise, serious damage may result.
• Plugmustbeaccessibleafterinstallation.
Risk of explosion!
• Donotwashordryarticlesthathavebeencleanedin,washedin,
soaked in, or dabbed with combustible or explosive substances
(suchaswax,oil,paint,gasoline,degreasers,dry-cleaning
solvents, kerosene, etc.) This may result in re or explosion.
• Beforehandthoroughlyrinseitemsofwashingbyhand.
Caution!
Installing the product!
• Thiswashingmachineisforindooruseonly.
• Itisn’tintendedtobebuilt-inusing.
• Theopeningsmustnotbeobstructedbyacarpet.
• Washingmachineshallnotbeinstalledinbathroomorverywet
rooms as well as in the rooms with explosive or caustic gases.
• Thewashingmachinewithsingleinletvalveonlycanbe
connected to the cold water supply. The product with double
inlet valves should be correctly connected to the hot water and
cold water supply.
• Plugmustbeaccessibleafterinstallation.
• Removeallpackagesandtransportboltsbeforeusingthe
appliance. Otherwise, serious damage may result.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 5
Risk of damaging appliance!
• Yourproductisonlyforhomeuseandisonlydesignedforthe
textiles suitable for machine washing.
• Donotclimbupandsitontopcoverofthemachine.
• Donotleanagainstmachinedoor.
• CautionsduringHandlingMachine:
1. Transport bolts shall be reinstalled to the machine by a
specialized person.
2. The accumulated water shall be drained out of the machine.
3. Handlethemachinecarefully.Neverholdeachprotrudedpart
onthemachinewhilelifting.Machinedoorcannotbeusedas
the handle during the conveyance.
4. This appliance is heavy. Transport with care.
• Pleasedonotclosethedoorwithexcessiveforces.Ifitisfound
dicult to close the door, please check if the clothes are put in or
distributed well.
• Itisforbiddentowashcarpets.
Operating the appliance!
• Flammableandexplosiveortoxicsolventsareforbidden.
Gasoline and alcohol etc. Shall not be used as detergents.
Please only select the detergents suitable for machine washing,
especially for drum.
• Makesurethatallpocketsareemptied.Sharpandrigiditems
such as coin,brooch,nail,screw or stone etc. may cause serious
damages to this machine.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 6
• Pleasecheckwhetherthewaterinsidethedrumhasbeen
drained before opening its door. Please do not open the door if
there is any water visible.
• Becarefulofburningwhentheproductdrainshotwashingwater.
• Neverrellthewaterbyhandduringwashing.
• Aftertheprogramiscompleted,Pleasewaitfortwominutesto
open the door.
Packaging/Old appliance
This marking indicates that this product should not be
disposed with other household wastes throughout the EU.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the
collection systems or contact the retailer where the
product was purchased. They return and can take this
product for environmental safe recycling.
This appliance is intended to be used only in households and not in similar
premises, such as:
–kitchenettes in shops, offices and other workplaces;
–appliances used appliances used by guests in hotels, motels, and other
accommodation facilities;
–appliances used in bed and breakfast facilities;
–appliances used in catering and other similar non-vending environments

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 7
PART 2: INSTALLATION
pProduct Description
Power supply cord
Control panel
Drain hose
Door
Detergent dispenser
Drum
Service lter
Note!
• Theproductlinechartisforreferenceonly,pleaserefertorealproductasstandard.
Accessories
Transport hole
plug
Supply hose cold
water
Drain hose
support
(optional)
Owner’s manual

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 8
pInstallation
Installation area
！
Warning!
• Stabilityisimportanttopreventtheproductfromwandering!
• Makesurethattheproductshouldnotstandonthepowercord.
Before installing the machine, the location characterized as follows shall be
selected:
1. Rigid, dry, and level surface
2. Avoid direct sunlight
3. Sucient ventilation
4. Room temperature is above 0°C
5. Keep far away from the heat resources such as coal or gas.
Unpacking the washing machine
！
Warning!
• Packagingmaterial(e.g.Films,Styrofoam)canbedangerousforchildren.
• Thereisariskofsuocation!Keepallpackagingwellawayfromchildren.
1. Remove the cardboard box and styrofoam packing.
2. Liftthewashingmachineandremovethebasepacking.Makesurethesmall
triangle foam is removed with the bottom one together. If not, lay the unit
down with side surface, then remove the small foam from the unit bottom
manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Remove transport bolts
！
Warning!
• Youmustremovethetransportboltsfromthebacksidebeforeusingtheproduct.
• You’llneedthetransportboltsagainifyoumovetheproduct,somakesureyoukeeptheminasafeplace.
Please take the following steps to remove the bolts:
1. Loosen 4 bolts with spanner and then remove them.
2. Stop the holes with transport hole plugs.
3. Keep the transport bolts properly for future use.
w
w
W> 20mm

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 9
Levelling the washing machine
！
Warning!
• Thelocknutsonallfourfeetmustbescrewedtightlyagainstthehousing.
1. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions
tighten the nuts.
2. Loosen the lock nut turn the feet until it closely contacts with the oor.
3. Adjust the legs and lock them with a spanner, make sure the machine is steady.
Raise Lower
Lock nut
foot
1 2 3 4
Connect Water Supply Hose
！
Warning!
• Topreventleakageorwaterdamage,followtheinstructionsinthischapter
• Donotkink,crush,modifyorseverwaterinlethose.
• Forthemodelequipshotvalve,connectittohotwatertapwithhotwatersupplyhose.Energy
consumption will decrease automatically for some program.
Connect the inlet pipe as indicated, There are two ways to connect the inlet pipe.
1. Connection between ordinary tap and inlet hose.
clamp nut
slide bushing
1 2 3 4
Loosen clamp nut and
four bolts
Tighten clamp nut Press slide bushing,
insert inlet hose into
connecting base
Connection
nished

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 10
2. Connection between screw tap and inlet hose.
slide bushing
Tap with threads and inlet hose Special tap for washing machine
Connect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly
clockwise.
water Inlet valve water supply hose
Drain Hose
！
Warning!
• Donotkinkorprotractthedrainhose.
• Positiondrainhoseproperly,otherwisedamagemightresultofwaterleakage.
There are two ways to place the end of drain hose:
Min.60cm
10 0cm
Max.
1. Put it into the water trough. 2. Connect it to the branch
drain pipe of the trough.
Water
trough
Note!
• Ifthemachinehasdrainhosesupport,pleaseinstallitlikethefollowing.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 11
Trough Hose
Retainer
Max.100cm
Max.100cm
Min.60cm
Min.60cm
Bind
！
Warning!
• Wheninstallingdrainhose,xitproperlywitharope.
• Ifdrainhoseistoolong,donotforceitintowashingmachineasitwillcauseabnormalnoises.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 12
PART 3: OPERATIONS
pQuick Start
Caution!
• Beforewashing,pleasemakesureit’sinstalledproperly.
• Beforewashingatrsttime,thewashingmachineshallbeoperatedinoneroundofthewholeprocedures
without clothes in as follows.
1. Before Washing
Plug in Open tap Load
Add detergent Close drum
door
Close machine
door
1 2 3
4
56
Softener
Prewash Mainwash
Note!
• Detergentneedtobeaddedin“caseI“afterselectingpre-washingformachineswiththisfunction.
• Makesurethatthedrumapsareproperlylocked.
• Allmetalhooksmustbeproperlyhookedinsidethereardoorap.
• Checktherollerbeforeeachlaundry,itmustrollsmoothly.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 13
2. Washing
Select
Programme
Select function or
default
Start up
1 2 3
Note!
• Ifdefaultisselected,step2canbeskipped.
3. After Washing
“End”ondisplay.
pBefore Each Washing
• Theworkingconditionofthewashershouldbe(0-40)°C.Ifusedunder0°C,theinletvalveanddraining
system may be damaged. If the machine is placed under condition of 0 °C or less, then it should be
transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen
before use.
• Pleasecheckthelabelsandtheexplanationofusingdetergentbeforewash.Usenon-foamingorless-
foaming detergent suitable for machine washing properly.
Check the label
Put small clothes into the
pillow slip
Take out the items out of
the pockets
Turneasy-pillingand
long-pilefabricinsideout
Knot the long strips, zip
or button
Separate clothes with
dierenttextures
！
Warning!
• Whenwashingasingleclothes,itmayeasilycausegreateccentricityandgivealarmduetogreat
unbalance. Therefore it is suggested to add one or two more clothes to be washed together so that
draining can be done smoothly.
• Don’twashingtheclothestouchingwithkerosene,gasoline,alcoholandotherammablematerials.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 14
pDetergent Dispenser
IPre Wash detergent
II MainWashdetergent
Softener
SoftenerPrewash Mainwash
Pull out the dispenser
Caution!
• Detergentonlyneedtobeaddedin“caseI“afterselectingpre-washingformachineswiththisfunction.
• Donotexceedthe“MAX”levelmarkwhenllingindetergent,additivesorsoftener.
Programme I II Programme I II
Cotton  Spin Only
Synthetic  Rinse & Spin 
Mix  Wool  
Jeans  Daily Wash 45’ 
Sportswear  Quick 15’  
Drum Clean ECO40-60  
20 °C   Rapid 45’ 
Intensive  
rMeans must Means optional
Note!
• Asfortheagglomeratedorropydetergentoradditive,beforetheyarepouredintothedetergentbox,it
is suggested to use some water for dilution to prevent the inlet of detergent box from being blocked and
overowing while lling water.
• Pleasechoosesuitabletypeofdetergentforthevariouswashingtemperaturetogetthebestwashing
performance with less water and energy consumption.

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 15
pControl Panel (PLD 127 D QTL)
53
1
2
4
1
1
Note!
• Thechartisforreferenceonly.Pleaserefertorealproductasstandard.
1O
 ProductisswitchedOn/O.
2Start/Pause
Press the button to start or pause the washing
cycle.
3Option
This allows you to select an additional function
and will light when selected.
4Programmes
Available according to the laundry type.
5Display
The display shows the settings, estimated time
remaining, options, and status messages for your
washer. The display will remain on through the
cycle.
A
C
B E
D
1200
ADisplay
BDoor Lock
DPre Wash
CDelay
EExtra Rinse
Wash Time
End
Delay Time
Error

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 16
pControl Panel (PLDI 138 C QTL)
5
3
1
2
4
1
1
Note!
• Thechartisforreferenceonly.Pleaserefertorealproductasstandard.
1O
 ProductisswitchedOn/O.
2Start/Pause
Press the button to start or pause the washing
cycle.
3Option
This allows you to select an additional function
and will light when selected.
4Programmes
Available according to the laundry type.
5Display
The display shows the settings, estimated time
remaining, options, and status messages for your
washer. The display will remain on through the
cycle.
A
C
B E
DADisplay
BDoor Lock
DPre Wash
CDelay
EExtra Rinse
Wash Time
End
Delay Time
Error

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 17
pOption
Pre Wash Pre Wash
The Prewash function can get an extra wash before main wash,it is suitable for washing the
dustrisestosurfaceoftheclothes;YouneedtoputdetergentintotheCase(I)whenselectit.
Extra Rinse Extra Rinse
The laundry will undergo extra rinse once after you select it.
Delay Delay
Set the Delay function:
1. Select a programme.
2. PresstheDelaybuttontochoosethetime(thedelayingtimeis0-24H/3H-6H-9H).
3. Press [Start/Pause] to commence the delay operation.
Delay
Choose the Programme Setting time Start
Cancel the Delay function:
Pressthe[Delay]buttonuntilthedisplaybe0H.Itshouldbepressedbeforestartingthe
programme.Iftheprogrammealreadystarted,shouldswitchoprogrammetoresetanew
one.
Caution!
• Ifthereisanybreakinthepowersupplywhilethemachineisoperating,aspecialmemorystoresthe
selected programme and when the power is restarted, the program will continue.
Programme Option Programme Option
Delay Extra
Rinse
Pre
Wash Delay Extra Rinse
Pre
Wash
Cotton    Drum Clean 
Quick 15’ Baby Care 
Rapid 45’    Sportswear 
ECO40-60 Jeans 
Intensive Wool  
20 °C   Synthetic 
Rinse & Spin   Mix 
Spin Only 
Means optional (Some models have intelligent weighing function, please refer to the actual product)

Copyright © 2020, Fast ČR, a. s. Revision 12/2020
EN - 18
pOther Functions
Temp. Temp.
Pressthebuttontoregulatethetemperature(Cold,20°C,40°C,60°C,90°C).
Spin Spin
Press the button to change the speed.
1200:0-600-800-1000-1200
1300:0-600-800-1000-1300
Programme Default Speed (rpm) Programme Default Speed (rpm)
1200 1300 1200 1300
Cotton 1200 1300 Drum Clean - -
Quick 15’ 800 800 Baby Care 800 800
Rapid 45’ 800 800 Sportswear 800 800
ECO40-60 1200 1300 Jeans 800 800
Intensive 800 800 Wool 600 600
20 °C 1000 1000 Synthetic 1200 1300
Rinse & Spin 800 1000 Mix 800 1000
Spin Only 800 1000
Child Lock
To avoid mis operation by children.
Choose the Programme Start
Spin Delay
Press [Spin] and [Delay] 3 sec.
till buzzer beep.
Caution!
• Duringthe“ChildLock”functionisactiving,thebuzzerwillbeep3times.
When the buttons are pressed.
• Pressthetwobutton3sec.alsotobereleasedthefunction.
• The“ChildLock”willlockallbuttonsexceptPowerbutton.
• Cutothepowersupply,thekid’sprotectionistobereleased.
