Philips SBT75/12 User manual

SBT75/12
Register your product and get support at
www.philips.com/welcome
User manual

2

3EN
Contents
1 Important 2
Safety 2
Notice 2
2 Your Bluetooth Speaker 4
Introduction 4
What's in the box 4
Overview of the main unit 4
3 Get started 5
Connect power 5
Turn on 5
4 Play 6
Play from a Bluetooth device 6
Play from an external device 7
Control play 7
5 Product information 7
Specications 7
6 Troubleshooting 8

4EN
1 Important
Safety
Important Safety Instructions
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this device near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or other
devices(includingampliers)thatproduce
heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the device.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug this device during lightning storms
or when unused for long periods of time.
• Referallservicingtoqualiedservice
personnel. Servicing is required when the
device has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have
fallen into the device, the device has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
• Devices shall not be exposed to dripping
or splashing.
• Do not place any sources of danger on
thedevice(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
Warning
•Never remove the casing of this apparatus.
•Never lubricate any part of this apparatus.
•Never place this apparatus on other electrical
equipment.
Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
WOOX Innovations may void the user’s
authority to operate the equipment.
This product complies with the requirement of
the 1999/5/EC directive.
This product complies with the radio
interference requirements of the European
Community.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product is
covered by the European Directive 2002/96/EC.

5EN
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment and
human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
Always bring your product to a professional to
remove the built-in battery.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separateintothreematerials:cardboard(box),
polystyrenefoam(buffer)andpolyethylene
(bags,protectivefoamsheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
The making of unauthorized copies of copy-
protected material, including computer
programs,les,broadcastsandsound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
Note
•The type plate is located on the bottom of the
apparatus.

6EN
2 Your Bluetooth
Speaker
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this speaker, you can enjoy audio from the
compatible Bluetooth device or other audio
devices.
What's in the box
Check and identify the contents of your
package:
• Main unit
• 1 x USB cable
• Quick start guide
Overview of the main unit
a ON/OFF
• Turn on/off the unit.
b /
• Adjust volume.
c
• Press to play/pause in Bluetooth mode.
• Press for 2s to wake up your speaker
from standby mode.
• Press for 8s to erase all connection
information stored on Bluetooth module.
d DC IN 5V-1A
• Charge your Bluetooth speaker
through the USB cable.
e MP3-LINK
• Connect an audio device.
f Built-in battery indicator
• Steadily on when charging.
• Flashes when the battery level is low.
g Bluetooth indicator
• Steadily on when the speaker is connected
with Bluetooth compatible device.
• Flashes when disconnected Bluetooth
pairing.
e
g
f
b
a
c
d

7EN
3 Get started
Caution
•Use of controls, adjustments, or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
bottom of the apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Connect power
Caution
•Risk of product damage! Make sure that the power
supply voltage corresponds to the voltage printed on
the back of the speaker.
ConnecttheACpoweradaptor(notsupplied)
to:
• the power supply socket on the back of
the speaker.
• the wall power outlet.
DC IN
5V . 1A
Built-in Battery
The speaker can also operate on built-in
rechargeable battery.
To recharge the built-in battery:
• Connect the speaker to the power supply.
Note
•Use only the supplied USB cable to charge the battery.
Turn on
• Switch ON/OFF on the speaker to the
ON position.
» TheBluetoothindicatorashes(blue).
Switch to standby mode
The speaker switches to standby mode in the
following situations.
• In Bluetooth mode: no audio signal from
your Bluetooth device over 15 minutes.
• In MP3 link mode: no audio signal
detected over 15 minutes.
• The battery level is low.
Note
•The Bluetooth connection will be terminated when the
speaker enters standby mode, you can wake up the
speaker by hold for 2 seconds.

8EN
4 Play
Play from a Bluetooth device
You can listen to a Buetooth device through this
speaker.
Note
•The effective operation range between the speaker
and your Bluetooth device is approximately 10 meters
(30feet).
1 Switch ON/OFF to turn on Bluetooth
function of the speaker.
» TheBluetoothindicatorashes.
2 Activate the Bluetooth function in your
Bluetooth device (see the device user
manual).
3 Select "PHILIPS SBT75" on your device for
pairing.
» The speaker gives out 2 beeps and the
Bluetooth indicator steadily on.
• For former devices, you need to input
"0000" as pairing password.
4 Start music play on your Bluetooth device .
DoDo
PHILIPS SBT75
0000
PIN
Play from a PC
You can also listen to audio through Bluetooth
in PC.
Note
•Make sure that you have installed Bluetooth driver in
your PC before pairing.
•The steps below are only for windows 7 operating
system. If you use windows XP , refer to windows XP
help.
1 Switch ON/OFF to turn on Bluetooth
function of the speaker.
» TheBluetoothindicatorashes.
2 Activate the Bluetooth function in your PC.
3 Add a Bluetooth device in your PC and
select "PHILIPS SBT75" for pairing.
» The speaker gives out 2 beeps and the
Bluetooth indicator steadily on.
4 Set "PHILIPS SBT75" as default
communication device in your PC.
1). Right click the speaker icon ( )inthe
lower right corner of the Windows home
screen and select "Playback Devices" from
the option menu
2). Right click desired speaker and select
"Set as Default communnication Device".
5 Start music play on your PC .

9EN
Play from an external device
You can also listen to an external audio device
through this speaker.
Note
•Your speaker can play under MP3-LINK audio only
when the Bluetooth paused or stopped.
1 Connect the MP3-LINK cable to:
• theMP3-LINKsocket(3.5mm)onthe
back of the speaker.
• the headphone socket on an external
device.
2 Start to play on the device.
Control play
During play,
• press VOL +/- to increase or decrease the
volume level.
• press to play or pause.
» Available only in Bluetooth mode.
MP3-LINK
5 Product
information
Note
•Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 2 x 2 W RMS
Signal to Noise Ratio >67 dB
Aux-in Link 600 mV RMS
20 kohm
General information
DC power input Input: 5V, 1A;
Operation Power
Consumption 3W
Standby Power Consumption <0.5W
Dimensions - Main Unit
(WxHxD) 184 x 62 x 63mm
Weight- Main Unit 0.388 kg

10 EN
6 Troubleshooting
Warning
•Never remove the casing of this apparatus.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
philips.com/welcome).Whenyoucontact
Philips, ensure that the apparatus is nearby
and the model number and serial number are
available.
No power
•When use build-in battery only, make sure
thatthepowerissufcient.
•When use AC power plug, make sure that
the plug is connected properly, and there is
power at the AC outlet.
No sound
•Adjust the volume.
No response from the speaker
•Restart the speaker.

11EN

Specifications are subject to change without notice
2014 © WOOX Innovations Limited.All rights reserved.
Philips and the Philips’ Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are
used by WOOX Innovations Limited under license from Koninklijke Philips N.V.
SBT75_12_UM_V3.0
