Philips Cucina HD7502 Assembly instructions

Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in The Netherlands Copyright reserved Subject to modification
©
PRODUCT INFORMATION
Voltage
Frequency
Power consumption
HD 7502
Coloursetting
:
:
:
:
:
100, 120, 220-240V
50-60Hz
1000 watt
1200 cc On/Off switch
various
SERVICE INFORMATION
Thermostat
Thermal fuse
REPAIR INSTRUCTIONS
1.
2.
Electrical circuit
When the appliance does not work, check the electrical
circuit. If the thermal fuse or thermostat prove defective,
the complete pump unit has to be replaced.
De-scaling
If the water system is nearly or less clogged by scale
then operate the coffeemaker a few times with vinegar
or with a 10-15% solution of either vinegar-acid, citric
acid or tartar-acid, into cold tap water.
Do not use other de-scaling agents as these may harm
the appliance.
If this procedure does not restore the function, then switch
off the coffeemaker when the acid has passed through
during appr. 3 min. Keep the appliance in this condition
overnight and continue/repeat the cleaning operation.
After the de-scaling procedure, operate the coffeemaker
twice with tap water in order to rinse away any residual
substances.
: 140°C
: 228°C
switch-off temp
cut-off temp
Pump unit removal
To seperate the pump unit (item 16) from the hotplate
unit (item 13), the two plastic snaps at place A have to
be loosened. Then the pump unit can be lifted out easily.
Base removal
Besides two screws, two plastic snap connections have
to be detached by means of using a simple screwdriver,
as indicated on the base of the appliance.
HD 7502
3.
4.
MSH Coding
8827 502 00000
E
HD 7502/E
Coffeemaker ”Café Cucino”
99/10
4322 277 00063
PCS 101 549
Service Manual 4822 729 22072 is herewith cancelled.
Service
Service
Service

1
6
7
TWO SMALL
DETENT PIECES A
2
3
3A
4
5
8
10
11
12
HD 7502/E
PCS 101 549
9
62
61
51 52
53
60
54
63
59
56
58
57
55

1 4822 442 01433 Tank lid yellow
- 4822 442 01432 ” ” ivory
2 4822 442 01437 Cover yellow
- 4222 247 58010 ” ivory
3 4822 442 01438 Spout aubergine
4 4822 462 40374 Stud
5 4822 256 10529 Filter with cap 1) yellow/aqua blue
- 4822 256 10531 ” ” 1) ivory/green
- 4222 259 33840 ” ” 1) ivory/ivory
6 4822 492 11676 Spring bracket
7 4822 276 13996 Switch 100-120V aqua blue
- 4822 276 13993 Switch 220-250V aqua blue
- 4822 276 13997 Switch 100-120V orange
- 4822 276 13994 Switch 220-250V orange
- 4822 246 25510 Switch 220-250V pearl blue
8 4822 360 10427 Drip stop unit aubergine
9 4822 360 10406 Drip stop unit aubergine
10 4822 442 01442 Jug lid blue
- 4822 442 01441 ” ” green
- 4222 247 58690 ” ” pearl blue
11 4822 418 10345 Jug 2) orange transp.
- 4822 418 10346 ” 2) blue transp.
- 4222 259 33810 ” 2) pearl blue
12 4822 462 11094 Jug buffer aqua blue
- 4822 441 12298 ” ” orange transp.
- 4222 247 58710 ” ” zinc brown
17 4822 492 71174 Wire spring
51 4222 247 06440 Hose piece
52 4222 259 20460 Valve + hose piece assy
53 4222 247 58680 Connection piece
54 4222 247 06800 Hose piece
55 4222 259 33950 Basic pump module III
56 4222 246 25640 Wire assy
57 4222 245 71630 Spring bpm III
58 4222 259 19960 Thermostat
59 4222 246 25650 Wire assy
60 4222 259 34210 Fuse assy
61 4222 240 06290 Leaf spring
62 4222 259 00751 Hotplate assy
63 4222 248 25620 Speednut
Notes:
1) Filter is changed in week 838. Look to the dripstop unit item 8 or 9.
Optional part for use as an insert in item 5:
4822 480 50479 Permanent filter nylon
4822 480 50402 Permanent filter gold coated
2) Commercial trade number: HD 7942 (jug included lid 10 aqua blue)
2) Commercial trade number: HD 7941 (jug included lid 10 green)
Commercial trade number: HD 7954 (jug included lid 10 pearl blue)
General: Not all colours have been listed;
customer has to make a selection.
If colours are no more avialable,
choose an other colour.

5. Replacing switch in HD 7502
6. Colour identification
- Firstly determine your type of appliance (Column A)
- Secondly determine the colourcode, which is printed on
the typeplate of the appliance:
HD 7502
/A /. /. is the colourcode
- Determine also the coloursetting of the jug handle
(Column B)
- In the next columns you can read the original coloursetting
of the other service parts.
A A1 B C D E F G H I
Type of Type Jug handle Jug lid Jug cap Housing Filterholder Tank lid Cover Switch
appliance (item 11) (item 10) (item 12) (item 3A) + (item 1) (item 2) (item 7)
colour- + Cap
code spring (item 5)
HD 7502 /3 Cucina orange green green ivory ivory/ ivory green orange
green transparant
HD 7502 /9 Cucina blue aqua blue aqua blue yellow yellow/ yellow yellow aqua blue
aqua blue transpar.
HD 7502 /6 pearl blue pearl blue pearl blue pearl blue ivory ivory/ivory ivory ivory pearl blue
PRESS
IN THIS
DIRECTION
MOVE THE
SWITCH IN
THIS DIRECTION
END
POSITION
PRESS
MID
POSITION
SWITCH HOLE IN
HOUSING PART
25MM.
HOUSING PART
SMALL
DETENT
PIECE A
START
POSITION
