1 Important
Safety
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Use only power supplies listed in the user
manual.
• The product shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
product(e.g.liquidlledobjects,lighted
candles).
• Batteries (battery pack or batteries
installed) shall not be exposed to excessive
heatsuchassunshine,reorthelike.
• Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
• Where the plug of the Direct Plug-in
Adapterisusedasthedisconnectdevice,
the disconnect device shall remain readily
operable.
Warning
•Never remove the casing of this apparatus.
•Never lubricate any part of this apparatus.
•Never place this apparatus on other electrical
equipment.
•Keepthisapparatusawayfromdirectsunlight,naked
amesorheat.
•Ensure that you always have easy access to the power
cord,plugoradaptortodisconnecttheapparatusfrom
the power.
Compliance
This product complies with the radio
interference requirements of the European
Community.
Declaration of conformity
Hereby,WOOXInnovationsdeclaresthatthis
product is in compliance with the essential
requirements and other relevant provisions
ofDirective1999/5/EC.Youcanndthe
Declaration of Conformity on www.philips.com/
support.
Note
•The type plate is located in the battery compartment.
Care of the environment
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separateintothreematerials:cardboard(box),
polystyrene foam (buffer) and polyethylene
(bags,protectivefoamsheet.)
Your system consists of materials which can
be recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials,andoldequipment.
Your product is designed and manufactured
withhighqualitymaterialsandcomponents,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product

3EN
is covered by the European Directive 2002/96/
EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment and
human health.
Your product contains batteries covered by
theEuropeanDirective2006/66/EC,which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
Always bring your product to a professional to
remove the built-in battery.
Notice
The Bluetooth®word mark and logos are
registered trademarks owned by Bluetooth
SIG,Inc.andanyuseofsuchmarksbyWOOX
Innovationsisunderlicense.
“MadeforiPod,”“MadeforiPhone,”and“Made
foriPad”meanthatanelectronicaccessory
hasbeendesignedtoconnectspecicallyto
iPod,iPhone,oriPad,respectively,andhas
beencertiedbythedevelopertomeet
Apple performance standards. Apple is not
responsible for the operation of this device
or its compliance with safety and regulatory
standards. Please note that the use of this
accessorywithiPod,iPhone,oriPadmayaffect
wireless performance.
iPodandiPhonearetrademarksofAppleInc.,
registered in the U.S. and other countries. iPad
isatrademarkofAppleInc.

4EN
2 Your Docking
Speaker
What's in the box
Check and identify the contents of your
package:
• Main unit
• AC/DC power adapter
• Quick start guide
• Safety and notice
iOS app for the dock
With the lightning dock on DS3480,your
iPhone/ iPod can work with the following app:
• ClockStudioapp (allows you to select
soundsettings,listentotheInternet
radio,setclockandalarmandupdate
rmware)
Tip
•You can get the ClockStudio app from the App Store
on your iPhone/ iPod.
Overview
a
• Press to switch on or oPress and hold
for 5 seconds to reset Bluetooth
• Battery level indicator
b DC IN
• AC power connector for the supplied
AC/DC power adapter
c
• Power charging connector for an
external device
d AUDIO IN
• Audio input connector for an external
audio device
e
• Bluetooth status indicator
f DockwiththeLightningconnectorfor
the iPod/iPhone
g ,
• Increaseordecreasethevolume
• Power on/off indicators
f
e
g
a
b
c
d

5EN
3 Get started
Charge DS3480
DS3480 has a built-in battery that can be
charged through the supplied AC/DC power
adapter.
• Connect DS3480 to AC power through
the supplied AC/DC power adapter.
» Duringpowercharging,
ashesingreenifyouhaveswitched
on DS3480.
is always on in red if you have
switched off DS3480.
» Whenthebatteryisfull,the is
always on in green if DS3480 is on; the
turns off if DS3480 is off.
Tip
•Whenthebatterylevelislow, ashesinred.
•Rechargeable batteries have a limited number of charge
cycles. Battery life and number of charge cycles vary by
use and settings.
Switchonoroff
• Press to switch on.
» , lights up amber.
» TheBluetoothstatusindicatorashes.
DS3480 starts to pair or reconnect
through Bluetooth.
• Toswitchoff,press again.
Automatic standby
After15minutesinidlemode(noplay,no
buttonispressed),theplayerswitchesoff.

6EN
4 Play
Play through the lightning
dock
With the lightning dock on DS3480,youcan
play from the following iPhone/ iPod:
• iPhone 5
• iPod touch (5th generation)
• iPod nano (7th generation)
1 Make sure that you have switched on
DS3480.
2 Mount your iPhone/ iPod onto the dock.
• Thersttimeyoumountyour
iPhone/ iPod onto DS3480,installthe
ClockStudio app on your iPhone/iPod
as prompted:
3 OnyouriPhone/iPod,startmusicplay.
Tip
•ToremovetheiPhone/iPod,pullitoutofthedock.
App store Ignore
Play through Bluetooth
ThroughBluetooth,youcanplayonDS3480
fromaBluetoothdevice,suchasaniPad,
iPhone,Androidphone,orlaptop.
Connect through Bluetooth
1 On DS3480,press to switch on.
» TheBluetoothstatusindicatorashes.
DS3480 starts to pair or reconnect
through Bluetooth.

7EN
2 OnyourBluetoothdevice,activate
Bluetooth and search for Philips DS3480.
• Fortherst-timeconnection,select
Philips DS3480 to start pairing.
» Whentheconnectioniscomplete,the
Bluetooth indicator is always on in blue
and two beeps sound.
» Next time you switch on DS3480,the
speaker connects to the last paired
device automatically.
Tip
•To connect DS3480toanotherBluetoothdevice,
switch off Bluetooth on current Bluetooth device.
•To clear paired devices from DS3480,pressandhold
forveseconds.
PHILIPS DS3480
Play from a Bluetooth device
1 Make sure that you have removed your
iPhone/ iPod from the lightning dock.
2 Aftersuccessfulconnection,startmusic
play on DS3480.
Note
•Make sure the distance between DS3480 and the
Bluetooth device is within 10 meters.
•The music streaming may be interrupted by obstacles
between the device and DS3480,suchaswalls,orother
devices nearby that operate in the same frequency.

8EN
Play through an audio cable
ThroughanMP3linkcable,youcanalsoplayon
DS3480fromanexternalaudiodevice,suchas
an MP3 player.
1 Use an MP3 link cable to connect DS3480
with an external audio device.
2 On DS3480,dothefollowing:
• Make sure that you have paused the
music on your iPhone/ iPod docked on
DS3480;
• Switch off Bluetooth on the Bluetooth
device that is connected to DS3480.
3 Ontheexternalaudiodevice,startmusic
play and change the volume.
Adjust the volume
• Press , repeatedly; or
• Press and hold , to increase or
decrease the volume quickly.
» When you reach the maximum or
minimumlevel, , ashesinamber.

9EN
5 Charge
Charge through the lightning
dock
With the lightning dock on DS3480,youcan
charge your iPhone/ iPod when music play is on
or off.
1 Mount your iPhone/ iPod onto the
lightning dock on DS3480.
2 Connect DS3480 to power.
Charge through the USB
connector
With the USB connector on DS3480,youcan
charge your mobile phone.
1 Use a USB cable to connect DS3480 with
the external device.
2 Connect DS3480 to power.

10 EN
6 Update the
firmware
With the ClockStudioapp on your iPhone/
iPod,youcanupdatethermwareofDS3480.
1 Make sure that your iPhone/ iPod is
connectedtotheInternet.
2 Mount the iPhone/ iPod onto the lightning
dock of DS3480.
» ClockStudio starts to search for
availablermwareupdate.
» Whenthermwareupdateisavailable,
a message is displayed.
3 Follow onscreen instructions to complete
rmwareupdating.
Note
•Duringthermwareupdating,keeptheiPhone/iPod
powered on and docked on DS3480.

11EN
7 Specifications
Amplier
Rated Output Power 2X5WRMS
General information
Power supply
- AC Power
- Battery
Model: KSASB0241200200HE (Philips);
Input:100-240V~,50/60Hz,0.6A;
Output:12V 2 A
Li-ion battery
Operation Power Consumption <18 W
Standby Power Consumption <0.5 W
Max. load for iPod/iPhone 5V 1 A
Dimensions
- Main Unit (W x H x D) 274 x 143 x 109 mm
Weight
- Main Unit 1.2 kg
Operating temperature and humidity: 0°Cto45°C,5%to90%Humidityforallclimates.
Storage temperature and humidity: -40°Cto70°C,5%to95%
Bluetooth
Bluetooth version V2.1+EDR
Frequency band 2.402-2.480GHzISMBand
Rang 10m (free space)

12 EN
8 Troubleshooting
Warning
•Never remove the casing of this apparatus.
Tokeepthewarrantyvalid,nevertrytorepair
the system yourself.
Ifyouencounterproblemswhenusingthis
apparatus,checkthefollowingpointsbefore
requestingservice.Iftheproblemremains
unsolved,gotothePhilipswebsite(www.
philips.com/support).WhenyoucontactPhilips,
ensure that the apparatus is nearby and the
model number and serial number are available.
No sound or poor sound
•Adjust the volume on the docking speaker.
•AdjustthevolumeonyouriOSdevice,
Bluetoothdevice,orotherexternaldevice.
No response from the
pressing of the keys on the
speaker
• Onthedockingspeaker,press and
simultaneously for 3 seconds.You can
restore the factory settings of the docking
speaker.
• DisconnectandreconnectACpower,and
then,switchonthedockingspeakeragain.
About Bluetooth connection
Cannot play music from my Bluetooth device
even after successful Bluetooth connection
•The Bluetooth device cannot work with
the speaker to play music.
ThesoundqualityispoorwhenIplaymusic
from a Bluetooth device.
•The Bluetooth reception is poor. Move
the Bluetooth device closer to the speaker
or remove the obstacles between the
Bluetooth device and the speaker.
CannotconnectmyBluetoothdevicewiththe
speaker
•The Bluetooth device does not support
theprolesthatarerequiredforthe
speaker.
•The Bluetooth function of the device is not
enabled. Refer to the user manual of the
device on how to enable the Bluetooth
function.
•The speaker is not in the pairing mode.
• The speaker is already connected with
another Bluetooth device. Switch off the
Bluetooth on that device and try again.
The paired device connects and disconnects
constantly.
•The Bluetooth reception is poor. Move
the Bluetooth device closer to the speaker
or remove the obstacles between the
Bluetooth device and the speaker.
•Onsomedevices,theBluetooth
connection can be deactivated
automatically for power-saving.

Specificationsaresubjecttochangewithoutnotice.
2013©WOOXInnovationsLimited.Allrightsreserved.
ThisproductwasbroughttothemarketbyWOOXInnovations
Limitedoroneofitsaffiliates,furtherreferredtointhis
document as WOOX Innovations, and is the manufacturer of the
product.WOOXInnovationsisthewarrantorinrelationtothe
productwithwhichthisbookletwaspackaged.Philipsandthe
Philips Shield Emblem are registered trademarks of Koninklijke
Philips N.V.
DS3480_12_UM_V2.0
