Philips HQ6075 s User manual

HQ6075, HQ6073, HQ6070
ENGLISH 4
 15
 27
 38
 48
 59
 70
 82
 93
 104
 115
 126
 138
 149
 159
 170

4
Important
Read this user manual carefully before you use the
appliance and save it for future reference.
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- Children should be supervised to ensure that they
do not play with the appliance.
- Only use the powerplug supplied.
- The powerplug transforms 100-240 volts to a safe
low voltage of less than 24 volts.
- The powerplug contains a transformer. Do not cut
off the powerplug to replace it with another plug,
as this causes a hazardous situation.
- Do not use a damaged powerplug.
- If the powerplug is damaged, always have it
replaced with one of the original type in order to
avoid a hazard.
- Charge and store the shaver at a temperature
between 5°C and 35°C.
- Do not recharge the shaver in a closed pouch.
- Make sure the powerplug does not get wet.
- Always unplug the shaver before cleaning it under
the tap.
- The appliance complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
Be careful with hot water. Always check if the water
is not too hot, to prevent your hands from getting
burnt.
- Noise level: Lc = 61dB(A)
ENGLISH


This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliance is safe to use based on
scientic evidence available today.
Charging
Make sure the appliance is switched off before you
start charging it.
To prevent the battery from going at during shaving,
you can also charge the shaver in between shaves,
even if the battery is not completely empty yet.This
will not damage the battery.
Charging normally takes approx. 8 hours.
Do not leave the appliance connected to the mains
for more than 24 hours.

Charging
,When you start charging the empty shaver the
battery symbol lights up.
Battery running low
,HQ6075/HQ6073:When the battery is running
low, the red battery symbol starts burning.When
you switch off the shaver, the red battery symbol
starts to ash.
,HQ6070:There is no warning or indication
that the battery is running low.The appliance
switches off automatically when the battery is
completely empty.
ENGLISH 5

Charging the appliance
Charge the appliance when the red battery symbol
burns or ashes (HQ6075/HQ6073) or when the
motor stops or starts running slower (HQ6070).
1 Put the appliance plug in the shaver.
2 Put the powerplug in the wall socket.
3 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver
when the battery has been fully charged.

A fully charged shaver has a cordless shaving time of
up to 40 minutes.


1 Press the on/off button once to switch on the
shaver.
The light ring goes on.
2 Move the shaving heads quickly over your skin,
making both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get accustomed
to the Philips shaving system.
3 Press the on/off button once to switch off the
shaver.
4 Put the protection cap on the shaver every
time you have used it, to prevent damage.
ENGLISH6


For grooming sideburns and moustache.
1 Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.

Regular cleaning guarantees better shaving
performance.
The easiest and most hygienic way to clean the
appliance is to rinse the shaving unit and the hair
chamber with hot water every time you have used
the appliance.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.

1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button (1) and open the
shaving unit (2).
ENGLISH 7

3 Clean the shaving unit and the hair chamber by
rinsing them under a hot tap for some time.
Make sure the inside of the shaving unit and the hair
chamber have been cleaned properly.
4 Rinse the outside of the appliance.
5 Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
6 Open the shaving unit again and leave it open
to let the appliance dry completely.
You can also clean the hair chamber without water
by using the brush supplied.

1 Open the shaving unit and pull it off the shaver.
You can also leave the shaving unit attached to the
shaver.
2 HQ6075: Remove the retaining frame.
3 HQ6073/HQ6070: Open the shaving unit, turn
the wheel anticlockwise (1) and remove the
retaining frame (2).
ENGLISH8

4 Clean the cutters and guards with the brush
supplied (your shaving heads may differ from
the one shown in the gure).
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
5 HQ6075: Put the shaving heads back into the
shaving unit and then put the retaining frame
back into the shaving unit.
Make sure that the projections of the shaving heads
t into the recesses.
6 HQ6073/HQ6070: Put the shaving heads back
into the shaving unit. Put the retaining frame
back into the shaving unit and turn the lock
clockwise (your shaving heads may differ from
the one shown in the gure).
7 Put the shaving unit back onto the shaver by
inserting the hinge into the slot in the rim of
the hair chamber and pushing it home until it
locks into place (‘click’).
8 Close the shaving unit.

Clean the trimmer every time you have used it.
1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
ENGLISH 9

2 Clean the trimmer with the brush supplied.
3 Lubricate the trimmer teeth with a drop of
sewing machine oil every six months.
Storage
,Put the protection cap on the shaver to prevent
damage.
,HQ6075/HQ6073: Store the appliance in the
pouch.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ64
Super Lift & Cut Shaving Heads (HQ6073/HQ6070)
or HQ8 Precise Cutting System Shaving Heads
(HQ6075).
1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Open the shaving unit and pull it off the shaver.
You can also leave the shaving unit attached to the
shaver.
ENGLISH10

3 HQ6075: Remove the retaining frame.
4 HQ6073/HQ6070: Open the shaving unit, turn
the wheel anticlockwise (1) and remove the
retaining frame (2).
5 Remove the shaving heads and place new ones
in the shaving unit.
6 HQ6075: Put the shaving heads back into the
shaving unit and then put the retaining frame
back into the shaving unit.
Make sure that the projections of the shaving heads
t into the recesses.
7 HQ6073/HQ6070: Put the shaving heads back
into the shaving unit. Put the retaining frame
back into the shaving unit and turn the lock
clockwise (your shaving heads may differ from
the one shown in the gure).
8 Put the shaving unit back onto the shaver by
inserting the hinge into the slot in the rim of
the hair chamber and pushing it home until it
locks into place (‘click’).
9 Close the shaving unit.
ENGLISH 11


The following accessories are available:
- HQ64 Super Lift & Cut Shaving Heads (HQ6073/
HQ6070)
- HQ8 Precise Cutting System Shaving Heads
(HQ6075)
- HQ110 Philips Shaving Head Cleaning Spray

- Do not throw away the appliance with the normal
household waste at the end of its life, but hand
it in at an ofcial collection point for recycling. By
doing this, you help to preserve the environment.
- The built-in rechargeable shaver battery contains
substances that may pollute the environment.
Always remove the battery before you discard
and hand in the shaver at an ofcial collection
point. Dispose of the battery at an ofcial
collection point for batteries. If you have trouble
removing the battery, you can also take the shaver
to a Philips service centre.The staff of this centre
will remove the battery for you and will dispose of
it in an environmentally safe way.

Only remove the battery if it is completely empty.
1 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver.
2 Let the shaver run until it stops, undo the
screws and open the shaver.
3 Remove the battery.
ENGLISH12
