Philips QG3380 User manual

User manual
QG3380

1

QG3380
ENGLISH 4
FRANÇAIS 19
INDONESIA 35
한국어 51
BAHASA MELAYU 66
PORTUGUÊS 82
简体中文‑ 98
ESPAÑOL 112
ภาษาไทย 128
 141
繁體中文 156
180
191

4
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benet from the support that Philips
offers, register your product at www.philips.com/
welcome.
General description (Fig. 1)
1 Body shaver
2 Mini-foil shaver
3 Nose/ear hair trimmer
4 Precision trimmer
5 Full metal beard trimmer
6 Handle
7 On/off button
8 TURBO button
9 Battery status indicator
10 Storage pouch
11 Small plug
12 Adapter
13 Cleaning brush
14 Body trimming comb (3-12mm)
15 Beard and moustache comb (1-18mm)
16 Hair clipping comb (3-20mm)
Important
Read this user manual carefully before you use the
appliance and save it for future reference.
Danger
- Keep the adapter dry.
Warning
- Check if the voltage indicated on the adapter
corresponds to the local mains voltage before you
connect the appliance.
ENGLISH

- The adapter contains a transformer. Do not cut
off the adapter to replace it with another plug, as
this causes a hazardous situation.
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- Keep the appliance and its cord out of the reach
of children.
Caution
- Use, charge and store the appliance at a
temperature between 5°C and 35°C.
- Only use the adapter supplied to charge the
appliance.
- If the appliance is subjected to a major change
in temperature, pressure or humidity, let the
appliance acclimatise for 30 minutes before you
use it.
- If the adapter is damaged, always have it replaced
with one of the original type in order to avoid a
hazard.
- Always check the appliance before you use it. Do
not use the appliance if any of its parts is damaged
or broken, as this may cause injury.
Compliance with standards
- The appliance complies with the internationally
approved IEC safety regulations and can be safely
used in the bath or shower.
- This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliance is safe to use based on
scientic evidence available today.
ENGLISH 5

Charging
Charging takes approximately 1 hour.When the
appliance is fully charged, it has an operating time of
up to 50 minutes.When the battery status indicator
lights up orange, the battery is running low (approx.
10 minutes of operating time left) indicating you
need to recharge the appliance soon.
Note:You can also quick charge the appliance,
a 5 minute charge equals approximately 5 minutes of
operating time.
1 Switch off the appliance before you charge it.
2 Insert the small plug into the appliance.
3 Put the adapter in the wall socket.
Using the appliance
The appliance is equipped with a turbo power
boost for fast results and a memory function that
remembers the last used speed setting.
Body trimming
It is recommended to trim your body hair when it is
dry because wet hair tends to stick to the body.
Tip: Take your time when you rst start to trim sensitive
areas. You have to acquire practice with the appliance.
Your skin also needs some time to adjust to the
procedure.
Tip: When you trim sensitive areas, we advise you
not to use the trimmer without the trimming comb.
ENGLISH6

1 Place the trimmer on the handle (1) and turn it
clockwise to x it (2).
2 Slide the body trimming comb into the guiding
grooves on both sides of the handle.
3 Press the setting selector (1) and slide the
comb to the desired hair length setting (2).
You can choose any setting between 3 and 12mm in
steps of 1mm.
4 Switch on the appliance.
5 To trim the hair, move the trimming comb
through the hair slowly.
6 When you are nished, switch off the appliance.
ENGLISH 7

Body shaving
You can use the body shaver wet or dry to shave
hair on all parts of the body below the neckline. Do
not use the body shaver to shave or trim facial or
scalp hair.
Note: Before you use the body shaver, always check it
for damage or wear. If the shaving foil unit of the body
shaver is damaged or worn, do not use the body shaver,
as injury may occur. Replace a damaged shaving foil
unit right away (see chapter ‘Replacement’).
1 Place the body shaver on the handle (1) and
turn it clockwise to x it (2).
2 Switch on the appliance.
3 Place the shaving foil unit on the skin.Always
make sure that the shaving foil unit is in full
contact with the skin.
4 Move the appliance slowly and against the
direction of hair growth. Press lightly.
Tip: Stretch your skin with your free hand to make the
hairs stand upright and minimise the chance of skin
irritation.
Tip: If the hairs are longer than 10mm, trim them rst
to a length of 3mm to make shaving easier.
ENGLISH8

Hair clipping
Preparing for hair clipping
1 Make sure that the head of the person whose
hair you intend to cut is at the same level as
your chest.This ensures that all parts of the
head are clearly visible and within easy reach.
2 Comb the hair in the growth direction.
Hair clipping with hair clipping comb
1 Place the trimmer on the handle (1) and turn it
clockwise to x it (2).
2 Slide the hair clipping comb into the guiding
grooves on both sides of the handle.
3 Press the setting selector (1) and slide the
comb to the desired hair length setting (2).
You can choose any setting between 3 and 20mm in
steps of 1mm.
Tip:Write down the hair length settings you selected
to create a certain hairstyle as a reminder for future
clipping sessions.
4 Switch on the appliance.
5 Move the appliance slowly and against the
direction of hair growth. Press lightly.
3 - 20
ENGLISH 9

Note: Since hair grows in different directions, you need
to move the appliance in different directions as well
(upward, downward or across).
6 Always make sure that the at part of the
comb is in full contact with the scalp to obtain
an even result.
Make overlapping passes over the head to ensure
that you cut all the hair that needs to be cut.
Note: When you trim for the rst time, start at the
highest setting (20mm) to familiarise yourself with the
appliance.
Hair clipping without hair clipping comb
You can use the trimmer without comb to clip hair
very close to the skin (to a length of 1mm) or to
create contours.
Caution: Be careful when you clip without the
comb because the trimmer removes every hair it
comes in contact with.
1 Press the setting selector (1) and slide the
comb upwards (2).Then pull the comb off the
appliance (3).
2 Before you start to contour the hairline
around the ears, comb the hair ends over
the ears.
ENGLISH10

3 Tilt the appliance in such a way that only one
edge of the trimmer touches the hair.
Only cut the hair ends.The hairline should be close
to the ear.
4 To contour the neckline and sideburns, turn
the appliance and make downward strokes.
5 Move the appliance slowly and smoothly.
Follow the natural hairline.
Beard trimming
When you trim your beard for the rst time, be
careful. Do not move the trimmer too fast. Make
smooth and gentle movements.
Beard trimming with the beard and
moustache comb
1 Place the trimmer on the handle (1) and turn it
clockwise to x it (2).
2 Slide the beard and moustache comb into the
guiding grooves on both sides of the handle.
3 Press the setting selector (1) and slide the
comb to the desired hair length setting (2).
You can choose any setting between 1 and 18mm in
steps of 1mm.
ENGLISH 11

4 Switch on the appliance.
5 Slowly move the trimmer against the hair
growth direction. Press lightly and always make
sure the surface of the comb is in full contact
with the skin.
Note: When you trim for the rst time, start at the
highest setting (18mm) to familiarise yourself with the
appliance.
Styling/contouring your beard
You can use the precision trimmer to cut shapes in
beard hair or scalp hair. It cuts hair very close to the
skin (to a length of 1mm).
Caution: Be careful when you use the precision
trimmer because it removes every hair it comes in
contact with.
1 Place the precision trimmer on the handle (1)
and turn it clockwise to x it (2).
2 To achieve a good cutting result, move the
precision trimmer against the direction of
hair growth.Always make sure the precision
trimmer is in full contact with the skin.
3 Make careful and controlled movements with
the precision trimmer.
Tip: For the perfect nish, you can use the mini-foil
shaver to make the edges and lines of your beard style
even smoother.
ENGLISH12

Grooming facial hair (nose and ear hair)
Trimming nose hair
1 Place the nose/ear hair trimmer on the handle
(1) and turn it clockwise to x it (2).
2 Make sure your nostrils are clean.
3 Switch on the appliance and insert the tip of
the trimmer into one of your nostrils.
Do not insert the tip more than 0.5cm into your
nostril.
4 Slowly move the tip in and out while turning it
round at the same time to remove unwanted
hair.
To reduce the tickling effect, make sure that you
press the side of the tip rmly against the skin.
Trimming ear hair
1 Place the nose/ear hair trimmer on the handle
(1) and turn it clockwise to x it (2).
2 Clean the outer ear channel. Make sure it is
free from wax.
3 Switch on the appliance and move the tip softly
round the ear to remove hairs that stick out
beyond the rim of the ear.
4 Carefully insert the tip into the outer ear
channel.
Do not insert the tip more than 0.5cm into the ear
channel as this could damage the eardrum.
ENGLISH 13

Cleaning
Never use compressed air, scouring pads, abrasive
cleaning agents or aggressive liquids such as petrol
or acetone to clean the appliance.
Note:The appliance does not need any lubrication.
Clean the appliance after each use.
1 Make sure the appliance is switched off and
disconnected from the mains.
2 Remove any comb and/or attachment from the
appliance.
3 Blow and/or shake out any hair that has
accumulated in the attachments and/or combs.
4 Clean the attachments, the combs and the
appliance under a lukewarm tap or with the
cleaning brush.
5 Clean the adapter with the cleaning brush or a
dry cloth.
Keep the adapter dry.
Cleaning the mini-foil shaver
1 After each use, pull the top part of the mini-foil
shaver off the bottom part.
The shaving foil is very delicate. Handle it carefully.
If the shaving foil is damaged, do not use the mini-
foil shaver anymore.
Do not clean the shaving foil with the
cleaning brush, as this may cause damage.
ENGLISH14

2 Blow and/or shake out any hair that has
accumulated inside the mini-foil shaver.
3 Clean the top part of the mini-foil shaver under
a lukewarm tap.
Cleaning the body shaver
1 After each use, pull the shaving foil unit out of
the body shaver.
The shaving foil is very delicate. Handle it carefully.
If the shaving foil is damaged, do not use the body
shaver anymore.
Do not clean the shaving foil with the
cleaning brush, as this may cause damage.
2 Blow and/or shake out any hair that has
accumulated inside the body shaver.
3 Clean the body shaver and the shaving foil unit
under a lukewarm tap.
ENGLISH 15

Storage
Store the appliance and attachments in the storage
pouch to prevent damage, or store it on the storage
stand.
Ordering accessories
To purchase accessories for this appliance, please
visit our online shop at www.shop.philips.com/
service. If the online shop is not available in your
country, go to your Philips dealer or a Philips
service centre. If you have any difculties obtaining
accessories for your appliance, please contact the
Philips Consumer Care Centre in your country.You
nd its contact details in the worldwide guarantee
leaet.
If the adapter is damaged, always have it replaced
with one of the original type in order to avoid a
hazard.
Only replace damaged or worn attachments or
combs with original Philips replacement attachments
or combs.
Shaving foil unit of body shaver
If you use the body shaver frequently, replace the
shaving foil unit of the body shaver (type number
TT2000) every year. Replace a damaged shaving foil
unit immediately.To replace the shaving foil unit:
1 Pull the shaving foil unit off the body shaver.
2 Snap the new shaving foil unit onto the body
shaver.
ENGLISH16

Environment
- Do not throw away the appliance with the normal
household waste at the end of its life, but hand
it in at an ofcial collection point for recycling. By
doing this, you help to preserve the environment.
- The built-in rechargeable battery contains
substances that may pollute the environment.
Always remove the battery before you discard
and hand in the appliance at an ofcial collection
point. Dispose of the battery at an ofcial
collection point for batteries. If you have trouble
removing the battery, you can also take the
appliance to a Philips service centre.The staff of
this centre will remove the battery for you and
will dispose of it in an environmentally safe way.
Removing the rechargeable battery
Only remove the rechargeable battery when you
discard the appliance. Make sure the battery is
completely empty when you remove it.
Be careful, the battery strips and housing parts are
very sharp.
1 Make sure the appliance is disconnected from
the mains.
2 Remove the attachment.
3 Remove the front cover of the appliance with a
athead screwdriver by placing it between the
front cover and back cover.
4 Remove the back cover of the appliance from
the inner.
ENGLISH 17

5 Place the athead screwdriver in the indicated
area and apply force to separate the inner.
6 Unhook the snap hooks on both sides of the
inner.
7 Remove the transparent cover to expose the
printed circuit board.
8 Lift up the printed circuit board to expose the
rechargeable batteries.
9 Cut the wires to separate the rechargeable
batteries and the printed circuit board from
the appliance.
10 Cut or snap off the battery tabs to separate
the rechargeable batteries from the printed
circuit board.
Guarantee and service
If you need service or information or if you have a
problem, please visit the Philips website at
www.philips.com/support or contact the Philips
Consumer Care Centre in your country. You nd its
phone number in the worldwide guarantee leaet. If
there is no Consumer Care Centre in your country,
go to your local Philips dealer.
ENGLISH18

19
Introduction
Félicitations pour votre achat et bienvenue dans
l’univers Philips ! Pour proter pleinement de
l’assistance Philips, enregistrez votre produit sur le
site à l’adresse suivante : www.philips.com/welcome.
Description générale (g. 1)
1 Rasoir pour le corps
2 Mini-rasoir à grille
3 Tondeuse pour nez ou oreilles
4 Tondeuse de précision
5 Tondeuse à barbe entièrement métallisée
6 Poignée
7 Bouton marche/arrêt
8 BoutonTURBO
9 Voyant d’état de la batterie
10 Trousse de rangement
11 Petite che
12 Adaptateur secteur
13 Brossette de nettoyage
14 Sabot corps (3-12 mm)
15 Sabot barbe et moustache (1-18 mm)
16 Sabot cheveux (3-20 mm)
Important
Lisez attentivement ce mode d’emploi avant d’utiliser
l’appareil et conservez-le pour un usage ultérieur.
Danger
- Évitez de mouiller l’adaptateur.
Avertissement
- Avant de brancher l’appareil, vériez que
la tension indiquée sur l’adaptateur secteur
correspond à la tension du secteur.
FRANÇAIS

- L’adaptateur contient un transformateur. N’essayez
pas de remplacer la che de l’adaptateur pour
éviter tout accident.
- Cet appareil n’est pas destiné à être utilisé par
des personnes (notamment des enfants) dont les
capacités physiques, sensorielles ou intellectuelles
sont réduites, ou par des personnes manquant
d’expérience ou de connaissances, à moins que
celles-ci ne soient sous surveillance ou qu’elles
n’aient reçu des instructions quant à l’utilisation de
l’appareil par une personne responsable de leur
sécurité.
- Tenez la bouilloire et le cordon hors de portée
des enfants.
Attention
- Utilisez, rechargez et conservez l’appareil à une
température comprise entre 5 °C et 35 °C.
- Utilisez exclusivement l’adaptateur fourni pour
charger l’appareil.
- Si l’appareil devait être soumis à une forte
variation de température, de pression ou
d’humidité, laissez-le s’acclimater pendant
30 minutes avant de l’utiliser.
- Si l’adaptateur secteur est endommagé, il doit
toujours être remplacé par un adaptateur secteur
de même type pour éviter tout accident.
- Vériez systématiquement l’appareil avant de
l’utiliser. N’utilisez pas l’appareil si l’un de ses
éléments est endommagé ou cassé car il existe un
risque de blessure.
FRANÇAIS20
