Philips CRYSTAL 660 - NETWORK User manual

660
RECHARGEABLE/MAINS

English Page 4
• Keep pages 3, 40, 41, and 42 open when reading
these operating instructions.
Français Page 9
• Pour le mode d'emploi: dépliez la page 3 et les pages 40,
41 et 42.
Deutsch Seite 14
• Schlagen Sie beim Lesen der Gebrauchsanweisung Seite
3 und Seiten 40, 41 und 42 auf.
Nederlands Pagina 19
• Sla bij het lezen van de gebruiksaanwijzing pagina 3 en de
pagina's 40, 41 en 42 op.
Italiano Pagina 24
• Prima di usare l'apparecchio, aprite la pagina 3 e le pagine
40, 41 e 42 e leggete attentamente le istruzioni per l'uso.
Español Página 29
• Desplegar la página 3 y las páginas 40, 41 y 42 al leer las
instrucciones de manejo.
Português Página 34
• Durante a leitura do modo de emprêgo, desdobre e
verifique a pág. 3 e as pág. 40, 41 e 42.
For Australian consumers
The rechargeable batteries used in your Philishave
appliance are recyclable.
When discarding the shaver or when the batteries require
replacement, take the shaver to a Philips Service Centre or
authorised agent.
For the address of your nearest service centre or agent
please contact our Customer Information Centre
on telephone [phone].
2

3
E
1
G
H
A
B
C
D
F
f

Important
•Please read these instructions carefully in
conjunction with the illustrations (pages 3, 40, 41
and 42) before using the appliance.
•Please bear in mind that your skin may need two
to four weeks to become fully accustomed to the
Philishave shaving system.
•Regular cleaning and maintenance ensures
optimal performance and prolongs the shaver's
working life.
•Do not allow the shaver to come into contact with
water.
•Do not leave the appliance in a very warm place or
in direct sunlight.
•Before first use (or if the shaver has not been
used for a month or longer) it should be charged
for a period of at least 4 hours.
4
To protect the environment, this
rechargeable Philishave appliance is equipped with a
nickel-hydride battery which contains less than 0.01%
cadmium.
However we advise you to ensure that the battery is
separated from the normal household refuse and disposed
of at an officially assigned place when discarding your
appliance in due course. Please refer to section "Protecting
the environment".
English

General description (fig. 1, page 3)
AShaving unit with three shaving heads. Each shaving
head consists of a guard and a cutter.
BGreen pilot light. Illuminates whilst the shaver is
connected to the mains supply (for charging or shaving
directly from the mains). Goes out as soon as the
rechargeable battery is full.
COn/Off switch. The shaver is prevented from being
switched on accidentally by the locking device
incorporated in the switch.
- On: keep the locking knob on the switch pressed-in
and slide the switch upwards.
- Off: slide the switch downwards.
DMains cord. Using the mains cord you can connect the
shaver to any mains voltage between 100 and 240 Volts
AC (for charging and shaving).
EConnector. When using the mains cord insert the small
plug firmly into the connector up to the indication mark.
FTrimmer. The trimmer can be switched on whilst the
motor is running.
- Switch on by moving the slide (f) upwards.
- Switch off by moving the slide downwards.
- Brush the trimmer clean after use.
GBrush. Refer to section "Maintenance and cleaning" for
correct usage.
HProtective cap. Keep the protective cap on the shaver
when not in use.
Shaving tips
for a close, quick and comfortable shave
• The best results are obtained if the skin is dry. So
preferably shave before washing or some time afterwards.
• If required, apply a preshave lotion. This can be
particularly helpful if the climate is warm and humid.
• The Philishave system gives you a quick, close and
comfortable shave. Just move the shaving unit quickly
over the skin.
5

• For the best results stretch the skin to bring the hairs into
an upright position.
Then move the shaving unit against the direction of the
growth of the hairs.
• The trimmer has been especially designed for grooming
sideburns, moustache and beard.
The trimmer is not required for long hairs in the neck area;
these hairs can easily be shaved off with the shaving unit.
Charging (voltages in the range 100-240 Volt AC)
•It is advisable to charge the shaver at temperatures
between 5 °C and 35°C (41 °F and 95 °F). This
guarantees maximum life from the rechargeable battery.
• Keep the cassette open if you charge the appliance in it.
- Slide the on/off switch (C) downwards.
- Insert the small plug firmly into the connector (E) up to the
indication mark.
- Then connect to the wall socket. The green pilot light (B)
will come on.
•A full charge requires approx. 1 hour.
• Regular cleaning of the shaver means that less battery
energy is consumed, so that more shaving time becomes
available.
• The shaver will not be damaged by leaving it connected to
the mains supply after it is fully charged.
However, it is not advisable to charge the shaver
permanently as this would shorten the life of the
rechargeable battery.
Shaving directly from the mains
- Slide the on/off switch (C) downwards.
- Connect the appliance to a wall socket.
- Then switch the appliance on.
6

Maintenance and cleaning (fig. 2-17 on pages 40 and 41)
• Always switch the shaver off before carrying out
maintenance or cleaning.
• The rotating cutter blades of the Philishave system keep
the shaved stubble neatly inside the shaving unit. In
general, the shaving unit needs cleaning only once a
week.
Every week
Fig. 2. Clean the guard slots using the short bristled end of
the brush.
Fig. 3. Pull the shaving unit from the shaver.
Fig. 4 & 5. Clean the inside using the long bristled end of
the brush.
Every three months
If your skin is of an oily type or if you have been using a pre-
shave lotion, this procedure should be carried out once a
month.
Fig. 6. Pull the shaving unit from the shaver.
Fig. 7. Press the wheel downward and turn it anti-clockwise
(see the arrow). Then lift the cluster frame holding
the shaving heads from the shaving unit.
Fig. 8. Slide one shaving head (guard and cutter) out of the
frame. Keep your finger under the shaving head to
prevent the cutter from falling out of the guard.
Fig. 9. Keep the guard and cutter together because
each pair has been especially ground to match
each other. If the guards and cutters are mixed, it
may take a couple of weeks before optimal shaving
performance is restored.
Fig. 10. Hold the cutter as shown...
Fig. 11 ....and brush it carefully clean as illustrated.
Use only the short bristled end of the brush.
Fig. 12.Clean the inside of the guard, using the long bristled
end of the brush.
Fig. 13. Slide the shaving head back into place. Then clean
the other two shaving heads one by one in the
same way.
7

Fig. 14. Replace the cluster frame with the shaving heads.
Do not forget to secure the cluster frame by
pressing the wheel downward and turning it
clockwise.
Fig. 15. Do not apply any pressure to the guards when
replacing the shaving unit on to the shaver.
Fig. 16. If you have used a degreasing liquid (e.g. alcohol) to
clean the shaving heads, or if your skin is very dry,
lubricate the guards with one drop of light machine
oil.
Every six months
Fig. 17. Put two drops of light machine oil on the teeth of the
trimmer.
Replacement shaving heads
Worn or damaged shaving heads must be replaced only with
the original Philips replacement heads type HP 1917.
Protecting the environment
How to remove the built-in rechargeable battery
(when discarding the appliance) (fig. 18-21, page 42)
• Please note: You can also take the appliance to a Philips
Service Centre. The staff will be happy to help you.
- Remove the plug from the wall socket.
- Before removing the battery should be completely
empty.
Let the appliance run until the motor stops.
- Push the trimmer slide (f) upwards (fig. 18).
- Unscrew the two countersunk screws at the back side of
the shaver. For this purpose you can use a small
screwdriver (width approx. 2 mm) or a Torx T-8 type
screwdriver (fig. 19).
- Remove the back plate of the appliance (fig. 20).
- Cut the two connector strips (fig. 21).
You will recognise the battery by the print NIMH.
Do not connect the appliance to the mains power after
the battery has been removed.
8

Important
•Lisez attentivement ce mode d'emploi et regardez
tous les dessins des pages 3, 40, 41 et 42 avant
d'utiliser l'appareil.
•Lorsque vous utilisez le système de rasage
Philishave pour la première fois, il est important de
savoir qu'une période d'adaptation de la barbe de 2
à4 semaines est nécessaire pour obtenir
l'efficacitéoptimale du rasage.
•Un nettoyage et un entretien réguliers vous
garantissent de bonnes performances et une
longue durée de vie de l'appareil.
•Evitez tout contact de l'appareil avec l'eau.
•Ne laissez pas l'appareil exposéàde fortes
chaleurs ou aux rayons directs du soleil.
•Lors de la première charge, (ou après une longue
période de non-utilisa-tion), rechargez l’appareil
pendant au moins 4 heures (sans tenir compte des
indications portées sur l’afficheur).
9
Pour ménager l'environnement, votre
rasoir rechargeable Philips est équipéde
piles àl'hydrure de nickel.
Celles-ci contiennent moins de 0.01 % de cadmium.
Nous vous conseillons toutefois lorsque vous vous
débarrassez de l'appareil en fin d'utilisation, de ne pas jeter
les piles dans les ordures ménagères ordinaires, mais de les
déposer à un endroit désigné à cet effet par les pouvoirs
publics. Veuillez vous référer au chapitre "Protection de
l'environnement".
Description générale (fig. 1, page 3)
AUnitéde rasage avec 3 têtes de rasage (grilles et
couteaux).
BTémoin lumineux vert. S'allume quand le rasoir est
Français

branché sur le secteur (pour recharge et rasage utilisant
le rasoir directement branché sur le secteur). S'éteint
lorsque l' accumulateur est rechargé.
CInterrupteur marche/arrêt, avec sécurité contre la mise
en marche involontaire.
Appuyez sur la sécurité et faites glisser l'interrupeur vers
le haut ou vers le bas.
Mise en marche: appuyez sur la sécurité et faites
glisser l'interrupteur vers le haut.
Arrêt: faites glisser l'interrupteur vers le bas.
DCordon d'alimentation. Le cordon d'alimentation
permet d'utiliser l'appareil sur des tensions secteur de
100 à 240 Volts AC.
EConnecteur. Enfoncez bien la fiche dans le connecteur
jusqu'au repère.
FTondeuse. La tondeuse peut être mise en service
pendant que le moteur fonctionne.
- Pour cela, faites glisser le curseur (f) vers le haut.
- Pour l'arrêter, ramenez le curseur vers le bas.
- Nettoyez la tondeuse avec la brosse après chaque
utilisation.
GBrosse. Lisez le chapitre "Entretien et nettoyage" pour
utiliser correctement la brosse.
HCapot de protection. Remettez le capot sur l'unité de
rasage après chaque utilisation.
Conseils de rasage
pour un rasage rapide, agréable et de très près.
• On obtient les meilleurs résultats quand la peau est bien
sèche. Il est donc préférable de se raser avant de se laver
ou quelque temps après.
• Utilisez éventuellement une lotion de pré-rasage, ce qui
assure un rasage plus agréable, particulièrement en climat
chaud et humide.
• Le système Philishave vous assure un rasage rapide,
agréable et de très près.
Déplacez rapidement la tête de rasage sur la peau.
• Pour obtenir un meilleur rasage, tendez la peau pour
redresser les poils et rasez à rebrousse-poils avec des
mouvements circulaires.
10
