Philips S1223 User manual

S1121, S1223

2
1
7
8
3
4
5
10
9
6

empty page before TOC

English 6
Bahasa Indonesia 21

English
General description (Fig. 1)
1 Protective cap
2 Shaving unit
3 Shaving unit release button
4 On/off button
5 Charging light
6 Socket for small plug
7 Pop-up trimmer (S1223 only)
8 Trimmer release slide switch (S1223 only)
9 Supply unit
10 Small plug
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Important safety information
Read this important information carefully before
you use the appliance and save it for future
reference.
Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the detachable
supply unit (A00390/A00380) provided with
the appliance.
6English

- The supply unit contains a transformer. Do not
cut off the supply unit to replace it with another
plug, as this causes a hazardous situation.
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
- Always unplug the shaver before you clean it
under the tap.
- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as
this may cause injury. Always replace a
damaged part with one of the original type.
- This appliance contains batteries that are non-
replaceable.
- Do not open the appliance to replace the
rechargeable battery.
Caution
- Never use water hotter than 60°C to rinse the
shaver.
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only
be used by one person.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
7
English

- Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the
shaver.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
General
- This shaver is waterproof. It is suitable for use in
the bath or shower and for cleaning under the
tap. For safety reasons, the shaver can
therefore only be used without cord.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
Charging
Charge the appliance before first use and when
the display indicates that the battery is almost
empty.
When you charge the appliance for the first time or
after a long period of disuse, let it charge until the
charging light lights up continuously.
Charging takes approx. 8 hours. A fully charged
appliance has a cordless operating time of up to
40 minutes.
8English

Charging with the supply unit
21
1Put the small plug in the appliance.
2Put the supply unit in the wall socket.
- The charging light shows the charging status of
the appliance (see 'Charging light').
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Charging light
Battery fully charged
When the battery is fully charged, the charging
light lights up white continuously.
Note: After approx. 30 minutes, the charging light
goes out to save energy.
Battery low
- When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
charging light flashes orange.
- When you switch off the appliance, the charging
light continues flashing orange for a few
seconds.
Charging
The charging light flashes white to indicate that the
appliance is charging.
9
English

Using the appliance
Note: This appliance is waterproof. It is suitable for
use in the bath or shower and for cleaning under
the tap. For safety reasons, this appliance can
therefore only be used without cord.
This symbol indicates that the product can be
rinsed under running tap water.
Shaving tips and tricks
- Make circular movements during use. Circular
movements provide better shaving results than
straight movements.
- Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
Switching the appliance on and off
To switch the appliance on or off, press the on/off
button once.
Shaving
- For the best results on skin comfort, pre-trim
your beard if you have not shaved for 3 days or
longer.
Dry shaving
1Switch on the appliance.
10 English

2Move the shaving heads in circular movements
over your skin to catch all hairs growing in
different directions.
3Stretch your skin with your free hand so the
blades can lift and cut hair. Gently press the
shaver onto you skin so the floating heads can
follow the contours of your face.
Note: Do not press too hard as too much
pressure can pinch the skin.
4Switch off and clean the appliance after each
use.
5Put the protective cap on the appliance to
protect the shaving heads during storage and
travel.
Note: You can also use the shaver while it is
plugged-in and charging.
Wet shaving
For a more comfortable shave, you can also use
this appliance on a wet face with shaving foam or
shaving gel.
1Apply some water to your skin.
11
English

2Apply shaving foam or gel to your skin.
3Rinse the shaving unit under the tap to ensure
that it glides smoothly over your skin.
4Switch on the appliance.
5Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.
6Switch off and clean the appliance after each
use.
7Dry your face.
Note: Make sure that you rinse all foam or
shaving gel off the appliance with warm water.
8Put the protective cap on the appliance to
protect the shaving heads during storage and
travel.
Trimming with pop-up trimmer (S1223 only)
You can use the trimmer to groom your sideburns
and moustache.
12 English

1Push the trimmer release slide downwards to
open the trimmer.
2Switch on the appliance.
3Hold the trimmer perpendicular to the skin and
move the appliance downwards while you exert
gentle pressure.
4Switch off and clean the trimmer after each use.
5Close the pop-up trimmer (‘click’).
Cleaning and maintenance
Cleaning the shaver
Caution: Never use compressed air, scouring
pads, abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean the
appliance.
Clean the shaver after every use for optimal
performance (see 'Cleaning and maintenance').
Caution: While rinsing the shaving heads, water
may drip out of the base of the appliance. This is
a normal occurrence. Internal electric parts are in
a waterproof compartment so the appliance will
be protected against water damage.
1Switch off the appliance and make sure it is
disconnected from the wall socket.
13
English

2Press the release button to open the shaving
unit.
3Rinse the shaving unit and hair chamber with
lukewarm water.
4Rinse the outside of the shaving unit with
lukewarm water.
Caution: Never dry the shaving unit with a
towel or tissue, as this may damage the
shaving heads.
5Carefully shake off excess water and let air dry
completely.
6Close the shaving unit.
Cleaning the pop-up trimmer (S1223 only)
Clean the pop-up trimmer after each use.
Caution: Never dry the trimmer teeth with a towel
or tissue, as this may damage the trimmer teeth.
1Switch off the appliance and make sure it is
disconnected from the wall socket.
2Push the trimmer release slide button down to
open the pop-up trimmer.
14 English

3Switch on the appliance and rinse the pop-up
trimmer with warm water.
4After cleaning, switch off the appliance.
5Carefully shake off excess water and let the
pop-up trimmer air dry.
6Close the pop-up trimmer (‘click’).
Tip: For optimal performance, lubricate the teeth
of the pop-up trimmer with a drop of mineral oil
every six months (oil not included).
Thorough cleaning
Clean the shaving heads thoroughly once a month
for optimal performance.
1Switch off the appliance and make sure it is
disconnected from the wall socket.
2Press the release button to open the shaving
unit. Pull the shaving unit off the appliance.
2
1
3Turn the lock anticlockwise and remove the
retaining frame.
4Remove and clean one shaving head at a time.
Each shaving head consists of a cutter and a
guard.
Note: Do not clean more than one cutter and
guard at a time, since they are all matching sets.
If you accidentally mix up the cutters and
guards, it may take several weeks before
optimal shaving performance is restored.
15
English

- Remove the cutter from the shaving guard and
clean both parts under the tap.
5Put the cutter back into the guard.
6Put the shaving heads back into the shaving
unit.
Note: Make sure that the projections of the
shaving heads fit exactly into the recesses of
the shaving head holder.
1
2
7Put the retaining frame back into the shaving
unit and turn the lock clockwise.
16 English

8Insert the lug of the shaving unit into the slot in
the top of the appliance. Then close the shaving
unit ('click').
Note: If the shaving unit does not close
smoothly, check if you have inserted the
shaving heads properly and if the retaining
frame is locked.
Replacement
Replacing the shaving heads
For maximum shaving performance, we advise you
to replace the shaving heads every two years.
Replace damaged shaving heads immediately.
Always replace the shaving heads with original
Philips shaving heads (see 'Ordering accessories').
1Switch off the appliance and make sure it is
disconnected from the wall socket.
2Press the shaving unit release button to open
the shaving unit. Pull the shaving unit off the
appliance.
2
1
3Turn the lock anticlockwise and remove the
retaining frame. Place it aside in a safe place.
4Remove the shaving heads from the shaving
unit.
Discard the used shaving heads immediately to
avoid mixing them with the new shaving heads.
17
English

5Place new shaving heads in the shaving unit.
Note: Make sure that the shaving heads with
the projections fit exactly onto the hooks of the
shaving head holder when placing them. The
shaving heads supplied with the shaver either
have notches or projections. Both shaving
systems are the same.
1
2
6Put the retaining frame back into the shaving
unit and turn the lock clockwise.
7Insert the hinge of the shaving unit into the slot
in the top of the shaver. Then close the shaving
unit.
Note: If the shaving unit does not close
smoothly, check if you have inserted the
shaving heads properly and if the retaining
frame is locked.
Storage
Put the protective cap on the shaver to prevent
damage.
Note: Always let the shaver dry completely before
storing.
Store the appliance in the pouch supplied.
Make sure the appliance is dry before you store it
in the pouch.
18 English

Ordering accessories
To buy accessories or spare parts, visit
www.philips.com/parts-and-accessories or go to
your Philips dealer. You can also contact the
Philips Consumer Care Center in your country (see
the international warranty leaflet for contact
details).
Recycling
- Do not throw away the product with the normal
household waste at the end of its life, but hand
it in at an official collection point for recycling.
By doing this, you help to preserve the
environment.
- This product contains a built-in rechargeable
battery which shall not be disposed of with
normal household waste. Please take your
product to an official collection point or a
Philips service center to have a professional
remove the rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the shaver. Before you remove
the battery, make sure that the shaver is
disconnected from the wall socket and that
the battery is completely empty
Take any necessary safety precautions
when you handle tools to open the shaver
and when you dispose of the rechargeable
battery.
19
English

1Check if there are screws in the back of the
shaver or in the hair chamber. If so, remove
them.
2Remove the outer panels of the shaver with a
screwdriver or other tool. If necessary, also
remove additional screws and/or parts until you
see the printed circuit board with the
rechargeable battery.
3Remove the rechargeable battery.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the
international warranty leaflet.
Warranty restrictions
The shaving heads (cutters and guards) are not
covered by the terms of the international warranty
because they are subject to wear.
20 English
