Philips RQ1051 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
RQ1051
07/08
PRODUCT INFORMATION
General:
- Rechargeble
- World wide automatic voltage selection
- Washable
- Charge indication
- Battery low indication
- Battery full indication
- Travel lock
- Cleaning indicator
- Charge indicator
- Shaving unit replacement indicator
Safety info
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100 - 240 V / 50 - 60 Hz
- Shaving unit : RQ10 (4222 036 15000)
- Charging time : 1 hour
- Shaving time : up to 21 day’s
- SAP coding : RQ1051

RQ1051
2-3
DISASSEMBLY- AND RE-ASSEMBLY ADVICE
- Remove shaving unit to prevent damaging during repairing
- Remove pivot cap (pos 3)
with a little knife
- Remove screws A
- Remove cover (pos 12)
Start on trimmerside
push left on the housing and
right on the cover and make
a smal opening
now push right on the
housing and left on the
cover so you can remove the
cover.
- Remove side grip’s
- Remove housing shell (pos 4) start on trimmer side
- Remove deco plate assy (pos 7) snaplock on the side
- Remove screws B
- Remove pivot base (pos 8)
- Remove trimmer
REPAIR INSTRUCTIONS
- No specific issues
OPTIONAL (accessories)
- 4222 036 02770 Brush black
- 4222 036 04080 Power plug U1 Str. EUR.
- 4222 036 05160 Power plug U1 Str. NOR
- 4222 036 05120 Power plug U1 Str. AUS/NZ
- 4222 036 04090 Power plug U1 Str. GBR
- 4222 036 05110 Power plug U1 Str. CAN/TW
- 4222 036 03810 Power plug U1 Str. MEX
- 4222 036 04850 Power plug U1 Str. KOR
- 4222 036 03870 Power plug U1 Str. JAP
- 4222 036 10320 Power plug U1 Str. PRC
- 4222 036 03760 Power plug U1 Str. ARG
- 4222 036 15020
Stand HE
PARTS LIST
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
4222 036 14990
4222 036 15000
4222 036 15080
4222 036 15100
4222 036 15050
4222 036 14950
4222 036 15160
4222 036 14980
4222 036 15010
4222 036 14940
4222 036 14970
4222 036 15060
4222 036 03540
4822 502 14545
Protection cap
Shaving unit SR1
Pivot cap SR1
Housing shell SR1 LE
Basic body SR1 LE
Magnet SR1
Deco Plate assy SR1 LE
Pivot base SR1
Trimmer assy SR1 HE/LE (Black knob)
Pivot Release spring SR1
Sidepanel (L+R) SR1 ME/LE
Cover shell SR1 HE/LE
Screw A (Black)
Screw B
= changed

RQ1051
3-3
EXPLODED VIEW
8
7
9
12
11
10
1
2
3
5
6
4
A
B
B
A
