Philips S5000 series User manual

series S5000

20
19
23
27
21
26
28
22
24 25
4
3
5
9
8
10
11
16
13
12
15
14
18
17
1
2
7
6
1

series S5000
ENGLISH 4
DANSK 39
DEUTSCH 73
ΕΛΛΗΝΙΚΑ 111
ESPAÑOL 150
SUOMI 187
FRANÇAIS 221
ITALIANO 258
NEDERLANDS 294
NORSK 331
PORTUGUÊS 365
SVENSKA 402
TÜRKÇE 437

4
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benet from the support that Philips
offers, register your product at www.philips.com/
welcome.
General description (Fig. 1)
1 Protection cap for cleansing brush attachment
(specic types only)
2 Click-on cleansing brush attachment
(specic types only)
3 Comb for beard styler attachment
(specic types only)
4 Click-on beard styler attachment
(specic types only)
5 Click-on trimmer attachment
(specic types only)
6 Protection cap for shaving unit
(specic types only)
7 Click-on shaving unit
8 On/off button
9 Turbo button (specic types only)
10 Handle
11 Socket for small plug
12 Battery charge indicator with 1 light
13 Battery charge indicator with 3 lights
14 Unplug for use symbol
15 Travel lock symbol
16 Replacement reminder
17 Cleaning reminder
18 Cleaning cartridge for SmartClean system
19 SmartClean system (specic types only)
20 Cap of SmartClean system
21 On/off button
22 Battery symbol
ENGLISH

23 Cleaning symbol
24 Replacement symbol
25 Ready symbol
26 Adapter
27 Small plug
28 Pouch (specic types only)
Note:The accessories supplied may vary for different
products.The box shows the accessories that have been
supplied with your appliance.
Important safety information
Read this important information carefully before you
use the appliance and its accessories and save it for
future reference.The accessories supplied may vary
for different products.
Danger
- Keep the adapter dry.
Warning
- The adapter contains a transformer. Do not cut
off the adapter to replace it with another plug,
as this causes a hazardous situation.
- This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not
be made by children without supervision.
- Always unplug the shaver before you clean it
under the tap.
- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as this
may cause injury. Always replace a damaged part
with one of the original type.
ENGLISH 5

Caution
- Never immerse the cleaning system or the
charging stand in water and do not rinse it under
the tap.
- Never use water hotter than 80°C to rinse the
shaver.
- Only use this appliance for its intended purpose as
shown in the user manual.
- For hygienic reasons, the appliance should only be
used by one person.
- Do not use the adapter in or near wall sockets
that contain or have contained an electric air
freshener to prevent irreparable damage to the
adapter.
- Never use compressed air, scouring pads, abrasive
cleaning agents or aggressive liquids such as petrol
or acetone to clean the appliance.
- If your shaver comes with a cleaning system,
always use the original Philips cleaning uid
(cartridge or bottle, depending on the type of
cleaning system).
- Always place the cleaning system on a stable, level
and horizontal surface to prevent leakage.
- If your cleaning system uses a cleaning cartridge,
always make sure that the cartridge compartment
is closed before you use the cleaning system to
clean or charge the shaver.
- When the cleaning system is ready for use, do not
move it to prevent leakage of cleaning uid.
- Water may drip from the socket at the bottom
of the shaver when you rinse it.This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the shaver.
Electromagnetic elds (EMF)
- This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic elds.
ENGLISH6

General
- This shaver is waterproof. It is suitable for use in
the bath or shower and for cleaning under the tap.
For safety reasons, the shaver can therefore only
be used without cord.
- The appliance is suitable for mains voltages ranging
from 100 to 240 volts.
- The adapter transforms 100-240 volts to a safe
low voltage of less than 24 volts.
The display
Charging
Battery charge indicator with 3 lights
- Charging takes approx. 1 hour
- Quick charge:When the appliance is connected
to the mains, the lights of the battery charge
indicator light up one after the other continuously.
When the appliance contains enough energy for
one shave, the bottom light of the battery charge
indicator ashes slowly.
- If you leave the appliance connected to the
mains, the charging process continues.To indicate
that the appliance is charging, rst the bottom
light ashes and then lights up continuously.
Then the second light ashes and then lights up
continuously, and so on until the appliance is fully
charged.
Battery charge indicator with 1 light
- Charging takes approx. 1 hour.
ENGLISH 7

- Quick charge:When the appliance does not
contain enough energy for one shave, the battery
charge indicator ashes quickly. When the battery
charge indicator starts ashing slowly, the
appliance contains enough energy for one shave.
- If you leave the appliance connected to the mains,
the charging process continues.To indicate that
the appliance is charging, the battery charge
indicator ashes slowly.
Battery fully charged
Note:This appliance can only be used without cord.
Note:When the battery is full, the display switches
off automatically after 30 minutes. If you press the
on/off button during charging, the ‘unplug for use’
symbol ashes white to remind you that you have to
disconnect the appliance from the mains.
When the battery is fully charged, all lights of the
battery charge indicator light up continuously.
- Battery charge indicator with 3 lights
- Battery charge indicator with 1 light
Battery low
When the battery is almost empty, the battery
charge indicator ashes orange.
ENGLISH8

- Battery charge indicator with 3 lights
- Battery charge indicator with 1 light
Remaining battery capacity
Battery charge indicator with 3 lights
- The remaining battery capacity is indicated by the
lights of the battery charge indicator that light up
continuously.
‘Unplug for use’ reminder
- The appliance is equipped with an ‘unplug for use’
reminder.The ‘unplug for use’ symbol starts to
ash to remind you that you have to disconnect
the appliance from the adapter before you can
switch it on.
Cleaning reminder
For optimal shaving performance, we advise you to
clean the shaver after every use.
ENGLISH 9

- When you switch off the shaver, the cleaning
reminder ashes to remind you to clean the
shaver.
Travel lock
You can lock the shaver when you are going to
travel.The travel lock prevents the shaver from being
switched on by accident.
Activating the travel lock
1 Press the on/off button for 3 seconds to enter
the travel lock mode.
- While you activate the travel lock, the travel lock
symbol lights up continuously.When the travel
lock is activated, the travel lock symbol ashes.
Deactivating the travel lock
1 Press the on/off button for 3 seconds.
- The travel lock symbol ashes and then lights up
continuously.
The shaver is now ready for use again.
Replacing shaving heads
For maximum shaving performance, we advise you
to replace the shaving heads every two years.
3 sec.
ENGLISH10

- The appliance is equipped with a replacement
reminder which reminds you to replace the
shaving heads.The replacement reminder lights up
continuously.
Note:After replacing the shaving heads, you need to
reset the replacement reminder by pressing the on/off
button for 7 seconds.
Turbo setting (specic types only)
The appliance is equipped with aTurbo or Turbo+
setting.This setting is intended for quicker and more
intense shaving and makes hard-to-reach areas easier
to shave.
Activating theTurbo setting
1 To activate the Turbo setting, press the Turbo
button once.
Deactivating theTurbo setting
1 To deactivate the Turbo setting, simply press
the Turbo button once again.
Charging
Charging takes approx. 1 hour.
Note:This appliance can only be used without cord.
Charge the shaver before you use it for the rst
time and when the display indicates that the battery
is almost empty.
ENGLISH 11

Charging with the adapter
1 Insert the small plug into the appliance and put
the adapter in the wall socket.
Charging in the SmartClean system
(specic types only)
1 Put the small plug in the SmartClean system.
2 Put the adapter in the wall socket.
3 Press down the top cap to be able to place the
shaver in the holder (‘click’).
4 Hold the shaver upside down above the holder.
Make sure the front of the shaver points
towards the SmartClean system.
5 Place the shaver in the holder, tilt the shaver
backwards and press down the top cap to
connect the shaver (‘click’).
- The battery symbol ashes slowly to indicate the
shaver is charging.
ENGLISH12

Using the shaver
Switching the appliance on and off
1 To switch on the appliance, press the on/off
button once.
2 To switch off the appliance, press the on/off
button once.
- Battery charge indicator with 3 lights:The display
lights up for a few seconds to show the remaining
battery status.
Shaving
Skin adaptation period
Your rst shaves may not bring you the result you
expect and your skin may even become slightly
irritated.This is normal.Your skin and beard need
time to adapt to any new shaving system.
We advise you to shave regularly (at least 3 times
a week) with this shaver for a period of 3 weeks to
allow your skin to adapt to the new shaver.
Note:This appliance can only be used without a cord.
1 Switch on the appliance.
2 Move the shaving heads over your skin in
circular movements.
Note: Do not make straight movements.
3 Clean the shaver after use (see chapter
‘Cleaning and maintenance’).
Wet shaving
You can also use this shaver in the shower or on a
wet face with shaving foam or shaving gel.
ENGLISH 13

To shave with shaving foam or shaving gel, follow the
steps below:
1 Apply some water to your skin.
2 Apply shaving foam or shaving gel to your skin.
3 Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4 Switch on the shaver.
5 Move the shaving heads over your skin in
circular movements.
Note: Rinse the shaver under the tap regularly to ensure
that it continues to glide smoothly over your skin.
6 Dry your face and thoroughly clean the
shaver after use (see chapter ‘Cleaning and
maintenance’).
Note: Make sure you rinse all foam or shaving gel off
the shaver.
ENGLISH14

Turbo setting (specic types only)
The appliance is equipped with aTurbo or Turbo+
setting for easy shaving of hard-to reach areas.
1 Switch on the shaver.
2 Press theTurbo button once to switch on the
Turbo setting if you want to shave hard-to-
reach areas more quickly.
3 Move the shaving heads over your skin in
circular movements.
Note: Do not make straight movements.
4 To deactivate the Turbo setting simply press
the Turbo button once.
Using the click-on attachments
Note:The accessories supplied may vary for different
products.The box shows the accessories that have been
supplied with your appliance.
Removing or attaching the click-on
attachments
1 Make sure the appliance is switched off.
2 Pull the attachment straight off the appliance.
Note: Do not twist the attachment while you pull it off
the appliance.
3 Insert the lug of the attachment into the slot
in the top of the appliance.Then press down
the attachment to attach it to the appliance
(‘click’).
ENGLISH 15

Using the trimmer attachment
You can use the trimmer attachment to groom
your sideburns and moustache.
1 Make sure the appliance is switched off.
2 Insert the lug of the attachment into the slot
in the top of the shaver.Then press down
the trimmer attachment to attach it to the
appliance (‘click’).
3 Switch on the appliance.
4 You can now start trimming.
5 Clean the attachment after use (see chapter
‘Cleaning and maintenance’).
Using the beard styler attachment
1 Make sure the appliance is switched off.
2 Insert the lug of the attachment into the slot
in the top of the appliance.Then press down
the attachment to attach it to the appliance
(‘click’).
Using the beard styler attachment with
comb
You can use the beard styler attachment with the
comb attached to style your beard at one xed
setting, but also at different length settings.You can
use it also to pre-trim any long hairs before shaving
to have a more comfortable shave.
The hair length settings on the beard styler
attachment correspond to the remaining hair length
after cutting and range from 1 to 5mm.
1 Slide the comb straight into the guiding
grooves on both sides of the attachment
(‘click’).
ENGLISH16

2 Press the length selector and then push it
to the left or right to select the desired hair
length setting.
3 Switch on the appliance.
4 You can now start styling your beard by
moving the attachment upwards with
gentle pressure making sure the front of
the comb is in full contact with the skin.
5 Clean the attachment after use (see chapter
‘Cleaning and maintenance’).
Using the beard styler attachment without
comb
You can use the beard styler attachment without the
comb to contour your beard, moustache, sideburns
or neckline to a length of 0.5mm.
1 Pull the comb off the attachment.
Note: Grab the comb in the centre to pull it off the
attachment. Do not pull at the sides of the comb.
2 Switch on the appliance.
3 You can now start contouring your beard,
moustache, sideburns or neckline by moving
the styler downwards with gentle pressure
while holding it perpendicular to the skin.
4 Clean the attachment after use (see chapter
‘Cleaning and maintenance’).
Using the cleansing brush attachment
Use the rotating cleansing brush attachment with
your daily cleansing cream.The cleansing brush
attachment removes oil and dirt, contributing to a
healthy and oil-free skin.
2
1
ENGLISH 17

1 Insert the lug of the attachment into the slot
in the top of the appliance.Then press down
the attachment to attach it to the appliance
(‘click’).
2 Moisten the attachment with water.
Do not use the appliance with a dry brush
head, as this can irritate the skin.
Tip: Use the attachment before shaving for easier
shaving and a more hygienic shaving result.
3 Moisten your face with water and apply a
cleanser to your face.
4 Place the attachment on your right cheek.
5 Switch on the appliance.
6 Gently move the attachment across your skin
from the nose towards the ear. Do not push
the attachment too hard onto the skin to make
sure the treatment remains comfortable.
7 After approx. 20 seconds you can move
the attachment to your left cheek and start
cleansing this part of your face.
Caution: Do not clean the sensitive area around
your eyes.
20 sec.
20 sec.
ENGLISH18

8 After approx. 20 seconds you can move
the attachment to your forehead and start
cleansing this part of your face. Gently move
the attachment from left to right.
Note:We advise you to not overdo the cleansing and to
not cleanse any zone longer than 20 seconds.
9 After the treatment, rinse and dry your face.
Your face is now ready for the next step of
your daily skincare routine.
10 Clean the attachment after use (see chapter
‘Cleaning and maintenance’).
Cleaning and maintenance
Note:The accessories supplied may vary for different
products.The box shows the accessories that have been
supplied with your appliance.
Cleaning the shaver in the SmartClean
system (specic types only)
Do not tilt the SmartClean system to prevent
leakage.
Note: Hold the SmartClean system while you prepare
it for use.
Note: If you clean the shaver in the SmartClean
system once a week, the SmartClean cartridge will last
approximately three months.
20 sec.
ENGLISH 19

Preparing the SmartClean system for use
1 Put the small plug in the back of the
SmartClean system.
2 Put the adapter in the wall socket.
3 Press the button on the side of the SmartClean
system and lift the top part of the SmartClean
system.
4 Pull the seal off the cleaning cartridge.
5 Place the cleaning cartridge in the SmartClean
system.
6 Push the top part of the SmartClean system
back down (‘click’).
Using the SmartClean system
Always make sure to shake excess water off the
shaver before you place it in the SmartClean
system.
1
2
ENGLISH20
