ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HQ9070
05/08
PRODUCT INFORMATION
General
- Rechargeable / Mains
- Automatic voltage selection
- Washable
- One hour charging time
- Green Li-ion battery
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100 - 240 V, 50 / 60 Hz
- Motor voltage : 3.6 V
- Shaving heads : HQ9 (4222 036 11150)
- SAP coding : HQ9070
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- Remove shaving unit, to prevent damages during repairing.
- Remove the two screws Aon the backside of the shaver.
- Remove the two screws Bout of the hairchamber.
- Remove the hairchamber from the body.
- Remove the cover.
- Remove the bridge.
- Disconnect the wires from the motor.
- Remove the driving unit by pushing the motor.
- Disconnect the wiring strip (L.C.D.) from the power
supply.
- Remove the power supply.
REPAIR INSTRUCTION
- No specific issues
OPTIONAL (accessories)
- Car cord : 4222 036 08920
HQ9070
PARTS LIST & EXPLODED VIEW
Li-ion
1
3
4
5
10
11
12
13
9
6
B
B
8
15
2
7
16
17
14
A
A
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
4222 036 11690
4222 036 02770
4222 036 11820
4222 036 11150
4222 036 11710
4222 036 11720
4222 036 11810
4222 036 11830
4222 036 11740
4222 036 11960
4222 036 11970
4222 036 11840
Protecting cap
Cleaning brush
Bracket
Shaving heads
Holder assy
Hairchamber assy
Housing
Driving unit assy
Bridge
Li-ion battery
Spacer
Power supply
Pos Service code Description
13
14
15
16
17
A
B
4222 036 07940
4222 036 11750
4222 036 11760
4222 036 11850
4222 036 06790
4222 036 08930
4222 036 06800
4222 036 04040
4222 036 04020
4822 502 14545
4222 036 11790
4222 036 11860
Contact lip
Trimmer assy
Trimmer knob
Cover assy
Power plug EUR
Power plug JAP
Power plug CAN/TW/VEN
Power plug PRC
Power plug AUS
Screw
Screw hairchamber
Pouch
