Philips Coolskin HS8060 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HS8060
CoolSkin
07/03
PRODUCT INFORMATION
General:
- Rechargeable
- World wide automatic voltage selection
- Washable
- Charge indication
- Battery low indcation
- Battery full indication
- Travel lock
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100 - 240 Volt / 50 - 60 Hz
- Shaving heads : HS85
- Charging time : 1.5 hours
- Shaving time : 40 minutes
- SAP coding : HS8060
DISASSEMBLY- AND RE-ASSEMBLY ADVICE
- Remove shaving unit, to prevent damaging during
repairing.
- Remove the 2 screws on top of the schaver.
- Remove the additive tubes and the IM cap.
REPAIR INSTRUCTION
Cleaning shaving heads
- Turn head clockwise and take off.
- Take cutter out and clean it with the brush.
1
2
- Place cutter back.
- Place head back and fix it by turning the head
anticlockwise.
OPTIONAL (accessories)
- Pouch : 4222 036 14360

HS8060
EXPLODED VIEW & PARTS LIST
8
7
6
13
2
5
11
9
12
10
14
4
1
3
15
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
4222 036 14220
4822 502 14545
4222 036 14210
4222 036 14230
4222 036 14250
4222 036 14280
4222 036 14270
4222 036 14290
4222 036 14320
4222 036 02770
Shaving unit
Screw
Protecting cap
Additive tubes
IM cap assy
V-spring
Z-spring
Additive lever
Stand ME
Brush
Pos Service code Description
11
12
13
14
15
4222 036 14330
4222 036 14340
4222 036 14350
4222 036 14300
4222 036 04080
4222 036 04090
4222 036 04850
4222 036 05110
4222 036 05160
4222 036 14360
Refill & charge stand (Lid)
Refill & charge stand (Backdoor)
Refill & charge stand (Transposer)
Trimmer assy
Power plug U1 EUR
Power plug U1 GBR
Power plug U1 KOR
Power plug U1 CAN/TW
Power plug U1 NOR
Pouch
