Philips SW3700 User manual

SW3700
© & ™ Lucaslm Ltd.
© Disney

9
2
3
4
5
6
10
8
7
1

empty page before TOC

English 6
Français (Canada) 20

English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Please read this user manual, as it contains
information about the features of this shaver as
well as some tips to make shaving easier and more
enjoyable.
General description (Fig. 1)
1 Protective cap
2 Shaving unit
3 Shaving unit release button
4 On/off button
5 Charging light
6 Socket for small plug
7 Trimmer
8 Trimmer release slide switch
9 Supply unit
10 Small plug
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
Danger
- Keep the supply unit dry.
6English

Warning
- To charge the battery, only use the detachable
supply unit (HQ850) provided with the
appliance.
- The supply unit contains a transformer. Do not
cut off the supply unit to replace it with another
plug, as this causes a hazardous situation.
- Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
- Always unplug the shaver before you clean it
under the tap.
- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as
this may cause injury. Always replace a
damaged part with one of the original type.
- Do not open the appliance to replace the
rechargeable battery.
Caution
- Never immerse the cleaning system or the
charging stand in water and do not rinse it
under the tap.
- Never immerse the shaver in water. Do not use
the shaver in the bath or in the shower.
- Never use water hotter than 60°C to rinse the
shaver.
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only
be used by one person.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
7
English

- If your shaver comes with a cleaning system,
always use the original Philips cleaning fluid
(cartridge or bottle, depending on the type of
cleaning system).
- Always place the cleaning system on a stable,
level and horizontal surface to prevent leakage.
- If your cleaning system uses a cleaning
cartridge, always make sure the cartridge
compartment is closed before you use the
cleaning system to clean or charge the shaver.
- When the cleaning system is ready for use, do
not move it to prevent leakage of cleaning fluid.
- Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the
shaver.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
Electromagnetic fields (EMF)
- This Philips appliance complies with all
applicable standards and regulations regarding
exposure to electromagnetic fields.
General
- This shaver can be safely cleaned under the
tap.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
Charging
Charge the shaver before you use it for the first
time and when the display indicates that the
battery is almost empty.
8English

Charging takes approx. 8 hours. A fully charged
shaver has a shaving time of up to 40 minutes.
Note: You cannot use the shaver while it is
charging.
Note: Depending on your shaving/styling behavior
and beard type, the operating time may vary over
time.
Charging with the supply unit
1Make sure the shaver is switched off.
2Put the small plug in the shaver and put the
supply unit in the wall socket.
- The charging light on the shaver indicates the
charging status (see 'Charge indications').
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
shaver.
Charge indications
Battery low
=
When the battery is almost empty, the charging
light starts to flash red.
When you switch off the shaver, the charging light
continues to flash red for a few seconds.
Charging
When the shaver is charging, the charging light
flashes green.
9
English

Battery fully charged
When the battery is fully charged, the charging
light lights up green continuously.
Note: After approx. 30 minutes, the charging light
goes out to save energy.
Using the shaver
Always check the shaver and all accessories
before using. Do not use the shaver or any
accessory if it is damaged, as this may cause
injury. Always replace a damaged part with one of
the original type.
This symbol indicates that the product can be
rinsed under running tap water.
- Use this shaver for its intended household use
as described in this manual.
- For hygienic reasons, the shaver should only be
used by one person.
- Trimming is easier when the skin and hair are
dry.
Note: This shaver can only be used without a cord.
Skin adaptation period
Your first shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week) and
exclusively with this appliance for a period of 3
weeks.
For the best results on skin comfort, pre-trim your
beard if you have not shaved for 3 days or longer.
10 English

Start-up sequence
When you press the on/off button for the very first
time, the charging light flashes in an irregular
pattern.
Charge the shaver before use.
Switching the shaver on and off
1To switch the shaver on or off, press the on/off
button once.
Dry shaving
1Switch the shaver on.
2Move the shaving heads over your skin in both
straight and circular movements to catch all
hairs growing in different directions. Exert
gentle pressure for a close comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
3Switch off and clean the shaver after each use.
4Put the protective cap on the shaver to protect
shaving heads.
Using the trimmer
You can use the trimmer to groom your sideburns
and moustache.
11
English

1Push the trimmer release slide switch
downwards to open the trimmer.
2Switch the shaver on.
3Hold the trimmer perpendicular to the skin and
move it downwards while exerting gentle
pressure.
4Switch off and clean the trimmer after each use.
5Close the trimmer (‘click’).
Cleaning and maintenance
- Regular cleaning guarantees better shaving
results.
- Never clean, remove or replace the shaving unit
while the shaver is switched on.
- Do not apply pressure to shaving head combs.
- Do not touch shaving heads with hard objects
as this may dent or damage the precision-made
slotted combs.
- Do not use abrasives, scourers or aggressive
liquids such as gasoline or acetone to clean the
shaver.
Cleaning the shaver under the tap
Clean the shaver after every shave for optimal
shaving performance.
12 English

Always check if the water is too hot, to prevent
burning your hands.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
While rinsing shaving heads, water may drip out
of the base of shaver. This is a normal occurrence.
1Switch the shaver off.
2Rinse the shaving unit under a warm tap.
3Press the unit release button to open the
shaving unit.
4Rinse the shaving unit and hair chamber under
a warm tap.
5Carefully shake off excess water and let the
shaver air dry.
6Close the shaving unit.
Cleaning the trimmer
Never dry the trimmer with a towel or tissue, as
this may damage the trimming teeth.
Clean the trimmer after each use.
1Switch the shaver off.
2Push the trimmer release slide switch down to
open the trimmer.
13
English

3Switch the shaver on and rinse the trimmer
under the tap.
4Switch the shaver off after cleaning.
5Carefully shake off excess water and let the
trimmer air dry.
6Close the trimmer (‘click’).
Tip: For optimal performance, lubricate the
teeth of the attachment with a drop of sewing
machine oil regularly.
Replacement
Replacing the shaving heads
For maximum shaving performance, we advise you
to replace the shaving heads every two years.
Replace damaged shaving heads immediately.
Always replace the shaving heads with original
Philips shaving heads.
1Switch the shaver off and disconnect it from the
wall socket.
2Press the shaving unit release button to open
the shaving unit. Pull the shaving unit off the
shaver.
2
1
3Turn the lock anticlockwise and remove the
retaining frame. Place it aside in a safe place.
14 English

4Remove the shaving heads from the shaving
unit.
Discard the used shaving heads immediately to
avoid mixing them with the new shaving heads.
5Place new shaving heads in the shaving unit.
Note: Make sure the notches on both sides of
the shaving heads fit exactly onto the
projections in the shaving head holder.
1
2
6Put the retaining frame back into the shaving
unit and turn the lock clockwise.
7Insert the lug of the shaving unit into the slot in
the top of the shaver. Then close the shaving
unit.
Note:If the shaving unit does not close
smoothly, check if you have inserted the
shaving heads properly and if the retaining
frame is locked.
Storage
Put the protective cap on the shaver to prevent
damage.
Note: Always let the shaver dry completely before
storing.
15
English

Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your
Philips dealer. You can also contact the Philips
Consumer Care Center in your country (see the
international warranty leaflet for contact details).
The following accessories and spare parts are
available:
- SH30 Philips Shaving Heads.
- HQ110 Philips shaving head cleaning spray
Disposal
- This product contains a rechargeable lithium-
ion battery which must be disposed of properly.
- Contact your local town or city officials for
battery disposal information. You can also call
888-224-9764 or visit www.call2recycle.ca for
battery drop-off locations.
- For assistance, visit our website
www.philips.com/support or call
1-800-243-3050 toll free.
- Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused. For recycling
information, please contact your local waste
management facilities or visit
www.recycle.philips.com.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the shaver. Before you remove
the battery, make sure that the shaver is
disconnected from the wall socket and that
the battery is completely empty
Take any necessary safety precautions
when you handle tools to open the shaver
16 English

and when you dispose of the rechargeable
battery.
1Check if there are screws in the back of the
shaver or in the hair chamber. If so, remove
them.
2Remove the outer panels of the shaver with a
screwdriver or other tool. If necessary, also
remove additional screws and/or parts until you
see the printed circuit board with the
rechargeable battery.
3Remove the rechargeable battery.
Warranty and support
If you need information or support, please
www.philips.com/support or call toll free:
1-866-800-9311. To locate the nearest Philips
warranty depot, visit our website www.philips.com.
Guarantee restrictions
- Philips Consumer Lifestyle warrants its products
for a period of two years after the date of
purchase. If any defect due to faulty materials
and workmanship occurs within this two-year
warranty period, Philips Consumer Lifestyle will
repair or replace the product at its expense.
- Philips Consumer Lifestyle will only pay for
repair or replacement if convincing proof is
provided, for instance by means of a receipt,
that the day on which service is claimed is
within the guarantee period. Parts that are
subject to wear (such as cutting units and
shaving heads) are not covered by the terms of
the international guarantee.
17
English

- The guarantee is not valid if a defect is due to
damage caused by incorrect use, poor
maintenance (e.g. parts blocked by scale) or if
alterations or repairs have been carried out by
persons not authorized by Philips Consumer
Lifestyle.
- For the appliance to be used correctly, the user
should strictly adhere to all instructions
included in the user manual and should abstain
from any actions or uses that are described as
undesired or which are warned against in the
user manual.
- These warranty restrictions do not affect your
statutory rights.
Troubleshooting
This chapter summarizes the most common
problems you could encounter with the appliance.
If you are unable to solve the problem with the
information below, visit www.philips.com/support
for a list of frequently asked questions or contact
the Consumer Care Center in your country.
Problem Possible cause Solution
Theappliancedo
es not shave as
well as it used to.
The shaving heads
are damaged or
worn.
Replace the shaving heads.
Long hairs obstruct
the shaving heads. Clean the shaving heads one by one.
You have not
inserted the
shaving heads
properly.
Make sure that the
projections of the shaving
heads fit exactly into the
recesses.
The appliance
does not work
when I press the
on/off button.
The rechargeable
battery is empty. Recharge the battery.
18 English

Problem Possible cause Solution
The temperature of
the appliance is too
high. In this case,
the appliance does
not work.
As soon as the
temperature of the
appliance has dropped
sufficiently, you can switch
on the appliance again.
19
English

Français (Canada)
Introduction
Félicitations pour votre achat et bienvenue dans
l'univers Philips! Pour profiter pleinement des
avantages de l'assistance Philips, enregistrez votre
produit à l'adresse www.philips.com/welcome.
Veuillez lire ce mode d'emploi, qui contient des
informations sur les fonctionnalités de ce
rasoir,ainsi que des conseils pour un rasage plus
facile et plus agréable.
Description générale (fig. 1)
1 Couvercle de protection
2 Unité de rasage
3 Bouton de libération de l’unité de rasage
4 Bouton marche/arrêt
5 Témoin de charge
6 Prise pour petite fiche
7 Tondeuse
8 Glissière de libération de la tondeuse
9 Bloc d’alimentation
10 Petite fiche
Renseignements importants sur la sécurité
Lisez attentivement ces informations importantes
avant d'utiliser l'appareil et ses accessoires et
conservez-les pour un usage ultérieur. Les
accessoires fournis peuvent varier selon les
différents produits.
Danger
- Gardez le bloc d’alimentation au sec.
20 Français (Canada)
