Philips SW7700/67 User manual

SW7700
© & ™ Lucaslm Ltd.
© Disney

1
2
812
11
9
10
3
4
6
5
7

empty page before TOC

English 6
简体中文 25

English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Please read this user manual, as it contains
information about the features of this shaver as
well as some tips to make shaving easier and more
enjoyable.
General description (Fig. 1)
1 Shaving unit with hair chamber
2 On/off button
3 Replacement reminder
4 Cleaning reminder
5 Travel lock symbol
6 Unplug for use symbol
7 Battery status indicator
8 Socket for small plug
9 Click-on precision trimmer attachment
10 Supply unit
11 Small plug
12 Pouch
Important safety information
Read this important information carefully before
you use the appliance and its accessories and
save it for future reference. The accessories
supplied may vary for different products.
6English

Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
appliance.
- The supply unit contains a transformer. Do not
cut off the supply unit to replace it with another
plug, as this causes a hazardous situation.
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
- Always unplug the shaver before you clean it
under the tap.
- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as
this may cause injury. Always replace a
damaged part with one of the original type.
- Do not open the appliance to replace the
rechargeable battery.
7
English

Caution
- Never immerse the cleaning system or the
charging stand in water and do not rinse it
under the tap.
- Never use water hotter than 60°C to rinse the
shaver.
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only
be used by one person.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
- If your shaver comes with a cleaning system,
always use the original Philips cleaning fluid
(cartridge or bottle, depending on the type of
cleaning system).
- Always place the cleaning system on a stable,
level and horizontal surface to prevent leakage.
- If your cleaning system uses a cleaning
cartridge, always make sure the cartridge
compartment is closed before you use the
cleaning system to clean or charge the shaver.
- When the cleaning system is ready for use, do
not move it to prevent leakage of cleaning fluid.
- Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the
shaver.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
8English

Electromagnetic fields (EMF)
- This Philips appliance complies with all
applicable standards and regulations regarding
exposure to electromagnetic fields.
General
- This shaver is waterproof. It is suitable for use in
the bath or shower and for cleaning under the
tap. For safety reasons, the shaver can
therefore only be used without cord.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The display
Start-up sequence
When you press the on/off button for the very first
time, all display indications light up in sequence.
Charge the shaver before use.
Charging
Quick charge: When the battery is empty and you
connect the shaver to a wall socket, the lights of
the battery status indicator light up white one after
the other repeatedly. When the battery contains
enough energy for one shave, the bottom light of
the battery status indicator starts flashing white
slowly.
9
English

While the shaver continues to charge, first the
bottom light of the battery status indicator flashes
white and then lights up white continuously. Then
the second light flashes and lights up
continuously, and so on until the shaver is fully
charged.
Battery fully charged
Note: This shaver can only be used without a cord.
When the battery is fully charged, all lights of the
the battery status indicator light up white
continuously.
Note: When you press the on/off button during or
after charging, the 'unplug for use' symbol lights up
to indicate that the shaver is still connected to the
wall socket.
Note: When the battery is full, the display switches
off automatically after 30 minutes.
Battery low
When the battery is almost empty, the bottom light
of the battery status indicator flashes orange.
Remaining battery charge
The remaining battery charge is shown by the
lights of the battery charge indicator that light up
continuously.
10 English

’Unplug for use’ reminder
The ‘unplug for use’ symbol flashes to remind you
that you have to disconnect the shaver from the
wall socket before you can switch it on.
Cleaning reminder
Clean the shaver after every shave for optimal
performance (see 'Cleaning and maintenance').
When you switch off the shaver, the cleaning
reminder flashes to remind you to clean the
shaver.
Travel lock
You can lock the shaver when you are going to
travel. The travel lock prevents the shaver from
being switched on by accident (see 'Activating the
travel lock').
Replacement reminder
For maximum shaving performance, replace the
shaving heads every two years. The shaver is
equipped with a replacement reminder which
reminds you to replace the shaving heads. The
replacement reminder flashes to indicate that you
have to replace the shaving heads (see 'Replacing
the shaving heads').
Note: After replacing the shaving heads, you need
to reset the replacement reminder by pressing the
on/off button for 7 seconds.
11
English

Charging
Charge the shaver before you use it for the first
time and when the display indicates that the
battery is almost empty.
Charging takes approx. 1 hour. A fully charged
shaver has a shaving time of up to 60 minutes.
Note: You cannot use the shaver while it is
charging.
Charging with the supply unit
1Make sure the shaver is switched off.
2Put the small plug in the shaver and put the
supply unit in the wall socket.
The display of the shaver indicates that the
shaver is charging.
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
shaver.
Using the shaver
Always check the shaver and all accessories
before using. Do not use the shaver or any
accessory if it is damaged, as this may cause
injury. Always replace a damaged part with one
of the original type.
This symbol indicates that the shaver can be used
in the bath or shower.
- Use this shaver for its intended household use
as described in this manual.
- For hygienic reasons, the shaver should only be
used by one person.
- Trimming is easier when the skin and hair are
dry.
Note: This shaver can only be used without a cord.
12 English

Switching the shaver on and off
1To switch the shaver on or off, press the on/off
button once.
The replacement symbol lights up continuously
when the shaver is switched on.
Shaving
Skin adaptation period
Your first shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week)
and exclusively with this appliance for a period of
3 weeks.
For the best results on skin comfort, pre-trim your
beard if you have not shaved for 3 days or longer.
Dry shaving
1Switch the shaver on.
2Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Exert gentle pressure for a
close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
3Switch off and clean the shaver after each use.
13
English

The display lights up for a few seconds to show
the battery status.
Wet shaving
For a more comfortable shave, you can also use
this shaver on a wet face with shaving foam or
shaving gel.
1Apply some water to your skin.
2Apply shaving foam or shaving gel to your skin.
3Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4Switch the shaver on.
5Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Exert gentle pressure for a
close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.
6Dry your face.
14 English

7Switch off the shaver and clean it after each
use.
Note: Make sure that you rinse all foam or shaving
gel off the shaver.
Using the click-on attachment
Removing or attaching the click-on attachment
1Make sure the shaver is switched off.
2Pull the attachment straight off the shaver.
Note: Do not twist the attachment while you
pull it off the shaver.
3Insert the lug of the attachment into the slot in
the top of the shaver. Then press down the
attachment to attach it to the shaver (‘click’).
Using the precision trimmer attachment
You can use the precision trimmer to groom your
beard, sideburns and moustache.
1Attach the trimmer to the shaver ('click').
2Switch on the shaver.
15
English

3Hold the trimmer perpendicular to the skin and
move it downwards while exerting gentle
pressure.
4Switch off and clean the trimmer after use.
Travel lock
You can lock the shaver when you are going to
travel. The travel lock prevents the shaver from
being switched on by accident.
Activating the travel lock
3 sec.
1Press the on/off button for 3 seconds to enter
the travel lock mode.
While you activate the travel lock, the
indications on the display light up briefly. When
the travel lock is activated, the travel lock
symbol flashes.
Deactivating the travel lock
1Press the on/off button for 3 seconds.
While you deactivate the travel lock, the
indications on the display light up briefly. When
the travel lock is deactivated, the travel lock
symbol flashes and goes out. The shaver
switches on and is now ready for use again.
Note: The shaver unlocks automatically when it is
connected to wall socket.
16 English

Cleaning and maintenance
- Regular cleaning guarantees better shaving
results.
- Never clean, remove or replace the shaving unit
while the shaver is switched on.
- Do not apply pressure to shaving head combs.
- Do not touch shaving heads with hard objects
as this may dent or damage the precision-made
slotted combs.
- Do not use abrasives, scourers or aggressive
liquids such as gasoline or acetone to clean the
shaver.
Cleaning the shaver under the tap
Clean the shaver after every shave for optimal
performance.
Always check if the water is too hot, to prevent
burning your hands.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
While rinsing shaving unit, water may drip out of
the base of shaver. This is a normal occurrence.
1Switch the shaver on.
2Rinse the shaving unit under a warm tap.
3Switch off the shaver. Pull the shaving head
holder off the bottom part of the shaving unit.
17
English

4Rinse the hair chamber under the tap.
5Rinse the shaving head holder under a warm
tap.
6Carefully shake off excess water and let the
shaving head holder air dry completely.
7Attach the shaving head holder to the bottom
part of the shaving unit (‘click’).
Cleaning the precision trimmer attachment
Never dry the trimmer with a towel or tissue, as
this may damage the trimming teeth.
Clean the trimmer after each use.
1Switch the shaver on.
2Rinse the trimmer under a warm tap.
3After cleaning, switch off the shaver.
4Carefully shake off excess water and let the
attachment air dry completely.
Tip: For optimal performance, lubricate the
teeth of the attachment with a drop of sewing
machine oil regularly.
18 English

Replacement
Replacing the shaving heads
2yrs
For maximum shaving performance, we advise you
to replace the shaving heads every two years.
Replace damaged shaving heads immediately.
Always replace the shaving heads with original
Philips shaving heads.
Replacement reminder
The replacement reminder indicates that the
shaving heads need to be replaced.The
replacement reminder flashes when you switch
the shaver off.
1Switch the shaver off.
2Pull the shaving head holder off the bottom
part of the shaving unit.
1
2
3Turn the retaining ring anticlockwise and lift it
off the shaving head.
Repeat this process for the other retaining rings.
Place them aside in a safe place.
4Remove the shaving heads from the shaving
head holder.
Discard the used shaving heads immediately to
avoid mixing them with the new shaving heads.
19
English

5Place the new shaving heads in the shaving
head holder.
Note: Make sure the notches on both sides of
the shaving heads fit exactly onto the
projections in the shaving head holder.
2
1
6Place the retaining ring on the shaving head
and turn it clockwise to reattach the retaining
ring. Repeat this process for the other retaining
rings.
- Each retaining ring has two recesses that fit
exactly around the projections of the shaving
head holder. Turn the ring clockwise until you
hear a click to indicate that the ring is fixed.
1
Note: Hold the shaving head holder in your
hand when you reinsert the shaving heads and
reattach the retaining rings. Do not place the
shaving head holder on a surface, as this may
cause damage to the shaving heads.
7Attach the shaving head holder to the bottom
part of the shaving unit (‘click’).
20 English
