Philips S5000 series User manual

www.philips.com/support/ifu
S5000 series

3
1
2
4
5
6
7
8 9
11 12
13 14 15
17 18 19 20 21
10
16

English
Contents
Introduction_______________________________________________________ 6
General description_______________________________________________ 7
What do the icons on my appliance handle mean?_____________ 8
What does the icon on my Quick Clean Pod mean?_____________ 9
How do I charge my appliance?__________________________________ 9
Charging with the supply unit____________________________________ 10
Charging in the charging stand (specific models only)__________ 10
'Unplug for use' symbol __________________________________________ 11
How do I use my appliance and the attachments?______________ 11
Shaving____________________________________________________________ 12
How do I clean my appliance and the attachments?____________ 18
Cleaning the shaver under the tap_______________________________ 18
Thorough cleaning________________________________________________ 19
Cleaning the pop-up trimmer____________________________________ 20
Cleaning the click-on attachments_______________________________ 21
How do I use the Quick Clean Pod?______________________________ 22
Preparing the Quick Clean Pod for use__________________________ 22
Using the Quick Clean Pod_______________________________________ 23
Replacing the Quick Clean Pod Cartridge_______________________ 24
How do I replace the shaving heads?____________________________ 25
Replacing the shaving heads_____________________________________ 25
Support___________________________________________________________ 27
Ordering accessories_____________________________________________ 27
Troubleshooting__________________________________________________ 28
Shaver_____________________________________________________________ 28
Philips Quick Clean Pod__________________________________________ 29
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome or via the app.
6English

General description
1 Pop-up trimmer
2 Trimmer release slide
3 Shaving unit
4 Shaving unit release button
5 On/off button
6 Handle
7 Socket for small plug
8 Charging stand
9 Supply unit
10 Small plug
11 Protection cap
12 Pouch
13 Philips Quick Clean Pod cartridge
14 Quick Clean Pod
15 Cleaning brush
16 Length settings
17 Click-on beard styler attachment
18 Comb for beard styler attachment
19 Attachment holder
20 Click-on cleansing brush attachment
21 Click-on nose trimmer attachment
Note: The accessories supplied may vary for
different products. The box shows the accessories
that have been supplied with your appliance.
7
English

What do the icons on my appliance handle
mean?
Icon Behavior Meaning
Flashing
slowly when
you remove
the shaver
from the
Quick Clean
Pod during
the cleaning
programa
The cleaning program was interrupted. If
you put the shaver back into the Quick
Clean Pod within four seconds, the
cleaning program resumes automatically.
Flashing Clean the shaver in the Quick Clean Pod
(see 'How do I use the Quick Clean
Pod?'). Clean the attachments under the
tap (see 'How do I clean my appliance
and the attachments?').
Lights up
continuously The cleaning program is in progress.
Flashing
quickly when
you remove
the shaver
from the
Quick Clean
Pod or press
the on/off
button
during the
cleaning
program
The cleaning program was stopped. If
you wish to continue, you need to restart
the cleaning cycle by putting the shaver
into the Quick Clean Pod and pressing
the on/off button.
Flashing
when you
press the
on/off
button
The travel lock is activated (see 'Storage
and travel').
8English

Icon Behavior Meaning
Lights up
when you
pick up the
appliance
The number of bars lit up show the
remaining battery charge.
Bottom light
flashing
orange
The battery is almost empty (see 'How do
I charge my appliance?').
Lights
flashing in
sequence
The appliance is charging.
Lights up
continuously The appliance is fully charged.
Flashing The appliance must be disconnected
from the wall socket before you can
switch it on (see 'How do I charge my
appliance?').
What does the icon on my Quick Clean Pod
mean?
Icon Behavior Meaning
Becomes visible on the
Quick Clean Pod The Quick Clean Pod Cartridge needs to be replaced (see
'How do I use the Quick Clean
Pod?').
How do I charge my appliance?
Charge the appliance before you use it for the first
time and when the bottom light of the battery
status indicator flashes orange, indicating that the
battery is almost empty.
Charging takes approx. 1 hour.
9
English

Quick Charge: After approx. 5 minutes of charging,
the battery contains enough energy for one shave.
When the appliance is fully charged it has a
cordless operating time of up to 60 minutes.
Note: You cannot use the appliance while it is
charging.
Charging with the supply unit
1Make sure that the appliance is switched off.
2Insert the small plug into the appliance and put
the supply unit in the wall socket.
-While the appliance is in quick charge mode,
the lights of the battery status indicator light
up one after the other. After approximately 5
minutes, the bottom light of the battery
status indicator flashes. The battery now
contains enough energy for one shave.
-While the appliance charges, first the bottom
light of the battery status indicator flashes
and then lights up continuously. Next the
second light flashes and then lights up
continuously, and so on until the appliance
is fully charged.
-When the appliance is fully charged, all three
battery indicator lights light up continuously.
After approx. 30 minutes, the light goes out
automatically.
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Charging in the charging stand (specific models only)
1Make sure the appliance is switched off.
10 English

2Put the small plug in the charging stand and put
the supply unit in the wall socket.
3Place the appliance in the charging stand.
Specific models only: The light ring on the
bottom of the charging stand lights up and
rotates quickly.
-After approximately 5 minutes, the light ring
rotates slower. The battery now contains
enough energy for one shave.
-As the appliance continues to charge, the
light ring becomes brighter and rotates
slower.
-When the appliance is fully charged, the light
ring lights up fully and stops rotating.
4After charging, remove the supply unit from the
wall socket and pull the small plug out of the
charging stand.
'Unplug for use' symbol
The 'unplug for use' symbol flashes to remind you
to disconnect the appliance from the wall socket
and remove the small plug from the appliance
before you switch it on.
How do I use my appliance and the
attachments?
Warning: Always check the appliance and
all accessories before use. Do not use the
appliance or any accessory if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.
Note: This appliance is waterproof. It is suitable for
use in the bath or shower and for cleaning under
11
English

the tap. For safety reasons, the appliance can
therefore only be used without cord.
Shaving
You can use this appliance either wet or dry, or
even under the shower. For a wet shave, apply
some water and shaving foam or gel to your skin
and rinse the shaving heads under the tap with
warm water before following the steps below.
1Switch on the appliance.
2Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable shave.
Note: Do not press too hard, as this can cause
skin irritation.
Note: If you are shaving with gel or foam, rinse
the shaving unit regularly during your shave to
ensure that it continues to glide smoothly over
your skin.
3Use the narrow sides of the shaving unit to
shave in hard-to-reach areas such as along
your jawline and under your nose.
4Switch off and clean the appliance after each
use.
12 English

Note: Make sure you rinse all foam or shaving
gel off the appliance.
Skin adaptation period
Your first shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week) and
exclusively with this appliance for a period of 3
weeks.
Cleaning reminder
When you switch off the appliance, the cleaning
reminder flashes to remind you to clean the
appliance.
- Clean the appliance and attachments after
each use to prevent clogging and damage (see
'How do I clean my appliance and the
attachments?').
- Clean the shaving heads thoroughly once a
month or when the appliance does not shave
as well as it used to (see 'Thorough cleaning').
Trimming
You can use the trimmer to groom your sideburns
and moustache.
1Push the trimmer release slide downwards to
open the trimmer.
2Switch on the appliance.
13
English

3Hold the trimmer perpendicular to the skin and
move the appliance downwards while you exert
gentle pressure.
4You can also use the trimmer under your nose.
5Switch off the appliance and clean the trimmer
after each use to prevent clogging and damage
(see 'How do I clean my appliance and the
attachments?').
6Close the trimmer.
Using the click-on attachments
Note: The accessories supplied may vary for
different products. The box shows the accessories
that have been supplied with your product.
Using the beard styler attachment with comb
You can use the beard styler attachment with the
comb attached to style your beard at one fixed
setting or at different length settings. You can also
use it to pre-trim any long hairs before shaving for
a more comfortable shave.
The hair length settings on the beard styler
attachment correspond to the remaining hair
length after cutting and range from 1 to 5mm.
1Twist the shaving head or other attachment to
remove it from the handle and press the beard
styler attachment onto the handle.
14 English

2Slide the comb straight into the guiding grooves
on both sides of the beard styler attachment.
3Press the length selector and then push it to
the left or right to select the desired hair length
setting.
4Switch on the appliance.
5Move the appliance upwards while you exert
gentle pressure. Make sure the front of the
comb is in full contact with the skin.
6Switch off the appliance and clean the
attachment after use.
Using the beard styler attachment without comb
You can use the beard styler attachment without
the comb to contour your beard, moustache,
sideburns or neckline to a length of 0.5mm.
You can use the beard styler attachment with the
comb attached to style your beard at one fixed
setting or at different length settings. You can also
use it to pre-trim any long hairs before shaving for
a more comfortable shave.
1Pull the comb off the beard styler attachment.
Note: Grab the comb in the center to pull it off
the beard styler attachment. Do not pull at the
sides of the comb.
2Switch on the appliance.
15
English

3Hold the beard styler attachment perpendicular
to the skin and move the appliance downwards
while you exert gentle pressure.
4Switch off the appliance and clean the
attachment after use.
Using the nose/ear trimmer attachment
You can use the nose/ear trimmer attachment to
trim your nose and/or ear hair.
Trimming nose hair
Make sure both the nose/ear trimmer attachment
and nasal passages are clean before trimming.
1Twist the shaving head or other attachment to
remove it from the handle and press the
nose/ear hair trimmer onto the handle.
2Switch on the appliance.
3Carefully insert the trimming head into one of
your nostrils.
Do not insert the attachment more than 0.5cm
into your nostrils.
4Slowly move the trimming head around inside
each nostril, making sure the side of the tip is
held firmly against the skin. This reduces the
tickling effect that can occur.
5Switch off the appliance and clean the
attachment after use.
Dried nasal mucus can block the cutting element,
preventing the appliance from switching on. If the
cutting element is blocked, clean the attachment
(see 'How do I clean my appliance and the
attachments?').
Trimming ear hair
Make sure your outer ear channels are clean and
free from wax.
1Switch on the appliance.
16 English

2Slowly move the trimming head along the rim of
the ear to remove hairs that stick out beyond
the rim.
3Carefully insert the trimming head into the
outer ear channel.
Do not insert the trimming head more than
0.5cm into your ear channel, as this could
damage the eardrum.
4Slowly turn the trimming head around to
remove all unwanted hairs from your outer ear
channel.
5Switch off the appliance and clean the
attachment after use.
Storage and travel
Note: We advise you to let the appliance and its
attachments dry before you store them for the
next use.
- Put the protection cap (if supplied) on the
shaver to protect it from dirt accumulation.
- Store the appliance in the pouch (if supplied).
- Alternatively, store the appliance on the
charging stand (if supplied) or in the Philips
Quick Clean Pod (if supplied).
Travel lock
You can lock the shaver when you are going to
travel to prevent it from switching on accidentally.
3 sec.
Press the on/off button for 3 seconds to use the
travel lock mode.
When the travel lock is activated, the travel lock
symbol flashes.
Press the on/off button for 3 seconds.
17
English

Once the travel lock is deactivated, the appliance
switches on automatically.
Note: The shaver unlocks automatically when it is
connected to a wall socket.
How do I clean my appliance and the
attachments?
Clean the appliance and the attachments after
each use for optimal performance.
Cleaning the shaver under the tap
Clean the shaver after each use to prevent
clogging and damage.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
While rinsing the shaving unit, water may drip out
of the base of the shaver. This is a normal
occurrence.
1Switch on the shaver.
2Rinse the shaving unit under a warm tap.
3Switch off the shaver. Press the release button
to open the shaving unit.
18 English

4Rinse the hair chamber under a warm tap.
5Rinse the shaving head holder under a warm
tap.
6Carefully shake off excess water and let the
shaving head holder air-dry completely.
7Close the shaving unit.
Thorough cleaning
We advise you to clean the shaving heads
thoroughly once a month or when the shaver does
not shave as well as it used to.
1Make sure that the appliance is switched off
and disconnected from the wall socket.
2Press the release buttons on the shaving unit
and pull the shaving head holder off the
shaving unit.
19
English

3Rinse the hair chamber and shaving head
holder under the tap.
4Remove the shaving heads. For detailed
instructions, see 'How do I replace the shaving
heads?.'
Note: Do not clean more than one cutter and
guard at a time, since they are all matching sets.
If you accidentally put a cutter in the wrong
shaving guard, it may take several weeks before
optimal shaving performance is restored.
5Clean the cutter and guard under the tap.
6Shake off excess water.
7Put the shaving heads back into the shaving
unit. For detailed instructions, see 'How do I
replace the shaving heads?.'
8Insert the hinge of the shaving head holder into
the slot in the top of the shaving unit and close
the shaving unit.
Cleaning the pop-up trimmer
Clean the trimmer after each use to prevent
clogging and damage.
Never dry the trimmer teeth with a towel or
tissue, as this may damage the trimmer teeth.
1Make sure that the appliance is switched off
and disconnected from the wall socket.
2Push the trimmer release slide down to open
the pop-up trimmer.
20 English

3Switch on the appliance and rinse the pop-up
trimmer with warm water.
4After cleaning, switch off the appliance.
5Carefully shake off excess water and let the
pop-up trimmer air dry.
6Close the trimmer.
Tip: For optimal performance, lubricate the teeth
of the pop-up trimmer with a drop of mineral oil
every six months (oil not included).
Cleaning the click-on attachments
Never dry the trimmer or beard styler attachments
with a towel or tissue, as this may damage the
trimming teeth.
The accessories supplied may vary for different
products. The box shows the accessories that have
been supplied with your product.
Clean the click-on attachments after each use for
optimal performance.
1Make sure that the appliance is switched off.
2Twist the attachment to remove it from the
handle.
Pull the cleansing brush head straight off of the
attachment holder.
3Clean the parts thoroughly with warm water.
Use soap only on the cleansing brush
attachment.
Tip: If rinsing the nose/ear trimmer attachment
under the tap is not sufficient, press the
attachment onto handle and immerse the
trimming head in a glass with warm water for a
few minutes. Then switch on the appliance and
rinse it under the tap.
21
English

4Carefully shake off excess water from the beard
styler, combs and nose/ear trimmer
attachments and let them air dry completely.
Dry the cleansing brush attachment with a
towel.
Never dry the cutting unit with a towel or
tissue, as this may damage the trimming teeth.
Tip: For optimal performance, lubricate the
teeth of the beard styler attachment with a
drop of sewing machine oil regularly.
How do I use the Quick Clean Pod?
Preparing the Quick Clean Pod for use
1Twist and remove the top of the Quick Clean
Pod.
2
1
2Twist the lid off of the Quick Clean Pod
Cartridge.
3Lift the tab on the seal and pull it by the corner
to remove the seal from the Quick Clean Pod
Cartridge.
22 English

4Press the small circular piece on the handle of
the Quick Clean Pod Cartridge to break the
snap hook on the handle.
5Place the Quick Clean Pod Cartridge into the
Quick Clean Pod.
6Put the top of the Quick Clean Pod back onto
the base and turn it clockwise until you hear a
click.
Do not tilt the Quick Clean Pod to prevent
leakage.
Using the Quick Clean Pod
Note: If you use the shaver with shaving foam,
shaving gel or pre-shave products, thoroughly
rinse the shaving heads before you use the Quick
Clean Pod (see 'How do I clean my appliance and
the attachments?').
23
English
