ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HQ8255
09/03
PRODUCT INFORMATION
General:
- Rechargeable
- World-wide automatic voltage selection
- Electronic on/off switch
- Washable
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100 - 240 Volt / 50 - 60 Hz
- Motor voltage : 1,2 Volt
- Shaving heads : HQ9 - 4222 036 15880
- SAP coding : HQ8255
DISASSEMBLY- AND RE-ASSEMBLY ADVICE
Disassembly:
- Remove shaving unit, to prevent damaging during repairing
- Remove the 2 screws Aout of the hairchamber
- Remove the hairchamber from the body
- Remove the 2 screws Bon the backside of the shaver
- Remove the cover
- Remove the side grips
- Remove the housing by bending the hooks with a
srcewdriver
- Take out the basic body
REPAIR INSTRUCTION
- No specific issues
OPTIONAL (accessories)
- Pouch soft 4222 036 16260
- Basic stand 4222 036 16270
- Power plug straight
Europa 4222 036 04080
Aus/Nz 4222 036 05120
GBR 4222 036 04090
Can/TW 4222 036 05110
MEX 4222 036 03810
KOR 4222 036 04850
JAP 4222 036 03870
PRC 4222 036 10320
ARG 4222 036 03760

HQ8255
EXPLODED VIEW & PARTS LIST
B
3
8
11
B
13
14
12
15
2
4
5
9
6
7
10
A
A
1
Pos Service code Description
1
2
3
4
5
6
7
8
4222 036 15400
4222 036 15410
see optional
4222 036 15880
4222 036 15430
4222 036 15450
4222 036 15650
4222 036 15570
Protecting cap
Bracket assy
Power plug
Shaving head HQ9
Holder assy
Hair chamber
Basic body
Front grip panel
Pos Service code Description
9
10
11
12
13
14
15
4222 036 15580
4222 036 16820
4222 036 15760
4222 036 02770
4222 036 15710
4222 036 15730
4222 036 16830
4222 036 14450
On/off knob
Housing assy
Bottom ring
Brush
Trimmer assy
Side grip left / right
Back shell assy
Screw
