Philips HP6583 User manual
HP6583
HP6581
10 12
17
11
4
5
18
19
6 8
9
7
3
22
23
25
2
1
14
15
16
24
20
21
13
3
4
Introduction
Congratulations on your purchase and welcome to Philips!
www.philips.com/welcome.
Important
Read this important information carefully before you
use the appliance and its accessories and save it for
future reference.The accessories supplied may vary
for different products.
Danger
- Keep the adapter dry.
-
do not use an extension cord.
Warning
- The adapter contains a transformer. Do not cut
as this causes a hazardous situation.
- This appliance can be used by children aged from
8 years and above and persons with reduced
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
- Always unplug the appliance before you clean it
under the tap.
- Do not insert metal-containing material into the
-
may cause injury. Always replace a damaged part
with one of the original type.
Caution
- Never use water hotter than 40°C to rinse the
appliance. It is strongly recommended to rinse the
appliance with cold water to prevent bacterial
growth.
ENGLISH
- Only use this appliance for its intended purpose as
shown in the user manual.
-
cleaning agents or aggressive liquids such as petrol
or acetone to clean the appliance.
-
bathrooms may be cut off when the light is turned off.
-
used by one person.
-
appliances (with or without attachment) away from
-
(with hairs) or wounds without consulting your
response or people who suffer from diabetes
-
regrowth becomes thinner and softer.
If the irritation has not disappeared within three
- Do not use any exfoliation brush immediately after
caused by the epilator.
- Do not use bath or shower oils when you epilate
-
temperature between 10°C and 30°C.
- If your epilator is equipped with a light for optimal
being dazzled by it.
ENGLISH 5
- Do not use the epilating head of the epilator
without one of the epilation caps.
-
if you do not use the epilator for a longer time.
-
replace the batteries of the tweezers with batteries
of the original type.
This Philips appliance complies with all applicable standards and regulations
General
- This epilator is waterproof. It is suitable for use in the bath or shower
therefore only be used without cord.
- The appliance is suitable for mains voltages ranging from 100 to 240 volts.
- The adapter transforms 100-240 volts to a safe low voltage of less
than 24 volts.
- Maximum noise level: Lc = 77dB(A).
1 Epilating discs
2 Epilating head
3 Opti-Light
4 On/off button
- Press once for speed II
- Press twice for speed I
5 Light for speed I
6 Light for speed II
7 Charging light
8 Epilator
9 Release button
10 Trimming comb
11 Shaving head
12 Basic epilation cap
13 Sensitive area cap
14 Active hair-lift and massage cap
16 Adapter
17 Cleaning brush
18 On/off slide
19 Precision epilator
20 Disposable non-rechargeable batteries
21 Storage case of Smart Tweezers
22 Smart Tweezers
23 Light of Smart Tweezers
24 On/off slide for light
25 Pouch
ENGLISH6
Charging
-
1 Connect the small plug to the appliance (1) and the mains plug to the
wall socket (2).
,The charging light pulsates white to indicate that the appliance is
charging.When the batteries are fully charged, the charging light
lights up white continuously for 20 minutes and then goes out.
-
a few minutes of operation.
-
operating and the charging light lights up red continuously.
1
2
60 min.
ENGLISH 7
Clean the epilating head and charge the appliance fully before you use the
Note:You cannot use the appliance while it is connected to the mains.
- Wet:
and gentler.The appliance is waterproof and can be safely used in the
shower or bathtub.
- Wet:
-
-
- General:
usually disappears overnight.
- General: Epilation is easier and more comfortable when the hairs
- General
-
the epilating head with the basic epilation cap.
-
lift and massage cap.This cap not only lifts up the hairs but its active
massaging roller also minimises the pulling sensation of epilation.
Note: Remove the basic epilation cap by pressing its both sides (1) before you
attach another cap (2) or the skin stretcher.
1 Put any cap on the epilating head.
3-4 mm
1
2
ENGLISH8
2 Press the on/off button once to switch on the appliance.
,The appliance starts to operate at speed II, which is the most
Note: If you want to use speed I, press the on/off button a second time.
Note: Speed I is suitable for areas with little hair growth and for hard-to-reach
areas, such as knees and ankles.
3 If you are not using the skin stretcher, stretch the skin with your free
hand to make the hairs stand upright (1). Place the epilating head at
an angle of 90° onto the skin with the on/off button pointing in the
direction in which you are going to move the appliance (2).
Note: If you are using the skin stretcher you do not need to stretch your skin
anymore.The skin stretcher also ensures that you keep the appliance on your
skin at the right angle. Make sure that the skin stretcher is in contact with your
4 Slowly move the appliance over the skin against the direction of the
hair growth while pressing it lightly.
Tip:To relax the skin, we advise you to apply a moisturising cream immediately
or a few hours after epilation. For the underarms, use a mild deodorant without
alcohol.
1x
2x
1
2
90º
ENGLISH 9
Note:To get the best shaving results, use the shaving head on a dry skin.
If you want to use the shaving head in the bath or shower, we advise you to
use your common shower gel for a more gentle shave.
1 Press the release button (1) and remove the epilating head from
the epilator (2).
Note:You can remove the shaving head in the same way.
2 Put the shaving head on the appliance and press it until it
snaps home.
3 Switch on the appliance.
4 Place the shaving head at an angle of 90° onto your skin with the
on/off button pointing in the direction in which you are going to
move the appliance.
5 Slowly move the appliance against the direction of hair growth.
Note: Make sure that the shaving head is always fully in contact with the skin.
6
your free hand and move the appliance in different directions.
1
2
90º
ENGLISH10
7
different directions and raise your arm to stretch the skin.
Note:When you use shaving foam or gel, clean the shaving head during and
after each use with water to ensure optimum performance.
8
the shaving head according to the instructions in chapter ‘Cleaning
and maintenance’.
9 Put the trimming comb on the shaving head when you store the
appliance.
Use the shaving head with the comb attached to trim your hairs in the
hairs (longer than 10 mm) on the underarms or legs.
1 Press the release button (1) and remove the epilating head from the
epilator (2).
2
Put the shaving head on the appliance and press it until it snaps home.
3 Put the comb on the shaving head.
4 Follow steps 3 to 8 in section ‘Shaving the underarms and bikini line’.
1
2
ENGLISH 11
Overheat protection
This function helps to prevent overheating of the appliance.
Note:To avoid overheating of the appliance, do not press it too hard onto
your skin.The appliance works best when you move it over your skin without
excessive pressure.
30 seconds.
You can deactivate the overheat protection by letting the appliance cool
down and then switch it on again.
down completely.
Overload protection
for 5 seconds.
1 Turn the epilating discs with your thumb until you can remove
whatever blocks the epilating discs.
1
Remove the lid of the battery compartment by pressing the snap hooks.
2 Insert 2 AA 1.5V alkaline batteries into the battery compartment.
Note: Make sure the + and - poles of the batteries point in the direction
indicated at the bottom of the battery compartment.
Note: New batteries have an operating time of up to 40 minutes.
1
2
ENGLISH12
3
the lid into the rim of the compartment (1) and then press the top
part of the lid home until it locks with a snap (2).
1 If you want to remove the batteries, open the lid of the battery
compartment, see step 1 in section ‘Inserting/changing the batteries’
above.
2
3 Turn the appliance around, so that the open part of the battery
and shake the appliance until the second battery falls out.
Note:When you put down the appliance, place it in such a way that the on/off
Do not use this appliance to epilate eyebrows or eyelashes.
Do not use this appliance to remove hairs that grow out of moles.
-
1 Thoroughly clean the area to be epilated. Remove any residues of
deodorant, cream etc.
2 Switch on the appliance.
1
2
2
1
ENGLISH 13
3 Place the epilating head at an angle of 90° onto the skin with the
on/off slide pointing in the direction in which you are going to move
the appliance.
4 Slowly move the appliance over the skin, against the direction of the
hair growth.
5
your free hand and move the appliance in different directions to
catch all hairs.
6
stretch the skin and move the appliance in different directions to
catch all hairs.
Tip: If you want to use the precision epilator in the bath or shower, we advise
you to use a small amount of your common shower gel for better gliding.
90º
ENGLISH14
Your epilator comes with Smart Tweezers with integrated light for easy
protected by a case with integrated mirror which allows you to depilate
wherever and whenever you want.The Smart Tweezers are supplied ready
for use with 3 button batteries in the battery compartment.
Do not use the Smart Tweezers to remove hairs that grow out of moles.
Do not point the light of the Smart Tweezers directly at your or
somebody else’s eyes.
1 Use an eye pencil to mark the desired shape of your eyebrows.
2 Switch on the light by sliding the on/off button.
3 Remove any hairs outside the marked shape.Always pull out the hair
in the direction of hair growth.
1 Open the battery and light compartment by turning the bottom
anticlockwise with a coin.
2 Remove the old button batteries.
Keep the button batteries out of the reach of children and pets.
Button batteries present a potential choking hazard.
ENGLISH 15
3 Insert the new button batteries with the negative side pointing
forward into the battery and light compartment.
Note:The Smart Tweezers work on three alkaline button batteries,
type L736H or AG3 (dia. 7.8 x 3.4 mm).
4 Screw the bottom back onto the battery and light compartment by
turning it clockwise with a coin.
Cleaning and maintenance
Never use scouring pads, abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the appliance.
Always keep the adapter dry. Never rinse it under the tap or immerse it in
water. If necessary, clean the adapter with the cleaning brush or a dry cloth.
Clean the epilating head after each wet use to ensure optimum
performance. Always switch off the appliance before you clean it.
1 Switch off the appliance.
2 Remove the cap from the epilating head.
3 Press the release button (1) and remove the epilating head from the
appliance (2).
Note: Never try to detach the epilating discs from the epilating head.
4 Remove loose hairs with the cleaning brush.
5 Rinse all parts (epilator, epilating head, caps and skin stretcher)
under a lukewarm tap while turning them.
1
2
ENGLISH16
6 Shake excess water off the parts and let them dry.
Note: For hygienic reasons, make sure all parts are dry before you reassemble
the appliance.
7 To reattach the epilating head, place it on the appliance and press it
onto the appliance until it snaps home.
1 Remove the comb, if attached, by pulling it off the shaving head.
2 Press the release button (1) and remove the shaving head from
the appliance (2).
3 Remove the shaving unit from the shaving head.
4 Rinse the shaving unit, the shaving head and the comb under
a lukewarm tap while turning them.
5
them dry.
Note: Do not exert any pressure on the shaving unit to avoid damage.
6 Reattach the shaving unit to the shaving head.
Note: Make sure all parts are dry before you place them back on the
appliance.
1
2
ENGLISH 17
Tip: Rub a drop of sewing machine oil onto the shaving unit twice a year to
extend the lifetime of the cutting element.
1 Clean the precision epilator regularly by removing loose hairs with
the cleaning brush.
Do not switch on the appliance while brushing.
2 Rinse the precision epilator under the tap.
3 Shake excess water off the precision epilator and let it dry.
Note:To make cleaning easier, the epilating head can also be detached by
pulling it off the appliance.
Storage
- Store the appliances and the accessories in the pouch.
- Put the comb on the shaving head to prevent damage.
Note: Make sure that all parts are dry when you store them.
from accidentally being switched on during travel.
1 To activate the travel lock, press and hold the on/off button for
,The epilator starts running and stops immediately when the travel
lock activates.
6M
3 sec.
ENGLISH18
2 To deactivate the travel lock, press and hold the on/off button for
Note:You can also insert the appliance plug into the inlet socket and the
adapter into a wall socket to deactivate the travel lock.
or go to your Philips dealer.You can also contact the Philips Consumer
contact details).
Epilating head
replace the epilating head after two years or when it is damaged.
- This symbol on a product means that the product is covered by
European Directive 2012/19/EU.
- This symbol means that the product contains a built-in rechargeable
battery covered by European Directive 2006/66/EC which cannot be
centre to have a professional remove the rechargeable battery.
- Inform yourself about the local separate collection system for electrical
and electronic products and rechargeable batteries. Follow local
rules and never dispose of the product and rechargeable batteries
with normal household waste. Correct disposal of old products and
rechargeable batteries helps prevent negative consequences for the
environment and human health.
3 sec.
ENGLISH 19
Note:We strongly advise you to have a professional remove the rechargeable
battery.
Only remove the rechargeable battery when you discard the appliance.
1 Check if there are any screws in the back or front of the appliance.
If so, remove them.
2 Remove the back and/or front panel of the appliance with a
screwdriver. If necessary, also remove additional screws and/or parts
until you see the printed circuit board with the rechargeable battery.
3 If necessary, cut the wires to separate the printed circuit board and
the rechargeable battery from the appliance.
user manual.
Cutting units are not covered by the terms of the international guarantee
because they are subject to wear.
This chapter summarises the most common problems you could
encounter with the appliances. If you are unable to solve the problem with
Problem Possible cause Solution
The epilator does
to charge the
epilator does not
The charging light goes on to indicate that the epilator
The rechargeable
batteries are
empty.
batteries are empty and you need to charge the epilator for
approx. 1 hour. Note:You have to charge the epilator fully
active.
You can also connect the epilator to the mains with the
ENGLISH20
Other manuals for HP6583
2
This manual suits for next models
2
Table of contents
Languages:
Other Philips Epilator manuals
Philips
Philips HP6541 User manual
Philips
Philips HP6583 User manual
Philips
Philips Satinelle Soft HP6409 User manual
Philips
Philips HP6578/00 User manual
Philips
Philips HP6502/10 User manual
Philips
Philips Satinelle Sensitive HP6416 User manual
Philips
Philips BRE610 User manual
Philips
Philips HP6511 User manual
Philips
Philips Satinelle HP6400 User manual
Philips
Philips Lumea SC198 Series User manual
Philips
Philips HP6459 Satin ICE Optima User manual
Philips
Philips HP6502/00 User manual
Philips
Philips HP6408 User manual
Philips
Philips HP6574/00 User manual
Philips
Philips HP6521/20 User manual
Philips
Philips HP6541/00 User manual
Philips
Philips HP6516 User manual
Philips
Philips HP6483 User manual
Philips
Philips HP6317/82 User manual
Philips
Philips HP6553 User manual
