Philips HF3480 User manual

HF3480

2

3
MHz.
䑰໰
开
E
3
1
2
13
14
12
4 5 6 7 8 9 10 11
A
C
B
D
G
F
1
2
3
1

4


 6
简体中文 20

6

Introduction 6
The effects of the Wake-up Light 7
General description 7
Important 8
Electromagnetic elds (EMF) 9
Preparing for use 9
Setting the clock time 10
Using the appliance 10
Top and bottom dials 10
Middle dial 11
Setting the alarm 11
Using the lamp 13
Radio/volume 14
Dusk simulation function 15
Display brightness function 15
Cleaning and maintenance 15
Environment 16
Guarantee and service 16
Guarantee restrictions 16
Troubleshooting 16

Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
The Philips Wake-up Light helps you wake up more pleasantly. The light
intensity of the lamp gradually increases to the set level in the 30 minutes
before the set wake-up time. The light gently prepares your body for
waking up at the programmed time. To make waking up an even more
pleasant experience, you can use natural wake-up sounds or the FM
radio.
You can use the dusk simulation function to have the Wake-up Light dim
the light and sound gradually before they are completely switched off at
the time you set.



The Philips Wake-up Light gently prepares your body for waking up
during the last half hour of sleep. In the early morning hours our eyes are
more sensitive to light than when we are awake. During that period the
relatively low light levels of a simulated natural sunrise prepare our body
for waking up and getting alert. People who use the Wake-up Light wake
up more easily, have a better overall mood in the morning. Because the
sensitivity to light differs per person, you can set the light intensity of your
Wake-up Light to a level that matches your light sensitivity for an optimal
start of the day.
For more information about the Wake-up Light, see www.philips.com.

 Vents
 Lamp housing
 Mains cord
 Antenna
 Display
 Light symbol
 Hour indication of clock time/alarm time
 Clock time symbol
 Alarm symbol
 Radio symbol
 ’Birds’ sound symbol
 ‘Beep’ sound symbol
 ‘African jungle’ sound symbol
 ‘Wind chimes’ sound symbol
 Dusk simulation symbol
 Display brightness symbol
 Minute indication of clock/alarm time
 Sound level symbol
 Control lever with ‘alarm off ’, ‘alarm on’ and ‘snooze’ positions
 Dials on the side of the appliance
 Top dial: light on/off and light intensity
 Middle dial: menu and radio frequency
 Bottom dial: radio on/off and volume
 7


- Read this user manual carefully before you use the appliance and save
it for future reference.
- This appliance is double insulated according to Class II (Fig. 2).

- Water and electricity are a dangerous combination. Do not use this
appliance in wet surroundings (e.g. in the bathroom or near a shower
or swimming pool).
- Do not let water run into the appliance or spill water onto the
appliance (Fig. 3).

- Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.
- The appliance is suitable for a mains voltage of 230V and a frequency
of 50Hz.
- If the mains cord is damaged, you must have it replaced by Philips, a
service centre authorised by Philips or similarly qualied persons in
order to avoid a hazard.
- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
- This appliance is for indoor use only (Fig. 4).

- Do not drop the appliance or expose it to heavy shocks.
- Place the appliance on a stable, level and non-slippery surface.
- Do not use the appliance at room temperatures lower than 10°C or
higher than 35°C.
- Make sure the vents in the top and in the bottom of the appliance
remain open during use.
8

- Never use the appliance if the lamp housing or top cover is damaged,
broken or missing.
- Consult your doctor before you start using the appliance if you have
suffered from or are suffering from serious depression.
- Do not use this appliance as a means to reduce your hours of sleep.
The purpose of this appliance is to help you wake up more easily. It
does not diminish your need for sleep.
- The appliance has no on/off switch. To disconnect the appliance from
the mains, remove the plug from the wall socket.
- This appliance is only intended for household use, including similar
use for instance in hotels.

- This appliance allows you to choose the light intensity level you want
to wake up to (see section ‘Using the lamp’, chapter ‘Using the
appliance’).
- If you often wake up too early or with a headache, reduce the light
level.
- If you share a bedroom with someone else, this person may
unintentionally wake up from the light of the appliance, even though
this person is further removed from the appliance. This phenomenon
is the result of differences in light sensitivity between people.

This Philips appliance complies with all standards regarding
electromagnetic elds (EMF). If handled properly and according to the
instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.

1 Place the Wake-up Light 40-50cm from your head, for example on a
bedside table.
2 Put the plug in the wall socket.
,The hour indication on the display starts ashing to indicate that
you have to set the clock time (Fig. 5).
 9


You cannot use the Wake-up Light until you have set the clock time.
1 When the hour indication on the display ashes, move the middle
dial up or down to select the hour.
2 Press the middle dial gently and release it to conrm.
,The minute indication starts ashing (Fig. 6).
3 Move the middle dial up or down to select the minutes.
4 Press the middle dial gently and release it to conrm.
,The appliance leaves the menu and the display shows the set clock
time.
The appliance is now ready for use.
Note: Every time you remove the plug from the wall socket for more than
approximately 15 minutes, you have to set the clock time again by following
steps 1 to 4 above.
Note: To change the set clock time when the plug is still in the wall
socket, press the middle dial gently two times to enter the menu for setting
the clock time. You are in the menu when the hour indication ashes. Then
follow steps 1 to 4 above.


- With the top dial you can switch the lamp on or off and set the light
intensity (see section ‘Using the lamp’ in this chapter).
- With the bottom dial you can switch the radio on or off and set the
volume (see section ‘Radio/volume’ in this chapter).
Note: Press the dial gently and release it to switch on or off the light (top
dial) or radio (bottom dial) and move the dial up or down to change the light
intensity (top dial) or volume level (bottom dial).
10


The middle dial allows you to choose various functions from the
menu. These functions appear in the menu in the following order:
- Clock time
- Alarm time
- Alarm sound
- Dusk simulation function
- Display brightness function
You can operate the middle dial in the following way:
1 Press the middle dial gently and release it to enter the
menu (Fig. 7).
Do not press the dial too hard. If you do, the dial does not work.
2 Move the middle dial up or down to select a function. (Fig. 8)
3 Press the middle dial gently and release it to enter this function.
4 Move the middle dial up or down to select an option in this
function.
5 Press the middle dial gently and release it to conrm.
If you do not operate the dial for  when you are in the
menu, the appliance automatically leaves the menu and displays the
clock time again.

To set the alarm, you choose an alarm time and the type of sound you
want to wake up to. The alarm is set when the alarm symbol and the
alarm sound symbol are visible on the display.
Note: You can set the light intensity by moving the top dial up or down and
you can set the alarm volume by moving the bottom dial up or down. If you
do not want to wake up to the lamp or to a sound, select a light intensity or
volume level of 0 (shown on the display as ‘OFF’). See sections ‘Using the
lamp’ and ‘Radio/volume’ in this chapter.
 11

Tip: When you use the appliance for the rst time, set the light intensity to
20. The moment you wake up, check which light intensity level the appliance
has reached by slightly moving the top dial up or down. When you do this, the
current alarm light intensity level appears on the display. Set the alarm light
intensity to this level for the next day.
1 Push the control lever down to the middle position to switch on
the alarm. (Fig. 9)
,The hour indication of the alarm time ashes (Fig. 10).
,To adjust the alarm time, follow steps 2 to 5 below. If the alarm
time is correct, just wait a few seconds.
2 Move the middle dial up or down to select the hour.
Note: You can only do this when the hour indication ashes. If this is not the
case, push the control lever up and down again to enter the alarm time
function.
Note: You can also use the middle dial to select the alarm time function and
set the alarm time (see section ‘Middle dial’ in this chapter).
3 Press the middle dial gently and release it to conrm.
,The minute indication of the alarm time starts to ash (Fig. 11).
4 Move the middle dial up or down to select the minutes.
5 Press the middle dial gently and release it to conrm or wait for a
few seconds.
,The appliance leaves the menu and the display shows the clock
time.
The alarm time is now set.

To switch off the alarm, push up the control lever to the top position.
Note: The lamp stays on. Press the top dial gently and release it to switch off
the lamp.
Note: The alarm (sound and/or light) automatically switches off after 90
minutes.
12


Follow steps 1 to 5 in section ‘Middle dial’ in this chapter.
You can choose one of the following sounds:
- Radio (Fig. 12)
- Birds (Fig. 13)
- Beep (Fig. 14)
- African jungle (Fig. 15)
- Wind chimes (Fig. 16)

1 Push down the control lever to the bottom position when the
alarm goes off. (Fig. 17)
,The lamp continues to be on at the selected intensity level, but the
alarm sound stops. After 9 minutes, the wake-up sound is
automatically played again.
Note: The 9-minute snooze time is xed. This time cannot be adjusted.
Note: If you push down the control lever with too much force, it may jump
back to off position.

If you want to get a quick demonstration (60 seconds) of the gradually
increasing light level and sound level, activate the test function of the
appliance.
1 Push the control lever down to the bottom position for a few
seconds until TEST appears on the display (Fig. 18).
2 Push the control lever down again to stop the demonstration.
Note: The appliance continues to run the alarm demonstration until you
push down the control lever again. The test automatically stops after 9 hours.

You can use the top dial to switch on the lamp as a bedside lamp and to
set the light intensity.
1 To switch on the lamp, press the top dial gently and release
it. (Fig. 19)
 13

Note: It takes approx. 1 second for the lamp to go on. This is normal, the
lamp needs to heat up.
Note: The lamp does not go on when you press the top dial while the
appliance is in the menu.
2 Move the top dial up or down to select the light intensity level you
prefer. (Fig. 20)
You can choose a light intensity between 1 and 20.
Note: The light intensity you have selected is automatically set as the light
intensity level for the alarm as well.
3 To switch off the lamp, press the top dial gently and release it.
Note: You can also move the top dial up or down to check and/or select a
light intensity level without pressing the top dial rst.

1 To switch on the radio, press the bottom dial gently and release
it. (Fig. 21)
2 To select the desired radio frequency manually, move the middle
dial up or down (Fig. 22).
Tip: To scan radio frequencies automatically, press and hold the middle dial
for approx. 2 seconds.
Tip: To make sure you get a good radio signal, fully unwind the antenna and
move it around until you have found a position at which reception is best.
3 To switch off the radio, press the bottom dial gently and release it.

1 To set the volume, move the bottom dial up or down to select
the volume level you prefer.
You can choose a volume level between 1 and 20.
Note: The volume level you select is automatically set as the volume level for
the alarm as well.
14


Select the dusk simulation function if you want the light and/or the sound
of the Wake-up Light to stay on and dim gradually during a set period of
time (15 minutes to 2 hours) before you go to sleep. The lamp and/or
sound switch off automatically after the set time.
1 Follow steps 1 to 5 in section ‘Middle dial’ in this chapter to select
the dusk simulation function and to set the dusk simulation time.
Note: You can choose a time from 15 to 120 minutes (15, 30, 60, 90 or 120
minutes).
,After the set time, no matter whether the light and/or the radio
are on, the appliance switches off both light and sound.

Select the display brightness function if you want to adjust the brightness
of the display.
1 Follow steps 1 to 5 in section ‘Middle dial’ in this chapter to select
the display brightness function and to set the display brightness.
You can choose a display brightness from 1 to 4.

Never use scouring pads, abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the appliance.
Regularly remove dust from the outside of the appliance with a dry
cloth.
1 Unplug the appliance before you clean it.
2 Clean the outside of the appliance with a dry cloth.
Do not let water run into the appliance or spill water onto the
appliance (Fig. 23).
 15


- Do not throw away the appliance with the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the
environment (Fig. 24).

If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Consumer Care Centre in
your country, go to your local Philips dealer.

For safety reasons, the lamp of this appliance cannot be replaced. If the
appliance or the lamp does not work, please visit the Philips website at
www.philips.com or contact the Philips Consumer Care Centre in your
country (you nd its phone number in the worldwide guarantee leaet).
If there is no Consumer Care Centre in your country, go to your local
Philips dealer.

This chapter summarises the most common problems you could
encounter with the appliance. If you are unable to solve the problem with
the information below, contact the Consumer Care Centre in your
country.
Problem Solution
The appliance
does not work
at all.
Perhaps the plug is not inserted properly in the wall
socket. Put the plug properly in the wall socket.
Perhaps there is a power failure. Check if the power
supply works by connecting another appliance.
16

Problem Solution
The appliance
functions
properly, but
the lamp does
not work
anymore.
Perhaps the lamp has reached the end of its life. The
lamp has an expected life of more than 10,000 hours
(more than 7 years of normal use). The life
depends on the use of the appliance. In case of
heavy use, the lamp may not last as long as you
expect. The lamp is not replaceable. If the lamp
breaks down, contact the Philips Consumer Care
Centre in your country.
The appliance
becomes hot
during use.
This is normal, as the appliance is heated up by the
light of the lamp and the electronics.
The appliance
does not
respond when I
try to press or
move the dials.
Remove the plug from the wall socket and reinsert
it. If you reinsert the plug within approximately 15
minutes, the appliance remembers all settings. If you
reinsert the plug after a longer period of time, the
appliance remembers all settings except the time.
The lamp does
not go on when
the alarm goes
off.
Perhaps you set a light intensity level that is too low.
Increase the light intensity level.
Perhaps you switched off the alarm function by
setting the control lever to the top position. To
switch on the alarm function, set the control lever to
the middle position
Perhaps the appliance is defective. Contact the
Philips Consumer Care Centre in your country.
The lamp does
not go on right
away when I
switch it on.
It takes approx. 1 second for the lamp to go on. This
is normal, the lamp needs to heat up.
 17

Problem Solution
I do not hear
the alarm
sound when
the alarm goes
off.
Perhaps you set a sound level that is too low. To set a
higher sound level, see chapter ‘Using the appliance’,
section ‘Radio/volume’.
Perhaps you switched off the alarm function by
setting the control lever to the top position.
If you selected the radio as the alarm sound, the
radio may be defective. Switch on the radio after you
switch off the alarm to check if the radio works. If it
does not work, contact the Philips Consumer Care
Centre in your country.
The radio does
not work.
The radio may be defective. Contact the Philips
Consumer Care Centre in your country.
The radio
produces a
crackling sound.
Perhaps the broadcast signal is weak. Move the
middle dial up or down to adjust the frequency and/
or change the position of the antenna by moving it
around. Make sure you have unwound the antenna
completely.
The alarm went
off yesterday,
but it did not
go off today.
Perhaps you switched off the alarm function by
setting the control lever to the top position.
Perhaps you set a sound level and/or light intensity
level that is too low. Set a higher sound and/or light
intensity level.
Perhaps there was a power failure that lasted more
than approximately 15 minutes. In this case the
appliance has remembered all settings except the
clock time. The clock time therefore ashes on the
display. Set the correct clock time.
18

Problem Solution
The alarm did
not go off 9
minutes after I
pushed the
control lever
down to
snooze.
Perhaps you pushed the control lever down with so
much force that it jumped to off position.
Perhaps you set the volume level to 0 (shown on the
display as ‘OFF’).
The light wakes
me too early.
Perhaps the light intensity level you have set is not
appropriate for you. Try a lower light intensity level if
you wake up too early. If light intensity 1 is not low
enough, move the appliance further away from the
bed.
The light wakes
me too late
Perhaps the appliance is positioned at a lower level
than your head. Make sure the appliance is located at
a height at which the light is not blocked by your
bed, duvet or pillow. Also make sure the appliance is
not placed too far away.
The lamp
ashes.
Perhaps there has been a power failure. It is normal
for the lamp to ash after a power failure.
Perhaps the appliance is not suitable for the voltage
to which it is connected. Make sure that the voltage
indicated on the appliance corresponds to the local
mains voltage.
 19

20
目录
产品简介 20
自然唤醒灯的功效 21
一般说明 21
注意事项 22
电磁场 (EMF) 23
使用准备 23
设置时钟时间 23
使用本产品 24
顶部和底部旋钮 24
中部旋钮 24
设置闹钟 25
使用自然唤醒灯 26
收音机/音量 27
黄昏模拟功能 28
显示屏亮度调节功能 28
清洁和保养 28
环境 28
保修和服务 28
保修限制 28
故障种类和处理方法 29
产品简介
感谢您的惠顾，欢迎光临飞利浦！为了您能充分享受飞利浦提供
的支持服务，请登陆 www.philips.com/welcome 网站注册您的产
品。
飞利浦自然唤醒灯让您的晨醒过程更愉悦。在所设定的晨醒时间
之前的 30 分钟内，自然唤醒灯的光线亮度会逐渐增加至设定的级
别，给您的身体一个过渡时间，以便您在设定的时刻自然醒来。
为使晨醒过程更加愉悦，您还可使用自然的唤醒声或 FM 收音机。
您可使用黄昏模拟功能，使自然唤醒灯的光线亮度逐渐变暗、音
量逐渐降低，然后在设定的时间完全关闭。
简体中文
