Philips TuffGuard™High
Intensity Discharge
Coated Lamps
Outstanding performance
and reliability
Philips TuffGuard™High Intensity Discharge Coated Lamps
offer a range of switch start and high pressure sodium lamps
that provide long life, high efficiency and high lumen output.
Philips TuffGuard™coated lamps
• Contains glass fragments in the event the lamp is accidentally
dropped or broken
• Easy-to-clean non-stick coating
Coating is not designed to contain an arc-tube rupture
Ideal for manufacturing and
warehouse applications
TUFFGUARD™SERIES

Philips TuffGuard™High Intensity Discharge
Coated Lamps—Metal Halide Lamps
Ordering, Electrical and Technical Data
Max.
Rated Approx.
Product Nom. Pkg. Avg. Life Initial
Number Description Watts Volts Qty. Bulb Base (Hrs)1Lumens2Availability
20211-9 MH175/U 12PK TG 175 132 12 ED-28 Mogul 10,000 14,700 Stocked
20212-7 MH250/U 12PK TG 250 133 12 ED-28 Mogul 10,000 21,250 Stocked
21147-4 MS360/BU/EW 6PK TG 360 120 6 ED-37 Mogul 20,000 36,000 Stocked
20213-5 MH400/U 6PK TG 400 135 6 ED-37 Mogul 20,000 36,000 Stocked
1) Average life under engineering data with lamps turned off and restarted once every 12 operating hours.
2) Protective coating may reduce actual lumens by up to 5%.
Above specifications are subject to change without notice.
WAR I GS:
• Coating can withstand bulb wall temperatures up to 500°F, subject to the following conditions:
1) Lamp must be installed and operated in ambient temperature below 150°F.
2) Lamp is not used in fixture that does not allow heat dissipation.
•UV radiation emitted from metal halide lamps may deteriorate the coating over time.
• The coating is not designed to contain an arc-tube rupture
• Under extreme conditions glass fragments may escape the coating
• Only protective shrouded lamps are resistant to metal halide non-passive failure.
RECOMMENDED WARNINGS, CA TIONS,AND OPERATING INSTR CTIONS
For Standard Metal Halide Lamps (Enclosed Fixtures nless Otherwise Noted)
R“WARNING:
These lamps can cause serious skin burn and eye inflammation from short wave ultraviolet
radiation if outer envelope of the lamp is broken or punctured. Do not use where people will remain for
more than a few minutes unless adequate shielding or other safety precautions are used. Certain lamps that will
automatically extinguish when the outer envelope is broken or punctured are commercially available.”This lamp
complies with FDA radiation performance standard 21 CFR subchapter J. (USA: 21CFR 1040.30
Canada:SOR/DORS/80-381)
If the outer bulb is broken or punctured, turn off at once and replace the lamp to avoid possible
injury from hazardous short wave ultraviolet radiation. Do not scratch the outer bulb or subject
it to pressure as this could cause the outer bulb to crack or shatter.A partial vacuum in the
outer bulb may cause glass to fly if the envelope is struck.
WARNING: The arc-tube of metal halide lamps are designed to operate under high pressure and at temperatures
up to 1000º C and can unexpectedly rupture due to internal or external factors such as a ballast failure or
misapplication. If the arc-tube ruptures for any reason, the outer bulb may break and pieces of extremely hot
glass might be discharged into the surrounding environment. If such a rupture were to happen,
THERE IS A RISK OF PERSONAL INJ RY, PROPERTY DAMAGE, B RNS AND FIRE.
Certain lamps that will retain all the glass particles should inner arc-tube rupture occur are
commercially available from Philips Lighting Company.
RELAMP FIXT RES AT OR BEFORE THE END OF RATED LIFE.
Allowing lamps to operate until they fail is not advised and may increase the possibility of inner
arc tube rupture.
CA TION: TO REDUCE THE RISK OF PERSONAL INJURY, PROPERTY DA AGE, BURNS AND FIRE RE-
SULTING FRO AN ARC-TUBE RUPTURE THE FOLLOWING LA P
OPERATING INSTRUCTIONS UST BE FOLLOWED:
LAMP OPERATING INSTR CTIONS:
1. Turn off lamps at least once a week for at least 15 minutes in systems which are operating on a continuous basis
(24 hours/day-7days/week). FAILURE TO TURN OFF LA PS FOR THE MINIM M RECOMMENDED
TIME MAY INCREASE THE POSSIBILITY OF AN INNER ARC-T BE R PT RE.
2. RELAMP FIXT RES AT OR BEFORE THE END OF RATED LIFE.Allowing lamps to operate until
they fail is not advised and may increase the possibility of inner arc tube rupture.
3. Before lamp installation/replacement, shut power off and allow lamp and fixture to cool to avoid electrical
shock and potential burn hazards.
4. Use only auxiliary equipment meeting Philips and/or ANSI standards. Use within voltage limits recommended
by ballast manufacturer.
A.Operate lamp only within specified limits of operation.
B. For total supply load refer to ballast manufacturers electrical data.
5. Periodically inspect the outer envelope. Replace any lamps that show scratches, cracks or damage.
6. If a lamp bulb support is used, be sure to insulate the support electrically to avoid possible decomposition of
the bulb glass.
7. Protect lamp base, socket and wiring against moisture, corrosive atmospheres and excessive heat.
8.Time should be allowed for lamps to stabilize in color when turned on for the first time.This may require
several hours of operation, with more than one start. Lamp color is also subject to change under conditions
of excess vibration or shock and color appearance may vary between individual lamps.
9. Lamps may require 10 to 20 minutes to re-light if there is a power interruption.
10. Take care in handling and disposing of lamps. If an arc tube is broken, avoid skin contact with any of the
contents or fragments.
11. Do not use this lamp:
A. In a fixture that contains a Pulse Start metal halide ballast.
B. In a fixture that is specifically designed for use with Pulse Start metal halide lamps.Operation of these lamps
on Pulse Start etal Halide systems may increase the chance of an outer bulb rupture and pieces of
extremely hot glass might be discharged into the surrounding environment. If such a rupture were to happen,
THERE IS A RISK OF PERSONAL INJ RY, PROPERTY DAMAGE, B RNS AND FIRE.
Made to order requires 3 week lead time
( o product returns on made to order lamps)

Philips TuffGuard™High Intensity Discharge
Coated Lamps—Protected Metal Halide
“O” Rated Lamps
Ordering, Electrical and Technical Data
Max.
Rated Approx.
Product Nom. Pkg. Avg. Life Initial
Number Description Watts Volts Qty. Bulb Base (Hrs)1Lumens2Availability
20214-3 MP175/BU 12PK TG 175 132 12 ED-28 Mogul 10,000 15,000 Stocked
20215-0 MP250/BU 12PK TG 250 133 12 ED-28 Mogul 10,000 22,000 Made to Order
21148-2 MP360/BU/EW 6PK TG 360 120 6 ED-37 Mogul 20,000 34,200 Stocked
20216-8 MP400/BU 6PK TG 400 135 6 ED-37 Mogul 20,000 38,000 Stocked
1) Average life under engineering data with lamps turned off and restarted once every 12 operating hours.
2) Protective coating may reduce actual lumens by up to 5%.
Above specifications are subject to change without notice.
WAR I GS:
• Coating can withstand bulb wall temperatures up to 500°F, subject to the following conditions:
1) Lamp must be installed and operated in ambient temperature below 150°F.
2) Lamp is not used in fixture that does not allow heat dissipation.
• UV radiation emitted from metal halide lamps may deteriorate the coating over time.
• The coating is not designed to contain an arc-tube rupture
• Under extreme conditions glass fragments may escape the coating
• Lamps must be burned base up only
• Only protective shrouded lamps are resistant to metal halide non-passive failure.
RECOMMENDED WARNINGS, CA TIONS,AND OPERATING INSTR CTIONS
For Protected Metal Halide Lamps (Base p Operation ± 15˚ nless Noted;
Open or Enclosed Fixtures)
R“WARNING:
These lamps can cause serious skin burn and eye inflammation from short wave ultraviolet
radiation if outer envelope of the lamp is broken or punctured. Do not use where people will remain for
more than a few minutes unless adequate shielding or other safety precautions are used. Certain lamps that will
automatically extinguish when the outer envelope is broken or punctured are commercially available.”This lamp
complies with FDA radiation performance standard 21 CFR subchapter J. (USA: 21CFR 1040.30 Canada:
SOR/DORS/80-381)
If the outer bulb is broken or punctured, turn off at once and replace the lamp to avoid possible
injury from hazardous short wave ultraviolet radiation. Do not scratch the outer bulb or subject
it to pressure as this could cause the outer bulb to crack or shatter.A partial vacuum in the
outer bulb may cause glass to fly if the envelope is struck.
WARNING: The arc-tube of metal halide lamps are designed to operate under high pressure and at temperatures
up to 1000º C and can unexpectedly rupture due to internal or external factors such as a ballast failure or
misapplication. If the arc-tube ruptures for any reason, the outer bulb may break and pieces of extremely hot
glass might be discharged into the surrounding environment. If such a rupture were to happen,
THERE ISA RISK OF PERSONAL INJ RY, PROPERTY DAMAGE, B RNS AND FIRE.
These lamps are designed to retain all the glass particles should an arc tube rupture occur.The
following operating instructions are recommended to minimize these occurrences. RELAMP
FIXT RES AT OR BEFORE THE END OF RATED LIFE.Allowing lamps to operate until they
fail is not advised and may increase the possibility of inner arc tube rupture.
CA TION: TO REDUCE THE RISK OF PERSONAL INJURY, PROPERTY DA AGE, BURNS AND FIRE
RESULTING FRO AN ARC-TUBE RUPTURE THE FOLLOWING LA P OPERATING INSTRUCTIONS
UST BE FOLLOWED:
LAMP OPERATING INSTR CTIONS:
1. RELAMP FIXT RES AT OR BEFORE THE END OF RATED LIFE.Allowing lamps to operate until
they fail is not advised and may increase the possibility of inner arc tube rupture.
2. Before lamp installation/replacement, shut power off and allow lamp and fixture to cool to avoid electrical
shock and potential burn hazards.
3. Use only auxiliary equipment meeting Philips and/or ANSI standards. Use within voltage limits recommended
by ballast manufacturer.
A.Operate lamp only within specified limits of operation.
B. For total supply load refer to ballast manufacturers electrical data.
4. Periodically inspect the outer envelope. Replace any lamps that show scratches, cracks or damage.
5. If a lamp bulb support is used, be sure to insulate the support electrically to avoid possible decomposition of
the bulb glass.
6. Protect lamp base, socket and wiring against moisture, corrosive atmospheres and excessive heat.
7. Time should be allowed for lamps to stabilize in color when turned on for the first time.This may require
several hours of operation, with more than one start. Lamp color is also subject to change under conditions
of excess vibration or shock and color appearance may vary between individual lamps.
8. Lamps may require 10 to 20 minutes to re-light if there is a power interruption.
9. Take care in handling and disposing of lamps. If an arc tube is broken, avoid skin contact with any of the con-
tents or fragments.
10 Do not use this lamp:
A. In a fixture that contains a Pulse Start metal halide ballast.
B. In a fixture that is specifically designed for use with Pulse Start metal halide lamps.Operation of these lamps
on Pulse Start etal Halide systems may increase the chance of an outer bulb rupture and pieces of
extremely hot glass might be discharged into the surrounding environment. If such a rupture were to happen,
THERE IS A RISK OF PERSONAL INJ RY, PROPERTY DAMAGE, B RNS AND FIRE.
Made to order requires 3 week lead time
( o product returns on made to order lamps)

© 2007 Philips Lighting Company. All rights reserved.
Printed in USA 08/07
P-5813-B
www. philips.com
Philips Lighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, J 08875-6800
1-800-555-0050
A Division of Philips Electronics orth America Corporation
Philips Lighting
281 Hillmount Road
Markham, Ontario
Canada L6C 2S3
1-800-555-0050
A Division of Philips Electronics Ltd.
Printed on chlorine free paper from Sappi Fine Paper mills, who are accredited with EMAS environmental certification.
Sappi claims that the pulp used in the manufacture of Magno Dull paper is derived from environmentally certified forests.
Philips TuffGuard™High Intensity Discharge
Coated Lamps—HPS Lamps
Ordering, Electrical and Technical Data
Max.
Rated Approx.
Product Nom. Pkg. Avg. Life Initial
Number Description Watts Volts Qty. Bulb Base (Hrs)1Lumens2Availability
20218-4 C70S62 12PK TG 70 52 12 ED-231⁄2Mogul 24,000 6500 Made to Order
20219-2 C100S54 12PK TG 100 55 12 ED-231⁄2Mogul 24,000 9400 Made to Order
20220-0 C150S55 12PK TG 150 55 12 ED-231⁄2Mogul 24,000 15,800 Made to Order
20222-6 C250S50 12PK TG 250 100 12 ED-18 Mogul 24,000 27,000 Stocked
20458-6 C50S68/M 12PK TG 50 52 12 BF-55 Medium 24,000 4000 Made to Order
20460-2 C100S54/M 12PK TG 100 55 12 BF-55 Medium 24,000 9500 Made to Order
1) Average life under engineering data with lamps turned off and restarted once every 12 operating hours.
2) Protective coating may reduce actual lumens by up to 5%.
Above specifications are subject to change without notice.
WAR I GS:
• Coating can withstand bulb wall temperatures up to 500°F, subject to the following conditions:
1) Lamp must be installed and operated in ambient temperature below 150°F.
2) Lamp is not used in fixture that does not allow heat dissipation.
RECOMMENDED WARNINGS, CA TIONS,AND OPERATING INSTR CTIONS
For High Pressure Sodium Lamps
R“WARNING:
These lamps must be operated in fixtures designed for use with High Pressure Sodium
lamps.The fixture wattage rating must match the wattage indicated on the outer glass bulb. Do not scratch
the outer bulb or subject it to pressure as this could cause the outer bulb to crack or shatter.A partial vacuum
in the outer bulb may cause glass to fly if the glass is struck.Operating the lamp improperly may result in
PERSONAL INJ RY, PROPERTY DAMAGE, B RNS AND FIRE.
1. If the outer glass bulb is broken, shut off power immediately and remove the lamp after it has cooled.
2. Use only auxiliary equipment meeting Philips and/or ANSI standards. Use within voltage limits recommended
by ballast manufacturer.
A.Operate lamp only within specified limits of operation.
B. For total supply load refer to ballast manufacturers electrical data.
3. Protect lamp base, socket and wiring against moisture, corrosive atmospheres and excessive heat.
4. Replace the lamp if the outer glass bulb has been scratched, cracked or damaged in any way.
5. If a lamp bulb support is used, be sure to insulate the support electrically so as to avoid possible decomposition
of the bulb glass.
6. Do not use this lamp in a fixture which redirects a substantial portion of the energy toward the arc tube and
its immediate vicinity, as this may lead to very early lamp failure.
7. Take care in handling and disposing of lamps. If arc tube is broken, avoid skin contact with any of the contents
or fragments.
8. The arc tube of this lamp contains sodium and mercury. Dispose of in accordance with federal, state and local
requirements.
Made to order requires 3 week lead time
( o product returns on made to order lamps)
