Philips MCD700/93 User manual

MCD 700
MCL 707
Quick start guide
MCL707
MCD700
What’s in the Box?
You should find these items upon opening the box.
2
User Manual
1
Quick Start Guide
CompositeVideo Cable FM and MW antenna Remote Control
Quick Start Guide
User Manual
Control Cable
MCD700 QUG_Eng-93 2005.5.18, 2:56 PM1

Connect the speakers to the SPEAKERS (8ohm) terminals with two speaker cables. Right speaker to "R" and
left speaker to "L", red wire to "+" and silver wire to "–".
For radio reception, connect the supplied MW loop antenna wires to the AM AERIAL jack.
Connect the serial port marked CONTROL CABLE at the rear of the DVD player to the same port at the
rear of the power amplifier with the supplied control cable.
Connect the VIDEO OUTPUT jack at the rear of the DVD player to the video input jack on the TV using the
supplied video cable (yellow).
Connect the power cord of the DVD system to the AC power outlet.
1
2
3
Tip
See the User Manual for otherTV connection options.
4
5
AC power cord
Speaker
(Right)
Speaker
(Left)
FM antenna MW antenna
1
5
4
3
2
1
Speaker connection for MCL707
Tip
It is unnecessary to connect the FM pigtail antenna since it
is fixed to the main unit.
MCD700 QUG_Eng-93 2005.5.18, 2:56 PM2

Setting up the TV
Press STANDBY ONBon the front panel of the DVD player or B on the remote to switch the DVD system
on and then select the disc source.
Switch on the TV set and set to the correct video-in channel until the blue Philips DVD background screen
appears on the TV.
2
1
2
1
Tip
See your TV manual for more details.
3
Setting TV type and preferences
Press SYSTEM on the remote to enter the system menu.
Press 1 2 on the remote to enter the 'Preference Page'.Then, select the color
system matching your TV and the preferred audio, subtitle and disc menu languages
using 1 2 3 4 and OK on the remote.
Press 1 2 on the remote to enter the 'General Setup Page' and select the
preferred OSD language using 1 2 3 4 and OK on the remote.
IR SENSOR
MCD700 DVD/RECEIVER/POWER AMPLIFIER
STANDBY-ON
STANDBY-ON
Tip
You can enter the 'Preference Page' in full stop mode only.
MCD700 QUG_Eng-93 2005.5.18, 2:56 PM3

Loading a disc
Select the disc source, then press OPEN•CLOSE at the top of the DVD player or 0on the remote.
Load in a DVD disc with the label side facing up.
A disc menu pops up.
Playback
Use 1 2 3 4 and OK or Numeric Keypad (0-9) on the remote to select a playback feature or item.
Press PRESET/ÉÅ (orÉÅ on the remote) to start playback.
Types of Discs used
on this DVD System
2
1
3
Tip
Refer to the User Manual for playback of other types of discs.
2
1
Type
DVD VIDEO
AUDIO CD
VIDEO CD
MP3-CD
WMA
Record Playback Edit
DVD+RW
Super VCD
VIDEO CD
2005 © Koninklijie Philips Electronics N.V.
All rights reserved.
www.philips.com
