Philips GC2800 Series User manual

GC2800 SERIES

2

3
D E F GA B C
JKLM
H
I

4

GC2800 SERIES
ENGLISH 6
ESPAÑOL 18
ITALIANO 31
PORTUGUÊS 44

6
Introduction
Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
General description (Fig. 1)
ASpray nozzle
B Cap of lling opening
CSpray button 8
DSteam control
- b= Calc-Clean function
- 0 = no steam
- l= minimum steam
- ;= maximum steam
ESteam boost button \
FAuto-off light (GC2860 only)
GMains cord
HTemperature light
IAnti-Calc tablet (GC2860/GC2840/GC2830/GC2820 only)
Note:Anti-Calc tablet not visible from the outside.
JType plate
KWater tank
LTemperature dial
MSoleplate
Important
Read this user manual carefully before you use the appliance and save it
for future reference.
Danger
- Never immerse the iron in water.
Warning
- Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.
ENGLISH

- Do not use the appliance if the plug, the mains cord or the appliance
itself shows visible damage, or if the appliance has been dropped
or leaks.
- If the mains cord is damaged, you must have it replaced by Philips, a
service centre authorised by Philips or similarly qualied persons in
order to avoid a hazard.
- Never leave the appliance unattended when it is connected to the
mains.
- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
- Do not let the mains cord come into contact with the hot soleplate
of the iron.
Caution
- Only connect the appliance to an earthed wall socket.
- Check the mains cord regularly for possible damage.
- The soleplate of the iron can become extremely hot and may cause
burns if touched.
- When you have nished ironing, when you clean the appliance, when
you ll or empty the water tank and also when you leave the iron
even for a short while: set the steam control to position O, put the
iron on its heel and remove the mains plug from the wall socket.
- Always place and use the iron on a stable, level and horizontal
surface.
- Do not put perfume, vinegar, starch, descaling agents, ironing aids or
other chemicals in the water tank.
- This appliance is intended for household use only.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards regarding
electromagnetic elds (EMF). If handled properly and according to the
ENGLISH 7

instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.
Before rst use
1 Remove any sticker or protective foil from the soleplate.
2 Let the iron heat up to maximum temperature and pass the iron
over a piece of damp cloth for several minutes to remove any
residues from the soleplate.
Preparing for use
Filling the water tank
Do not put perfume, vinegar, starch, descaling agents, ironing aids,
chemically descaled water or other chemicals in the water tank.
1 Switch off the appliance and unplug it.
2 Set the steam control to position 0 (= no steam) (Fig. 2).
3 Openthecapofthellingopening.
4 Tilttheironandllthewatertankuptomaximumlevelunderthe
tap (Fig. 3).
Note: Do not ll the water tank beyond the MAX indication.
Note: If the tap water in your area is very hard, we advise you to use distilled
water. Do not use chemically descaled water.
5 Closethecapofthellingopening(‘click’).
Selecting the temperature and the steam settings
Fabric type Temperature
setting
Steam
setting
Steam boost
Linen MAX &Yes
Cotton 3&Yes
ENGLISH8

Fabric type Temperature
setting
Steam
setting
Steam boost
Wool 2$N.A.
Silk 10 N.A.
Synthetic fabrics (e.g.
Acrylic, nylon,
polyamide, polyester).
10 N.A.
- Check the laundry care label for the required ironing temperature:
If you do not know what kind or kinds of fabric an article is made of,
determine the right ironing temperature by ironing a part that will not be
visible when you wear or use the article.
Silk, woollen and synthetic materials: iron the reverse side of the fabric to
prevent shiny patches.Avoid using the spray function to prevent stains.
1 To set the appropriate ironing temperature, turn the temperature
dialtotheappropriateposition(see‘Temperatureandsteam
settingstable’)(Fig.4).
2 Settheappropriatesteamsetting(see‘Temperatureandsteam
settingstable’).
Note: Make sure that the steam setting you select is suitable for the set
ironing temperature.
3 Put the iron on its heel.
4 Put the mains plug in an earthed wall socket.
,The temperature light goes on.
5 When the temperature light goes out, wait a while before you start
ironing.
,During ironing, the temperature light goes on from time to time.
This indicates that the iron is heating up to the set temperature.
ENGLISH 9

Using the appliance
Note: The iron may give off some smoke when you use it for the rst time.
This stops after a short while.
Steam ironing
1 Make sure that there is enough water in the water tank.
2 Settherecommendedironingtemperature(seechapter‘Preparing
foruse’,‘Temperatureandsteamsettingtable’).
3 Set the appropriate steam setting. Make sure that the steam setting
is suitable for the ironing temperature selected:
- $for minimum steam (temperature settings 2and 3).
- &for maximum steam (temperature settings 3to MAX).
Note:The iron starts to produce steam as soon as it has reached the set
temperature.
Ironing without steam
1 Set the steam control to position 0 (= no steam) (Fig. 2).
2 Settherecommendedironingtemperature(seechapter‘Preparing
foruse’,‘Temperatureandsteamsettingtable’).
Features
Spray function
You can use the spray function at any temperature to moisten the article
to be ironed.This helps remove stubborn creases.
1 Make sure that there is enough water in the water tank.
2 Press the spray button several times to moisten the article to be
ironed (Fig. 5).
Steam boost function
A powerful boost of steam helps to remove very stubborn creases.
The steam boost function only works at temperature settings between
3and MAX.
ENGLISH10

1 Press and release the steam boost button (Fig. 6).
Vertical shot of steam
You can also use the steam boost function when you hold the iron in
vertical position.This is useful for removing creases from hanging clothes,
curtains etc.
1 Hold the iron in vertical position and press and release the steam
boost button (Fig. 7).
Never direct the steam at people.
Drip stop
This iron is equipped with a drip-stop function: the iron automatically
stops producing steam when the temperature is too low to prevent
water from dripping out of the soleplate.When this happens you hear a
click sound.
Automatic shut-off function (specic types only)
The automatic shut-off function automatically switches off the iron if it
has not been moved for a while.
,Theredauto-offlightashestoindicatethattheironhasbeen
switched off by the automatic shut-off function (Fig. 8).
To let the iron heat up again:
1 Pick up the iron or move it slightly.
,Theautomaticshut-offlightstopsashing.
,If the temperature of the soleplate has dropped below the set
ironing temperature, the temperature light goes on.
2 If the temperature light goes on after you have moved the iron,
wait for it to go out before you start ironing.
Note: If the temperature light does not go on after you move the iron, the
soleplate still has the right temperature and the iron is ready for use.
ENGLISH 11

Cleaning and maintenance
Cleaning
1 Set the steam control to position 0, remove the plug from the wall
socket and let the iron cool down.
2 Wipeakesandanyotherdepositsoffthesoleplatewithadamp
cloth and a non-abrasive (liquid) cleaning agent.
To keep the soleplate smooth, avoid hard contact with metal objects.
Never use a scouring pad, vinegar or other chemicals to clean the
soleplate.
3 Clean the upper part of the iron with a damp cloth.
4 Regularly rinse the water tank with water. Empty the water tank
after you have rinsed it (Fig. 9).
Double-Active Calc System (specic types only)
Note: Refer to chapter ‘General description’ for the specic type numbers.
The Double-Active Calc System consists of an Anti-Calc tablet inside the
water tank combined with the Calc-Clean function.
- The Anti-Calc tablet prevents scale from clogging the steam vents.
The tablet is constantly active and does not need to be
replaced (Fig. 10).
- The Calc-Clean function removes scale particles from the iron.
Calc-Clean function
Use the Calc-Clean function once every two weeks. If the water in your
area is very hard (i.e. when akes come out of the soleplate during
ironing), use the Calc-Clean function more frequently.
1 Make sure the appliance is unplugged.
2 Set the steam control to position 0.
3 Fill the water tank to the maximum level.
Do not pour vinegar or other descaling agents into the water tank.
4 Set the temperature dial to MAX (Fig. 11).
ENGLISH12

5 Put the mains plug in an earthed wall socket.
6 Unplug the iron when the temperature light goes out.
7 Hold the iron over the sink. Push the steam control to the Calc-
Clean position and hold it. Gently shake the iron to and
fro (Fig. 12).
,Steam and boiling water come out of the soleplate. Impurities and
akes(ifany)areushedout.
8 Release the steam control as soon as all the water in the tank has
been used up.
9 Repeat the Calc-Clean process if the iron still contains a lot of
impurities.
After the Calc-Clean process
1 Put the plug back into the wall socket and let the iron heat up to
let the soleplate dry.
2 Unplug the iron when the temperature light goes out.
3 Move the iron gently over a piece of used cloth to remove any
water stains that may have formed on the soleplate.
Storage
1 Set the steam control to position 0, remove the plug from the wall
socket and let the iron cool down.
2 Wind the mains cord round the cord storage facility (Fig. 13).
3 Store the iron on its heel in a safe and dry place.
Environment
- Do not throw away the appliance with the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the
environment (Fig. 14).
ENGLISH 13

Guarantee & service
If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Consumer Care Centre in
your country, go to your local Philips dealer.
Troubleshooting
This chapter summarises the most common problems you could
encounter with the appliance. If you are unable to solve the problem with
the information below, contact the Consumer Care Centre in your
country.
Problem Cause Solution
The iron is
plugged in, but
the soleplate is
cold.
There is a
connection
problem.
Check the mains cord, the plug
and the wall socket.
The temperature
dial is set to MIN. Set the temperature dial to the required position.
The iron does
not produce any
steam.
There is not
enough water in
the water tank.
Fill the water tank (see chapter
‘Preparing for use’, section
‘Filling the water tank’).
The steam control
is set to position 0. Set the steam position to $
or &(see chapter ‘Using the
appliance’, section ‘Steam
ironing’).
ENGLISH14

Problem Cause Solution
The iron is not hot
enough and/or the
drip-stop function
has been activated.
Set an ironing temperature
that is suitable for steam
ironing ( 2to MAX). Put the
iron on its heel and wait until
the temperature light goes out
before you start ironing.
The steam
boost function
does not work
properly.
You have used the
steam boost
function too often
within a very
short period.
Continue ironing in horizontal
position and wait a while
before you use the steam
boost function again.
The iron is not hot
enough. Set an ironing temperature at which the steam boost
function can be used ( 3
to MAX). Put the iron on its
heel and wait until the
temperature light goes out
before you use the steam
boost function.
Flakes and
impurities come
out of the
soleplate during
ironing.
Hard water forms
akes inside the
soleplate.
Use the Calc-Clean function
one or more times (see
chapter ‘Cleaning and
maintenance’, section ‘Calc-
Clean function’).
The light on the
handle ashes
(GC2860 only).
The automatic
shut-off function
has been activated
(see chapter
‘Features’, section
‘Automatic shut-
off’).
Pick the iron up or move it
slightly to deactivate the
automatic shut-off function.
The automatic shut-off light
goes out.
ENGLISH 15

Problem Cause Solution
Water droplets
drip on the
fabric during
ironing.
You have not
closed the cap of
the lling opening
properly.
Press the cap until you hear a
click.
The set
temperature is too
low for steam
ironing.
Set an ironing temperature
that is suitable for steam
ironing ( 2to MAX). Put the
iron on its heel and wait until
the temperature light goes out
before you start ironing.
You have put an
additive in the
water tank.
Rinse the water tank and do
not put any additive in the
water tank.
You have used the
steam boost
function at a
setting below
3.
Set the temperature dial to a
setting between 3and
MAX.
You have used the
steam boost
function too often
within a short
period.
Continue ironing in horizontal
position and wait a while
before you use the steam
boost function again.
Water drips
from the
soleplate after
the iron has
cooled down or
has been stored.
You have put the
iron in horizontal
position while
there was still
water in the water
tank.
Empty the water tank and set
the steam control to position
0 after use. Store the iron on
its heel.
ENGLISH16

Problem Cause Solution
Water spots
appear on the
garment during
ironing.
These wet spots
may be caused by
steam that has
condensed onto
the ironing board.
Iron wet spots without steam
from time to time to dry them.
If the underside of
the ironing board
is wet, wipe it dry
with a piece of dry
cloth.
To prevent steam from
condensing onto the ironing
board, use an ironing board
with wire mesh top.
ENGLISH 17

18
Introducción
Enhorabuena por la compra de este producto y bienvenido a Philips. Para
sacar el mayor partido de la asistencia que Philips le ofrece, registre su
producto en www.philips.com/welcome.
Descripción general (g. 1)
ABoquilla del spray
BTapa de la abertura de llenado
CBotón spray 8
DControl de vapor
- b= función Calc-Clean
- 0 = sin vapor
- l= vapor mínimo
- ;= vapor máximo
EBotón Supervapor \
FPiloto de desconexión automática (sólo modelo GC2860)
GCable de alimentación
HPiloto de temperatura
IPastilla antical (sólo modelos GC2860/GC2840/GC2830/GC2820)
Nota: La pastilla antical no es visible desde el exterior.
JPlaca de modelo
KDepósito de agua
LControl de temperatura
MSuela
Importante
Antes de usar el aparato, lea atentamente este manual de usuario y
consérvelo por si necesitara consultarlo en el futuro.
Peligro
- No sumerja nunca la plancha en agua.
Advertencia
- Antes de enchufar el aparato, compruebe si el voltaje indicado en el
mismo se corresponde con el voltaje de red local.
ESPAÑOL

- No utilice el aparato si la clavija, el cable de alimentación o el propio
aparato tienen daños visibles, o si el aparato se ha caído o está
goteando.
- Si el cable de alimentación está dañado, debe ser sustituido por
Philips o por un centro de servicio autorizado por Philips, con el n
de evitar situaciones de peligro.
- No deje nunca el aparato desatendido cuando esté enchufado a la
toma de corriente.
- Este aparato no debe ser usado por personas (adultos o niños) con
su capacidad física, psíquica o sensorial reducida, ni por quienes no
tengan los conocimientos y la experiencia necesarios, a menos que
sean supervisados o instruidos acerca del uso del mismo por una
persona responsable de su seguridad.
- Asegúrese de que los niños no jueguen con este aparato.
- No permita que el cable de alimentación entre en contacto con la
suela caliente de la plancha.
Precaución
- Conecte el aparato únicamente a un enchufe con toma de tierra.
- Compruebe el cable de alimentación con regularidad por si estuviera
dañado.
- La suela de la plancha puede calentarse mucho y, si se toca, puede
causar quemaduras.
- Cuando haya acabado de planchar, cuando limpie el aparato, cuando
llene o vacíe el depósito del agua o cuando deje la plancha aunque
sólo sea durante un momento, ajuste el control de vapor a la
posición O, ponga la plancha sobre su base de apoyo y desenchúfela
de la red.
- Ponga y utilice siempre la plancha sobre una supercie estable, plana
y horizontal.
- No eche en el depósito de agua perfume, vinagre, almidón, productos
desincrustantes, productos que ayuden al planchado ni otros
productos químicos.
- Este aparato es sólo para uso doméstico.
ESPAÑOL 19

Campos electromagnéticos (CEM)
Este aparato Philips cumple todos los estándares sobre campos
electromagnéticos (CEM). Si se utiliza correctamente y de acuerdo con
las instrucciones de este manual, el aparato se puede usar de forma
segura según los conocimientos cientícos disponibles hoy en día.
Antes de utilizarlo por primera vez
1 Quite cualquier pegatina o lámina protectora de la suela.
2 Deje que la plancha se caliente hasta la temperatura máxima y
pásela durante unos minutos sobre un paño húmedo para eliminar
cualquier residuo que pudiera haber en la suela.
Preparación para su uso
Llenado del depósito de agua
No eche en el depósito de agua perfume, vinagre, almidón, productos
desincrustantes, productos que ayuden al planchado, agua tratada
químicamente ni otros productos químicos.
1 Apague el aparato y desenchúfelo.
2 Pongaelcontroldevaporenlaposición0(=sinvapor)(g.2).
3 Abra la tapa de la abertura de llenado.
4 Incline la plancha y llene con el grifo el depósito de agua hasta el
nivelmáximo(g.3).
Nota: No llene el depósito de agua por encima de la indicación MAX.
Nota: Si el agua de su zona es muy dura, le aconsejamos que utilice agua
destilada. No utilice agua tratada químicamente para eliminar la cal.
5 Cierre la tapa de la abertura de llenado (“clic”).
ESPAÑOL20
