Philips Mistral GC2105 User manual

GC2225, GC2220, GC2215,
GC2130, GC2115, GC2110, GC2105

2

3
I
I
I
F
E
E
E
A
B
B
B
C
C
C
L
L
J
G
H
D
D
1
K

4

ENGLISH 6
POLSKI 14
ROMÂNĂ 23
РУССКИЙ 31
ČEŠTINA 41
MAGYAR 49
SLOVENSKY 57
УКРАЇНСЬКА 66
HRVATSKI 76
EESTI 84
LATVIEŠU 92
LIETUVIŠKAI 100
SLOVENŠČINA 108
БЪЛГАРСКИ 116
SRPSKI 126
134
GC2225, GC2220, GC2215, GC2130, GC2126, GC2125, GC2120, GC2115, GC2110, GC2105

General description (fig. 1)
ASpray nozzle
BFilling cap (GC2225/2220/2215/GC2130/2126/2125/2120 only)
CFilling opening
DShot-of-steam button 9
(GC2225/2220/2215/GC2130/2126/2125/2120/2115/2110 only)
ESpray button T
FSteam control
- O= no steam
- Á= minimum steam
- q= moderate steam
(GC2225/2220/2215/GC2130/2126/2125/2120 only)
- w= maximum steam
- 1= Calc-Clean function
GExtra-steam function (GC2105 only)
HTemperature light (all types) and automatic shut-off light
(GC2225/GC2130 only)
ITemperature dial
JMains cord
KType plate
LWater tank
Important
Read these instructions for use carefully before using the appliance and
save them for future reference.
◗Check if the voltage indicated on the type plate corresponds to
the local mains voltage before you connect the appliance.
◗Only connect the appliance to an earthed wall socket.
◗Do not use the appliance if the plug, the cord or the appliance
itself shows visible damage, or if the appliance has been dropped
or is leaking.
◗Check the cord regularly for possible damage.
◗If the mains cord is damaged, it must be replaced by Philips, a
service centre authorised by Philips or similarly qualified persons
in order to avoid a hazard.
◗Never leave the appliance unattended when it is connected to the
mains.
◗Never immerse the iron and the stand, if provided, in water.
◗Keep the appliance out of the reach of children.
◗The soleplate of the iron can become extremely hot and may
cause burns if touched.
◗Do not allow the cord to come into contact with the soleplate
when it is hot.
◗When you have finished ironing, when you clean the appliance,
when you fill or empty the water tank and also when you leave
the iron even for a short while: set the steam control to position
O, put the iron on its heel and remove the mains plug from the
wall socket.
ENGLISH6

◗Always place and use the iron and the stand, if provided, on a
stable, level and horizontal surface.
◗Do not put perfume, vinegar, starch, descaling agents, ironing aids
or other chemicals in the water tank.
◗This appliance is intended for household use only.
Preparing for use
Filling the water tank
1Remove the mains plug from the wall socket.
C2Set the steam control to position O (= no steam).
3Open the filling cap (specific types only).
C4Tilt the iron and fill the water tank up to maximum level.
Do not fill the water tank beyond the MAX indication.
5Close the filling cap (click!) (specific types only).
If the tap water in your area is very hard, we advise you to use distilled
water. Do not use vinegar, starch or chemically descaled water.
Setting the temperature
◗The iron may give off some smoke when you use it for the first
time.This will cease after a short while.
C1Put the iron on its heel and set the temperature dial to the
required ironing temperature by turning it to the appropriate
position.
- Check the garment label for the required ironing temperature.
-1Synthetic fabrics (e.g. acrylic, viscose, polyamide, polyester)
-1Silk
-2Wool
-3Cotton, linen
- If you do not know what kind or kinds of fabric an article is made of,
determine the right ironing temperature by ironing a part that will
not be visible when you wear or use the article.
- Silk, woollen and synthetic materials: iron the reverse side of the
fabric to prevent shiny patches. Avoid using the spray function to
prevent stains.
2Put the mains plug in an earthed wall socket.
ENGLISH 7

3When the temperature light has gone out, wait a while before
you start ironing.
BThe temperature light will go on from time to time during ironing.
Using the appliance
Steam ironing
Make sure that there is enough water in the water tank.
1Set the temperature dial to the recommended position.
See 'Setting the temperature'.
C2Set the steam control to the appropriate steam position.
-Áfor minimum steam (temperature settings 2and 3).
-Ëfor moderate steam (temperature settings 3to MAX)
(specific types only).
-Èfor maximum steam (temperature settings 3to MAX).
BSteaming will start as soon as the set temperature has been reached.
GC2215/2120/2115/2110/2105 only:
Water may leak from the soleplate if the set temperature is too low
(MIN to 2).
Ironing without steam
1Set the steam control to position O(= no steam).
2Set the temperature dial to the recommended position.
See 'Setting the temperature'.
Features
Spraying
To remove stubborn creases at any temperature
1Make sure that there is enough water in the water tank.
C2Press the spray button several times to moisten the garment to
be ironed.
ENGLISH8

Extra Steam (specific types only)
This function provides extra steam to remove really stubborn creases.
The Extra Steam function only works at temperature settings between
3and MAX.
C1Set the steam control to maximum position È.
C2Press and hold the Steam Control button down for max. 5
seconds.
3Wait at least 1 minute before using Extra Steam again to
prevent water from dripping out of the soleplate.
Shot of Steam (specific types only)
A powerful shot of steam helps to remove very stubborn creases.
The Shot-of-Steam function only works at temperature settings
between 2and MAX.
C1Press and release the Shot-of-Steam button.
Vertical Shot of Steam
(GC2225/2220/2215/2130/2126/2125/2120/2115 only)
C1The Shot-of-Steam function can also be used when you are
holding the iron in vertical position.This is useful for removing
creases from hanging clothes, curtains, etc.
Never direct the steam towards people.
Drip stop (GC2225/2220/GC2130/2126/2125 only)
This iron is equipped with a drip stop function: the iron automatically
stops steaming when the temperature is too low to prevent water
from dripping out of the soleplate.When this happens you will hear a
click.
ENGLISH 9

Automatic shut-off (specific types only)
An electronic safety device will automatically switch the heating
element off if the iron has not been moved for a while.
C◗To indicate that the heating element has been switched off, the
automatic shut-off light will start blinking.
To heat up the iron again: pick it up or move it slightly.The automatic
shut-off light will go out.
1If the temperature light goes on, wait for it to go out before
you start ironing.
2If the temperature light does not go on, the iron is ready for
use.
Cleaning and maintenance
Calc-Clean function
◗The Calc-Clean function removes the scale particles.
Use the Calc-Clean function once every two weeks. If the water in
your area is very hard (i.e. when flakes come out of the soleplate
during ironing), the Calc-Clean function should be used more
frequently.
1Set the steam control to position O.
2Fill the water tank to the maximum level.
Do not pour vinegar or other descaling agents into the water tank..
C3Set the temperature dial to MAX.
4Put the plug in the wall socket.
5Unplug the iron when the temperature light has gone out.
6Hold the iron over the sink and set the steam control to
position 1(Calc-Clean).The steam control knob will spring up
slightly.
C7Pull the steam control knob upwards to remove the steam
control needle.
ENGLISH10
