Philips 19PFL3403 User manual

Philips
LCD TV with Crystal Clear
III
48 cm (19")
HD Ready
19PFL3403
Clearly the smart choice
Designed for ease of use, this Flat TV features modern design, 2 HDMI connections, a
powerful and brilliant Crystal Clear III engine. Making the smart choice in total picture
quality has never been easier.
Superb picture quality
• Crystal Clear III for natural images with enhanced quality
• HD LCD display, with a 1440 x 900p resolution
• HD Ready for the highest quality display of HD signals
• Up to 5ms response time for clear, fast moving action
Hear crisp and clear sound
• Incredible Surround for enhanced audio enjoyment
Connect, install and enjoy
• 2 HDMI inputs for full digital HD connection in one cable
• EasyLink: easy control of TV & connected device via HDMI CEC
• PC-input allows you to use your TV as a PC monitor
• Smart Picture and Smart Sound to personalize your viewing

19PFL3403/10
Highlights
LCD TV with Crystal Clear III
48 cm (19") HD Ready
Crystal Clear III
Crystal Clear III combines a whole range of
enhancements to provide a better picture.
They include a 2D Comb filter, Dynamic
contrast, Blue stretch and Green enhancement
so that you always get the most natural looking
colors.
LCD display, 1440 x 900p
This WXGA+ display with state-of-the-art
LCD screen technology gives you widescreen
HD resolution of 1440 x 900p pixels. It
produces brilliant flicker-free progressive scan
pictures with optimum brightness and superb
colors. This vibrant and sharp image will
provide you with an enhanced viewing
experience.
HD Ready
Enjoy the exceptional picture quality of High
Definition pictures and be fully prepared for
HD sources like HDTV settop box or Blu-ray
disc. HD Ready is a protected label that offers
picture quality beyond that of progressive scan.
It conforms to strict standards laid out by
EICTA to offer a HD screen that displays the
benefits of resolution and picture quality of a
High Definition signal. It has a universal
connection for both analog YPbPr and
uncompressed Digital connection of DVI or
HDMI, supporting HDCP. It can display 720p,
and 1080i signals at 50 and 60Hz.
Incredible Surround
Incredible Surround is an audio technology
from Philips that dramatically magnifies the
sound field to immerse you in the audio. Using
state-of-the-art electronic phase shifting,
Incredible Surround mixes sounds from left
and right in such a way that it expands the
virtual distance between the two speakers.
This wider spread greatly enhances the stereo
effect and creates a more natural sound
dimension. Incredible Surround allows you to
experience total surround with greater depth
and width of sound, without the use of
additional speakers.
2 HDMI inputs
HDMI makes an uncompressed digital RGB
connection from the source to the screen for
the ultimate picture quality. HDMI intelligently
communicates the highest output resolution
with the source device. The HDMI input is fully
backward compatible with DVI sources and
includes digital audio. HDMI uses HDCP copy
protection. With one HDMI inputs on the back
and one HDMI on the side of the TV you can
connect multiple HD sources, for instance an
HD settop box, a Blu-ray player, and game
console or digital Camcorder. Your TV is fully
prepared for the HD future.
EasyLink
EasyLink uses the HDMI CEC industry
standard protocol to share functionality
between connected devices and the TV. With
EasyLink only one remote control is needed to
operate main functionalities on your TV and
connected devices. EasyLink uses the standard
HDMI cable to transfer system commands. It
works between all electronic devices equipped
with HDMI CEC.
Smart Picture and Smart Sound
Philips preset modes for Smart Picture and
Smart Sound provide you with direct access via
a single key on the remote control. You can
select optimized picture and sound settings for
the various picture and sound modes.

Issue date 2012-01-20
Version: 3.0.8
12 NC: 8670 000 35165
EAN: 87 12581 37657 4
© 2012 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
HDMI side
S-VIDEO R - AUDIO - L VIDEO IN
EXT 2
19PFL3403/10
Specifications
LCD TV with Crystal Clear III
48 cm (19") HD Ready
Picture/Display
• Aspect ratio: Widescreen
• Brightness: 300 cd/m²
• Contrast ratio (typical): 1000:1
• Response time (typical): 5 ms
• Viewing angle: 170º (H) / 160º (V)
• Diagonal screen size: 19 inch / 48 cm
• Display screen type: LCD WXGA+ Active Matrix
TFT
•Panel resolution: 1440 x 900p
• Picture enhancement: Crystal Clear III, 2D
Combfilter, 3/2 - 2/2 motion pull down, White
stretch, Progressive scan, Smart Picture
• Screen enhancement: Anti-Reflection coated
screen
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
1280 x 1024 60Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 24, 50, 60Hz
Sound
• Output power (RMS): 2 x 3W
• Sound Enhancement: Auto Volume Leveller,
Incredible Surround, Smart Sound
• Sound System: Mono, Stereo
Convenience
• Clock: Sleep Timer, Start timer, Stop timer
• Connection Enhancement: Easy link
• Ease of Installation: Auto Program Naming,
Automatic Channel Install(ACI), Automatic Tuning
System (ATS), Autostore, Fine Tuning, Plug & Play
• Ease of Use: Auto Volume Leveller (AVL), On
Screen Display, Program List, Side Control, Smart
Picture, Smart Sound
• Picture in Picture: Text dual screen
• Remote Control: TV
• Remote control type: RCPF01E08B
• Screen Format Adjustments: 4:3, Movie expand
14:9, Movie expand 16:9, Subtitle Zoom, Super
Zoom, Widescreen
• Teletext: 100 page Smart Text
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,
SECAM D/K, SECAM L/L'
• Video Playback: NTSC, SECAM, PAL
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in/out, RGB
• Ext 2: S-video in, CVBS in, Audio L/R in
• Ext 3: YPbPr, Audio L/R in
•HDMI1:HDMIv1.3
•HDMI2:HDMIv1.3
• EasyLink (HDMI-CEC): One touch play, System
standby
• Other connections: Headphone out, PC Audio in,
PC-In VGA
Power
• Ambient temperature: 5 °C to 35 °C
• Mains power: 100-240V, 50/60Hz
• Power consumption: 46.5 W
• Standby power consumption: <0.3 W
Dimensions
•Setdimensions(Wx H x D): 468 x 349 x 69 mm
• Set dimensions with stand (W x H x D):
468 x 392 x 166 mm
• Weight incl. Packaging: 5.84 kg
• Product weight: 3.9 kg
• Product weight (+stand): 4.4 kg
•Boxdimensions(Wx H x D):
512x 458 x 136 mm
• VESA wall mount compatible: 100 x 100 mm
Accessories
• Included accessories: Table top stand, Power cord,
Quick start guide, User Manual, Warranty
certificate, Remote Control, Batteries for remote
control
•
