Philips 20PFL4122 User manual

Philips
Flat TV with Crystal Clear
III
51 cm (20")
LCD
20PFL4122
Turn up your viewing experience
with Crystal Clear III
Here is an LCD TV that not only enhances the décor of your home with its European
styling and slim design, but also provides a great audio-visual experience with Crystal
Clear III and Incredible Surround™.
Vivid, natural and razor sharp images
• Enhanced-definition LCD VGA display, 640 x 480p
• Crystal Clear III for natural images with enhanced quality
• Progressive Scan component video for optimized image quality
Exciting and lifelike sound
• Incredible Surround™ for enhanced audio enjoyment
Stylish design
• Compact and slim design that fits in every room
Designed for your convenience
• Smart Picture and Smart Sound to personalize your viewing
• 1000 page Hypertext for instant fast access to teletext
• PC input lets you also use your TV as a PC monitor
For advanced performance
• HDMI input for full digital HD connection in one cable

20PFL4122/10
Highlights
Flat TV with Crystal Clear III
51 cm (20") LCD
LCD VGA display, 640 x 480p
This VGA display with state-of-the-art LCD
screen technology has an enhanced resolution
of 640 x 480p.
Crystal Clear III
Crystal Clear III combines a whole range of
enhancements to provide a better picture.
They include a 2D Comb filter, Dynamic
contrast, Blue stretch and Green enhancement
so that you always get the most natural looking
colors.
Progressive Scan
Progressive Scan doubles the vertical
resolution of the image resulting in a noticeably
sharper picture. Instead of sending a field
comprising the odd lines to the screen first,
followed by the field with the even lines, both
fields are written at one time. A full image is
created instantaneously, using the maximum
resolution. At such a speed, your eye perceives
a sharper picture with no line structure.
Incredible Surround™
Incredible Surround is an audio technology
from Philips that dramatically magnifies the
sound field to immerse you in the audio. Using
state-of-the-art electronic phase shifting,
Incredible Surround mixes sounds from left
and right in such a way that it expands the
virtual distance between the two speakers.
This wider spread greatly enhances the stereo
effect and creates a more natural sound
dimension. Incredible Surround allows you to
experience total surround with greater depth
and width of sound, without the use of
additional speakers.
Compact and slim design
This design style emphasizes a slim, compact
look that saves space and fits in anywhere.
Smart Picture and Smart Sound
Philips preset modes for Smart Picture and
Smart Sound provide you with direct access via
a single key on the remote control. You can
select optimized picture and sound settings for
the various picture and sound modes.
1000 page Hypertext
The teletext is a common system transmitted
by most broadcasters. The 1000 page smart
text feature gives you extremely fast access to
information when changing pages.
HDMI input
HDMI makes an uncompressed digital RGB
connection from the source to the screen. By
eliminating conversion to an analog signal, it
delivers an unblemished image. The non-
degraded signal reduces flicker and leads to a
clearer picture. HDMI intelligently
communicates the highest output resolution
with the source device. The HDMI input is fully
backward compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy
protection.
PC input
With PC input you can connect your TV to a
computer and use the TV as a PC monitor.

Issue date 2012-01-20
Version: 6.0.21
12 NC: 8670 000 27677
EAN: 87 12581 31982 3
© 2012 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
20PFL4122/10
Specifications
Flat TV with Crystal Clear III
51 cm (20") LCD
Picture/Display
• Color cabinet: Silver, in mould black
• Aspect ratio: 4:3
• Brightness: 450 cd/m²
• Contrast ratio (typical): 800:1
• Response time (typical): 25 ms
• Viewing angle (H / V): 178 / 178 degree
• Diagonal screen size: 20 inch / 51 cm
• Display screen type: LCD VGA Active Matrix TFT
• Panel resolution: 640 x 480p
• Picture enhancement: Crystal Clear III, 2D
Combfilter, Blue stretch, Green enhancement,
Color Temperature Adjustment, Progressive scan,
Automatic skin tone correction
• Screen enhancement: Anti-Reflection coated
screen
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 60Hz
720p 50, 60Hz
1080i 60Hz
1080i 50, 60Hz
1080p 60Hz
1080p 50Hz
1080p 24, 50, 60Hz
Sound
• Output power (RMS): 2 x 3W
• Sound Enhancement: Incredible Surround
• Sound System: Mono, Nicam Stereo, Stereo
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Ease of Installation: Auto Program Naming,
Automatic Channel Install(ACI), Automatic Tuning
System (ATS), Autostore, Fine Tuning, PLL Digital
Tuning, Plug & Play, Sorting
• Ease of Use: Auto Volume Leveller (AVL), On
Screen Display, Program List, Smart Picture, Smart
Sound, Top Controls
• Remote control type: C19335016/01B
• Screen Format Adjustments: 16:9 compress, 4:3,
4:3 expand
• Teletext: 1000 page Smart Text
• Teletext enhancements: Program information Line
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,
SECAM D/K, SECAM L/L'
• Video Playback: NTSC, SECAM, PAL
• Tuner bands: Hyperband, S-Channel, UHF, VHF
• Number of Preset Channels: 100
•TunerDisplay:PLL
Connectivity
• AV 1: Audio L/R in, CVBS in, S-Video
• AV 2: Audio L/R in, YPbPr
•AV3:HDMI
• Ext 1 Scart: CVBS in/out, RGB
•NumberofScarts:1
• Other connections: Headphone out, PC Audio in,
PC-In VGA
Power
• Ambient temperature: 5 °C to 40 °C
• Mains power: 90-240 VAC, 50/60 Hz
• Power consumption: 55 W
• Standby power consumption: < 1 W
Accessories
• Included accessories: Table top stand, Power cord,
Quick start guide, User Manual, Registration card,
Warranty certificate, Remote Control, Batteries
for remote control
Dimensions
•Setdimensions(Wx H x D):
497 x 429 x 80.5 mm
• Set dimensions with stand (W x H x D):
497 x 472 x 218 mm
• Product weight: 7.5 kg
• Product weight (+stand): 8.55 kg
•Boxdimensions(Wx H x D):
548x 528 x 185 mm
• Weight incl. Packaging: 10.2 kg
• VESA wall mount compatible: 100 x 100 mm
•
