Philips 32PFL5605H User manual

Philips 5000 LED series
LCD TV with Pixel Plus
HD
32"
Full HD 1080p digital TV
32PFL5605H
Entertainment comes to life
with brilliant LED picture performance
Live the moment as if you were there with Pixel Plus HD and an impressive invisible
sound.
Your entertainment in brilliant detail
• Full HD TV with Pixel Plus HD for better details and clarity
• Brilliant LED images with low power consumption
• 100 Hz LCD, 2 ms performance for superb motion sharpness
• HD Natural Motion for ultra-smooth motion in Full HD movies
Rich and clear sound.
• 2.1 system for 40 W surround sound (2 x 10 W plus virtual 20 W)*
• Hear every word with Clear Sound
Complete digital connectivity made simple
• Seamless connectivity with 3 HDMI inputs and Easylink
• USB for fantastic multimedia playback
• Integrated Digital DVB-C/T Tuner for digital cable reception
Greener every day
• LED is up to 40% more energy efficient than normal LCD TVs
• 0 W Power Consumption when switched off

32PFL5605H/05
Highlights
LCD TV with Pixel Plus HD
32" Full HD 1080p digital TV
Pixel Plus HD
Pixel Plus HD offers the unique combination of
ultimate sharpness, natural detail, vivid colours
and smooth natural motion on all qualities of
HD, standard TV signals and multimedia
content, for high definition displays. Artefacts
and noise in all sources from multimedia to
standard TV and also in highly compressed HD
are detected and reduced ensuring that the
picture is clear and razor sharp.
LED
LED lighting technology is the most advanced
available. In this TV it combines an eye-catching
minimalistic design with stunning image quality,
as well as having the lowest power
consumption in its category. Another
environmental benefit is that LED lighting
technology does not contain hazardous
materials. With an LED backlight you can enjoy
low power consumption, high brightness,
incredible contrast and sharpness and vibrant
colours.
100 Hz LCD, 2 ms response time
100 Hz LCD creates extreme motion
sharpness. The Double Frame Rate Insertion
increases the sharpness of motion
reproduction to more than twice that of
conventional LCD, resulting in a performance
with a response time of 2 milliseconds. Now
you can enjoy clear images even with fast on-
screen motion.
HD Natural Motion
Philips invented HD Natural Motion to
minimise juddering effects that are visible with
movie-based picture content. The award
winning algorithm estimates motion in the
picture and corrects juddering movements in
both broadcast and recorded movie material
(such as DVD and Blu-ray Disc). The resulting
smooth motion reproduction and excellent
sharpness take the viewing experience to a
higher level.
2.1 sound system 40 W*
Virtual 2.1 speaker system for an incredible 40
W sound (2 x 10 W + 20 W Virtual Power*).
*This virtual 2.1 speaker system manages
power intelligently to deliver twice the original
power supplied and produces an excellent
bass. Enjoy the purity and detailed sound with
the additional dome tweeter which delivers
uncompromised sound in a slim invisible
speaker design.
3 HDMI inputs with Easylink
HDMI is a single cable to carry both picture
and audio signals from your devices to your
TV, saving you from cable clutter. It carries
uncompressed signals, ensuring that you have
the highest quality from source to screen.
Together with Philips Easylink, you need only
one remote control to perform most
operations on your TV, DVD, Blu-ray, set top
box or home theatre system. Enjoy high quality
picture and sound without clutter or fuss.
Matching home theatre experience
Take your home cinema experience to
the next level with the Philips SoundHub
home theatre 5000 series. Bring every
detail to life, and experience fully
immersive, crystal clear surround sound.
Enquire more about this unique
combination today at www.philips.com
x3

Issue date 2010-09-06
Version: 5.4.9
12 NC: 8670 000 60078
EAN: 87 12581 52615 3
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
32PFL5605H/05
Specifications
LCD TV with Pixel Plus HD
32" Full HD 1080p digital TV
Picture/Display
• Colour cabinet: High gloss black deco front with
black cabinet
• Peak Luminance ratio: 65 %
• Aspect ratio: Widescreen
• Brightness: 450 cd/m²
• Dynamic screen contrast: 500,000:1
• Response time (typical): 2 ms
• Viewing angle: 176º (H)/176º (V)
• Diagonal screen size: 32 inch / 81 cm
• Display: LCD Full HD, direct LED backlight
• Panel resolution: 1920 x 1080p
• Picture enhancement: 100 Hz, 2 ms, Pixel Plus HD,
Active Control + Light sensor, Colour
Enhancement, 100 Hz Clear LCD, Digital Noise
Reduction, Dynamic contrast enhancement,
Luminance Transient Improver, MPEG artefact
reduction, 2D/3D noise reduction, 1080p 24/25/
30 Hz processing, 1080p 50/60 Hz processing, HD
Natural Motion, LED backlight Display
• Screen enhancement: Anti-Reflection coated
screen
Supported Display Resolution
• Computer inputs: up to 1920 x 1080 @ 60 Hz
• Video inputs: up to 1920 x 1080p, 24, 25, 30, 50, 60
Hz
Sound
• Output power (RMS): 40 W virtual, Invisible Sound
• Sound Enhancement: Auto Volume Leveller,
Incredible Surround, Treble and Bass Control,
Clear Sound
• Sound System: Mono, Nicam Stereo, Stereo
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Connection Enhancement: Easy link
• Ease of Installation: Channel installation wizard,
Settings assistant wizard, Device connection
wizard, Auto detect Philips devices, Auto
Programme Naming, Autoinstall, Programme
Name, Sorting
• Ease of Use: Smart Picture, Smart Sound, On-
screen User manual, EasyLink, Favourite
programme selection, Mozaïc channel grid, One-
stop experience button, One-stop Home button
• Electronic Programme Guide: Now + Next EPG*
• Screen Format Adjustments: Auto Format, Super
Zoom, Movie expand 16:9, Widescreen, unscaled
(1080p dot by dot)
• Teletext: 1200-page Hypertext
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB
• Multimedia: USB autobreak-in, USB media browser
Multimedia Applications
• Multimedia connections: USB memory class device
• Picture Playback Formats: JPEG
• Music Playback Formats: MP3
• Video Playback Formats: Codec support:, H264/
MPEG-4 AVC, MPEG-1, MPEG-2, MPEG-4
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G,
SECAM D/K, SECAM L/L', DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• Digital TV: DVB Terrestrial*, DVB-T MPEG4*,
DVB-C MPEG4*
•Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Summary: 3 x HDMI, 1 x USB, 1 x SCART
• Ext 1 Scart: Audio L/R, CVBS in, RGB
• Ext 2: YPbPr in, Audio L/R in
• VGA-in: PC input, D-sub 15
•HDMI1:HDMIv1.4(AudioReturn Ch.)
•HDMI2:HDMIv1.3
• Front/Side connections: HDMI v1.3, USB
• Other connections: Headphone out, Common
Interface Plus (CI+)
• EasyLink (HDMI-CEC): One touch play, EasyLink,
Pixel Plus link, Remote control pass-through,
System audio control, System standby
• Audio Output - Digital: Coaxial (cinch)
Power
• Off mode power consumption: < 0.01 W
• Green label: ECO label certified
• Presence of lead: Yes*
• Annual energy consumption: 103.66 kW·h
• Ambient temperature: 5°C to 35°C
• Mains power: 220-240 V ~ ;50-60 Hz
• Power consumption (typical): 71 W
• Standby power consumption: < 0.15 W
• Power Saving Features: 0 Watt Power-off switch,
Light sensor, Eco mode
Dimensions
•Setdimensions(Wx H x D):
790 x 501.3 x 92 mm
• Set dimensions with stand (W x H x D):
790 x 542.4 x 221.4 mm
• Weight incl. Packaging: 13.5 kg
• Product weight: 10 kg
• Product weight (+stand): 11.5 kg
•Boxdimensions(Wx H x D):
968 x 585 x 198 mm
• VESA wall mount compatible: 200 x 200 mm
Accessories
• Included accessories: Tabletop stand, Quick start
guide, Registration card, Warranty Leaflet, Remote
Control, 2 x AAA Batteries, Safety/legal
instructions, Software declaration
•
* 8 days EPG, service not available in all countries
* Typical on-mode power consumption measured according to
IEC62087 Ed 2.
* The TV supports DVB reception for 'Free to air' broadcast. Specific
DVB operators may not be supported. An up to date list can be
found in the FAQ section of the Philips support website. For some
operators Conditional Access and subscription are required.
Contact your operator for more information.
* Annual energy consumption is calculated using the typical power
consumption 4 hours per day, 365 days per year.
* This television contains lead only in certain parts or components
where no technology alternatives exist in accordance with existing
exemption clauses under the RoHS Directive.
REAR CONNECTORS
BOTTOM REAR CONNECTORS
SIDE CONNECTORS
