Philips 8000 series
LCD TV with Ambilight
Spectra and Pixel Precise
HD
42"
Full HD 1080p digital TV
42PFL8694H
Enjoy a movie night in
with Ambilight
Treat yourself to a movie night in. Enjoy the pleasure of the movies in your living room
with Pixel Precise HD and the immersive power of Ambilight.
Immersive viewing experience
• Ambilight Spectra enhances the viewing experience
See precise details in action
• Pixel Precise HD for extremely sharp and clear pictures
• Full HD LCD display, with a 1920 x 1080p resolution
• Perfect Natural Motion for ultra-smooth Full HD movies
• 100 Hz LCD, 3 ms performance for superb motion sharpness
Exciting and powerful sound
• 2 x 12 W with BBE for fresh, clear sound
Connect and enjoy the online world
• Net TV for popular online services on your TV
• DLNA PC network link for watching videos from your computer
Ready for digital
• MPEG4 HDTV reception via DVB-T and DVB-C tuner with CI+*

42PFL8694H/12
Highlights
LCD TV with Ambilight Spectra and Pixel Precise HD
42" Full HD 1080p digital TV
Ambilight Spectra
Add a new dimension to your viewing
experience with Ambilight Spectra. This
patented Philips technology enlarges the
screen further by projecting a glow of light
from the back of the screen onto the
surrounding wall. Ambilight automatically
adjusts the colour and brightness of the light
surrounding the TV to match the picture,
creating an immersive viewing experience.
With Ambilight Spectra movies truly come to
life!
Full HD LCD display 1920 x 1080p
The Full HD screen has the widescreen
resolution of 1920 x 1080p. This is the highest
resolution of HD sources for the best possible
picture quality. It is fully future-proof as it
supports 1080p signals from all sources,
including the most recent sources such as Blu-
ray and advanced HD game consoles. The
signal processing is extensively upgraded to
support this much higher signal quality and
resolution. It produces brilliant flicker-free
progressive scan pictures with superb
brightness and colours.
Net TV
Experience a rich selection of online services
with Net TV. Enjoy movies, pictures,
infotainment and other online content directly
on your TV whenever you like. Simply connect
your home theatre directly to your home
network through the Ethernet connection, and
navigate and select what you want to watch
with the remote control. The Philips menu
gives you access to popular Net TV services
fitted for your TV screen. Additionally, with
the DLNA certified PC network you can watch
videos or access pictures stored on your
computer using your remote control.
Perfect Natural Motion
Enjoy the action without any judder. Perfect
Natural Motion estimates motion in the
picture and corrects juddering movements in
both broadcast and pre-recorded movie
material (including 1080p movies and 24p True
Cinema on Blu-ray and DVD). The result is
even smoother and quieter pictures with
excellent sharpness. Enjoy motion
performance that surpasses cinema quality!
100 Hz LCD (3 ms)
100 Hz LCD creates extreme motion
sharpness for clear and vibrant images even
with fast on-screen motion. The Double Frame
Rate Insertion works with a high 100 Hz
refresh rate. It increases the sharpness of
motion reproduction to more than twice that
of conventional LCD, resulting in a
performance with a response time of 3
milliseconds (measured in Perceived Blur-
Edge-Width: BEW). This unique Philips
technology takes motion sharpness of LCD
displays to an unprecedented level.
2 x 12 W with BBE
BBE high definition sound is the core sound
enhancement technology (licensed by BBE
Sound) that will enable you to experience real
natural music and speech intelligibility with rich
and clear audible vocals.
ECO Flower
Over the last 10 years we
have worked hard to
lower our environmental
impact and will continue to
do so. Our eco-design
process aims to create Philips televisions
that are increasingly eco-friendly and that
have significantly less impact on the
environment. Philips has been awarded
the EU ECO label (the flower) on the
majority of its models because of the
televisions' high energy efficiency, ultra
low standby power (up to 50% less than
the required EU ECO label level), absence
of hazardous substances (e.g. lead) and the
fact that Philips has designed televisions
that can be easily recycled.

Issue date 2010-09-03
Version: 10.1.6
12 NC: 8670 000 53231
EAN: 87 12581 48579 5
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
42PFL8694H/12
Specifications
LCD TV with Ambilight Spectra and Pixel Precise HD
42" Full HD 1080p digital TV
Picture/Display
• Aspect ratio: Widescreen
• Brightness: 500 cd/m²
• Dynamic screen contrast: 80,000:1
• Response time (typical): 3 ms
• Viewing angle: 176º (H)/176º (V)
• Diagonal screen size: 42 inch / 107 cm
• Display screen type: LCD Full HD W-UXGA Act.
matrix
• Panel resolution: 1920 x 1080p
• Picture enhancement: Pixel precise HD, Perfect
Natural Motion, 3/2 - 2/2 motion pull down, 3D
Combfilter, Active Control + Light sensor, Digital
Noise Reduction, Dynamic contrast enhancement,
Luminance Transient Improver, Progressive scan,
2D/3D noise reduction, 100 Hz LCD
• Screen enhancement: Anti-Reflection coated
screen
• Colour processing: 4 trillion colours (14-bit RGB)
Ambilight
• Ambilight Features: Ambilight Spectra, Lounge light
mode
• Dimming Function: Manual and via Light Sensor
• Ambilight light system: LED-wide colour
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60 Hz
800 x 600 60 Hz
1024 x 768 60 Hz
1280 x 1024 60 Hz
1360 x 768 60 Hz
1600 x 1200 60 Hz
1920 x 1080 60 Hz
•Video formats
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576i 50 Hz
576p 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 24, 25, 30, 50, 60 Hz
Sound
• Output power (RMS): 2 x 12 W
• Sound Enhancement: Incredible Surround, Treble
and Bass Control
• Sound System: Nicam Stereo, BBE
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Ease of Installation: Auto Programme Naming,
Automatic Channel Install (ACI), Automatic
Tuning System (ATS), Autostore, Fine Tuning, PLL
Digital Tuning, Plug and Play
• Ease of Use: Auto Volume Leveller (AVL), Delta
Volume per preset, Programme List, Settings
assistant Wizard, One-stop Home button,
Favourite programme selection
• Electronic Programme Guide: Now + Next EPG,
8-day Electronic Programme Guide*
• Remote Control: Universal
• Remote control type: RC4495
• Screen Format Adjustments: Auto Format, Movie
expand 16:9, Super Zoom, Widescreen, unscaled
(1080p dot by dot)
• Teletext: 1000-page Smart Text
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB
• Multimedia: DLNA media Browser, Internet
browser, Net TV services, USB media browser
• Smart mode: Game, Cinema, Personal, Standard,
Vivid
Multimedia Applications
• Multimedia connections: Ethernet-UTP5, USB
• Playback Formats: MP3, LPCM, WMA v2 up to
v9.2, JPEG Still pictures, MPEG1, MPEG2, MPEG4,
AVI, H.264/MPEG-4 AVC, MPEG-Programme-
stream PAL, WMV9/VC1
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• Digital TV: DVB-T MPEG4*, DVB-C MPEG4*
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in, RGB
• Ext 2 Scart: Audio L/R, CVBS in, RGB
• Ext 3: YPbPr, Audio L/R in
• Front/Side connections: HDMI v1.3, S-video in,
CVBS in, Audio L/R in, Headphone out, USB
•PC network link: DLNA 1.0 certified
• Other connections: Analogueaudio Left/Right out,
PC Audio in, PC-In VGA, S/PDIF out (coaxial),
Common Interface Plus (CI+), Common Interface
•HDMI1:HDMIv1.3
•HDMI2:HDMIv1.3
•HDMI3:HDMIv1.3
• EasyLink (HDMI-CEC): One touch play, Remote
control pass-through, System audio control,
System standby
Power
• Ambient temperature: 5°C to 35°C
• Mains power: 220 - 240 V, 50 Hz
• Power consumption (typical): 146 W
• Standby power consumption: 0.15 W
Dimensions
•Setdimensions(Wx H x D): 996 x 603 x 88 mm
• Set dimensions with stand (W x H x D):
996 x 656 x 260 mm
• Weight incl. Packaging: 26.3 kg
• Product weight: 17.7 kg
• Product weight (+stand): 21.9 kg
•Boxdimensions(Wx H x D):
1203 x 682 x 266 mm
• Colour cabinet: Black deco front with brilliant
pearl speakers
• VESA wall mount compatible: 400 x 400 mm
Accessories
• Included accessories: Tabletop swivel stand, Power
cord, Quick start guide, User Manual, Warranty
certificate, Remote Control, Batteries for remote
control
•
* DVB-T, supported in selected countries only
* DVB-C in selected countries and for selected operators only. Most
up to date information is available on the type plate of the TV.
* Net TV, service offering is dependent on country and subject to
terms of use.
EXT 2
(RGB/CVBS)
EXT 1
(RGB/CVBS)
SPDIF
OUT
AUDIO
VGA
TV ANTENNA
HDMI 3
AUDIO IN:
LEFT / RIGHT
HDMI 1 / DVI
HDMI 2 / DVI
HDMI 3 / DVI
VGA
EXT 3 HDMI 2 HDMI 1
OUT
NETWORK
