Philips BTM2180 User manual

Philips
Micro music system
Bluetooth®
CD, USB, FM
70W max
BTM2180
Rich and powerful sound
Obsessed with sound
Listen to all your digital music from your Smartphone via Bluetooth. This Philips Micro
system also plays MP3-CD and CD-R/RW, and features Bass Reflex speakers for
powerful and dramatic bass.
Enjoy your music from multiple sources
• Wireless music streaming via Bluetooth
• Play MP3-CD, CD and CD-R/RW
• USB Direct for easy MP3 music playback
• Audio-in for portable music playback
Enrich your sound experience
• Bass Reflex Speaker System delivers a powerful, deeper bass
• Digital Sound Control
• Dome tweeter for detailed and natural sound
• 70W RMS maximum output power
Easy to use
• Motorized CD loader for convenience access
• Digital tuning with preset stations for extra convenience

Issue date 2016-05-11
Version: 1.0.7
12 NC: 8670 001 02917
UPC: 6 09585 23369 0
© 2016 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
Highlights
BTM2180/37
Micro music system
Bluetooth® CD, USB, FM, 70W max
Specifications
Wireless music streaming
Bluetooth is a short range wireless communication
technology that is both robust and energy-efficient.
The technology allows easy wireless connection to
iPod/iPhone/iPad or other Bluetooth devices, such as
smartphones, tablets or even laptops. So you can
enjoy your favorite music, sound from video or game
wireless on this speaker easily.
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep bass
experience from a compact loudspeaker box system.
It differs from a conventional loudspeaker box
system in the addition of a bass pipe that is
acoustically aligned to the woofer to optimize the
low frequency roll-off of the system. The result is
deeper controlled bass and lower distortion. The
system works by resonating the air mass in the bass
pipe to vibrate like a conventional woofer.
Combined with the response of the woofer, the
system extends the overall low frequency sounds to
create a whole new dimension of deep bass.
Audio-in
The Audio in connectivity allows direct playback of
Audio in content from portable media players.
Besides the benefit of enjoying your favorite music in
the superior sound quality delivered by the audio
system, the Audio in is also extremely convenient as
all you have to do is to plug your portable MP3 player
to the audio system.
Digital Sound Control
Digital Sound Control offers you a choice of pre-set
balanced, clear, powerful, warm and bright controls
you can use to optimise the frequency ranges for
different musical styles. Each mode uses graphic
equalizing technology to automatically adjust the
sound balance and enhance the most important
sound frequencies in your chosen music style.
Ultimately, Digital Sound Control makes it easy for
you get the most out of your music by precisely
adjusting the sound balance to match the type of
music you are playing.
USB Direct for easy MP3 music
Thanks to the complete file transferability, you can
easily enjoy the convenience and fun of accessing
more digital music via the built-in USB Direct.
Dome tweeter
Dome tweeters reproduce clear high and mid-range
frequencies that enhance the overall sound clarity
coming from the speakers. Delivering a harmonious
blend of undistorted and uncolored wide-ranging
sound, they offer detailed vocal clarity and
instruments tone purity, thereby balancing the
overall sound when paired with a combination of
woofers.
Sound
• Sound enhancement: digital sound control
• Maximum output power (RMS): 70W (30% THD),
50W (10% THD)
Loudspeakers
• Loudspeaker types: Dome tweeter
• Main Speaker: 2 way, 4" woofer, Bass Reflex
Speaker System
Audio playback
• Disc playback modes: fast forward/backward, next/
previous track search, repeat/shuffle/program
• Playback media: CD, CD-R/RW, MP3-CD, USB
flash drive
• USB Direct playback modes: fast backward/fast
forward, play/pause, previous/next, repeat, shuffle,
stop
• Others: ID3-tag support
Tuner/Reception/Transmission
• Tuner bands: FM mono, FM stereo
• Station presets: 20
• Antenna: FM antenna (75 ohm)
• Tuner enhancement: auto digital tuning, auto scan,
Easy set (plug & play)
Connectivity
• USB: USB host
• Audio in (3.5mm)
• Bluetooth profiles: A2DP
Convenience
• Alarms: CD Alarm, Radio Alarm, USB alarm
• Clock: On main display, sleep timer
• Display type: LED display
• Loader type: tray
Accessories
• Included accessories: AC Power Cord, FM
antenna, User Manual
• Remote control: 21-key remote
Dimensions
• Main unit width: 180 mm
• Main unit height: 119 mm
• Main unit depth: 220.4 mm
• Main speaker dimensions (W x D): 140 x 185 mm
• Main speaker height: 260 mm
• Packaging width: 663 mm
• Packaging height: 315 mm
• Packaging depth: 208 mm
• Gross weight: 6.7 kg
• Net weight: 5.74 kg
Power
• Power supply: 120V, 60Hz
•
