Philips MCD110/94 User manual

MCD110
Register your product and get support at
www.philips.com/welcome
EN User manual
MCD110_94_UM_EN_V1.0.indd 1 10/28/2009 1:39:53 PM

3
English
EN
6 Adjust settings 17
General setup 17
Audio setup 17
Video setup 17
Preferences 18
7 Product information 19
Specications 19
Supported disc formats 19
USB playability information 20
8 Troubleshooting 20
Contents
1 Important 4
Safety 4
Notice 5
2 Your DVD Micro Theater 6
Introduction 6
What’s in the box 7
Overview of the main unit 7
Overview of the remote control 7
3 Connect 9
Connect TV 9
Connect power 10
4 Get started 11
Activate demonstration mode 11
Prepare the remote control 11
Turn on 11
Find the correct viewing channel 11
Select the correct TV system 12
Change system menu language 12
Turn on Progressive Scan 12
5 Play 13
Play a disc 13
Play from USB 14
PlayMP3/WMA/pictureles 14
Play control 14
Play options 15
Picture view options 16
MCD110_94_UM_EN_V1.0.indd 3 10/28/2009 1:39:53 PM

4
gDo not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
hDo not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including ampliers)
that produce heat.
iProtect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
jOnly use attachments/accessories
specied by the manufacturer.
kUse only with the cart,
stand, tripod, bracket,
or table specied by
the manufacturer or
sold with the apparatus.
When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
lUnplug this apparatus during lightning
storms or when unused for long periods
of time.
m Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
nBattery usage CAUTION – To prevent
battery leakage which may result in
bodily injury, property damage, or
damage to the unit:
Install all batteries correctly, + and -•
as marked on the unit.
Do not mix batteries (old and new•
or carbon and alkaline, etc.).
Remove batteries when the unit is•
not used for a long time.
1 Important
Safety
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an
electrical shock. For the safety of everyone
in your household, please do not remove
product covering.
The ‘exclamation point’ calls attention to
features for which you should read the
enclosed literature closely to prevent
operating and maintenance problems.
WARNING:Toreducetheriskofreor
electric shock, this apparatus should not be
exposedtorainormoistureandobjectslled
with liquids, such as vases, should not be
placed on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Important Safety Instructions
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eDo not use this apparatus near water.
fClean only with dry cloth.
EN
MCD110_94_UM_EN_V1.0.indd 4 10/28/2009 1:39:54 PM

5
Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
The making of unauthorized copies of
copy-protected material, including computer
programs,les,broadcastsandsound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
‘DVD Video’ is a trademark of DVD Format/
Logo Licensing Corporation.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
oApparatus shall not be exposed to
dripping or splashing.
pDo not place any sources of danger on
the apparatus (e.g. liquid lled objects,
lighted candles).
qThis product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
Caution
Use of controls or adjustments or•
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Warning
Where the MAINS plug or an appliance•
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
Warning
Never remove the casing of this unit.•
Never lubricate any part of this unit.•
Placethisunitonaat,hardandstable•
surface.
Never place this unit on other electrical
•
equipment.
Only use this unit indoors. Keep this unit away
•
fromwater,moistureandliquid-lledobjects.
Keep this unit away from direct sunlight, naked
•
amesorheat.
Never look into the laser beam inside the unit.
•
English
EN
MCD110_94_UM_EN_V1.0.indd 5 10/28/2009 1:39:55 PM

6
2 Your DVD
Micro Theater
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this unit, you can:
watch video from DVD/VCD/SVCD or•
USB devices
enjoy audio from discs or USB devices•
view pictures from discs or USB devices•
The unit supports these media/disc formats:
You can play DVD discs with the following
region codes:
DVD region code Countries
India
Recordable
ReWritable
The USB-IF Logos are trademarks of Universal
Serial Bus Implementers Forum, Inc.
This apparatus includes this label:
Note
The type plate is located on the bottom of the•
apparatus.
EN
MCD110_94_UM_EN_V1.0.indd 6 10/28/2009 1:39:56 PM

7
h
Open or close the disc•
compartment.
iUSB DIRECT
USB socket.•
jDisc compartment
kSOURCE
Select a source.•
l
Turn on the apparatus; switch to•
standby mode.
Overview of the remote
control
a
b
c
d
e
f
g
i
h
j
l
k
m
n
r
q
p
o
What’s in the box
Check and identify the contents of your package:
Main unit•
Remote control•
Composite video cable (yellow)•
Audio cables (red/white)•
User manual•
Quick start guide•
Overview of the main unit
aVOLUME /
Adjust volume.•
bDisplay panel
Display current status.•
cRemote control sensor
d/
Skip to the previous/next track.•
Skip to the previous/next title or•
chapter.
e/
Search within a track.•
f
Start or pause play.•
g
Stop play.•
In demo mode, activate or deactivate•
demonstration.
a b
l k j h gi
dc ef
English
EN
MCD110_94_UM_EN_V1.0.indd 7 10/28/2009 1:39:59 PM

8
mNumeric keypad
Select a title/chapter/track directly.•
nZOOM/PROG
Zoom in or out a picture/video•
image.
Program titles/chapters for DVD play.•
Program tracks.•
oGOTO
During disc play, specify a position to•
start play.
pMODE
Select repeat play modes.•
Selectshufeplaymodes.•
qDISC MENU
For video discs: access or exit the•
disc menu.
For video discs with playback•
control(PBC): turn on/off PBC.
rDISPLAY
Display play information on a•
connected TV.
a
Turn on the apparatus; switch to•
standby mode.
bSOURCE
Select a source.•
cMUTE
Mute or restore volume.•
dSLOW/ ANGLE
For menus, navigate up/down.•
Rotate or invert pictures.•
(• SLOW) For video: select a slow
play mode.
(• ANGLE) Select a DVD camera
angle.
e/ ( / )
For menus, navigate left/right.•
Move an enlarged image left/right.•
Rotate or invert pictures.•
Search within a track.•
f/ OK
Start or pause play.•
Conrmaselection.•
gSYSTEM MENU
Access or exit the system setup•
menu.
h
Stop play.•
i/
Skip to the previous/next track.•
Skip to the previous/next title or•
chapter.
jVOL +/-
Adjust volume.•
kAUDIO
For VCD, select stereo, mono-left or•
mono-right channel.
For DVD video, select an audio•
language.
lSUBTITLE
Select a subtitle language.•
EN
MCD110_94_UM_EN_V1.0.indd 8 10/28/2009 1:40:00 PM

9
Note
The progressive scan video quality is only•
available when a progressive scan TV is
connected.
If your TV does not support progressive scan,
•
you cannot view the picture.
For how to activate progressive scan on your
•
TV, refer to the TV user manual.
Connect a progressive scan TV through
component video for higher quality video.
1Connect component video cables (red/
blue/green - not supplied) to:
the• VIDEO OUT (Pr/Cr Pb/Cb Y)
sockets on this unit.
the component input sockets on the•
TV.
Option 3: Connect through
composite video
1Connect the supplied composite video
cable to:
the• VIDEO OUT socket on this unit.
the video input socket on the TV.•
3 Connect
Connect TV
Connect video cables
With this connection, you can watch video
from the unit on the TV screen.
You can select the best video connection that
your TV supports.
Option 1: connect through component•
video (for a standard TV or Progressive
Scan TV).
Option 2: connect through composite•
video (CVBS) (for a standard TV).
Option 1: Connect through
component video
Connect a progressive scan TV through
component video for higher quality video.
English
EN
MCD110_94_UM_EN_V1.0.indd 9 10/28/2009 1:40:01 PM

10
Connect power
Caution
Risk of product damage! Ensure that the•
power supply voltage corresponds to the
voltage printed on the back or the underside
of the unit.
Before connecting the AC power cord, ensure
•
you have completed all other connections.
1Connect the AC power cord to the wall
socket.
Connect audio cables
1To play sound from this unit through the
TV, connect the supplied audio cables
(red/white) to:
the• AUDIO OUT L/R sockets on
this unit.
the audio input sockets on the TV.•
EN
MCD110_94_UM_EN_V1.0.indd 10 10/28/2009 1:40:02 PM

11
3Insert one lithium CR2025 battery with
correct polarity (+/-) as indicated.
4Close the battery compartment.
Note
Before you press any function button on the•
remotecontrol,rstselectthecorrectsource
with the remote control.
Turn on
1Press .
The unit switches to the last selected»
source.
Switch to standby mode
1Press again.
Find the correct viewing
channel
1Press to turn on the unit.
2Press SOURCE repeatedly to select the
disc source.
3Turn on the TV and switch to the correct
video-in channel in one of the following
ways:
Go to the lowest channel on your•
TV, then press the Channel Down
button until you see the blue screen.
Press the source button repeatedly•
on the remote control of your TV.
Tip
The video-in channel is between the lowest•
and highest channels and may be called
FRONT, A/V IN, VIDEO etc. See the TV user
manual on how to select the correct input on
the TV.
4 Get started
Caution
Use of controls or adjustments or•
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
bottom of the apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Activate demonstration mode
You can see an overview of all features.
1In standby mode, press on the main
unit to activate the demonstration mode.
A demonstration of major available»
features starts.
To deactivate the demonstration mode:
1Press on the main unit again.
Prepare the remote control
Caution
Risk of explosion! Keep batteries away from•
heat,sunshineorre.Neverdiscardbatteries
inre.
For rst-time use:
1Remove the protective tab to activate the
remote control battery.
2Open the battery compartment.
English
EN
MCD110_94_UM_EN_V1.0.indd 11 10/28/2009 1:40:03 PM

12
Turn on Progressive Scan
Progressive scan displays twice the number of
frames per seconds than interlaced scanning
(ordinary TV system).With nearly double the
number of lines, progressive scan offers higher
picture resolution and quality.
Before you turn on this feature, ensure that:
The TV supports progressive scan signals.•
You have connected this unit with the TV•
through component video.
1Turn on the TV.
2Ensure that the TV progressive scan
mode is deactivated (see the TV user
manual).
3Switch the TV to the correct viewing
channel for this unit.
4Press SOURCE repeatedly to select the
disc source.
5Press SYSTEM MENU.
6Press / to select [Video Setup] in the
menu, then press .
7Select [Component Video], then press .
8Select [P-Scan], then press /OK.
The progressive setup is complete.»
Select the correct TV system
Change this setting if the video does not appear
correctly. By default, this setting matches the
most common setting for TVs in your country.
1Press SYSTEM MENU.
2Select [Video Setup].
3Select [TV System] and then press .
4Select a setting and then press /OK.
• [NTSC] - For TV with NTSC color
system.
• [PAL] - For TV with PAL color
system.
• [Multi] - For TV that is compatible
with both PAL and NTSC.
To exit the menu, press• SYSTEM
MENU.
Change system menu
language
1Press SYSTEM MENU.
2Select [General Setup].
3Select [OSD language] and then press .
4Select a setting and then press /OK.
To exit the menu, press• SYSTEM
MENU.
EN
MCD110_94_UM_EN_V1.0.indd 12 10/28/2009 1:40:03 PM

13
Use the disc menu
When you load a DVD/(S)VCD disc, a menu
may be displayed on the TV screen.
To access or exit the menu manually:
1Press DISC MENU.
For VCD with PlayBack Control (PBC)
feature (version 2.0 only):
With the PBC feature, you can play VCD
interactively according to the menu screen.
1During play, press DISC MENU to
enable/disable PBC.
When PBC is enabled, the menu»
screen is displayed.
When PBC is disabled, normal play is»
resumed.
Select an audio language
You can select an audio language on DVDs.
1During disc play, press AUDIO.
The language options appear. If the»
selected audio channels is unavailable,
the default disc audio channel is used.
Note
For some DVDs, the language can only be•
changed from the disc menu. Press DISC
MENU to access the menu.
Select a subtitle language
You can select a subtitle language on DVDs.
During play, press• SUBTITLE.
Note
For some DVDs, the language can only be•
changed from the disc menu. Press DISC
MENU to access the menu.
5 Play
Note
Withsomedisc/letypes,playmaydiffer.•
Play a disc
Caution
Never look at the laser beam inside the unit.•
Risk of product damage! Never play discs with•
accessories such as disc stabilizer rings or disc
treatment sheets.
Never put any objects other than discs into
•
the disc compartment.
1Press SOURCE repeatedly to select the
disc source.
2Press on the front panel.
The disc tray opens.»
3Place a disc onto the tray and press .
Ensure that the label faces up.»
4Play starts automatically.
To stop play, press• .
To pause or resume play, press•
/OK.
To skip to the previous/next title/•
chapter/track, press / .
If play does not start automatically:
Select a title/chapter/track and then press•
/OK.
Tip
To play a locked DVD, enter the 4-digit•
parental control password.
English
EN
MCD110_94_UM_EN_V1.0.indd 13 10/28/2009 1:40:03 PM

14
Play MP3/WMA/picture les
YoucanplayMP3/WMA/picturelescopied
onto a CD-R/RW, recordable DVD or USB
device.
1Insert a disc or connect a USB device.
2Select a source:
For discs, press• SOURCE repeatedly
to select the disc source.
For USB devices, press• SOURCE
repeatedly to select the USB source.
3Press DISC MENU until the folder is
displayed.
4Press / to select a folder, then press
/OKtoconrm.
5Press / toselectalefromthefolder.
6Press /OK to start play.
To stop play, press• .
To pause or resume play, press•
/OK.
Toskiptotheprevious/nextle,•
press / .
Play control
Select repeat/shufe play options
1During play, press MODE repeatedly to
selectarepeatoptionortheshufeplay
mode.
To resume normal play, press• MODE
repeatedly until “OFF” is displayed.
Search forward/backward
1During play, press / repeatedly to
select a search speed.
To resume play at normal speed,•
press .
Play from USB
Note
Ensure that the USB device contains playable•
music, pictures or video.
1Insert the USB device.
2Press SOURCE repeatedly to select the
USB source.
3Press DISC MENU until the folder is
displayed.
4Press / to select a folder, then press
/OKtoconrm.
5Press / toselectalefromthefolder.
6Press /OK to start play.
To stop play, press• .
To pause or resume play, press• .
Toskiptotheprevious/nextle,•
press / .
EN
MCD110_94_UM_EN_V1.0.indd 14 10/28/2009 1:40:04 PM

15
For MP3/WMA les:
1During play or in stop mode, press DISC
MENUuntilthelelistisdisplayed.
2 Selectale,thenpressZOOM/PROG to
addtheletotheprogramlist.
3Repeat steps 2 until the program is
complete.
4Press /OK to play the program.
To delete a le from the [Program List]:
1Press DISC MENU until the program list
is displayed.
2 Selectale,thenpressZOOM/PROG to
deletethelefromtheprogramlist.
Adjust volume level
1During play, press VOL +/- to increase/
decrease the volume level.
Mute sound
1During play, press MUTE to mute/unmute
sound.
Play options
Display play information
1During play, press DISPL AY repeatedly to
display play information.
Zoom in/out image
1During video play, press ZOOM/PROG
repeatedly to zoom in/out the image.
When the image is zoomed in, you•
can press / / / to pan through
the image.
Search by time or chapter/track
number
1During video/audio play, press GOTO
untilatimeeldorchapter/trackeldis
displayed.
Forthetimeeld,entertheplay•
position in hours, minutes and seconds.
Forthechapter/trackeld,enterthe•
chapter/track.
Play starts automatically at your•
selected point.
Resume video play from last stopped
point
Note
This feature is only available for DVD/VCD•
play.
1In stop mode and when the disc has not
been removed, press /OK.
To cancel resume mode and stop play
completely:
1In stop mode, press .
Program
Note
Youcannotprogrampictureles/discs.•
For video discs/audio CDs:
1During play or in stop mode, press
ZOOM/PROG to access the program
menu.
2Enter the tracks/chapters to add to the
program.
3Repeat step 2 until the program is
complete.
4Select [Start], then press /OK to play
the program.
English
EN
MCD110_94_UM_EN_V1.0.indd 15 10/28/2009 1:40:04 PM

16
Picture view options
Preview pictures
1During play, press .
The pictures in the current folder are»
displayed.
2Press / to select a picture from the
folder.
A thumbnail of the selected picture is»
displayed in the right pane.
3Press /OK to start slideshow from the
selected picture.
Rotate picture
1During play, press / / / to rotate the
picture anti-clockwise/clockwise.
Slow-motion play
1During video play, press (SLOW)
repeatedly to select a slow play option.
The sound is muted.»
To resume play at normal speed, press»
/OK.
Change the audio channel
Note
This feature is only available for VCD play.•
1During play, press AUDIO repeatedly to
select an audio channel available on the
disc:
Mono Left•
Mono Right•
Stereo•
Select a camera angle
Note
This feature is only available for DVDs•
recorded with multiple camera angles.
1During play, press (ANGLE) repeatedly
to select a camera angle.
EN
MCD110_94_UM_EN_V1.0.indd 16 10/28/2009 1:40:05 PM

17
Audio setup
On the [Audio Setup] page, you can set the
following options:
[Night Mode]
Make loud sound level softer and soft sound
level louder so that you can watch the DVD
movies at a low volume, without disturbing
others.
• [On] – enjoy quiet viewing at night
(DVDs only).
• [Off] – enjoy surround sound with
its full dynamic range.
Video setup
On the [Video Setup] page, you can set the
following options:
[TV System]
Change this setting if the video does not
appear correctly. By default, this setting
matches the most common setting for TVs in
your country.
• [NTSC] - For TV with NTSC color
system.
• [PAL] - For TV with PAL color
system.
• [Multi] - For TV that is compatible
with both PAL and NTSC.
[TV Display]
The TV format determines the aspect ratio of
display according to the type of TV you have
connected.
• [4:3 Pan Scan] – For 4:3 screen TV:
full-height display with the trimmed
sides.
• [4:3 Letter Box] – For 4:3 screen TV:
wide-screen display with black bars
on the top and bottom of the screen.
4:3 Letter Box (LB)
4:3 Pan Scan (PS) 16:9 (Wide Screen)
6 Adjust settings
1Press SYSTEM MENU.
2Select a setup page.
3Select an option and then press .
4Select a setting and then press /OK.
To return to the previous menu,•
press .
To exit the menu, press• SYSTEM
MENU.
General setup
On the [General Setup] page, you can set the
following options:
[Disc Lock]
Setplayrestrictionforspecicdiscs.
Before you start, place the disc in the disc
compartment (maximum 40 discs can be
locked).
• [Lock] – Restrict access to the
current disc. You need to enter a
password to unlock and play the disc.
• [Unlock] – Play all discs.
Tip
To set or change the password, go to•
[Preference Setup] > [Password].
[OSD language]
Select the preferred language for on-screen
display.
[Sleep Timer]
Switches to standby automatically after the
preset time.
• [15 mins], [30 mins], [45 mins], [60
mins] – select the count down time
before the apparatus switches to
standby.
• [Off] – disable sleep mode.
English
EN
MCD110_94_UM_EN_V1.0.indd 17 10/28/2009 1:40:07 PM

18
Press /OK.
Select a rating level, then press /OK.
Press the numeric keys to enter the
password.
Note
Rated discs above the level you set in•[Parental
Control] require a password to be played.
The ratings are country-dependent. To allow
•
all discs to play, select [8. Adult].
Some discs have ratings printed on them but
•
are not recorded with ratings. This function
has no effect on such discs.
[Password]
This setting allows you to change the
password for parental control. The default
password is 0000.
1) Press the numeric keys to enter ‘0000’ or
your last set password at [Old Password]
eld.
2) Enter the new password at [New
Password]eld.
3) Enter the new password again at [Conrm
new password]eld.
4) Press /OK to exit the menu.
Note
If you forget the password, enter ‘0000’ before•
you set a new password.
[Version Info]
Display the software version of this apparatus.
[Default]
Resets all the settings of this unit to factory
default, except for the password and parental
settings.
• [16:9] – For wide-screen TV: display
ratio 16:9.
[Picture Settings]
Selectapredenedsetofpicturecolor
settings or customize your personal setting.
• [Standard] – original color setting.
• [Bright] – vibrant color setting.
• [Soft] – warm color setting.
• [Personal] – customize the color
setting. Adjust the level of brightness,
contrast, sharpness/tint and color
saturation.
[Component Video]
Set the video output according to the video
connection. If the composite connection is
used, this setting is not required.
• [Interlaced] – For ordinary TV: turn
on the interlace mode.
• [P-Scan] – For progressive scan TV:
turn on the progressive scan mode.
Preferences
On the [Preferences] page, you can set the
following options:
[Audio]
Select the preferred audio language for disc
play.
[Subtitle]
Select the preferred subtitle language for disc
play.
[Disc Menu]
Select the preferred disc menu language.
Note
If the language you have set is not available on•
the disc, the disc uses its own default language.
For some discs, the subtitle/audio language can
•
only be changed from the disc menu.
[Parental Control]
Restricts access to discs that are unsuitable
for children. These types of discs must be
recorded with ratings.
EN
MCD110_94_UM_EN_V1.0.indd 18 10/28/2009 1:40:08 PM

19
Weight
- With Packing
- Main Unit
1.8 kg
1.2 kg
Supported disc formats
Digital Video Discs (DVDs)•
Video CDs (VCDs)•
Super Video CDs (SVCDs)•
Digital Video Discs + Rewritable•
(DVD+RW)
Compact Discs (CDs)•
Picture(Kodak,JPEG)lesonCDR(W)•
WMA•
Supported MP3-CD formats:
ISO 9660•
Max. title/album name: 12 characters•
Max. title number plus album: 255.•
Max. nested directory: 8 levels.•
Max. album number: 32.•
Max. MP3 track number: 999.•
Supported sampling frequencies for MP3•
disc: 32 kHz, 44.1 kHz, 48 kHz.
Supported Bit-rates of MP3 disc are: 32,•
64, 96, 128, 192, 256 (kbps).
The following formats are not supported:•
Files like *.VMA, *.AAC, *.DLF,•
*.M3U,
*.PLS, *.WAV•
Non-English Album/Title name•
Discs recorded in Joliet format•
MP3 Pro and MP3 with ID3 tag•
7 Product
information
Note
Product information is subject to change•
without prior notice.
Specications
Disc
Laser Type Semiconductor
Disc Diameter 12cm/8cm
Video Decoding MPEG-1 / MPEG-2
Video DAC 12Bits
Signal System PAL / NTSC
Video Format 4:3 / 16:9
Video S/N >48dB
Audio DAC 24Bits / 96kHz
Total Harmonic
Distortion <1% (1 kHz)
Frequency
Response
4Hz - 20kHz (44.1kHz)
4Hz - 22kHz (48kHz)
4Hz - 24kHz (96kHz)
S/N Ratio >67dBA
General information
AC power 220 - 240V, 50 Hz
Operation Power
Consumption 6W
Eco Power Consumption <0.5W
Composite Video
Output 1.0Vp-p, 75ohm
USB Direct Version 2.0
Dimensions
- Main Unit
(W x H x D)
220 x 90 x 240mm
English
EN
MCD110_94_UM_EN_V1.0.indd 19 10/28/2009 1:40:08 PM

20
8 Troubleshooting
Warning
Never remove the casing of this apparatus.•
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site www.
philips.com/welcome.When you contact Philips,
ensure that the apparatus is nearby and the
model number and serial number are available.
No power
Ensure that the AC cord of the apparatus•
is connected properly.
Ensure that there is power at the AC•
outlet.
As a power-saving feature, the system•
switches off automatically 15 minutes
after track play reaches the end and no
control is operated.
No disc detected
Insert a disc.•
Check if the disc is inserted upside down.•
Wait until the moisture condensation at•
the lens has cleared.
Replace or clean the disc.•
UseanalizedCDorcorrectformatdisc.•
No picture
Check the video connection.•
Turn on the TV to the correct Video-In•
channel.
Progressive scan is activated but the TV•
does not support progressive scan.
USB playability information
Compatible USB devices:
USBashmemory(USB2.0orUSB1.1)•
USBashplayers(USB2.0orUSB1.1)•
memory cards (requires an additional•
card reader to work with this apparatus)
Supported formats:
USBormemoryleformatFAT12,•
FAT16, FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps and•
variable bit rate
WMA v9 or earlier•
Directory nesting up to a maximum of 8•
levels
Number of albums/ folders: maximum 99•
Number of tracks/titles: maximum 999•
ID3 tag v2.0 or later•
File name in Unicode UTF8 (maximum•
length: 128 bytes)
Unsupported formats:
Empty albums: an empty album is an•
album that does not contain MP3/WMA
les,andisnotbeshowninthedisplay.
Unsupportedleformatsareskipped.For•
example, Word documents (.doc) or MP3
leswithextension.dlfareignoredand
not played.
AAC,WAV,PCMaudioles•
DRMprotectedWMAles(.wav,.m4a,•
.m4p, .mp4, .aac)
WMAlesinLosslessformat•
EN
MCD110_94_UM_EN_V1.0.indd 20 10/28/2009 1:40:08 PM

21
As a power-saving feature, the system•
turns off automatically 15 minutes after
disc play reaches the end and no control
is operated.
Audio or subtitle languages cannot be set
The disc is not recorded with sound or•
subtitles in multiple languages.
The audio or subtitle language setting is•
prohibited on the disc.
Cannot display some les in USB device
ThenumberoffoldersorlesintheUSB•
device has exceeded a certain limit. This
phenomenon is not a malfunction.
Theformatsoftheselesarenot•
supported.
USB device not supported
The USB device is incompatible with the•
unit. Try another one.
Black and white or distorted picture
The disc does not match the TV color•
system standard (PAL/NTSC).
Sometimes a slight picture distortion may•
appear. This is not a malfunction.
Clean the disc.•
A distorted picture may appear during•
progressive scan setup.
The aspect ratio of the TV screen cannot be
changed even though you have set the TV
display format.
Theaspectratioifxedontheloaded•
DVD disc.
The aspect ratio may not be changed for•
some TV systems.
No sound or poor sound
Adjust the volume.•
Check that the audio cables (red/white)•
are connected correctly.
Remote control does not work
Before you press any function button,•
rstselectthecorrectsourcewiththe
remote control instead of the main unit.
Reduce the distance between the remote•
control and the unit.
Insert the battery with its polarities (+/–•
signs) aligned as indicated.
Replace the battery.•
Aim the remote control directly at the•
sensor on the front of the unit.
Disc does not play
Insert a readable disc and ensure that the•
label side faces up.
Check the disc type, color system and•
regional code. Check for any scratches or
smudges on the disc.
Press•SYSTEM MENU to exit the system
setup menu.
Disable the password for parental control•
or change the rating level.
Moisture has condensed inside the•
system. Remove the disc and leave the
system turned on for about an hour.
Disconnect and reconnect the AC power
plug, and then turn on the system again.
English
EN
MCD110_94_UM_EN_V1.0.indd 21 10/28/2009 1:40:08 PM
