Philips 104S12 User manual

electronic user's manual
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/104S/manual.html [8/29/2001 11:36:02 AM]

Safety and Troubleshooting Information
Safety Precautions and Maintenance • Troubleshooting • Regulatory Information • Other
Related Information
Safety precautions and maintenance
WARNING: Use of controls, adjustments, or procedures other than those
specified in this documentation may result in exposure to shock, electrical
hazards, and/or mechanical hazards.
Read and follow these instructions when connecting and using your computer monitor:
Disconnect the monitor from the power supply if the monitor is not to be used for an extended period
of time.
●
Do not attempt to remove the back cover, as you will be exposed to a shock hazard. The back cover
should only be removed by qualified service personnel.
●
Do not place objects on top of the monitor cabinet, objects could fall into vents or cover them and
prevent proper cooling of the monitor's electronic devices.
●
To avoid the risk of shock or permanent damage to the set, do not expose the monitor to rain or
excessive moisture.
●
Do not use alcohol or ammonia-based liquid to clean the monitor. If necessary, clean with a slightly
damp cloth. Disconnect the monitor from the power supply before cleaning.
●
When positioning the monitor, make sure the power plug and outlet are easily accessible.●
Consult a service technician if the monitor does not operate normally when operating instructions of this
manual are followed.
RETURN TO TOP OF THE PAGE
Safety & Troubleshooting
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/104S/SAFETY/SAFETY.HTM [8/29/2001 11:59:45 AM]

About This Electronic User's Manual
About This Guide • Other Documents You May Need • Notational Descriptions
About This Guide
This electronic user's guide is intended for anyone who uses the Philips Color Monitor. It describes the
monitor's features, setup, operation and all other information, which is the same exact information described
in our printed version.
The sections are as follows:
Safety and Troubleshooting Information provides tips and solutions for common problems, and other
related information you may need.
●
About This Electronic User's Manual gives overview of what information are included as well as
notation icon descriptions and other documentation you can refer to.
●
Product Information gives an overview of the monitor's features and as well as the technical
specifications for this monitor.
●
Installing Your Monitor describes the initial setup process and gives an overview of how to use the
monitor.
●
Front Controls provides information on adjusting the settings on your monitor.●
Customer Care and Warranty is a list of worldwide Philips consumer information centers along with
the help desk phone numbers and information on the applicable warranty of your product..
●
Glossary provides more information for technical terms.●
Download allows users to install the entire manual on their hard drive.●
Frequently Asked Questions provides answers to commonly asked questions.●
RETURN TO TOP OF THE PAGE
Other Documents You May Need
In addition to this Electronic User's Guide, you may need to refer to the following documentation:
Philips Color Monitor Quick Start Guide which summarizes the steps for setting up the monitor. This is
included with this product.
●
RETURN TO TOP OF THE PAGE
Notational Descriptions
About This Electronic User's Manual
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/104S/ABOUT/ABOUT.HTM (1 of 2) [8/29/2001 11:59:45 AM]

The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type.
These blocks are notes, cautions, and warnings, and they are used as follows:
NOTE: This icon indicates important information and tips that help you make better
use of your computer system.
CAUTION: This icon indicates information that tells you how to avoid either potential
damage to hardware or loss of data.
WARNING: This icon indicates the potential for bodily harm and tells you how to
avoid the problem.
SMART HELP: This icon indicates helpful information when adjusting the On Screen
Display of your monitor.
Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such cases, the
specific presentation of the warning is mandated by regulatory authority.
RETURN TO TOP OF THE PAGE
©2001 Koninklijke Philips Electronics N.V.
All rights reserved. Reproduction, copying, usage, modifying, hiring, renting, public performance, transmission and/or broadcasting in whole or in
part is prohibited without written consent of Philips Electronics N.V.
About This Electronic User's Manual
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/104S/ABOUT/ABOUT.HTM (2 of 2) [8/29/2001 11:59:45 AM]

Product Information
Product Features • Technical Specifications • Automatic Power Saving • Physical
Specification • Pin Assignment • Product Views
Product Features
104S12, 104S19
14-inch (13.3" VIS) color monitor with excellent front of screen performance for use with MACs and
PCs
●
Autoscan covers horizontal frequencies up to 54kHz offering a maximum resolution of 1024 x 768
with flicker free display of 800 x 600 at up to 87Hz
●
CRT with high-resolution 0.28 mm dot pitch (0.24 hdp).● Smallest footprint in its class requires minimum desk space: maximum depth is only 367 mm/14.4"● FCC, CE (in selected countries only) and ISO9241, ISO14001 certified●
RETURN TO TOP OF THE PAGE
Technical Specifications*
CRT
• Size and deflection 14 inch / 35.5 cm ; 90° deflection angle
• Dot pitch / Grille pitch 0.28 mm
• Horizontal pitch 0.24 mm
• Tube type Shadow mask, anti-glare(104S12), anti-static(104S19), anti
reflection, light transmission 57%
• Phosphor P22
• Recommended display area 9.8" x 7.4" / 250 x 188mm
• Maximum display area 10.8" x 7.9" / 274 x 201 mm
SCANNING
• Horizontal scanning 30 - 54KHz
• Vertical scanning 50 - 120 Hz
VIDEO
104S Product Information
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/104S/PRODUCT/PRODUCT.HTM (1 of 4) [8/29/2001 11:59:45 AM]

• Video dot rate 65 MHz
• Input impedance
- Video 75 ohm
- Sync 2.2 kOhm
• Input signal levels 0.7 Vpp
• Sync input signal Separate sync
• Sync polarities Positive and negative
WHITE COLOR TEMPERATURE
Chromaticity CIE coordinates:
• at 9300 K degrees x = 0.281 / y = 0.311
* These information are subject to change without notice.
RETURN TO TOP OF THE PAGE
Automatic Power Saving
If you have VESA's DPMS compliance display card or software installed in your PC, the monitor can
automatically reduce its power consumption when not in use. And if an input from a keyboard, mouse or
other input device is detected, the monitor will automatically "wake up". The following table shows the power
consumption and signaling of this automatic power saving features:
Power Management Definition
VESA's Mode Video H-sync V-sync Power Used Power
Saving
(%) LED color
ON Active Yes Yes < 65W 0 % Green
Stand-by Blanked No Yes < 8W 88% Yellow
Suspend Blanked Yes No < 8W 88% Yellow
OFF Blanked No No < 8W 88% Yellow
This monitor is ENERGY STAR®compliant. As an ENERGY STAR®Partner, PHILIPS has
determined that this product meets the ENERGY STAR®guidelines for energy efficiency.
104S Product Information
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/104S/PRODUCT/PRODUCT.HTM (2 of 4) [8/29/2001 11:59:45 AM]

RETURN TO TOP OF THE PAGE
Physical Specifications
• Dimensions
13.7" x 14.4" x 14.2" / 347 x 367 x 360 mm (including base)
13.7" x 14.4" x 12.2" / 347 x 367 x 310 mm (excluding base)
• Weight 9.5 kg
• Power supply 90 - 264 VAC, 50/60Hz
• Temperature (operating) 0° to 40°C / 32° to 104°F
• Temperature (storage) -25° to +65°C / -13° to +149°F
• Relative humidity 5% to 95%
* Resolution 800 x 600, standard size, contrast max., brightness 50%, 9300°, full white pattern.
* These information are subject to change without notice.
RETURN TO TOP OF THE PAGE
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable (IBM systems):
Pin
No. Assignment
Pin
No. Assignment
1 Red video input 9 No pin
2 Green video input 10 Logic ground
3 Blue video input 11 Identical output - connected
to pin 10
104S Product Information
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/104S/PRODUCT/PRODUCT.HTM (3 of 4) [8/29/2001 11:59:45 AM]

4Identical output - connected
to pin 10 12 Serial data line (SDA)
5 Ground 13 H. Sync / H+V
6 Red video ground 14 V. Sync (VCLK for DDC)
7 Green video ground 15 Data clock line (SCL)
8 Blue video ground
RETURN TO TOP OF THE PAGE
Views
Follow the links to see various views of the monitor and its components.
Front View
Rear View
RETURN TO TOP OF THE PAGE
104S Product Information
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/104S/PRODUCT/PRODUCT.HTM (4 of 4) [8/29/2001 11:59:45 AM]

Installing your Monitor
Front View • Rear View • Pedestal •PCUH411 USB Hub (option)
Front View
For detailed information about the knobs and keys, please refer to Front Controls.
RETURN TO TOP OF THE PAGE
Rear View
Installing your Monitor
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/INSTALL_1/INSTALL.HTM (1 of 2) [8/29/2001 11:59:46 AM]

1. Power in - attach power cable here.
2. Video In - this is a cable which is already attached to your monitor. Connect the
other end of the cable to your PC.
RETURN TO TOP OF THE PAGE
Installing your Monitor
file:///D|/rita/LF2/LF2/LFa1/multi_manual/english/INSTALL_1/INSTALL.HTM (2 of 2) [8/29/2001 11:59:46 AM]
