109B4
109B4
·19-inch (18.0" VIS) Color CRT Monitor
Enjoy excellent display performance providing an optimum resolution of 1280 x 1024 for amazing
image clarity and sRGB compatibility for better color matching.
·Breakthrough Real Flat Tube
Experience natural viewing with less distortion and reflection with Philips Real Flat monitors.
·LightFrame™3 — 2x Normal Brightness
By increasing brightness and sharpness in user selected areas, Philips patented technology dramatically
improves photos and graphics without sacrificing performance for text-based applications.
·XtraSpace Design™
Moving beyond industry standards, Philips monitors increase available desk space while delivering the
smallest total footprint in its class.
·Philips First Choice Program
One-call support includes a comprehensive 3-year warranty with a 1-year 48-hour
advance swap guarantee.
Dare to compare. . .LightFrame™3 for the sharpest
and brightest displays ever!
Philips Business Series Monitors
Optional USB HUB
PCUH411
KEY TECHNOLOGIES
3
Optional Multimedia
Base available in
Stealth Black
and Mist White
Available in Mist White
109B40

Product Number 109B43 Stealth Black
109B40 Mist White
CRT
•Size (inch/cm) 19"/46 cm (18.0" VIS)
•Deflection Angle (degrees) 90°
•Dot Pitch 0.25 mm
•Horizontal Pitch 0.21 mm
-Tube Type REAL FLAT, Flat Shadow Mask, High
Contrast,Anti-Glare, Anti-Static,
Anti-Reflection, Light Transmission 45%
• Phosphor P22
•Recom. Display Area (mm) 355 x 265 mm
•Recom. Display Area (inch) 14.0" x 10.4"
•Max. Display Area (mm) 360 x 270 mm
•Max. Display Area (inch) 14.4" x 10.8"
Scanning
•Horizontal Scanning 30 - 97kHz
•Vertical Scanning 50 - 160Hz
Video
•Video Dot Rate 203MHz
•Input Impedance
-Video 75Ω
-Sync 2.2kΩ
•Input Signal Levels 0.7 Vp-p
•Sync Input Signal Separate Sync
Composite Sync
•Sync Polarities Positive and Negative
White Color Temperature
Chromaticity CIE Coordinates:
•at 9300 K: x=0.283, y=0.297
•at 6500 K: x=0.313, y=0.329
•at 5500 K: x=0.332, y=0.347
Resolution and Preset Modes
•Max. Resolution 1920 x 1440
•Recom. Resolution 1280 x 1024
•16 User Definable Modes
•33 Factory Preset Modes:
Plug and Play Compatibility
•Display Data Channel DDC 2B (VESA)
•Microsoft®,Windows® 95/98/Me 2000/NT/XP PC2001 compatible
• sRGB
Power Management
Complies with EPA Energy Star, NUTEK Specifications
•Operation (typ.) 83 W
•Suspend/Stand-By Mode (typ.) < 2 W
•Off Mode/Deep Sleep < 2 W
Low-Emission Characteristics
•Complies with MPR-II and TCO '99 Specifications
Monitor Controls and Functions
•Main 5-Button OSD
Brightness +/- Direct Access
Contrast+/- Direct Access
•On Screen Display Language (English, Spanish, French, German, Italian,
Chinese, Portuguese, Korean), Zoom, Horiz/Vert
Position and Size, Pincushion, Balanced, Trapezoid,
Parallelogram, Color, Reset, Degauss, Moire, Serial
Number, Resolution, Frequency, sRGB
•LightFrame™3 For improving the picture display of multimedia
content such as photos, videos and games.Will
boost brightness and sharpness performance on
user selected areas/ windows on the screen.With
automatic detection of graphical content in Internet
Explorer for the web browsing. Can process up to
16 images simultaneously. One-button full screen
mode. Advanced user adjustments via Windows
control panel. Easy to use control software for
Windows 98, Me, XP and 2000. Software in English,
French, German, Spanish, Italian, Portuguese, Dutch,
Chinese and Korean.
Connections and Cables
• Connections
-Video 15-pin D-Sub Input
•Cables D-Sub Video (fixed) and Power Cord
Regulatory Approvals
•TCO '95 109B43 • MPR-II Low Emission
•TCO '99 109B40 • TüV/GS,TüV-Ergo,TüV/9241-3
•FCC-B, UL, CSA, DHHS • SEMKO, Poland-B Sign, C-Tick
•CE, BCIQ, PSB • NUTEK, Energy Star
Physical Specifications
•UPC Code 109B43 (Stealth Black) 0 37849 92920 9
109B40 (Mist White) 0 37849 92899 8
•Unit Dimensions (WxHxD) 17.3" x 17.5" x 17.6"
440 x 447 x 449 mm (incl base)
17.3" x 16.1" x 17.6"
440 x 410 x 449 mm (excl base)
•Unit Weight 46.6 lbs./21.3 kg
•Carton Dimensions (WxHxD) 20.50" x 23.30" x 21.90"
520 x 591 x 556 mm
•Carton Weight 55.0 lbs./24.95 kg
•Power Supply 90 - 264 VAC, 50/60Hz
•Temperature (operating) 0°C to +40°C/32° to 104°F
•Temperature (storage) -25°C to +65°C/ -13° to 149°F
•Relative Humidity 5% to 95%
•mtbf (excl. CRT) > 75,000 H
Optional Accessories
•USB Hub Option Type PCUH411
•Multimedia Base Option Type 6G3B12 (Stealth Black)
6G3B11 (Mist White)
•Mac Adapter Free Upon Request viaTech Support
Carton contains: 109B Monitor, power cord, and user’s manual on CD.
INTERNET ADDRESS: http://www.philipsusa.com
TECHNICAL SUPPORT: [phone] (USA)
[phone] (outside USA)
Specifications subject to change without notice.
Printed in the U.S.A., ©2003 Philips Consumer Electronics Co.A Division of Philips Electronics North America
Corp. As an Energy Star partner, Philips has determined that this product meets the Energy Star guidelines for
energy efficiency. Microsoft andWindows are registered trademarks of Microsoft Corporation MacOS is a regis-
tered trademark of Apple Computer, Inc. All trademarks acknowledged. Copyright 2001 Koninklijke Philips
Electronics N.V.
CCM-110-01/03
Literature Order Number: 109B40/109B43
Resolution H.freq V.freq
640 x 480 31.5(kHz) 60(Hz)
640 x 480 37.9(kHz) 72(Hz)
640 x 480 37.5(kHz) 75(Hz)
640 x 480 43.3(kHz) 85(Hz)
640 x 480 50.6(kHz) 100(Hz)
720 x 400 31.5(kHz) 70(Hz)
720 x 400 37.9(kHz) 85(Hz)
800 x 600 37.9(kHz) 60(Hz)
800 x 600 48.1(kHz) 72(Hz)
800 x 600 46.9(kHz) 75(Hz)
800 x 600 53.7(kHz) 85(Hz)
800 x 600 63.9(kHz) 100(Hz)
832 x 624 49.7(kHz) 75(Hz)
1024 x 768 48.4(kHz) 60(Hz)
1024 x 768 56.5(kHz) 70(Hz)
1024 x 768 60.0(kHz) 75(Hz)
1024 x 768 68.7(kHz) 85(Hz)
Resolution H.freq V.freq
1152 x 864 67.5(kHz) 75(Hz)
1152 x 864 77.0(kHz) 85(Hz)
1152 x 870 68.7(kHz) 75(Hz)
1152 x 900 71.8(kHz) 76(Hz)
1280 x 960 60.0(kHz) 60(Hz)
1280 x 960 85.9(kHz) 85(Hz)
1280 x 1024 64.0(kHz) 60(Hz)
1280 x 1024 80.0(kHz) 75(Hz)
1280 x 1024 91.1(kHz) 85(Hz)
1600 x 1200 75.0(kHz) 60(Hz)
1600 x 1200 81.3(kHz) 65(Hz)
1600 x 1200 87.5(kHz) 70(Hz)
1600 x 1200 93.8(kHz) 75(Hz)
1792 x 1344 83.6(kHz) 60(Hz)
1856 x 1392 86.3(kHz) 60(Hz)
1920 x 1440 90.0(kHz) 60(Hz)
