Philips 109E50/00 User manual

electronic user's manual
file:///D|/EDFU/crt_19_5/edoc/english/109E/manual.html2005-04-21 ¤W¤È 09:34:47

Safety & Troubleshooting
Safety and Troubleshooting Information
Safety Precautions and Maintenance • Troubleshooting • Regulatory Information • Other
Related Information
Safety precautions and maintenance
WARNING: Use of controls, adjustments, or procedures other than those
specified in this documentation may result in exposure to shock, electrical
hazards, and/or mechanical hazards.
Read and follow these instructions when connecting and using your computer monitor:
●Disconnect the monitor from the power supply if the monitor is not to be used for an
extended period of time.
●Do not attempt to remove the back cover, as you will be exposed to a shock hazard. The
back cover should only be removed by qualified service personnel.
●Do not place objects on top of the monitor cabinet, objects could fall into vents or cover them
and prevent proper cooling of the monitor's electronic devices.
●To avoid the risk of shock or permanent damage to the set, do not expose the monitor to rain
or excessive moisture.
●Do not use alcohol or ammonia-based liquid to clean the monitor. If necessary, clean with a
slightly damp cloth. Disconnect the monitor from the power supply before cleaning.
●When positioning the monitor, make sure the power plug and outlet are easily accessible.
Consult a service technician if the monitor does not operate normally when operating instructions of
this manual are followed.
RETURN TO TOP OF THE PAGE
file:///D|/EDFU/crt_19_5/edoc/english/109E/SAFETY/SAFETY.HTM2005-04-21 ¤W¤È 09:34:50

About This Electronic User's Manual
About This Electronic User's Manual
About This Guide • Other Documents You May Need • Notational Descriptions
About This Guide
This electronic user's guide is intended for anyone who uses the Philips Color Monitor. It describes
the monitor's features, setup, operation and all other information, which is the same exact
information described in our printed version.
The sections are as follows:
●Safety and Troubleshooting Information provides tips and solutions for common problems,
and other related information you may need.
●About This Electronic User's Manual gives overview of what information are included as well
as notation icon descriptions and other documentation you can refer to.
●Product Information gives an overview of the monitor's features and as well as the technical
specifications for this monitor.
●Installing Your Monitor describes the initial setup process and gives an overview of how to
use the monitor.
●On Screen Display provides information on adjusting the settings on your monitor.
●Customer Care and Warranty is a list of worldwide Philips consumer information centers
along with the help desk phone numbers and information on the applicable warranty of your
product..
●Glossary provides more information for technical terms.
●Download allows users to install the entire manual on their hard drive.
●Frequently Asked Questions provides answers to commonly asked questions.
RETURN TO TOP OF THE PAGE
Other Documents You May Need
In addition to this Electronic User's Guide, you may need to refer to the following documentation:
file:///D|/EDFU/crt_19_5/edoc/english/109E/ABOUT/ABOUT.HTM (1 of 3)2005-04-21 ¤W¤È 09:34:51

About This Electronic User's Manual
●Philips Color Monitor Quick Start Guide which summarizes the steps for setting up the
monitor. This is included with this product.
RETURN TO TOP OF THE PAGE
Notational Descriptions
The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in
italic type. These blocks are notes, cautions, and warnings, and they are used as follows:
NOTE: This icon indicates important information and tips that help you make
better use of your computer system.
CAUTION: This icon indicates information that tells you how to avoid either
potential damage to hardware or loss of data.
WARNING: This icon indicates the potential for bodily harm and tells you how
to avoid the problem.
SMART HELP: This icon indicates helpful information when adjusting the On
Screen Display of your monitor.
Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such
cases, the specific presentation of the warning is mandated by regulatory authority.
file:///D|/EDFU/crt_19_5/edoc/english/109E/ABOUT/ABOUT.HTM (2 of 3)2005-04-21 ¤W¤È 09:34:51

About This Electronic User's Manual
RETURN TO TOP OF THE PAGE
©2005 Koninklijke Philips Electronics N.V.
All rights reserved. Reproduction, copying, usage, modifying, hiring, renting, public performance, transmission and/or
broadcasting in whole or in part is prohibited without written consent of Philips Electronics N.V.
file:///D|/EDFU/crt_19_5/edoc/english/109E/ABOUT/ABOUT.HTM (3 of 3)2005-04-21 ¤W¤È 09:34:51

109E Product Information
Product Information
Product Features • Lead-free product • Technical Specifications • Automatic Power Saving • Physical
Specification • Pin Assignment • Product Views
Product Features
Model Regulation Color
109E50 TCO'03 Gray
109E51 MPRII Gray
109E5
●19-inch (18.0" VIS) color monitor with excellent front of screen performance for use with MACs and PCs
●Autoscan covers horizontal frequencies up to 92 kHz offering a maximum resolution of 1920 x 1440 with
flicker free display of 1280 x 1024 up to 86 Hz
●Flat Square High Contrast CRT with 0.26 mm pitch (0.23 hdp)
●XSD-Xtra Space Design for large screen display in a small footprint: 19-inch conventional monitor with
maximum depth of only 437 mm/17.2"
●Multimedia Base option
●sRGB for true on screen color representation.
●FCC, CE (in selected countries only) and ISO9241, ISO14001 certified
RETURN TO TOP OF THE PAGE
Lead-free product
Philips eliminated toxic substances like lead from its displays. Lead-free display helps protect your health and
promotes environmentally sound recovery and disposal of waste from electrical and electronic equipment. Philips
complies with the European Community stringent RoHS Directive mandating restrictions on hazardous
substances in electrical and electronic equipment. With Philips, you can be confident that your display device
does not harm the environment.
Technical Specifications*
file:///D|/EDFU/crt_19_5/edoc/english/109E/PRODUCT/PRODUCT.HTM (1 of 5)2005-04-21 ¤W¤È 09:34:52

109E Product Information
CRT
• Size and deflection 19 inch / 46 cm ; 90° deflection angle
• Dot pitch 0.26 mm
• Horizontal pitch 0.23 mm
• Tube type Shadow mask, real flat, high contrast, anti-glare, anti-static,
anti reflection
• Phosphor P22
• Recommended display area 14.0" x 10.4" / 355 x 265 mm
• Maximum display area 14.4" x 10.8" / 365 x 270 mm
SCANNING
• Horizontal scanning 30 - 92 KHz
• Vertical scanning 50 - 160 Hz
VIDEO
• Video dot rate 240 MHz
• Input impedance
- Video 75 ohm
- Sync 4.7 kOhm
• Input signal levels 0.7 Vpp
• Sync input signal Separate sync
Composite sync
• Sync polarities Positive and negative
WHITE COLOR TEMPERATURE
Chromaticity CIE coordinates:
• at 9300 degrees K x = 0.283 / y = 0.297
• at 6500 degrees K x = 0.313 / y = 0.329
sRGB
file:///D|/EDFU/crt_19_5/edoc/english/109E/PRODUCT/PRODUCT.HTM (2 of 5)2005-04-21 ¤W¤È 09:34:52

109E Product Information
sRGB is a standard for ensuring correct exchange of colors between different devices (e.g.
digital cameras, monitors, printers, scanners, etc.)
Using a standard unified color space, sRGB will help represent pictures taken by an sRGB
compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors are
calibrated and you can rely on the correctness of the colors shown on your screen.
Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to a
predefined setting as well as the color gamut. Therefore it is important to select the sRGB
setting in the monitor's OSD.
To do so, open the OSD by pressing the OK button on the front of your monitor. Use the down
button to go to Color temperature and press OK again. Then move the down button to go to
sRGB and press OK again.
Exit this OSD.
After this, please don't change the brightness or contrast setting of your monitor. If you change
either of these, the monitor will exit the sRGB mode and go to a color temperature setting of
6500K.
* These information are subject to change without notice.
RETURN TO TOP OF THE PAGE
Automatic Power Saving
If you have VESA's DPMS compliance display card or software installed in your PC, the monitor can automatically
reduce its power consumption when not in use. And if an input from a keyboard, mouse or other input device is
detected, the monitor will automatically "wake up". The following table shows the power consumption and
signaling of this automatic power saving features:
Power Management Definition
VESA's Mode Video H-sync V-sync Power Used Power
Saving (%) LED color
Active On Yes Yes Typical 65W 0 % Green
Sleep Off No No < 1W 99% Flashing
Green
Switch Off Off -- -- < 1W 99% Off
file:///D|/EDFU/crt_19_5/edoc/english/109E/PRODUCT/PRODUCT.HTM (3 of 5)2005-04-21 ¤W¤È 09:34:52

109E Product Information
This monitor is ENERGY STAR®compliant. As an ENERGY STAR®Partner, PHILIPS has
determined that this product meets the ENERGY STAR®guidelines for energy efficiency.
RETURN TO TOP OF THE PAGE
Physical Specifications
• Dimensions 17.3" x 17" x 17.2" / 440 x 433 x 437 mm (including base)
17.3" x 15" x 17.2" / 440 x 383 x 437 mm (excluding base)
• Weight 17.8 kg
• Power supply 100-240VAC, 60-50Hz
• Temperature (operating) 0° to 40°C / 32° to 104°F
• Temperature (storage) -25° to +65°C / -13° to +149°F
• Relative humidity
(storage) 5% to 95%
* Resolution 1280 x 1024, standard size, contrast max., brightness 50%, 9300°, full white pattern.
* These information are subject to change without notice.
RETURN TO TOP OF THE PAGE
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable (IBM systems):
file:///D|/EDFU/crt_19_5/edoc/english/109E/PRODUCT/PRODUCT.HTM (4 of 5)2005-04-21 ¤W¤È 09:34:52

109E Product Information
Pin
No. Assignment
Pin
No. Assignment
1Red video input 9No pin
2Green video input 10 Logic ground
3Blue video input 11 Identical output - connected
to pin 10
4Identical output - connected
to pin 10 12 Serial data line (SDA)
5Ground 13 H. Sync / H+V
6Red video ground 14 V. Sync (VCLK for DDC)
7Green video ground 15 Data clock line (SCL)
8Blue video ground
RETURN TO TOP OF THE PAGE
Views
Follow the links to see various views of the monitor and its components.
Front View
Rear View
