Philips 190S5CG/00 User manual

Horizontal frequencies
30 - 82KHz
Service
Service
Service
TABLE OF CONTENTS
Published by BCU Monitors Printed in Taiwan Copyright reserved Subject to modification M Feb. 26 2004
Description Page
Important Safety Notice ---------------------------- 2
Technical Data --------------------------------------- 3
Front control & Connections-----------------------4~5
On-screen Display(OSD)------------------------------6
OSD Aging Mode & Lock/unlock----------------------7
Pixel Defect Policy-------------------------------------8
Warning Message--------------------------------------9
Factory Mode------------------------------------------10
Wiring Message----- ----------------------------------11
Mechanical Instructions-------------------------12~13
Electrical Instructions---------------------------14~15
ISP Instruction ----------------------------------16~17
Description Page
DDC Instructions & HEX Data------------------18~23
Safety Test Requirements--------------
Block Diagram----------------------
------------24
-----------------25
Control Diagram & C.B.A.----------------------------32
Inverter & Adapter Diagram & C.B.A.----------33~36
Warning and Notes----------------------------------37
Exploded View
Recommended parts list ----------------------------39
Spare
Scaler Diagram----------------------------------26~29
Scaler board C.B.A.------------------------------30~31
--------------------------------------- 38
parts list ---------------------------------------40
General product specification------------------41~62
SH 4 190S5
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
SAFETY NOTICE
GB 3138 106 10364
19" TFT LCD Colour Monitor
«
190S5CG/00
190S5CB/00
http://www.wjel.net

Important Safety Notice
2
FOR PRODUCTS CONTAINING LASER :
Invisible laser radiation when open.
AVOID DIRECT EXPOSURE TO BEAM.
Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
The use of optical instruments with this
product will increase eye hazard.
DANGER-
CAUTION-
CAUTION-
TO ENSURE THE CONTINUED RELIABILITY OF THIS
PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S REPLACEMENT
PARTS, WHICH ARE LISTED WITH THEIR
PART NUMBERS IN THE PARTS LIST SECTION OF THIS SERVICE
MANUAL.
190S5 LCD
Proper service and repair is important to the safe, reliable operation
of all Philips Consumer Electronics Company** Equipment. The
service procedures recommended by
Philips and described in this service manual are effective methods of
performing service operations. Some of these service operations
require the use of tools specially designed for the purpose. The
specialtoolsshouldbeusedwhenandasrecommended.
It is important to note that this manual contains various CAUTIONS
andNOTICESwhichshouldbecarefullyreadinordertominimizethe
risk of personal injury to service personnel. The possibility exists that
improper service methods may damage the equipment. It is also
important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. Philips could not possibly know, evaluate and
advise the service trade of all conceivable ways in which service
might be done or of the possible hazardous consequences of each
way. Consequently, Philips has not undertaken any such broad
evaluation. Accordingly, a servicer who uses a service procedure or
toolwhichisnotrecommendedbyPhilipsmustfirstsatisfyhimself
thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
* * Hereafter throughout this manual, Philips Consumer
Electronics Company will be referred to as Philips.
WARNING
Critical components having special safety characteristics are
identified with a by the Ref. No. in the parts list and enclosed
withinabrokenline*
(where several critical components are grouped in one area) along
with the safety symbol on the schematics or exploded views.
Use of substitute replacement parts which do not have the same
specified safety characteristics may create shock, fire, or other
hazards.
Under no circumstances should the original design be modified or
altered without written permission from Philips. Philips assumes no
liability, express or implied, arising out of any unauthorized
modification of design.
Servicer assumes all liability.
*BrokenLine
Take care during handling the LCD module with backlight unit
- Must mount the module using mounting holes arranged in four
corners.
- Do not press on the panel, edge of the frame strongly or electric
shock as this will result in damage to the screen.
- Do not scratch or press on the panel with any sharp objects, such
as pencil or pen as this may result in damage to the panel.
- Protect the module from the ESD as it may damage the electronic
circuit (C-MOS).
- Make certain that treatment person s body are grounded through
wrist band.
-Donotleavethemoduleinhightemperatureandinareasofhigh
humidityforalongtime.
-Avoidcontactwithwaterasitmayashortcircuitwithinthe
module.
-Ifthesurfaceofpanelbecomedirty,pleasewipeitoffwithasoft
material. (Cleaning with a dirty or rough cloth may damage the
panel.)
Go to cover page
http://www.wjel.net

190S5 LCD 3
Technical Data
Go to cover page
Automatic Power Saving
If you have VESA DPMS compliance display card or software
installed in your PC, the monitor can automatically reduce its
power consumption when not in use. If an input from a keyboard,
mouse or other input device is detected, the monitor will 'wake
up' automatically. The following table shows the power consumption
and signaling of this automatic power saving feature:
Power Management Definition
VESA
Mode Video H-sync V-sync Power Used
LED
color
ON Active Yes Yes <34W
(typ.) Blue
OFF Blanked No No <1W Amber
This monitor is ENERGY STAR compliant. As an ENERGY
STAR Partner, PHILIPS has determined that this product meets
the ENERGY STAR guidelines for energy efficiency.
Data Storage
Factory preset mode:
This monitor has 15 factory-preset modes as indicated in
the following table
Meanwhile, it also reverse 15 sets data space available for user
Storage New timings data.
# Resolution H-Frequency Pixel rate V-Frequency
1 640X350 31.5KHz 25.175 70Hz
2 720X400 31.5KHz 28.322 70Hz
3 640X480 37.5KHz 31.501 75Hz
4 640X480 35.0KHz 30.24 67Hz
5 640X480 31.5KHz 25.175 60Hz
6 800X600 35.2KHz 36 56Hz
7 800X600 46.9KHz 49.498 75Hz
8 800X600 37.9KHz 40 60Hz
9 832X624 49.7KHz 57.28 75Hz
10 1024X768 60.0KHz 78.75 75Hz
11 1024X768 48.4KHz 65 60Hz
12 1152X870 68.7KHz 100 75Hz
13 1152X900 71.8KHz 108 76Hz
14 1280X1024 64.0KHz 108 60Hz
15 1280X1024 80.0KHz 135 75Hz
Technical Specifications
LCD Panel
Type NR. : LM190E03 (LPL.)
Number of Pixels. : 1280 (H) x1024 (V)
Physical Size. : 404.2(w)*330.0(h)*20.0(d) mm
Pixel Pitch. : 0.264 (per one triad) x 0.264 mm
Color pixel arrangement. : RGB vertical stripes
Support Color : 16.2M colors
Display Mode : Normally White
Backlight. : CCFL edge light system
Active area. (WXH). : 376.320 x 301.056mm (19 diagonal)
Viewing Angle. : Vertical 140 degree, Horizontal 140
degree (CR=10)
Contrast ratio. : 500:1 (Typ.)
White luminance. : 250nits (Typ.)
Scanning frequencies
Horizontal scan : 30 - 82 KHz
Vertical scan : 56 - 76 Hz
Power supply
Main Voltage : AC 90 - 135 Vrms and 170 - 264 Vrms,
50/60±2Hz
Power consumption : 40 watts max.
Operating < 34W(typical),
standby<1W.
DC power switch off < 1W.
Video
Video dot rate: 135MHZ
Input impedance
-Video 75ohm
-Sync 2.2K ohm
Input signal levels 0.7Vpp
Sync input signal Separate sync
Composite sync
Sync on green
Sync polarities Positive and negative
Video interface D-Sub (analog)
Resolution & Preset Modes
Maximum : 1280*1024 at 75 Hz
Recommended :1280*1024 at 60 Hz
Physical Specifications
Dimension (WxHxD) : 425 x 377 x235 mm (in lowest position)
Weight : 7 Kg
Tilt/Swivel :-5 -30 /+-175
Temperature :5 -30 (Operating)
-20 -60 (Storage)
Relative humidity :20%-80%
System MTBF :50K hours(Including CCFL 40K hours)
The 15 pin D-SUB connector(male) of the signal cable
Pin assisgnemnt:
Pin
No. Assignment Pin No. Assignment
1Red video input 9DDC +5V
2Green video input/SOG 10 Logic ground
3Blue video input 11 Ground
4GND 12 Serial data line (SDA)
5GND-Cable detect 13 H. Sync / H+V
6Red video ground 14 V. Sync
7Green video ground 15 Data clock line (SCL)
8Blue video ground
R
R
R
''
http://www.wjel.net

Connection to PC
4190S5 LCD
Go to cover page
Connecting to Your PC
1) Plug in the cables into connectors
Note: If you use an Apple
Macintosh, you need to connect the
special Mac adapter to one end of
the monitor signal cable
Front View Product Description
Accessory Pack
Unpack all the parts.
http://www.wjel.net

190S5 LCD
Connection to PC
Go to cover page
5
2) Connect to PC
a)Turn off your computer and unplug its power cable.
b)Connect the monitor signal cable to the video
connector on the back of your computer.
c)Plug the power cord of your computer and your monitor
into a nearby outlet.
d)Turn on y our computer and monitor. If the monitor
displays an image, installation is complete.
Cable management
a) Remove the top cover of the arm box
b) Put the cables inside the arm box
c) Put the top cover back
http://www.wjel.net

6190S5 LCD On Screen Display
Go to cover page
The OSD Tree
Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want to
work your way around the different adjustments later on.
http://www.wjel.net

7
190S5 LCD
OSD Lock/Unlock, Aging Mode
Go to cover page
Front Control Panel
To Lock/Unlock OSD FUNCTION(User Mode)
The OSD function can be locked by pressing"OK"button(1) for more
than 10 seconds, the screen shows following windows for 3 seconds.
Everytime when you press"AUTO" or "OK" button, this message app-
ears on the screen automatically.
ATTENTION SIGNAL
OSD MAIN CONTROLS UNLOCKED
Unlock OSD function
Locked OSD function can be released by pressing "OK" button for more
than 10 seconds again
ATTENTION SIGNAL
OSD MAIN CONTROLS LOCKED
NO VIDEO INPUT
This screen appears if there is no video signal input. Please check that
the signal is properly connected to the video card of PC and make sure
PC is on
ATTENTION SIGNAL
CHECK CABLE CONNECTION
CANNOT DISPLAY THIS VIDEO MODE..
This screen warns when the input frequency from the computer is not
a standard video mode or out of the monitor's scanning range.
Please change the display mode of the operating software in the com-
puter(i.e.windows) to 1280*1024@60HZ for best display results.
ATTENTION SIGNAL
CANNOT DISPLAY THIS VIDEO
MODE,CHANGE COMPUTER DISPLAY
INPUT TO 1280*1024@60HZI
WAIT FOR AUTOMATIC ADJUSTMENT
This screen appears when you press the "AUTO" buttons at the same
time. It will disappear when the monitor is properly adjusted
ATTENTION SIGNAL
WAITING FOR AUTOMATIC ADJUSTMENT
Access Aging.. Mode
Step1:TurnoffLCDmonitor, and disconnect Interface Cable betwe-
en Monitor and PC.
Step 2 : [Push AUTO " " & " " buttons at the same time and
hold it]+[Press power " " button untill comes out " AGING screen"
] => then release all buttons.
Bring up:
AGING...
After 15 seconds, bring up:
After 15 seconds, bring up:
AGING...
After 15 seconds, bring up:
----------
----------
repeatly
Connect Signal cable again=> go back to normal display
http://www.wjel.net

8190S5 LCD Pixel Defect Policy
Go to cover page
Philips' Flat Panel Monitors Pixel Defect Policy
Pixels and Subpixels
Types of Pixel Defects
Philips strives to deliver the highest quality products. We use some of
the industry's most advanced manufacturing processes and practice
stringent quality control. However, pixel or subpixel defects on the TFT
LCD panels used in flat panel monitors are sometimes unavoidable.
No manufacturer can guarantee that all panels will be free from pixel
defects, but Philips guarantees that any monitor with an unacceptable
number of defects will be repaired or replaced under warranty.
This notice explains the different types of pixel defects and defines
acceptable defect levels for each type. In order to qualify for repair or
replacement under warranty, the number of pixel defects on a TFT LCD
panel must exceed these acceptable levels.
For example, no more than 0.0004% of the subpixels on a 15" XGA
monitor may be defective. Additionally, because some types or
combinations of pixel defects are more noticeable than others, Philips
sets even higher quality standards for those.
A pixel, or picture element, is composed of three subpixels in the
primary colors of red, green and blue. Many pixels together form an
image. When all subpixels of a pixel are lit, the three colored subpixels
together appear as a single white pixel. When all are dark, the three
colored subpixels together appear as a single black pixel.
Other combinations of lit and dark subpixels appear as single pixels of
other colors.
Pixel and subpixel defects appear on the screen in different ways.
There are two categories of pixel defects and several types of subpixel
defects within each category.
Bright Dot Defects Bright dot defects appear as pixels or subpixels that
are always lit or "on".
These are the types of bright dot defects:
One lit red, green or blue subpixel
Two adjacent lit subpixels:
- Red + Blue = Purple
-Red+Green=Yellow
- Green + Blue = Cyan (Light Blue)
Three adjacent lit subpixels
(one white pixel)
Black Dot Defects
Proximity of Pixel Defects
Pixel Defect Tolerances
Black dot defects appear as pixels or subpixels that are always dark or
"off".
These are the types of black dot defects:
One dark subpixel
Two or three adjacent dark subpixels
Because pixel and subpixels defects of the same type that are nearby
one another may be more noticeable, Philips also specifies tolerances
for the proximity of pixel defects.
In order to qualify for repair or replacement due to pixel defects during
the warranty period, a TFT LCD panel in a Philips flat panel monitor
must have pixel or subpixel defects exceeding the tolerances listed in
the following tables.
http://www.wjel.net

9
190S5 LCD
Go to cover page
Warning Message Table
Warning message table
Item AttentionSignals DisplayTime ConditionAttentionoff
1CANNOTDISPLAY
THIS VIDEO MODE,
CHANGE COMPUTER
DISPLAY
INPUTTO 1024X768
@ 60HZ
30 mins This warning appears when theinput signal fromyour
computer is notinastandardvideomodeorisoutof the
monitor’sscanning range.After 30 mins,monitor enters
sleeping mode.
No
2NO VIDEO INPUT30 mins This message appears when there is nosignal inputbutwith
cable while AC orDC while power on.After 30 mins,monitor
enters sleeping mode.
Yes
Show floating
menu
ATTENTION
SIGNAL OFF
3CHECK CABLE
CONNECTION
30 mins This message appears when a signal cable is disconnected
while monitorisworking.After 30 mins,monitorenters
sleeping mode.
Yes
Show floating
menu
ATTENTION
SIGNAL OFF
4ENTERING SLEEP
MODE
3secs This message appears when monitorisabouttoenter power
saving mode.
No
5WAITING FOR
AUTOMATIC
ADJUSTMENT
till auto
adjustment
finished
This message is displayedwhen theautoadjustment button
is pressed. Itdisappears when automaticadjustments are
completed.
No
6USE 1024 X 768 FOR
BESTRESULT
Ontop of OSD
main menu
The message will show up at thetop of theOSD main menu
in redcolorwhen theinputresolutionisnotthe1024x768.
Yes
7OSD MAIN
CONTROLS LOCKED
3secs/orTill
OSD MAIN
CONTROLS
UNLOCKED
appear
This message will appear 3secondstoindicate theOSD
MAIN CONTROLS statuswhen tolock orun-lock it by
pressing MENU(OK) buttonformore than 10 secondswhile
there is videoinputfromPC. This functionprovides the
alternativethat user can lock all theOSD main controlin
case user don’twant theFOS performance setting tobe
changed, forinstance,during commercial exhibition.
No functionwhen
push10secs(If
OSD lock then
attentionoff, not
anymessage and
onlyattentionon)
8OSD MAIN
CONTROLS
UNLOCKED
3secs This message will appear 3secondstoindicate theOSD
MAIN CONTROLS statuswhen toun-lock it bypressing
MENU(OK) buttonformore than 10 secondswhile there is
videoinputfromPC.
No functionwhen
push10secs
9 ATTENTION SIGNAL
ON
ATTENTION SIGNAL
OFF
3secs
3secs
This message will appear 3secondstoindicate the attention
signals in ON orOFF statuswhen toswitch this functiononor
off bypressing theAUTObuttonformore than 10 seconds
while at novideoinputfromPC.
Yes
10 THIS IS 85HZ
OVERSCAN, CHANGE
COMPUTER DISPLAY
INPUTTO
1024X768@60HZ
10 mins This message will appear 5secondsinevery60secondsfor
10 minutes when theinputof PC videotiming is at 85Hz
mode.
Remark: AUTOis still functional in this mode
No
11 thewindow of OSD
MAIN CONTROLS
60 secs This message will appear when theOK buttonispressed. Yes
12 thewindow of
BRIGHTNESS
60 secs This message will appear when theBRIGHTNESS buttonis
pressed.
Yes
13
(Notfor
150S
project)
SELECTED INPUT
NOTAVAILABLE
5secs When just one input(analogordigital), press inputswitch or
hotkey, then after show this warning message 5sec, return
tooriginal input.
TBD
http://www.wjel.net

10 190S5 LCD Factory Mode
Go to cover page
Hudson 190S5 T034 2004-01-29
Front Control Panel
Access Factory Mode
How to get into Factory Mode Menu
Step1:
Turn off monitor.
Step2:
[Push AUTO " " & OK " " buttons at the same time and hold it]
+[Press power " " button untill comes out "Windows screen" ]
=> then release all buttons
Step3:
Press OK " " button, bring up Factory mode indication as shown
in Fig2.
Mean: it is not
1280*1024
resolution now
Factory Mode indicator
Factory Menu
Cursor can move on gray color area
Hot key function: by pressing " up " and " DOWN " key
Simultaneously at User Mode (or Factory Mode)
(PS: The OffsetRGBfunction can be used on reduce or eliminate
snowy noise on the background when the resolution of video signal
is 1280*1024 vertical 60Hz. Slightly increase or decrease the value
until snowy noise completely disappear
BL : Black level value
SUB- BRI : Brightness value range( Min Max )
SUB- CON : Contrast value range( Min Mid Max )
SRGB- B : Brightness of sRGB
SRGB- C : Contrast of sRGB
Gain- m : Minimum value of User Gain
Gain- M : Maximum value of User Gain
AUTO- SUB : To do Auto color function when push Menu key in white
pattern
OSDTIMER : OSD time out control( sec)
IDX : Limit current of inverter
SCALER : Read/Write scaler register
Panel : HS ( Hannstar panel )
LG ( LG. Philips panel )
AU
QDI ( Quanta Display Inc.)
DEFAULT
Contrast adjustment (Sub - Contrast).Use this menu item
to adjust the contrast gain of pre-amp ranges from 0 to
255.
9300 K R G B
6500 K R G B
Color temperature gain adjustment. Use these menu
items to adjust the RGB gains of pre-amp for different color
temperatures, ranges from 0 to 255
Sub-Brightness adjustment. Use this menu item to adjust .
The brightness level (DC - level) of pre-amp range from 0
to 255. (R/G/B ANALOG DC-level)
R/G/B GAIN adjustment. Use this menu item to adjust the
R/G/B (GAIN) of Amp. Range from 0 to 255.
(R/G/B ANALOG GAIN Values)
SUB- CON:
OFFSET R G B:
GAIN R G B:
http://www.wjel.net
