Product Information
• Product
Features
• SmartImage
• Technical
Specifications
• Resolution &
Preset Modes
• Philips Pixel
Defect Policy
• Automatic
Power Saving
• Physical
Specification
• Pin
Assignment
• Product
Views
• Physical
Function
• Rotating the
Monitor
Product Information
Product Features
200P7
●Outstanding front of screen performance
❍SmartImage for the best LCD viewing experience
❍UXGA, 1600x1200 resolution for sharper display
❍VGA analog plus dual digital DVI plugs for input choice
❍Fast response time for better display of moving images
●Maximum comfort for maximum productivity
❍Display more images and content without scrolling
❍90 degree screen rotation and smart cable management
❍Built-in hight-speed USB 2.0 solution for easy connections
●Best total cost of ownership solution
❍SmartManage compatibility enables LAN-based asset management
❍Lead-free design safeguards our environment
●Great convenience
❍Easy plug-and-play DVI for a true digital experience
❍Embedded power supply eliminates external power adaptors
RETURN TO TOP OF THE PAGE
Lead-free Product
Philips eliminated toxic substances like lead from its displays. Lead-free display helps protect your health
and promotes environmentally sound recovery and disposal of waste from electrical and electronic
equipment.Philips complies with the European Community stringent RoHS Directive mandating
restrictions on hazardous substances in electrical and electronic equipment. With Philips, you can be
confident that your display device does not harm the environment.
SmartImage
Introduction
Philips SmartImage features with Philips LightFrame technology to enhance your front of screen performance depend
by content type. It is not only changing brightness or contrast profiles but utilizing Philips Pacific3 hardware chip inside
monitor to enrich color of image and sharpen text. No matter your application is on text processing or watching image
or video, you can always get best viewing experience from Philips SmartImage.
file:///D|/My%20Documents/dfu/200P7/english/200p7/product/product.htm (1 of 10)2005-12-14 9:24:44 AM

Product Information
How to enable SmartImage
1. Press to launch the SmartImage on screen display;
2. Keep press to toggle between Office Work, Internet, Image Viewing, Video Playback, Custom, and Off;
3. The SmartImage on screen display will remain on screen for 3 seconds or you can also press “OK“ to make
confirmation.
Expect using key to scroll down, you can also press buttons to choose and press “ok” to confirm selection
and close the SmartImage OSD.
There are six modes to be selected:
1. Office Work: Select this mode for general office application, like word processing, spreadsheet, and email. The
screen is dominated by text.
2. Internet: Select this mode for Internet application, especially web browsing. The screen is mixed by text and
picture.
3. Image Viewing: Select this mode for image viewing application, especially in slid show. The screen is
dominated by picture.
4. Video Playback: Select this mode for video application, like Microsoft Media Player or Real Player. The screen
is dominated by video.
5. Custom: Select this mode for you to adjust the rate of luminance, contrast gap, color boost, sharpness, and
text enhancement by yourself.
●Press to enter sub-
menu selections
●Press or to toggle
between
❍Exit
❍Luminance
❍Contrast Gap
❍Color Boost
❍Sharpness
❍Text Enhancement
❍Reset
●to adjacent sub-
menu selections
●Then, press "OK" to go
back to sub-menu and
SmartImage OSD.
file:///D|/My%20Documents/dfu/200P7/english/200p7/product/product.htm (2 of 10)2005-12-14 9:24:44 AM

Product Information
6. Off: No optimization by SmartImage.
RETURN TO TOP OF THE PAGE
Technical Specifications*
LCD PANEL
• Type TFT LCD
• Screen size 20.1" / 51cm
• Pixel Pitch 0.255 x 0.255mm
• LCD Panel type
1600 x 1200pixels
R.G.B. vertical stripe
Anti-glare polarizer, hard coated
• Effective viewing area 408 x 306mm
• Display Colors 8 bits interface (16M colors)
SCANNING
Vertical refresh rate 56Hz-85Hz
Horizontal Frequency 30kHz-98kHz (Analog input)
VIDEO
• Video dot rate 202.5 MHz
• Input impedance
- Video 75 ohm
- Sync 2K2 ohm
• Input signal levels 0.7 Vpp
• Sync input signal
Separate sync
Composite sync
Sync on green
• Sync polarities Positive and negative
Optical characteristics
• Peak contrast angle 6 o'clock
• White Chromaticity: x: 0.283 y: 0.297 (at 9300°K)
x: 0.313 y: 0.329 (at 6500°K)
* This data is subject to change without notice.
RETURN TO TOP OF THE PAGE
Resolution & Preset Modes
file:///D|/My%20Documents/dfu/200P7/english/200p7/product/product.htm (3 of 10)2005-12-14 9:24:44 AM

Product Information
• Maximum 1600 x 1200 at 75Hz(analog input)
1600 x 1200 at 60Hz(digital input)
•
Recommended 1600 x 1200 at 60Hz * at DVI digital input
15 factory preset modes:
H. freq (kHz) Resolution V. freq (Hz)
31.5 640*350 70 (IBM VGA 10h)
31.5 720*400 70
31.5 640*480 60
37.5 640*480 75
35.2 800*600 56
37.9 800*600 60
46.9 800*600 75
48.4 1024*768 60
60.0 1024*768 75
60 1280*960 60
69.0 1152*870 75
63.9 1280*1024 60
80.0 1280*1024 75
75.0 1600*1200 60
93.8 1600*1200 75 (Analog only)
RETURN TO TOP OF THE PAGE
Automatic Power Saving
If you have VESA DPMS compliance display card or software installed in your PC, the monitor can automatically
reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected,
the monitor will be waken up automatically by your PC. The following table shows the power consumption and signaling
of this automatic power saving feature:
Power Management Definition
VESA Mode Video H-sync V-sync Power Used LED color
Active ON Yes Yes < 70W Green
Sleep OFF No No < 1W Amber
Switch Off OFF - - < 1W OFF
This monitor is ENERGY STAR®compliant. As an ENERGY STAR®Partner, PHILIPS has
determined that this product meets the ENERGY STAR®guidelines for energy efficiency.
file:///D|/My%20Documents/dfu/200P7/english/200p7/product/product.htm (4 of 10)2005-12-14 9:24:44 AM

Product Information
RETURN TO TOP OF THE PAGE
Physical Specifications
• Dimension (WxHxD) 461 x 421 x 235 mm (incl. Pedestal) (in lowest position)
• Weight 8.9 Kg
• Tilt / Swivel -5° ~ 25° / ± 45°
• Height adjustment rang 130 mm
• Power supply 100— 240 VAC, 60 - 50 Hz
• Power consumption 50 W* (typ.)
• Temperature 5° C to 35° C (operating)
-20° C to 60° C (storage)
• Relative humidity 20% to 80%
• System MTBF 50K hrs (excluding CCFL 40K hrs)
• Cabinet color Black/Silver
• Altitude
- storage/shipment
- operating 0 - 40,000 feet (12,192m)
0 - 12,000 feet (3657.6m)
* This data is subject to change without notice.
* Resolution 1600 x 1200, standard size, contrast max., brightness 50%, 6500° K, full white pattern.
RETURN TO TOP OF THE PAGE
Pin Assignment
1. The DVI connector contains 24 signal contacts organized in three rows of eight contacts. Signal pin assignments are
listed in the following table:
Pin
No. Signal Assignment Pin No. Signal Assignment Pin
No. Signal Assignment Pin No. Signal Assignment
1T.M.D.S. Data2- 9T.M.D.S. Data1- 17 T.M.D.S. Data0- C1 * Analog R
2T.M.D.S. Data2+ 10 T.M.D.S. Data1+ 18 T.M.D.S. Data0+ C2 * Analog G
3T.M.D.S. Data2
Shield 11 T.M.D.S. Data1 Shield 19 T.M.D.S. Data0 Shield C3 * Analog B
4NC 12 NC 20 NC C4 * Analog H-sync
5NC 13 NC 21 NC C5
* Analog GND
(Analog R, G, B
return)
6DDC Clock 14 +5V 22 T.M.D.S. Clock
Shield
file:///D|/My%20Documents/dfu/200P7/english/200p7/product/product.htm (5 of 10)2005-12-14 9:24:44 AM

Product Information
7DDC Data 15 Ground (return for
+5V and H/V-sync) 23 T.M.D.S. Clock+
8* Analog V-sync 16 Hot Plug Detect 24 T.M.D.S. Clock-
2. The 15-pin D-sub connector (male) of the signal cable:
Pin
No. Assignment Pin No. Assignment
1Red video input 9+5V
2Green video input/SOG 10 Ground
3Blue video input 11 Ground
4Ground 12 Serial data line (SDA)
5Cable detect 13 H. Sync / H+V
6Red video ground 14 V. Sync (VCLK for DDC)
7Green video ground 15 Data clock line (SCL)
8Blue video ground
RETURN TO TOP OF THE PAGE
Product Views
Follow the links to see various views of the monitor and its components.
Front View Product Description
RETURN TO TOP OF THE PAGE
file:///D|/My%20Documents/dfu/200P7/english/200p7/product/product.htm (6 of 10)2005-12-14 9:24:44 AM

Product Information
Physical Function
1) Tilt
2) Swivel
file:///D|/My%20Documents/dfu/200P7/english/200p7/product/product.htm (7 of 10)2005-12-14 9:24:44 AM

Product Information
3) Height adjustment
4) Portrait display
