Philips 31BDL7531L User manual

Professional
Display Solutions
L Line
31BDL7531L
User Manual (English)
www.philips.com/welcome

31BDL7531L
ii
Table Of Contents
1. Safety Instructions ......................................................... 1
2. Preparations ..................................................................10
2.1. Unpacking ..........................................................10
2.2. Package Contents.............................................10
2.3. Holding the cabinet........................................11
2.4. Installation Notes.............................................11
3. Product overview .........................................................12
3.1. Front view...........................................................12
3.2. Rear view ............................................................12
3.3. Side view.............................................................12
3.4. Top view..............................................................12
3.5. Bottom view.......................................................12
4. Preparation....................................................................13
4.1. Testing the cabinet ..........................................13
4.2. Removing the opening...................................13
5. Installation .....................................................................14
6. Connection.....................................................................20
6.1. Connecting the signal and power cables..20
6.2. Mounting scheme............................................21
7. Installing the modules................................................22
8. Dehumidicationfunction........................................24
8.1. Installing the program....................................24
8.2. Firmwareupgradeandverication............24
8.3. Conguringdehumidicationsettings .....29
8.4. ActivatingDehumidicationfunction.......31
8.5. CancellingDehumidicationfunction.......31
8.6. Notes....................................................................31
9. Using the LED display controller..............................32
Appendices..............................................................................33
Appendix A. Warranty Statement.........................33
Appendix B. Troubleshooting................................ 35
Appendix C. Dew point VS. Relative Humidity..36
Appendix D. Optional Components/
Accessories ................................................................37
AppendixE. TechnicalSpecications................... 40
Appendix F. Magnet tension ................................. 42
Appendix G. Power/Data cable measure............ 43
Appendix H. Mounting scheme.............................47

31BDL7531L
1
1. Safety Instructions
Read this rst
The latest User’s Manual, Quick Start Guide and FAQ are available for download from the Philips website.
Warning & Symbols
Refer to the following graphic symbols to alert you to important information:
Notes: useful information that help you get better use of the product.
Cautions: notices describing actions that may damage your product.
Warnings: instructions that must be followed. Failure to observe may damage your product.
Safety guidelines
Useofcontrols,adjustmentsorproceduresotherthanthosespeciedinthisdocumentationmayresultin
exposure to shock, electrical hazards and/or mechanical hazards.
Safety precautions and maintenance
WARNING:Useofcontrols,adjustmentsorproceduresotherthanthosespeciedinthisdocumentationmayresult
in exposure to shock, electrical hazards and/or mechanical hazards.
Read and follow these instructions when connecting and using your display:
Operation:
• Keep the display out of direct sunlight and away from stoves or any other heat sources.
• Keep the display away from oil, otherwise the plastic cover may be damaged.
• It is recommended to set the display up in the well-ventilated place.
• Ultra-violetraylterisnecessaryofoutdooroperation.
• If the product will be used in extreme conditions such as high temperature, humidity, display patterns or operation time etc...
It is strongly recommended to contact Philips for Application engineering advice. Otherwise, its reliability and function may
not be guaranteed. Extreme conditions are commonly found at Airports, Transit Stations, Banks, Stock market, and Controlling
systems.
• Remove any object that could fall into ventilation holes or prevent proper cooling of the display’s electronics.
• Do not block the ventilation holes on the cabinet.
• When positioning the display, make sure the power plug and outlet are easily accessible.
• Whenturningothedisplaybydetachingthepowercord,wait6secondsbeforere-attachingthepowercordfornormal
operation.
• Ensure the use of an approved power cord provided by Philips at all times. If your power cord is missing, please contact your
local service center.
• Do not subject the display to severe vibration or high impact conditions during operation.
• Do not knock or drop the display during operation or transportation.
• The eye bolt is for usage in short-time maintenance and installation. We suggest not to use the eye bolt for more than 1 hour.
Prolong usage is prohibited. Please keep a clear safety area under the display while using the eye bolt.
Maintenance:
• To protect your display from possible damage, do not put excessive pressure on the LED display. When moving your display,
grasptheframetolift;donotliftthedisplaybyplacingyourhandorngersontheLEDdisplay.
• Unplug the display if you are not going to use it for an extensive period of time.
• Unplug the display if you need to clean it with a slightly damp cloth. The screen may be wiped with a dry cloth when the power
iso.However,neveruseorganicsolvent,suchas,alcohol,orammonia-basedliquidstocleanyourdisplay.
• To avoid the risk of shock or permanent damage to the set, do not expose the display to dust, rain, water or an excessively
moist environment.
• If your display becomes wet, wipe it with dry cloth as soon as possible.
• Ifaforeignsubstanceorwatergetsinyourdisplay,turnthepoweroimmediatelyanddisconnectthepowercord.Then
remove the foreign substance or water, and send the unit to the maintenance center.
• Do not store or use the display in locations exposed to heat, direct sunlight or extreme cold.
• In order to maintain the best performance of your display and ensure a longer lifetime, we strongly recommend using the
display in a location that falls within the following temperature and humidity ranges.

31BDL7531L
2
Environmental absolute ratings
Item Min. Max. Unit
Storage temperature -20 50 °C
Operation temperature -20 45 °C
Storage humidity 10 85 % RH
Operating humidity 10 80 % RH
• LED display temperature need to be 25 degrees Celsius at all time for better luminance performance.
• Onlythelifetimeofthedisplaystatedinthisspecicationisguaranteedifthedisplayisusedundertheproperoperation
conditions.
IMPORTANT: Always activate a moving screen saver program when you leave your display unattended. Always activate a periodic
screen refresh application if the unit will display unchanging static content. Uninterrupted display of still or static images over an
extended period may cause inconsistent display performance
Service:
• ThecabinetandLEDmodulesshouldbeinstalledorremovedonlybyqualiedservicepersonnel.
• If there is any need for repair or integration, please contact your local service center.
• Do not leave your display under direct sunlight.
If your display does not operate normally, having followed the instructions set out in this document, please contact
a technician or your local service center.
Stability Hazard.
Thedevicemayfall,causingseriouspersonalinjuryordeath.Topreventinjury,thisdevicemustbesecurelyattachedtotheoor/
wall in accordance with the installation instructions.
IEC/EN 62368: A product may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided
by taking simple precautions such as:
• ALWAYS use cabinets or stands or installation methods recommended by the manufacturer of the product set.
• ALWAYS use furniture that can safely support the product.
• ALWAYS ensure the product is not overhanging the edge of the supporting furniture.
• ALWAYS educate children about the dangers of climbing on furniture to reach the product or its controls.
• ALWAYS route cords and cables connected to your product so they cannot be tripped over, pulled or grabbed.
• NEVER place a product in an unstable location.
• NEVER place the product on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the
product to a suitable support.
• NEVER place the product on cloth or other materials that may be located between the product and supporting furniture.
• NEVER place items that might tempt children to climb, such as toys and remote controls, on the top of the product or furniture
on which the product is placed.
If the existing product is going to be retained and relocated, the same considerations as above should be applied.

31BDL7531L
3
Read and follow these instructions when connecting and using your display:
• Unplug the display if you are not going to use it for an extensive period of time.
• Unplug the display if you need to clean it with a slightly damp cloth. The screen many be wiped with a dry cloth
whenthepoweriso.However,neverusealcohol,solventsorammonia-basedliquids.
• Consult a service technician if the display does not operate normally when you have followed the instructions in
this manual.
• ThecabinetandLEDmodulesshouldbeinstalledorremovedonlybyqualiedservicepersonnel.
• Keep the display out of direct sunlight and away from stoves or any other heat sources.
• Remove any object that could fall into the vents or prevent proper cooling of the display’s electronics.
• Do not block the ventilation holes on the cabinet.
• Keep the display dry. To avoid electric shock, do not expose it to rain or excessive moisture.
• WhenturningothedisplaybydetachingthepowercableorDCpowercord,waitfor6secondsbeforere-
attaching the power cable or DC power cord for normal operation..
• To avoid the risk of shock or permanent damage to the set do not expose the display to rain or excessive
moisture.
• When positioning the display, make sure the power plug and outlet are easily accessible.
• If provided with a 3-pin attachment plug on the power cord, plug the cord into a grounded (earthed) 3-pin
outlet. Do not disable the power cord grounding pin, for example, by attaching a 2-pin adapter. The grounding
pin is an important safety feature.
EU Declaration of Conformity
ThisdevicecomplieswiththerequirementssetoutintheCouncilDirectiveontheApproximationoftheLawsoftheMember
States relating to Electromagnetic Compatibility (2014/30/EU), Low-voltage Directive (2014/35/EU), RoHS directive (2011/65/EU).
ThisproducthasbeentestedandfoundtocomplywiththeharmonizedstandardsforInformationTechnologyEquipment,these
harmonizedstandardspublishedunderDirectivesofOcialJournaloftheEuropeanUnion.
ESD Warnings
WhenuserclosetothemonitormaycausetheequipmentdischargeandreboottothedisplayofmainmenuwhileUSBmediais
playing.
Warning:
ThisequipmentiscompliantwithClassAofEN55032/CISPR32.Inaresidentialenvironmentthisequipmentmaycauseradio
interference.
Federal Communications Commission (FCC) Notice (U.S. Only)
NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevice,pursuantto
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
whentheequipmentisoperatedinacommercialenvironment.Thisequipmentgenerates,uses,andcanradiate
radiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructionmanual,maycause
harmfulinterferencetoradiocommunications.Operationofthisequipmentinaresidentialareaislikelytocause
harmfulinterferenceinwhichcasetheuserwillberequiredtocorrecttheinterferenceathisownexpense.
Changesormodicationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser’s
authoritytooperatetheequipment.
Use only an RF shielded cable that was supplied with the display when connecting this display to a computer device.
Topreventdamagewhichmayresultinreorshockhazard,donotexposethisappliancetorainorexcessivemoisture.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Envision Peripherals Inc.
490 N McCarthy Blvd, Suite #120
Milpitas, CA 95035
USA

31BDL7531L
4
Polish Center for Testing and Certication Notice
Theequipmentshoulddrawpowerfromasocketwithanattachedprotectioncircuit(athree-prongsocket).Allequipmentthat
works together (computer, display, printer, and so on) should have the same power supply source.
The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a
fuse with a nominal value no larger than 16 amperes (A).
Tocompletelyswitchotheequipment,thepowersupplycablemustberemovedfromthepowersupplysocket,whichshouldbe
locatedneartheequipmentandeasilyaccessible.
Aprotectionmark“B”conrmsthattheequipmentisincompliancewiththeprotectionusagerequirementsofstandardsPN-93/
T-42107 and PN-89/E-06251.
Electric, Magnetic and Electromagnetic Fields (“EMF”)
1. We manufacture and sell many products targeted at consumers, which, like any electronic apparatus, in general have the
ability to emit and receive electromagnetic signals.
2. One of our leading Business Principles is to take all necessary health and safety measures for our products, to comply with all
applicablelegalrequirementsandtostaywellwithintheEMFstandardsapplicableatthetimeofproducingtheproducts.
3. Wearecommittedtodevelop,produceandmarketproductsthatcausenoadversehealtheects.
4. Weconrmthatifitsproductsarehandledproperlyfortheirintendeduse,theyaresafetouseaccordingtoscienticevidence
available today.
5. We play an active role in the development of international EMF and safety standards, enabling us to anticipate further
developments in standardization for early integration in its products.

31BDL7531L
5
Information for U.K. only
(A)
(B)
WARNING - THIS APPLIANCE MUST BE EARTHED.
Important:
This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this
type of plug proceed as follows:+
1. Remove fuse cover and fuse.
2. Fit new fuse which should be a BS 1362 5A,A.S.T.A. or BSI approved type.
3. Retthefusecover.
Ifthettedplugisnotsuitableforyoursocketoutlets,itshouldbecutoandan
appropriate3-pinplugttedinitsplace.
If the mains plug contains a fuse, this should have a value of 5A. If a plug without a
fuse is used, the fuse at the distribution board should not be greater than 5A.
NOTE: The severed plug must be destroyed to avoid a possible shock hazard should it
be inserted into a 13A socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured in accordance with the following code:
BLUE - “NEUTRAL” (“N”)
BROWN - “LIVE” (“L”)
GREEN & YELLOW - “EARTH” (“E”)
1. The GREEN & YELLOW wire must be connected to the terminal in the plug which is
marked with the letter “E” or by the Earth symbol or coloured GREEN or GREEN &
YELLOW.
2. The BLUE wire must be connected to the terminal which is marked with the letter “N”
or coloured BLACK.
3. The BROWN wire must be connected to the terminal which marked with the letter “L”
or coloured RED.
Before replacing the plug cover, make certain that the cord grip is clamped over the
sheath of the lead - not simply over the three wires.
North Europe (Nordic Countries) Information
Placering/Ventilation
VARNING:
FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS.
Placering/Ventilation
ADVARSEL:
SØRG VED PLACERINGEN FOR, AT NETLEDNINGENS STIK OG STIKKONTAKT ER NEMT TILGÆNGELIGE.
Paikka/Ilmankierto
VAROITUS:
SIJOITALAITESITEN,ETTÄVERKKOJOHTOVOIDAANTARVITTAESSAHELPOSTIIRROTTAAPISTORASIASTA.
Plassering/Ventilasjon
ADVARSEL:
NÅR DETTE UTSTYRET PLASSERES, MÅ DU PASSE PÅ AT KONTAKTENE FOR STØMTILFØRSEL ER LETTE Å NÅ.

31BDL7531L
6
China RoHS
根据中国大陆《电器电子产品有害物质限制使用管理办法》，以下部分列出了本产品中可能包含的有害
物质的名称和含量。
部件名称
有害物质
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr (VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
铁框 O O O O O O
发光二极管 X O O O O O
电路板组件* X O O O O O
电源线 X O O O O O
其他线材 X O O O O O
本表格依据SJ/T 11364 的规定编制。
*: 电路板组件包括印刷电路板及其构成的零部件，如电阻、电容、集成电路、连接器等。
O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572规定的限量要求以下。
X: 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。
上表中打“X”的部件，应功能需要，部分有害物质含量超出GB/T 26572规 定 的 限 量 要 求 ，但 符 合 欧 盟
RoHS法规要求（属于豁免部分）。
备注：上表仅做为范例，实际标示时应依照各产品的实际部件及所含有害物质进行标示。
10 环保使用期限
此标识指期限 (十年 )，电子电气产品中含有的有害物质在正常使用的条件下不会发生外泄或突变，电
子电气产品用户使用该电子电气产品不会对环境造成严重污染或对其人身、财产造成严重损害的期限。
《废弃电器电子产品回收处理管理条例》提示性说明
为了更好地关爱及保护地球，当用户不再需要此产品或产品寿命终止时，请遵守国家废弃电器电子产品
回收处理相关法律法规，将其交给当地具有国家认可的回收处理资质的厂商进行回收处理，不当利用或
者处置可能会对环境和人类健康造成影响。
警告
此为 A级产品。在生活环境中，该产品可能会造成无线电干扰。在这种情况下，可能需要用户对
干扰采取切实可行的措施。

31BDL7531L
7
單元
限用物質及其化學符號
鉛
(Pb)
汞
(Hg)
鎘
(Cd)
六價鉻
(Cr+6)
多溴聯苯
(PBB)
多溴二苯醚
(PBDE)
鐵框 ○ ○ ○ ○ ○ ○
發光二極管 － ○ ○ ○ ○ ○
電路板組件 － ○ ○ ○ ○ ○
電源線 － ○ ○ ○ ○ ○
其他線材 － ○ ○ ○ ○ ○
備考1.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
備考2.〝－〞係指該項限用物質為排除項目。
警語 : 使用過度恐傷害視力。
注意事項 :
(1) 使用30分鐘請休息10分鐘。
(2) 未滿2歲幼兒不看螢幕，2歲以上每天看螢幕不要超過1小時。
警告使用者 :
此為甲類資訊技術設備 , 於居住環境中使用時 , 可能會造成射頻擾動 , 在此種情況下 , 使用者會被
要求採取某些適當的對策。
Turkey RoHS:
TürkiyeCumhuriyeti:EEEYönetmeliğineUygundur
Ukraine RoHS:
ОбладнаннявідповідаєвимогамТехнічногорегламентущодообмеженнявикористаннядеякихнебезпечнихречовинв
електричномутаелектронномуобладнанні,затвердженогопостановоюКабінетуМіністрівУкраїнивід3грудня2008№
1057
End-of-Life Disposal
Your new Public Information Display contains materials that can be recycled and reused. Specialized companies can recycle your
product to increase the amount of reusable materials and to minimize the amount to be disposed of.
PleasendoutaboutthelocalregulationsonhowtodisposeofyourolddisplayfromyourlocalPhilipsdealer.
(For customers in Canada and U.S.A.)
This product may contain lead and/or mercury. Dispose of in accordance to local-state and federal regulations. For additional
information on recycling contact www.eia.org (Consumer Education Initiative)
Waste Electrical and Electronic Equipment-WEEE
Attention users in European Union private households
This marking on the product or on its packaging illustrates that, under European Directive 2012/19/EU governing
used electrical and electronic appliances, this product may not be disposed of with normal household waste. You
areresponsiblefordisposalofthisequipmentthroughadesignatedwasteelectricalandelectronicequipment
collection.Todeterminethelocationsfordroppingosuchwasteelectricalandelectronic,contactyourlocal
governmentoce,thewastedisposalorganizationthatservesyourhouseholdorthestoreatwhichyoupurchased
the product.

31BDL7531L
8
Attention users in United States:
Please dispose of according to all Local, State and Federal Laws. For the disposal or recycling information, contact:
www.mygreenelectronics.com or www.eiae.org.
End of Life Directives-Recycling
Your new Public Information Display contains several materials that can be recycled for new users.
Please dispose of according to all Local, State, and Federal laws.
Restriction on Hazardous Substances statement (India)
This product complies with the “E-Waste (Management) Rules, 2016” CHAPTER V, rule 16, sub-rule (1) . Whereas New Electrical
andElectronicEquipmentandtheircomponentsorconsumablesorpartsorsparesdonotcontainLead,Mercury,Cadmium,
Hexavalent Chromium, polybrominated biphenyls and polybrominated diphenyl ethers beyond a maximum concentration value of
0.1% by weight in homogenous materials for lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated
diphenyl ethers and of 0.01% by weight in homogenous materials for cadmium. except of exemptions set in Schedule 2 of the
Rule.
E-Waste Declaration for India
This symbol on the product or on its packaging indicates that this product must not be disposed of with your
otherhouseholdwaste.Insteaditisyourresponsibilitytodisposeofyourwasteequipmentbyhandingitover
toadesignatedcollectionpointfortherecyclingofwasteelectricalandelectronicequipment.Theseparate
collectionandrecyclingofyourwasteequipmentatthetimeofdisposalwillhelptoconservenaturalresources
and ensure that it is recycled in a manner that protects human health and the environment. For more information
about E -waste please visit http://www.india.philips.com/about/sustainability/recycling/index.page and to
knowwhereyoucandropoyourwasteequipmentforrecyclinginIndiapleasecontactonbelowgivencontact
details.
Helpline number: 1800-425-6396 (Monday to Saturday, 9 a.m. to 5:30 pm)
E-mail: [email protected]
Batteries
For EU: The crossed-out wheeled bin implies that used batteries should not be put to the general household
waste! There is a separate collection system for used batteries, to allow proper treatment and recycling in
accordance with legislation.
Please contact your local authority for details on the collection and recycling schemes.
For Switzerland: The used battery is to be returned to the selling point.
For other non-EU countries: Please contact your local authority for correct method of disposal of the used battery.
According to EU directive 2006/66/EC, the battery can’t be disposed improperly. The battery shall be separated to collect by local
service.
Após o uso, as pilhas
deverão ser entregues ao
estabelecimento comercial ou
e/ou baterias
rede de assistência técnica
autorizada.

31BDL7531L
9
Information for EAC
Month and year of manufacturing please refer information in Rating label.
Name and location of manufacturer ООО“Профтехника”
Адрес:3-йПроездМарьинойрощи,40/1офис1.Москва,127018,Россия
Importer and information
Наименованиеорганизации:ООО“Профтехника”
Адрес:3-йПроездМарьинойрощи,40/1офис1.Москва,127018,Россия
Контактноелицо:НатальяАстафьева,
[phone]
[e-mail]
Cleaning
IftheLEDdisplay/cabinetbecomesdusty,useanairblowerwhichcanproduceairowtoblowawaydust.
Cautions when cleaning the display:
Do not use a wet cloth to clean the LED display.
DonotallowwaterorotherliquidtoentertheLEDdisplay.
Do not use tool that generate large amount of static electricity, such as a bristle brush.
ThefrontoftheLEDdisplayhasbeenspeciallytreated.DonottouchthesurfaceoftheLEDdisplaywithngernailsoranyhard
object,otherwisetheLEDelementsmayfallo.
Storage
If you are not going to use it for an extensive period of time, unplug the display and keep the product in a dry and well-ventilated
location.

31BDL7531L
10
2. Preparations
2.1. Unpacking
Warning:
To prevent damage to the LED panel, wear anti-static gloves before installing/touching the display.
Afterunpacking,donotplacethedisplayverticallyontheoor,anaccidentsuchasfallmaybecaused.
1. Use a pair of scissors to cut sealing tape on the cardboard box.
2. Carefully take the cabinet and accessories out of the cardboard box.
3. After opening the cardboard box, ensure that the contents are complete and in good condition.
2.2. Package Contents
Please verify that you received the following items with your package content:
• LED display
• Quick start guide
• Power cable (daisy chain)
• LANcable(RJ45,CAT-5)
Quick start guideLED display
Power cable
(daisy chain)
LAN cable
(RJ45, CAT-5)
Professional
DisplaySolutions
LL ine
*Displaydesignandaccessoriesmaydierfromthoseillustratedabove.
NOTES:
• For all other regions, apply a power cord that conforms to the AC voltage of the power socket and has been approved by and
complies with the safety regulations of the particular country.
• You might like to save the package box and packing material for shipping the display.

31BDL7531L
11
2.3. Holding the cabinet
Warning:
To prevent damage to the LED, do NOT touch the edge of each LED module when holding the cabinet by hand.
Refer to the illustration below for the recommended manner of holding a cabinet.
2.4. Installation Notes
• Onlyusethepowercableprovidedwiththisproduct.Ifanextensioncordisrequired,pleaseconsultyourserviceagent.
• Theproductshouldbeinstalledonaatsurface,ortheproductmaytipover.Leaveaspacebetweentherearoftheproduct
and the wall for proper ventilation. Do not install the product in a kitchen, bathroom or a place exposed to moisture, failure to
do so may shorten the life of the internal parts.
• Do not install the product where it is 5000m and higher in altitude. Failure to do so may result in malfunctions.

31BDL7531L
12
3. Product overview
3.1. Front view
23
1
1
3.2. Rear view
4
3.3. Side view
Left side Right side
3.4. Top view
3.5. Bottom view
No. Component No. Component
Data connector (s) Power Out connector
Power In connector CHECK button
The Data connector ( )isanRJ45connector,butitcannotbeconnectedwithanetworkswitchorcommoncomputer
networking device as it is not compatible.

31BDL7531L
13
4. Preparation
4.1. Testing the cabinet
1. Power on the product by connecting the power cable from the cabinet to the power outlet.
2. Press the CHECK button on the back of each cabinet to check if the product can operate normally.
3. Check whether each color is displayed normally on the screen from the front side of the display.
21
Totestthecabinet,apowercablethatconnectsfromthecabinettothepoweroutletisrequired(butnotprovided).
4.2. Removing the opening
Before breaking the opening, determine the number of displays to install and the installation layout to form a large video wall
array.

31BDL7531L
14
5. Installation
Precautions when handling the cabinets:
• Do not drop or apply shock/vibration to the product. Strong impacts may damage the component inside.
• Onlyaqualiedservicetechnicianshouldperforminstallation.
• Only use approved cabinets.
• Be careful not to damage the corners of the cabinet.
• Install the display in a well-ventilated area.
• Always wear anti-static gloves when touching the display.
• Provide air conditioning around the LED display to allow heat dissipation away from the display.
• To maintain proper ventilation, keep clear space from the mounted displays to the wall. (Refer to the diagram below for the
recommended distance between the LED display and wall). Installing the product in poorly ventilated spaces may damage the
LED.
A wall mount kit (in some regions sold separately or available from third party vendors) allows you to mount the LED display on
the wall. For detailed information on installing the wall mount, see the instructions provided with the wall mount. Wall mounting
can only be performed from the front side of cabinets.
*
Not included
*
*
Optional accessory
CTN: BM907009
The mounting interface should be strong enough to bear the weight of the display. Ensure that your wall mount bracket has
the mounting holes accurately drilled at proper position.

31BDL7531L
15
Step 1.
Start your installation from the bottom row. Insert the connecting plate with screw bolt into the mounting hole on the bracket.
Rotatethehexkeyclockwiseuntilthescrewboltsarermlyfastened.
T style inner hexagon
wrench, size 7
*
Not included
*
Optional accessory
CTN: BM907001
Optional accessory
CTN: BM907005
Step 2.
Move up to install the next row. Install the connecting plates on the bracket. Rotate the hex key clockwise until the screw bolts
are inserted. Do not tighten the screw bolts yet, as this will cause unevenness of the connecting plates.

31BDL7531L
16
Step 3.
Align the cabinet with the connecting plate and secure the cabinet to the holes on the connecting plate. Rotate the hex key
clockwise until the screw bolts are inserted. Do not over tighten the screw bolts yet as you may need to adjust the connecting
plates again.
Step 4.
Tighten the screw bolts (
1
). Move up to install the next row. Install the connecting plates on the bracket. Rotate the hex key
clockwise until the screw bolts are inserted (
2
). Do not tighten the screw bolts yet, as this will cause unevenness of the connecting
plates.
2
1

31BDL7531L
17
Step 5.
When mounting two cabinets one on top of the other, hold the cabinet at both side edges and slide it down vertically. If the
cabinet seems to be tilting to one side, adjust it until the display becomes level.
Step 6.
Align the second cabinet with the connecting plate and secure the cabinet to the holes on the connecting plate. Rotate the hex
key clockwise until the screw bolts are inserted. Do not over tighten the screw bolts yet as you may need to adjust the connecting
plates again.

31BDL7531L
18
Step 7. (for 90° angle installation)
Tighten the screw bolts (
1
).Repeattheabovestepsuntilallcabinetsaremountedontothebracket.Adjusttheatnessofthe
LED display (if necessary). Firmly tighten the screw bolts to secure the cabinets to the mounting bracket (
2
).
2
1
Step 8. (for 180° angle installation)
For 180° angle installation, appropriate clearance between two cabinets must be considered. Follow the installation steps below.
Tighten the screw bolts (
1
). Repeat the above steps until all cabinets are mounted onto the bracket.
Use the feeler gauges to ensure accurate gap is reserved between the cascaded cabinets. Insert 2 pieces of 1mm feeler gauge into
the gap between two parts as illustrated below (
2
).
The feeler gauges are not provided with the product.
AdjusttheatnessoftheLEDdisplay(ifnecessary).Firmlytightenthescrewboltstosecurethecabinetstothemountingbracket(
3
).
After installation is complete, pull out the feeler gauges.
1
3
0.5 mm1 mm 2
1mm
Forinstallationoftwotypesofcabinetswithdierentsideangles(e.g.,xxBDL7531LandxxBDL7431L),usethe0.5mmfeeler
gauge to keep clearance between two cabinets.
