Philips Optispace BCB500 User manual

Disconnect before servcing
Me re hors tension avant interven on
O en nur apsnnungsfrei
Demonterem voor onderhoud
Togliere tensione prima di fare manutencione
Desconectar antes de manipular
Bryt strömmen fore lampbyte
RG1
Op space
BCB500
ø
If the external fl exible cable or cord of this luminaire is damaged, it shall
be exclusively replaced by the manufacturer or his service agent or a
similar qualifi ed person in order to avoid a hazard.

OPTIC Inrush
current
Maximun num-
ber luminaires
per MCB16A
type B
BCB500
740 LED16-4S 9 A 1450 12,3 +50˚C -40˚C +50˚C 15A / 360µs 23 16
740 LED27-4S 9 A 2390 20 +50˚C -40˚C +50˚C 15A / 360µs 23 16
740 LED38-4S 9 A 3320 28,5 +50˚C -40˚C +50˚C 15A / 360µs 23 16
740 LED27-4S 23 S 2360 17,7 +50˚C -40˚C +50˚C 22A / 282µs 20 16
740 LED56-4S 23 S 4900 37,3 +50˚C -40˚C +50˚C 22A / 282µs 20 16
830 LED16-4S 9 A 1420 14,7 +50˚C -40˚C +50˚C 15A / 360µs 23 16
830 LED25-4S 9 A 2150 21,9 +50˚C -40˚C +50˚C 15A / 360µs 23 16
830 LED35-4S 9 A 3010 29,9 +50˚C -40˚C +50˚C 15A / 360µs 23 16
830 LED27-4S 23 S 2290 20,4 +50˚C -40˚C +50˚C 22A / 282µs 20 16
830 LED56-4S 23 S 4740 44,3 +50˚C -40˚C +50˚C 22A / 282µs 20 16
Mains /Control Connec on
Note: L80B10 life me (100000 h) is valid for 25°C
1

Off set installa on on nuts is permi ed as long
as the space under the foot plate is fi lled using
a non-shrink grou ng space mortar.
Le montage décalé sur écrous est toléré á
la seule condi on que l’espace libre sous la
semelle soit comblé à l’aide d’un mor er de
bourrage sans retrait.
Se permite el montaje decalado sobre tuercas
siempre y cuando el espacio libre debajo de la
zapata sea rellenado con un mortero de relleno.
Use the M8 screw and washer supplied
in a bag to connect to earth the tube.
23
45
45 mm min
6a
Ground base tube connec on Class I Turn Bollard to ver cal posi on
Base placement indica on Minimum anchor bolt length
out of founda on
Instala on on nuts
Leveling of the washers Placing the base plate
22
70
M14

Install the broad based ligh ng tube directly
to the founda on (concrete pedestal) which
sholud be smooth, fl at and horizontal.
Installer le bolard á semelle directement sur
la fonda on (massif béton) qui doit être lisse,
plate et horizontale.
Instalar la placa de la baliza directamente sobre
la cimentación (zapata) que debe estar lisa,
plana y horizontal.
6b
Leveling of founda on Placing the base plate
Instala on on founda on
22
70
7Instala on with EMBEDDED TUBE
Place tubes, screws M14,
washers and nuts M14
22
70
ZCB500 TUBE L500
