Philips AE2330/00 User manual

Register your product and get support at
EN User manual
AE2330

1
32
a
b
cf
e
d
+
__
+
_
+
+
_
+
_
+
_

English
1 Important
Safety
Important Safety Instructions
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eClean only with dry cloth.
fDo not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
g Only use attachments/accessories specied by the manufacturer.
h Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way.
i Battery usage CAUTION – To prevent battery leakage which
may result in bodily injury, property damage, or damage to
the unit:
Install all batteries correctly, + and - as marked on the unit.•
Do not mix batteries (old and new or carbon and alkaline, etc.).•
Remove batteries when the unit is not used for a long time.•
jDo not place any sources of danger on the apparatus (e.g. liquid
lled objects, lighted candles).

Notice
This product complies with the radio interference requirements of
the European Community.
Anychangesormodicationsmadetothisdevicethatarenot
expressly approved by Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Recycling
Your product is designed and manufactured with high quality materials
and components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a
product, it means the product is covered by the European Directive
2002/96/EC:
Never dispose of your product with other household waste. Please
inform yourself about the local rules on the separate collection of
electrical and electronic products. The correct disposal of your old
product helps prevent potentially negative consequences on the
environment and human health.
Your product contains batteries covered by the European Directive
2006/66/EC, which cannot be disposed of with normal household
waste.

When you see the crossed-out wheel bin symbol with the chemical
symbol ‘Pb’, it means that the batteries comply with the requirement
set by the directive for lead:
Please inform yourself about the local rules on separate collection of
batteries. The correct disposal of batteries helps prevent potentially
negative consequences on the environment and human health.
Environmental information
All unnecessary packaging has been omitted. We have tried to make
the packaging easy to separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags, protective foam
sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.
Norge
Typeskiltnnespåapparatensunderside.
Observer: Nettbryteren er sekundert innkoplet. Den innebygde
netdelenerderforikkefrakopletnettetsålengeapparateter
tilsluttet nettkontakten.
Foråreduserefarenforbrannellerelektriskstøt,skalapparatetikke
utsettes for regn eller fuktighet.
2 Your Bathroom Radio
Congratulations on your purchase, and welcome to Philips!To fully
benetfromthesupportthatPhilipsoffers,registeryourproductat
www.philips.com/welcome.

Introduction
With this unit, you can:
know the time•
listen to FM/MW radio stations•
What’s in the box
Check and identify the contents of your package:
Main unit•
User manual•
Overview of the main unit 1
a/VOL
Turn on/off radio.•
Adjust volume.•
Scan and store radio stations automatically.•
Tune to the previous/next radio station.•
Select the previous/next preset radio station.•
Adjust hour/minute digits.•
bTIMER/BAND
Set time.•
Activate or deactivate timer.•
Select FM or MW band.•
cTUNE/PRESET
Tune to a radio station.•
Program preset radio stations.•
dAntenna
Improve radio reception.•
eDisplay panel

Show the time/radio information.•
f+/-
Select the previous/next preset radio station.•
Adjust hour/minute digits.•
3 Get started
Caution
Use of controls or adjustments or performance of procedures other•
than herein may result in hazardous radiation exposure or other unsafe
operation.
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number
of this apparatus.The model number and serial number are on the
bottom of the apparatus.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Install battery 2
Caution
Riskofexplosion!Keepbatteriesawayfromheat,sunshineorre.•
Neverdiscardbatteriesinre.
Risk of product damage! When the apparatus is not used for long
•
periods, remove the battery.
Batteries contain chemical substances, so they should be disposed
•
of properly.

1Open the battery compartment.
2Insert 3 AA batteries (not supplied) with correct polarity (+/-)
as indicated.
3Close the battery compartment.
Placement 3
Youcanplacetheunitonaatsurfaceorhangitinyourbathroom
through the strap.
Tip
The strap is detachable.•
Set time
1Press to turn off the radio.
2Press and hold TIMER/BAND.
The hour digits begin to blink.»
3Press +/- to set the hour.
4Press TIMER/BANDtoconrm.
The minute digits begin to blink.»
5Press +/- to set the minute.
6PressTIMER/BANDtoconrm.
Turn on
1Press to turn on the radio.

4 Listen to radio
Select FM/MW band
1Press to turn on the radio.
2Press and hold TIMER/BAND to switch between FM/MW band.
Tune to a radio station
1Press to turn on the radio.
2Press TUNE/PRESET to start tuning.
»[FM] or [MW] begins to blink.
3Rotate clockwise or counter-clockwise to tune to a radio
station.
4Press TUNE/PRESETagaintoconrm.
Program radio stations automatically
Note
You can program a maximum of 20 preset FM radio stations and•
20 preset MW radio stations.
1Press to turn on the radio.
2Press and hold for 2 seconds.
All available stations are programmed in the order of waveband»
reception strength.
Therstprogramedradiostationbroadcastsautomatically.»

Program radio stations manually
Note
You can program a maximum of 20 preset FM radio stations and•
20 MW radio stations.
1Press to turn on the radio.
2Tune to a radio station.
3Press and hold TUNE/PRESET.
The number begins to blink.»
4Rotate clockwise or counter-clockwise to select a preset
number.
5Press TUNE/PRESETtoconrm.
6Repeat steps 2 - 5 to program more stations.
Tip
To overwrite a programmed station, program another station in its•
place.
Select a preset radio station
1Press to turn on the radio.
2Press +/- to select a preset radio station.
Set the sleep timer
You can set the clock radio to turn off automatically after a certain
period of time.

1Press TIMER/BAND repeatedly to select time (in minutes).
The apparatus turns off automatically after the set period of»
time.
To turn off the sleep timer:
1Press TIMER/BANDrepeatedly until [OFF] (off) appears or
press .
»is displayed when sleep timer is on and disappears when
it is off.
5 Product information
Note
Product information is subject to change without prior notice.•
Tuner
Tuning range FM: 87.5 - 108 MHz
MW: 531 - 1602 kHz
Tuning grid 50 KHz (FM); 9 KHz (MW)
Number of presets FM: 20
MW: 20
General

Power supply 3 x AA battery
Maximum power output 300 mW
Operation Power Consumption 100 mW
Dimensions
- Main Unit (H x W x D) 155 x 89 x 62 mm
Weight
- With Packing
- Main Unit
0.41 kg
0.25 kg
6 Troubleshooting
Warning
Never remove the casing of this apparatus.•
To keep the warranty valid, never try to repair the system yourself.
If you encounter problems when using this apparatus, check the
following points before requesting service. If the problem remains
unsolved, go to the Philips web site (www.philips.com/welcome).When
you contact Philips, ensure that the apparatus is nearby and the model
number and serial number are available.
No power
Ensure that the battery is installed properly.•
Replace the exhausted battery.•
Timer does not work
Set the clock correctly.•
Switch on the timer.•
No sound
Adjust the volume.•

Clock/timer setting erased
Replace the exhausted battery.•
Reset the clock/timer.•
No response from the unit
Take out the batteries and turn on the unit again.•

© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
AE2330_00_UM_V2.0
