Philips MX990DHT User manual

• Just add a TV to upgrade into a complete Digital Home Cinema System
• 550 Watts Surround Power output
• 5 x 100 Watts Dolby Digital Receiver
• 6 Speaker Package with 50 Watts Subwoofer and 5 compact
2-way satellite loudspeakers
• Discrete Dual Laser DVD-Video Player
• 10 Audio input connections in total
• 3 Digital input, 1 digital output connector (for CD recording)
• 6 channel input terminal
• Digital Sound Processing via DUET Core
• 5 S-Video connections
• 3 video input, 2 video output connectors
• Screw Terminal for main speaker (L, R, C) connection
• Menu Navigator Rotary knob for quick set-up
• 51-key Audio/Video Multibrand Universal Remote Control
• DVD-Video, Video CD, CD, CD-R and CD-RW playback
• Advanced Parental Approval System with Disc Lock
• Perfect Still Picture with Multiple Zoom
Digital Audio/Video Surround Sound Package
MX990D
MX990D
S
VIDEO
P
r
e
l
i
m
i
n
a
r
y
P
r
o
d
u
c
t
D
a
t
a

MX990D
MX990D
Sound Enhancement
Dolby Digital Surround Sound - Available on DVD,
Laserdisc*, satellite broadcasts, Cable and as the standard for
HDTV, Dolby Digital® offers the ultimate experience in home
theater surround with six discrete channels of digital CD sound.
Discrete means that each channel carries its own sound and
depending on what happens on screen each speaker plays its
own unique role in providing the right sound. Front left, center
and right join two surround speakers to reproduce highs, mid
and bass frequencies in five full-range channels of surround. Bass
rumble, explosions and low frequency effects you feel are
delivered through a dedicated sixth, subwoofer channel. Also
known as AC-3 and Dolby 5.1, Dolby Digital® delivers the
expanded sense of depth, localization and overall realism which
was formerly only known from digital surround sound equipped
cinemas.
6-speaker package - No less then 5 compact 2-way satellite
loudspeakers to build your personal cinema on a stand or wall-
mounted with the enclosed wall-brackets.The five speakers are
acoustically specially designed to match the tonal characteristics
of the receiver. Front left, right and center speaker are
magnetically protected to prevent any interference with television
picture tube purity. The sixth speaker is a 50 watt powered
subwoofer.
550W surround power output - The five, 3 x 100W (left,
right, center) and 2 x 100W (rear), receiver amplifiers together
with the 50W subwoofer amplifier deliver 500 Watts of home
theater power.The stereo output power of 100W per channel is
specified at 6 Ohm, 40Hz-20KHz and 0.7% total harmonic
distortion (THD).The amplifiers have been designed with special
attention to a short 'rise' and 'fall' time, so characteristic for the
frequent and sudden drastic changes in dynamics of movie sound
in general. Furthermore, the amplification reserves are designed
such that they are more than sufficient to follow sudden needs
for more sound pressure.
50 W powered subwoofer - Subwoofers add dynamism to
normal music and motion pictures. It sets the stage for a more
intense sensation.The 50W Philips subwoofer features a down-
firing 61/2" woofer to reflect sound waves off the floor, thereby
adding impact. In all, the subwoofer is sufficiently power packed
to generate that cinema essential sonic sound boom.
Digital Sound Processing via DUET CORE - Philips
Semiconductors is highly specialized in digital sound processing.
One of their crown DSP (digital sound processing) ICs is the
'DUET'.The DUET's huge processing power of 80 MIPS (million
instructions per second) assures the highest possible accuracy in
digital audio processing. Other characteristics are automatic
detection of source (AC-3, MPEG or PCM audio) and smooth
(clicking free) automatic switching between coding formats.
Furthermore DUET carries digital bass cross-over filters (for
subwoofer signal) and 3rd generation virtualizer algorithms for
highly realistic virtual Dolby. Lastly, DUET has the unique
capability of translating Dolby Digital multi-channel sound into a
stereo signal suitable for digital recording onto e.g.CD-R.
Virtual 3D Surround / Virtual Dolby® Surround - A
Dolby Surround playback system delivers amazingly rich and
convincing surround sound from only the two (or three) front
speakers. The Pro-Logic or Dolby Digital® surround channel is
processed by a 'virtualizer' DSP to add the surround effect from
just the front speakers. The Philips virtualizer algorithm on the
'DUET' DSP is the current state of the art reference for virtual
surround sound processing.
'Hall' feature - For use with non-surround sound sources in
order to create a cinema effect through normal stereo with rear
speaker sound. This 'simulated' surround provides an extra
musical ('live') ambience to stereo sound.
Equalizer Smart Sound - Has 5 modes, specially designed to
match the sound of variousTV (and Audio) programs. 'Speech' is
used for news, discussions and talk show programs. 'Music' is
used for music programs. 'Movie' is used for movies orTV-series
or soaps. 'Multi-Media' is used when video games are connected
to theTV. 'Personal' corresponds with the bass and treble setting
chosen by the user.
Screw terminals - For left , right and center speaker
connection ensures a loss-less flow of electrical signals from the
set to all main loudspeakers.
Convenience
Digital inputs and output - 3 digital inputs (2 coax, 1 optical)
are foreseen to connect digital sound sources (e.g. DVD player,
CD player and DigitalTV). A digital output connection (coax) is
foreseen to enable digital (CD) recordings from any of the digital
inputs. The output can provide a down-mixed (stereo) DVD
multi-channel sound signal in order to record from DVD to e.g.
CD-R.
Stereo Downmix - The digital output will automatically
provide a stereo downmix in case a multichannel signal is
detected at any of the digital input connectors. In that way digital
audio recordings can be made from movie DVD's (e.g. Live
concerts from music DVD's)
Night mode - Establishes dynamic range compression of digital
sound to reduce the volume differences between the loud and
soft passages in source material with digital surround sound
where sound level differences can be so dramatic.This feature is
especially useful at night when you don't want to disturb the
neighbors or wake up the kids!
Video Connections - 3 video input connections and 2 outputs
(incl. monitor) are foreseen to hook up video sources. As these
video inputs switch simultaneously with the audio inputs, correct
picture with correct sound is guaranteed. All video connections
are both S-Video and composite video.
6 Channel input -Six input selectors at the back of the set
allow to connect to any type of multichannel decorder. Be it DTS,
DVD Audio or Super Audio CD.The 6 Channel input makes your
system future proof!
Easy hook up - With color coded speaker connections for
quick and easy connection of all loudspeakers. By using distinct
colors for each of the speaker connection terminal on the
speaker and on the set, and using the same color for the cable,
the chance of faulty connection (and customer complaints) are
practically zero!
51-key Audio/Video Multi Brand Universal remote
control - To operate all main receiver functions and Philips,
Magnavox or any other mainstream branded CD player, tape
deck,VCR, television and DVD player, Satellite or cable box! The
remote will operate your non-Philips/Magnavox equipment by
simply entering a code from the instruction manual in the remote
control. The remote has a clear ergonomically designed lay-out
(see picture)
30 tuner presets with station name display -The available
tuner presets can be randomly used to store AM and FM stations
(30 in total). Each of the presets can be given a user defined
name of up to 8 characters. Giving the preset a name is as easy
as 1-2-3 with the menu navigator.
Tuner sensitivity adjustment - The tuner sensitivity to pick
up radio stations can be set to high and low. In case of low, only
the 'strong' stations will be picked up during a search.When even
some of the weaker stations are of interest, the 'low' option will
pick up every station the tuner can possibly receive.
Display brightness adjustment - Conveniently adjusts the
brightness of the display in 3 steps.
2 switched mains outlets - Allows to connect another HiFi
component. Switching the receiver to standby will automatically
switch off the connected set.
Standby power <2W -To help save energy consumption, the
standby transformer of this set has been designed not to
consume more than 2Watt in standby mode.
UPC Code :0 3784990 6743
Product Dimensions:
17.2"W x 5.3" H x 13.8" D (receiver)
17.2"W x 3.6" H x 12.6" D (DVD player)
3.8"W x 6.2" H x 3.5" D (l/r,center + surround)
10.0"W x 3.8" H x 3.5" D (center speaker)
7.9"W x 12.2" H x 14.6" D (subwoofer)
Product weight: 20.7 lbs (receiver)
Package Dimensions:
35.5"W x 17.2" H x 19.5" D
Total package weight : 66 lbs
Container loading : 260 pieces
Country of Origin : China
Carton contains: receiver FR968/17, DVD711, 2 remote
controls, batteries, instruction for use, AM + FM antenna,
quick installation card, warrantee information, 6
loudspeakers (incl. subwoofer), loudspeaker cable (L/R:
2x9ft, C: 1x9ft, S: 2x33ft.), subwoofer mains + connection
cable, digital audio cable for DVD connections, 2 CVBS
video cables
Printed in Singapore
Date printed :Aug 2000
©2000 Royal Philips Electronics N.V.
All rights reserved.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Dolby,Dolby Digital®,Dolby ProLogic® and the
double-D symbol are trademarks of Dolby Laboratories
Design
Harmonized Philips Home Cinema Components Design -
The design of this component follows the design language of the
Philips Harmonized Home Cinema design. Characteristics of this
design language are stylish, simple, capable, powerful and rich. All
Philips Home Cinema components and HiFi components will follow
this design (e.g.VCR, CD Changer,CD Recorder DVD, etc).
Display - Color and graphic/character size are defined such that at
visibility remains clear even at larger distances.
Connections
• Audio inputs/outputs 7 analogue input sources,
3 analogue output connections
- Phono :in
- CD :in
- CDR/Tape :in/out
- TV : in
-SAT :in
- VCR : in/out
- 6 CH/DVD :in
- DVD :see digital audio inputs/outputs
- Headphone : 6.3mm
• Digital audio in/output 3 digital input sources,
1 digital output connection
- 2 digital coax connections: :in
- 1 optical slink to connection : in
- 1 digital coax connection :out
• Video inputs/outputs 3 input sources,
2 output connections
- DVD :in (S-VHS + CVBS)
- SAT :in (S-VHS + CVBS)
- VCR : in/out (2 x S-VHS + CVBS)
- Monitor :out (S-VHS + CVBS)
• Speaker Connections suitable for speakers ≥6 Ohm
- left,right,center :screw type connection
- rear left,right :click-fit connection
• Miscellaneous connections
- Cinema Link System control bus
- subwoofer pre-out : 1
- center pre-out : 2
- mains outlet :switched 2x
- AM antenna :loop type
- FM antenna :click-fit 300 Ohm
* Dolby Digital laserdisc use requires optional AC-3 RF demodulator
As an ENERGY STAR® Partner, Philips has determined that this product
meets the ENERGY STAR® guidelines for energy efficiency.
13
2
4
DVD
2
H
AA
TV
Ç
É
MENU OK
GUIDE
NEWS/TA
5
13
2
46
79
8
0
MUTE
TUNER CD CDR/TAPE
DVD
SAT
VCR
TV
PHONO
CABLE BOXCINEMA
Home Cinema Control
Multibrand/Universal
REC CANCEL FR.D. INDEX
íë
CHANNEL/TRACK LOUDNESS
VIRTUALNIGHT
DISC MODE
MODE
SURROUND
SURROUND
SUBW.
T-C
Å
+
-
+
-
REAR
CHANNEL
SUB WOOFER TEST TONE
ON/
OFF
ON/
OFF
AUDIO
