FW C777
FW C777
Connect to great games and excitement
• Gameport connection to your game console
• Game Sound modes for different types of games
• MIX-IT for mixing the game sound with your favorite music
Remote Control your MP3 music on your PC
• USB PC Link
• Song titles from PC on audio system display
Powerful bass you can hear and feel
• 2 x 165W RMS / 330W RMS Total Power
• Front firing wOOx Technology™ Speakers
Navigate with ease
• Animated dashboard display with dual VU meter
Mini Hi-Fi System with 5 CD Tray Changer
Ultimate Gaming Experience with wOOx Technology

remote control physical info
Mini Hi-Fi System with 5 CD Tray Changer
standard product information
game port
•Front game port connection
•Game volume control
•3 game sound modes
(speed,punch & blast)
•MIX-IT
USB PC link
•Bundled MusicMatch Jukebox software
•Track info display
• Navigate via set remote control for Play,
Pause,Stop,Next and Previous track
disc player
•5 CD Changer
•Plays CD,CD-R and CD-RW discs
•40 tracks CD random program
•Play modes (repeat/shuffle/program)
•CD Repeat (track/disc/all)
tuner
• FM/AM DigitalTuning with 40 presets
• Autostore facility
• Plug & Play for easy installation of radio
stations
sound
• wOOxTechnology™ Speaker System for
Deeper Bass
• Digital Sound control
(rock,techno,jazz,optimal)
• VirtualAmbience control
(hall,cinema,arcade,concert,cyber)
• Incredible Surround™
amplifier
• 2 x 165 watts RMS
• 330 watts RMSTotal Power
loudspeaker boxes
• 3 way Bass Reflex speaker system
• 6.5" woofer
• 2" Ferro Fluid tweeter
• 1" Polydome piezo
• 6.5" wOOx Bass Radiator
• Detachable grilles
connections
• Audio InputAnalog :AUX (cinch) & Game
Port
• Audio Input Digital :USB PC Link
• Video Input :composite cinch
• Video Output :composite cinch
• Stereo headphones :3.5mm stereo jack
• Antenna :FM click-fit,AM loop
general
•FTD display
•Dim mode
• Clock,Alarm & Sleep timer
• 32 key Remote Control
•Demo mode
•Eco power standby mode (<1 watt)
•Interactive Dashboard Display with dual
VU meter
FW C777
wOOxTechnology™
Philips patented wOOx Techonolgy ensures superior bass
results. The dual suspension bass radiator, together with
dedicated amplifier circuitry, is especially designed to
produce and handle high dynamic sound signals at very low
frequencies. Because of the dual suspension, the excursion
of the membrane can be extreme (see illustration). This is in
combination with the symmetrical sandwich construction,
provides for very low and precise bass without noticeable
distortion. The net effect of using wOOxTechnology is a tight
bass sound that is significantly "lower and louder" than
conventional mini shelf systems.
3-Step wOOx Level Control
As the human ear does not perceive low frequencies at the
same level as higher frequencies (though at the same
"volume"), the bass sound needs to be enhanced to achieve
maximum impact. The wOOx is progressively driven at
different optimization levels in setting wOOx 1,2 and 3.
Gameport
With the growing demand for game consoles, we will see a
similar increase in the need for a complete entertainment
system that can give enhancement to the sound quality of
games. Gameport allows users to connect their game
console to the Philips Mini Hi-Fi system to enjoy a total
game immersion experience by having powerful sound
output. Through the Game Sound Mode, the user can also
select the type of sound setting to best suit the game
currently on play;i.e.Blast for Explosive and Shooting games;
Punch for games with lots of kicks and punches and Speed
for games which involves high speed driving and flying. The
Game Mix function (MIX-IT) allows users to mix their game
sound to their favorite music from CD, Radio Stations or an
external source such as Portable CD,MP3 Player,etc.
suspension 1suspension 2
excursion 1
excursion 2
excursion 2
excursion 1
wOOxTechnology
double suspension = double excursion
AUX/GAME
TITLE
USB PC LINK
DIM SLEEP CLK/TIMER TIMER ON/OFF
REPEAT PROGRAM SHUFFLE DISPLAY
DSC VAC
GAME GAME
SOUND MIX-IT
MUTE wOOx ON/OFF
ALBUM
UPC code : 0 3784993 2742
Product Dimensions:
10.4"W x 12.7" H x 15.4" D (center unit)
13.7"W x 12.7" H x 9.4" D (speakers)
Package Dimensions:
24.6"W x 28.6" H x 16.2" D
Product weight: 46.3 lbs
Carton contains: 5 CD Changer Mini System, Multi-Function
Remote Control,Operating instructions,Warranty Information
Printed in Singapore
Date Printed : Nov 2002
© 2002 Koninklijke Philips Electronics N.V.
All rights reserved.
Specifications subject to change without notice.
Incredible Surround™ is a Trademark of Philips Consumer Electronics
Company
http://www.philipsusa.com
