Philips FW-C71 User manual

w
a
k
e
u
p
/
s
l
e
e
p
t
i
m
e
r
d
i
g
i
t
a
l
r
e
c
o
r
d
i
n
g
r
e
a
d
y
24
KEY
S
O
U
N
D
N
A
V
I
G
A
T
I
O
N
auto reverse
FW-C71
Mini Hi-Fi System
3 CD Changer with 120WattsTotal Power
Logic Deck andVariable Incredible Surround™
• 2 x 60Watts RMS Stereo
• Sound Navigation withVariable Incredible Surround™ and
26 Digital Sound Control modes
• 3-Step Dynamic Bass Boost
• 7-Band Spectrum Analyzer with 3 Display Modes
• 2-Way Bass Reflex Speaker System with Detachable Grilles
• CD-Rewritable Compatible
• 40-Track CD Random Program
• AM/FM Stereo DigitalTuning with 40 Presets
• OneTouch CD Synchro Recording
• Dual LogicTape Deck with Auto Reverse (R+1)
• Digital Recording Ready (digital and line out)
• Subwoofer Ready
• Easy set for radio
• 24-Button Remote Control
• Bedroom Clock withWake-upAlarm and Sleep-timer
• 4-Color Packaging

Sound Enhancement
2 x 60Watts RMS Stereo
60 watts continuous RMS power output per channel,at 6
Ohms, from 80Hz-16kHz, with no more than 10% Total
Harmonic Distortion (THD).
Sound Navigation via jog
The JOG SHUTTLE of this feature adds a new
dimensions in fine-tuning the sound settings and the
incredible surround™ to suit your personal taste.
26-step Digital Sound Control
The feature offers 26 different sound settings based on 6
basic settings : (CLASSIC - 1 setting, ROCK - 5 settings,
VOCAL - 5 settings,TECHNO - 5 settings, OPTIMAL - 5
settings,JAZZ - 5 settings)
Variable Incredible Surround™ (12 steps via Jog)
12 steps of exciting, new, psycho-acoustic method of
widening the stereo spatial image especially suited for
applications with limited separation of left and right speakers.
3-Step Dynamic Bass Boost (Beat,Punch, Blast)
Bass reproduction is essential for deep and rich music. 3
Step DBB offers the optimal level for any kind of music.
2-Way Bass Reflex Speaker System
Equipped with one 5 1/4" woofer, one 2 1/2" ferro-fluid
cooled tweeter. 2-way enclosures feature a wider range
of frequency response for greater listening pleasure.
AM/FM Stereo DigitalTuner
State-of-the-art precision tuning system insures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Design
Design Concept
The attractive and shelf appealing emphasis on the sound
control panel dominates and determines this range’s
character. The sound control panel emphasis which
supports the entire sound story is reinforeced by 2
distinctive rotaries(sound jog and volume) that builds itself
logically up the range with features, finishing, colours and
product design detail differentiation. Uninterrupted display
and cassette window lens set on a strong underlying
profile gives strong rational while the use of appropriate
backlighting, lightstrips and rings coupled with choice
colours evokes the emotional appeal.
Oversized,MultiColor,Digital FTD Display
This large display is easy to read at any distance with no
distortion or distraction and the multi-color format
makes it easy to recognize different functions at a glance.
Detachable Cloth Speaker Grilles
Detachable cloth covered grilles protect delicate speaker
components with rich, high-tech styling.
Convenience
3-Disc CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
CD-Rewritable Compatible
The player offers 100% playback guarantee of CD-
Rewritable CD's over the entire lifetime of the player. Even
CD-RW audio recordings on computers can be used.
Dual LogicTape Deck
Offer the ability to switch from one function, such as fast
forward, to another function, such as play, by remote
control without first pressing the stop button.
Auto Reverse
The feature employs an auto reverse mechanism to
sense the end of the tape and automatically reverse the
direction of tape travel in the PLAY mode providing an
uninterrupted, continuous flow of music without manually
flipping the cassette tape.
24-Button Remote Control
This infrared remote control operates volume +/–, all CD
functions (POWER, NEXT, PREVIOUS, PLAY, STOP,
PAUSE, REPEAT, SHUFFLE, PROGRAM, DISC 1, 2, 3 ), CD,
AUX, TAPE 1/2, TUNER, SLEEP TIMER, and sound
enhancement features including Incredible Surround™,
Dynamic Bass Boost,and Digital Sound Control.
Easy Set
Press Standby ‘ON’ for 5 secs to automatically program
40 tuner presets.
40-Random Channel Presets
Random memory presets allow pre-programming of up to
40AM and FM station frequencies into the tuner memory.
Auto Store
Automatically stores up to 40 preset FM orAM stations.
40-Track CD Random Program
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Auto Record Level Control
Micro electronic circuitry constantly monitors the final
audio amplifier stage to insure accurate, distortion-free
recordings every time.
AUX/Video Input
For connection of audio accessory pieces such as a LD
or DVD player,television,or external cassette deck.
Direct Source Selection
Automatically switch to a new source and pause the
current source at the touch of a single button.
Demo Mode
Functions always. Press “STOP” for 5 secs to interrupt
demo mode.
Direct Play Button
Allows you to select and play any CD in the carousel by
touching only one button.
ChangeWhile Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start
of a recording on an analog audio cassette deck with the
start of a CD or a CD program.
Repeat track/disc/all
Repeat your favorite track, disc or all.
UPC Code:0 37849 89279 4
Product Dimensions:
10.4"W x .12.2" H x 15.4" D (electronics)
9.4"W x 12.2" H x 12.4" D (speakers)
Package Dimensions:
21.4"W x 28.3" H x 15.7" D
Product weight: 39.7 lbs.
Carton contains: 3CD Changer Mini System, Multi-Function Remote
Control,Batteries, Operating instructions,Warranty information
Printed in Singapore
Date printed : Oct 1999
©1999 Royal Philips Electronics N.V.
All rights reserved.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Incredible Surround™ is a Trademark of Philips Consumer Electronics
Company
Pause
Interrupts playback of a CD without returning to the
beginning of the disc, so when play resumes, the music
begins exactly where it stopped.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order, ignoring the
sequential order in which they were originally recorded.
Next/Previous Skip
This two button feature offers you the opportunity to skip
back to the previous track or skip up to the next track
instantly.
High-Speed Dubbing
High-speed dubbing makes it possible to create good
quality recordings (dubs) from one tape to another at
twice the normal speed in RECORD mode.
Clock/Timer and Sleeptimer
Set the alarm portion of a built-in digital clock to wake
you to music from your favorite CD or an AM/FM radio
station at any desired time of the day. Sleeptimer settings
of 60,45,30 or 15 minutes.
3 Dim Display modes (including nite mode)
2 different display options showing different amounts of
display activity can be selected and 1 nite mode display which
shows minimal display activity and turns most of the lights off.
Stereo Headphone Jack
2
21 3
TUNERTAPE 1/2CD
SLEEP TIMERAUXPROGRAM
DSC DBB
IS
REPEAT PAUSE SHUFFLE
Å
CD DIRECT
VOLUME
á
à
ë
í
É
Ç
FW-C71
Mini Hi-Fi System
