Philips FW910R User manual

CD-Recorder with 3 CD Changer
Mini System
Mini component CD-Recorder:
•Records and plays digitalAudio CD,CD-R and CD-RW discs
•CD Synchronised auto start recording from all analogue and
digital sources
•Menu controlled user interface via jog
•CDText (input & editing for max.80 characters)
•Digital coaxial input & output
3 CD Changer Mini System:
•2 x 100 watts Music Power
•2 x 50 watts RMS
•Incredible Surround™
•Digital Sound Control (optimal, jazz, rock, techno)
•Dynamic Bass Boost
•2-way Speaker System with Bass Reflex and Detachable Grilles
•CD-Rewritable compatible
•Dual LogicTape Deck withAuto Replay
•Subwoofer Ready
CD-Recorder with 3 CD Changer
Mini System
Mini component CD-Recorder:
• Records and plays digitalAudio CD, CD-R and CD-RW discs
• CD Synchronised auto start recording from all analogue and
digital sources
• Menu controlled user interface via jog
• CDText (input & editing for max.80 characters)
• Digital coaxial input & output
3 CD Changer Mini System:
• 2 x 100 watts Music Power
• 2 x 50 watts RMS
• Incredible Surround™
• Digital Sound Control (optimal, jazz, rock, techno)
• Dynamic Bass Boost
• 2-way Speaker System with Bass Reflex and Detachable Grilles
• CD-Rewritable compatible
• Dual LogicTape Deck withAuto Replay
• Subwoofer Ready
2x100
MPOMPO
wattswatts
auto reverse
d
i
g
i
t
a
l
r
e
c
o
r
d
i
n
g
r
e
a
d
y
DIGITAL TUNING
40
PRESETS
WITH
FW910R
CD Mini System & CD-R

Mini System FW930
amplifier
•2 x 100 watts Music Power
•2 x 50 watts RMS,±10%THD, 6 Ohm,1 kHz
•Incredible Surround™
•Digital Sound Control
(optimal,jazz,rock,techno)
•Dynamic Bass Boost
compact disc player
•motorized front loading 3 CD changer
•CD-Rewritable compatible
•digital servo technology
•bit-check D/A converter
•40-track CD random program
•play modes (repeat/shuffle/program)
•repeat track/disc/all
•change 2 discs while playing 1
tuner
•RDS - station name,program type,RDS text,
clock set (/22)
•RDS -‘NEWS’ &TrafficAnnouncement (/22)
•FM/MW/LW DigitalTuner with 40 presets
•easy set/auto store for radio (and clock /22)
tape deck
•Dual LogicTape Deck
•Auto Reverse (tape 2)
•high speed dubbing
•CD synchro recording
•automatic recording level control
•automatic tape type selection
•electronic speed control and full auto stop
loudspeaker boxes
•3-way Bass Reflex
•5.25" woofer
•2.5" Ferro FluidTweeter
•2 x 1" polydome tweeter
•detachable grilles
connections
•stereo headphones :3.5mm stereo jack
•video/aux :cinch type sockets
•subwoofer output :cinch type socket
general
•multicolor FTD display
•demo mode
•clock/timer
•wake-up with CD,tuner or tape
CD-Recorder CDR930
audio
•frequency response :2 Hz - 22,05 kHz
•playback S/N :100 dB
•playback dynamic range :95 dB
•playback total harmonic distortion :85 dB (0,0056%)
•recording S/N (analogue) :90 dB
•recording S/N (digital) :recording quality equal
to source
•recording dynamic range :92 dB
•recording total harmonic distortion :85 dB
(0,0056%)
recording values for line input/output
•digital coaxial input :11-96 kHz / 0.5Vrms/ 75Ω
•digital optical input :11-96 kHz
•direct line recording (bypass SRC) for 44.1
:+/-1000ppm
•analogue input (level adjustment)
:500mVrms/50kΩ= 0dB
•line output voltage :2Vrms +/- 2 dB / 0.2 kΩ
•digital coaxial output :0.5Vpp / 75Ω
recording functions
•recording on CD-R & CD-RW discs
•auto start recording per disc,track
•multi track erase (CD-RW disc)
•erase disc (CD-RW disc)
•unfinalise disc (CD-RW disc)
•manual/auto track increment
•remaining recording time display
•finalise (make disc compatible to CD-player)
•SCMC (Serial Copy management system)
•RID code (Recorder Unique Identifier)
playback functions
•Play - Introscan - Pause - Stop
•direct track selection
•track selection with easy jog
•search forward/reverse
•repeat (all/per track)
•program play (99 tracks)
•time display switching
/21M /21 /22 /30 /34
Asia Pacific
Australia/NZ
Middle East/SAfrica
Latam
Europe •
E Europe
Mexico
tuner
FM65.81-74MHz
FM87.5-108MHz •
MW522-1602kHz •
LW153-279kHz •
FM75 Ohm clickfit •
mains supply
120/230V 50~60Hz
230V/50Hz •
general
made in sticker •
FW910R
CD Mini System & CD-R
CD-Recorder with 3 CD Changer Mini System
standard product information
FW930 EAN:
CD-R 930 EAN: 87 10101 61006 1 (/00)
Product Dimensions:
265mmW x 310mm H x 363mm D (center unit)
240mmW x 310mm H x 310mm D (speakers)
264mmW x 86mm H x 305mm D (CD-Recorder)
Package Dimensions:
624mmW x 606mm H x 474mm D (mini)
346mmW x 188mm H x 386mm D (CD-R)
Product weight: 18 kg (mini system)
: 4.5 kg (CD-Recorder)
Carton contains: CD Mini System, Multi-Function Remote Control
(for mini system and CD-Recorder),Batteries (2 x AA), Operating
instructions,Warranty information, FM antenna,AM antenna, CD-
Recorder,Audio Cable (x 2),Digital Coaxial Cable (x 1)
Printed in Singapore
Date printed :Apr 1999
Specifications subject to change without notice.
© 1998 Koninklijke Philips Electronics N.V.
All rights reserved.
