Philips FWC798 User manual

• 500 watts Total Power
• 2 x 140 watts RMS Stereo + 2 x 110 watts RMS Power Boost
• wOOx Technology Speaker System for Deeper Bass
• Power Booster with 2 extra 3-way Bass Reflex Speakers
• 6 modes Digital Sound Control and 6 modes Virtual Ambience Control
• 3-step wOOx level control
• Incredible Surround™
• Interactive Dashboard display with VU meter
• 3 way Bass Reflex Speaker System
• 6 " Front firing wOOx woofer
• Plays CD, CD-R and CD-RW discs
• FM/AM Digital Tuning with 40 presets
• Full Dual Logic Tape Deck with Auto Replay
• Digital out and Line out for perfect CD recording
• Bedroom Clock with Wake-up and Sleep-timer
• 31-key Remote Control
3 CD Changer Mini HIFI System
with wOOx Technology
FWC798
FWC798
VAC
wOOx
wOOx
technology
technology

2
21 3
TAPE 1/2TUNERCD 123
ISAUX/CDR
SLEEPCLOCK DISPLAY
AUTO RE. PAUSE TIMER ON/OFF
CD DIRECT
VOLUME
REPEAT
WOOX
ON/OFF WOOX LEVEL
PROGRAM
á
à
ë
í
É
Ç
SHUFFLE
Å
MUTE
DSC VAC
Sound Enhancement
2 x 140Watts RMS Stereo +
2 x 110Watts RMS Power Boost
The power boost generates 110 watts continuous RMS
power output per channel on top of the 140 watts
continuous RMS power output per channel at 6 Ohm,
from 120 Hz - 15 kHz with no more than 10% total
harmonic distortion (THD).
wOOxTechnology
Philips patented wOOxTechonolgy ensures superior bass
results. The dual suspension bass radiator, together with
dedicated amplifier circuitry, is especially designed to
produce and handle high dynamic sound signals at very
low frequencies. Because of the dual suspension, the
excursion of the membrane can be extreme (see
illustration). This is in combination with the symmetrical
sandwich construction, provides for very low and precise
bass without noticeable distortion. The net effect of
using wOOx Technology is a tight bass sound that is
significantly "lower and louder" than conventional mini
shelf systems.
3-Step wOOx Level Control
As the human ear does not perceive low frequencies at
the same level as higher frequencies (though at the same
"volume"), the bass sound needs to be enhanced to
achieve maximum impact. The wOOx is progressively
driven at different optimization levels in setting wOOx 1,
2 and 3.
Incredible Surround™
An exciting, new, psycho-acoustic method of widening
the stereo spatial image especially suited for applications
with limited separation of left and right speakers.
6 modes Digital Sound Control
(digital,pop,classic,rock,newage,electric)
6 modesVirtualAmbience Control
(hall,cinema,arcade,concert,disco,cyber)
3-Way Bass Reflex Speaker System
Equipped with one 6 1/2" woofer and one 2" tweeter and
one 1" polydome piezo, 3-way enclosures feature a wider
range of frequency response for greater listening pleasure
and bass reflex enclosures for deep,rich bass response.
AM/FM Stereo DigitalTuner
State-of-the-art precision tuning system insures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Convenience
3-CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
Plays CD,CDR and CD-RW discs
The player offers 100% playback guarantee of CD, CD-
Recordable and CD-Rewritable CD's over the entire life
time of the player. Even CD-RW audio recordings on
computers can be used.
Interactive Dashboard Display
An integrated Flourescent Tube Display (FTD) Volume
Unit (VU) Meter shows volume level and musical
amplitude during playback.
31-key Remote Control
This infrared remote control operates volume +/–, all
CD functions (POWER, NEXT, PREVIOUS, PLAY, STOP,
PAUSE, SHUFFLE, REPEAT, PROGRAM, CD123, CD
DIRECT 1, 2, 3, G and F), AUX/CDR select,TUNER
select,TAPE 1/2 select, AUTO REPLAY,TIMER ON/OFF,
CLOCK, DISPLAY, SLEEP and sound enhancement
features including MUTE, Digital Sound Control (DSC),
Virtual Ambience Control (VAC), Incredible Surround,
wOOx On/Off and wOOx Level.
Plug & Play
Press 'PLAY' to perform auto programming and storing
of audio stations in presets as well as initiation of sound
presets.
40-Random Channel Presets
Random memory presets allow pre-programming of up
to 40 AM and FM station frequencies into the tuner
memory.
Auto Store
Automatically stores up to 40 preset FM orAM stations .
40-Track CD Random Program
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Auto Record Level Control
Micro electronic circuitry constantly monitors the final
audio amplifier stage to insure accurate, distortion-free
recordings every time.
Video/AUX Input
For connection of audio accessory pieces such as a LD
or DVD player,television,or external cassette deck.
Direct Source Selection
Automatically switch to a new source and pause the
current source at the touch of a single button.
Demo Mode
Functions always. Press “STOP” for 5 secs to interrupt
demo mode.
Direct Play Button
Allows you to select and play any CD in the carousel by
touching only one button.
ChangeWhile Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
UPC Code: 0 37849920640
Product Dimensions:
10.4"W x 12.2" H x 15.4" D (electronics)
9.4"W x 13.8" H x 12.2" D (speakers)
5.5"W x 12.2" H x 13.6" D (booster amplifier)
5.5"W x 12.2" H x 12.2" D (booster speakers )
Package Dimensions:
41.2"W x 16.1" H x 21.7" D
Product weight: 48.4 lbs.
Carton contains: 3CD Changer Mini System, Multi-
Function Remote Control, Operating instructions,
Warranty information
Printed in Singapore
Date printed : Jun 2001
©2001 Royal Philips Electronics N.V.
All rights reserved.
A Division of Philips Electronics North America
Corp.
Specifications subject to change without notice.
Incredible Surround™ is a Trademark of Philips
Consumer Electronics Company
http://www.philipsusa.com
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start of
a recording on an analog audio cassette deck with the start
of a CD or a CD program.
Repeat
Repeat your favorite track.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order, ignoring the sequential
order in which they were originally recorded.
Next/Previous Skip
This two button feature offers you the opportunity to skip
back to the previous track or skip up to the next track
instantly.
Dual LogicTape Deck
Offer the ability to switch from one function, such as fast
forward, to another function, such as play by remote
control.
Auto Replay
The feature employs an auto rewind mechanism to sense
the end of the tape of the same side and automatically
rewind and playback at the beginning of the tape providing
an uninterrupted, continuous flow of music.
Continuous Play
Continuous play offers automatic switching from cassette
deck A to cassette deck B providing an uninterrupted,
continuous flow of music in the PLAY mode.
Clock,Alarm & Sleep-Timer
Set the alarm portion of a built-in digital clock to wake you
to music from your favorite CD or an AM/FM radio station
at any desired time of the day. Sleep timer settings of 60,
45,30 or 15 minutes.
3 Display modes (including nite mode)
2 different display options showing different amounts of
display activity can be selected and 1 nite mode display
which shows minimal display activity and turns most of the
lights off.
FWC798
FWC798
suspension 1suspension 2
excursion 1
excursion 2
excursion 2
excursion 1
wOOxTechnology
double suspension = double excursion
