Philips FWD831/12 User manual

FWD831
DVD Mini HiFi System
User manual
Manuel d'utilisation
Manual de usuario
Benutzerhandbuch
Gebruikershandleiding
Manuale dell'utente
Användarhandbok
Brugervejledning
pg 001-039_FWD831-Eng 2007.6.15, 13:351

2
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in
hazardous radiation exposure or
other unsafe operation.
Italia
DICHIARAZIONE DI CONFORMITA’
Si dichiara che l’apparecchio MCD515 Philips
risponde alle prescrizioni dell’art. 2 comma 1 del
D.M. 28 Agosto 1995 n. 548.
Fatto a Eindhoven
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven,The Netherlands
Important notes for users in the
U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1Remove fuse cover and fuse.
2Fix new fuse which should be a BS1362 5 Amp,
A.S.T.A. or BSI approved type.
3Refit the fuse cover.
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board
should not be greater than 5 Amp.
Note: The severed plug must be disposed of to
avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N),
brown = live (L).
¶As these colours may not correspond with the
colour markings identifying the terminals in
your plug, proceed as follows:
–Connect the blue wire to the terminal
marked N or coloured black.
–Connect the brown wire to the terminal
marked L or coloured red.
–Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
Norge
Typeskilt finnes på apparatens underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller elektrisk
støt, skal apparatet ikke utsettes for regn eller
fuktighet.
pg 001-039_FWD831-Eng 2007.6.15, 13:352

9
2
3
4
0
%
$
#
@
1
8
6
5
!
7
6
31
pg 001-039_FWD831-Eng 2007.6.15, 13:353

1
4
7
2
5
8
0
3
6
9
ANGLE
PROG
GOTO
ELTITBUSOIDUA
ZOOM
VOL
+
ECHO
KEY
SOUND
DBB
IS
OK
SYSTEM MENU
MODE REPEAT A-B SLEEP
TIMER OSD
DISPLAY
MUTEAUX
DISC MENU
DISC
1
)
5
7
%
2
0
(
4
^
&
*
6
$
8
7
8
#
¡
™
£
3
!
@
TUNER
TUNER
pg 001-039_FWD831-Eng 2007.6.15, 13:354

DK
Advarsel: Usynlig laserstråling ved åbning
når sikkerhedsafbrydere er ude af funktion.
Undgå utsættelse for stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen fra
nettet. Den indbyggede netdel er derfor
tilsluttet til lysnettet så længe netstikket
sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på annat
sätt än i denna bruksanvisning specificerats,
kan användaren utsättas för osynlig
laserstrålning, som överskrider gränsen för
laserklass 1.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är därför
ansluten till elnätet så länge stickproppen
sitter i vägguttaget.
SF
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen
muulla kuin tässä käyttöohjeessa mainitulla
tavalla saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei
saa olla alttiina tippu-ja roiskevedelle.
Huom.Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu verkko-
osa on kytkettynä sähköverkkoon aina
silloin, kun pistoke on pistorasiassa.
Manufactured under license from Dolby
Laboratories.
"Dolby", "Pro Logic" and the double-D symbol
are trademarks of Dolby Laboratories.
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual
property rights owned by Macrovision
Corporation and other rights owners. Use of this
copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing
uses only unless otherwise authorized by
Macrovision Corporation. Reserve engineering
or disassembly is prohibited.
Windows Media is a trademark of
Microsoft Corporation.
pg 001-039_FWD831-Eng 2007.6.15, 13:355

Language Code
Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja
7889
9072
Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
 6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inupiaq 7375
Irish 7165
Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Português 8084
Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
Tonga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Turkmen 8475
Twi 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yoruba 8979
Zulu 9085
pg 001-039_FWD831-Eng 2007.6.15, 13:356

English
7
.
Index
English ------------------------------------------------ 8
Español --------------------------------------------- 72
Français -------------------------------------------- 40
Deutsch ------------------------------------------- 104
Nederlands -------------------------------------- 136
Italiano -------------------------------------------- 168
Svenska ------------------------------------------- 200
Dansk --------------------------------------------- 232
English
Français
EspañolDeutschNederlandsItalianoSvenskaDansk
pg 001-039_FWD831-Eng 2007.6.19, 10:477

8
English
Contents
General Information
Features .................................................................. 9
Discs for playback ................................................ 9
Supplied accessories ............................................ 9
Environmental information .............................. 10
Care and safety information ...................... 10-11
Connections
Step 1: Placing speakers .................................... 12
Step 2: Connecting speakers ............................ 13
Step 3:Antenna connection ............................. 13
Step 4: Connecting TV ................................. 13-15
Using componentVideo In jack (Cr Cb Y)
Using Video In jack
Using S-Video In jack
Using an accessory RF modulator
Step 5: Connecting the power cord ............... 15
Optional: Connecting additional equipment .....
.......................................................................... 15-16
Controls
Controls on the system .................................... 17
Controls on the remote control .............. 17-18
Preparations
Step 1: Inserting batteries into the remote
control .................................................................. 19
Using the remote control to operate the
system
Step 2: Setting the clock ................................... 19
Step 3: Setting video preference ............... 20-21
Step 4: Setting language preference ................ 22
Basic Functions
Switching the system on/off ............................. 23
Power-saving automatic standby ..................... 23
Sound control ..................................................... 23
Volume control ................................................... 23
Microphone Mixing ............................................ 23
Key Control ......................................................... 23
Plug and Play (for tuner installation) .................... 24
Disc Operations
Playing discs ......................................................... 25
Using the disc menu .......................................... 25
Basic playback controls ............................... 25-27
Pausing playback
Selecting a track/chapter/title
Resuming playback from the last stopped
point
Zoom
Repeat
Repeat A-B
Program
Forward/Reverse Searching
Time search & search by chapter/track
number
Information display during playback
Special disc features ........................................... 27
Playing a Title
Camera Angle
Changing the Audio Language
Changing the Audio Channel
Subtitles
Playing MP3/WMA disc ..................................... 28
General operation
Playback selection
Playing JPEG Picture CD ................................... 28
General operation
Playback selection
Special JPEG features ......................................... 29
Zoom picture
Playback with multi-angles
pg 001-039_FWD831-Eng 2007.6.15, 13:358

English
9
Contents
System Menu Options
Basic operations ................................................. 30
SYSTEM SETUP ............................................ 30-33
TV SYSTEM
SCREEN SAVER
TV TYPE
PASSWORD
RATING
DEFAULT
LANGUAGE SETUP .......................................... 32
VIDEO SETUP .................................................... 32
COMPONENT
TV MODE
BRIGHTNESS
CONTRAST
HUE
SATURATION
AUDIO SETUP ............................................. 32-33
DIGITAL OUT
DOWNMIX
3D PROCESSING
LPCM
NIGHT MODE
Radio Reception
Tuning to radio stations .................................... 34
Programming radio stations ............................. 34
Automatic programming
Manual programming
Tuning to preset radio stations ....................... 34
Clock/Timer
Clock setting ....................................................... 35
Timer setting ....................................................... 35
Sleep timer setting ............................................. 35
Specifications ........................................... 36
Troubleshooting .............................. 37-38
Glossary ......................................................... 39
Disposal of your old product
Your product is designed and
manufactured with high quality
materials and components,
which can be recycled and
reused.
When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and do
not dispose of your old products with your
normal household waste.The correct disposal of
your old product will help prevent potential
negative consequences for the environment and
human health.
pg 001-039_FWD831-Eng 2007.7.30, 14:129

10
English
General Information
Features
Additional Component Connections
Lets you connect other audio and audio/visual
components to the system so you can use the
system’s surround sound speakers.
Parental control (rating level)
Lets you set a rating level so that your children
cannot watch a DVD that has a rating higher
than you set.
Sleep timer
Enables the system to switch to standby mode
automatically at a preset time.
Night Mode
Lets you compress the dynamic range, reducing
the difference in loudness between different
sounds in Dolby Digital mode.
Progressive Scan
Provides high quality flicker-free images for film
based sources.When a picture refreshes, its
vertical resolution can double to 525 lines.
Note:
–To fully enjoy the progressive scan feature, you
need a progressive scanTV.
Discs for playback
Your DVD System will play:
–Digital Video Discs (DVDs)
–Video CDs (VCDs)
–Super Video CDs (SVCDs)
–Digital Video Discs + Rewritable (DVD+RW)
–Compact Discs (CDs)
–Picture (Kodak, JPEG) files on CDR(W)
–Windows Media Audio (WMA)
–Supported MP3-CD format
•ISO 9660/UDF format
•Max. title/album name –10 characters
•Max. title number plus album is 255.
•Max. nested directory is 8 levels.
•The max. album number is 32.
•The max. MP3 track number is 999.
•Supported sampling frequencies for MP3
disc: 32 kHz, 44.1 kHz, 48 kHz.
•Supported Bit-rates of MP3 disc are: 32, 64,
96, 128, 192, 256 (kbps).
The following formats can’t be supported.
•The files like *.VMA, *.AAC, *.DLF, *.M3U,
*.PLS, *.WAV,
•The discs recorded under Joliet format
Region Codes
DVDs must be labeled for ALL regions or Region
2 in order to play on this DVD system.You
cannot play discs that are labeled for other
regions.
Notes:
–For mixed mode discs, only one mode will be
selected for playback according to the recording
format.
–If you are having trouble playing a certain disc,
remove the disc and try a different one. Improperly
formatted discs will not play on this system.
–DTS surround audio output is not available in
this DVD player.
Supplied accessories
–Composite video cable (yellow)
–Component video cables (red/blue/green)
–Audio cables (white/red)
–AC power cord
–2speaker boxes including 2 speaker cables
–MW loop antenna
–FM wire antenna
–Remote Control
–This instruction booklet and a quick start guide
2
ALL
pg 001-039_FWD831-Eng 2007.6.15, 13:3510

English
11
Environmental information
Any unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialised company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Care and safety information
Avoid high temperatures, moisture,
water and dust
●Do not expose the system, batteries or discs to
humidity, rain, sand or excessive heat (caused by
heating equipment or direct sunlight). Always
keep disc trays closed to avoid dust buildup on
the lens.
●No objects filled with liquids, such as vases, shall
be placed on the apparatus.
●No naked flame sources, such as lighted candles,
should be placed on the apparatus.
●The apparatus shall not be exposed to dripping
or splashing.
Avoid condensation problem
●The lens may cloud over when the player is
suddenly moved from cold to warm
surroundings, making it impossible to play a disc.
Leave the player in the warm environment until
the moisture evaporates.
Do not block the vents
●Do not operate the system in an enclosed
cabinet and allow about 10 cm (4 inches) of free
space all around the player for adequate
ventilation.
10 cm
(4 inches)
10 cm
(4 inches)
10 cm
(4 inches)
DVD Micro Hi-Fi System
●The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers table-cloths, curtains, etc.
Cleaning the cabinet
●Use soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning discs
●To clean a CD, wipe it in a
straight line from the center
towards the edge using soft
and lint-free cloth. A cleaning
agent may damage the disc.
●Write only on the printed side
of a CDR(W) and only with a
soft felt-tipped pen.
●Handle the disc by its edge. Do not touch the
surface.
Cleaning the disc lens
●After prolonged use, dirt or dust may
accumulate at the disc lens.To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
General Information/Maintenance
pg 001-039_FWD831-Eng 2007.6.15, 13:3511

12
English
General Information/Maintenance
Finding a suitable location
●Place the player on a flat, hard, stable surface.
●Install this unit near the AC outlet and where the
AC power plug can be reached easily.
Hearing Safety
Listen at a moderate volume.
●Using headphones at a high volume can impair
your hearing. This product can produce sounds
in decibel ranges that may cause hearing loss for
a normal person, even for exposure less than a
minute. The higher decibel ranges are offered
for those that may have already experienced
some hearing loss.
●Sound can be deceiving. Over time your hearing
"comfort level" adapts to higher volumes of
sound. So after prolonged listening, what sounds
"normal" can actually be loud and harmful to
your hearing. To guard against this, set your
volume to a safe level before your hearing
adapts and leave it there.
To establish a safe volume level:
●Set your volume control at a low setting.
●Slowly increase the sound until you can hear it
comfortably and clearly, without distortion.
Listen for reasonable periods of
time:
●Prolonged exposure to sound, even at normally
"safe" levels, can also cause hearing loss.
●Be sure to use your equipment reasonably and
take appropriate breaks.
Be sure to observe the following
guidelines when using your
headphones.
●Listen at reasonable volumes for reasonable
periods of time.
●Be careful not to adjust the volume as your
hearing adapts.
●Do not turn up the volume so high that you
can't hear what's around you.
●You should use caution or temporarily
discontinue use in potentially hazardous
situations.
●Do not use headphones while operating a
motorized vehicle, cycling, skateboarding, etc.; it
may create a traffic hazard and is illegal in many
areas.
pg 001-039_FWD831-Eng 2007.6.15, 13:3512

English
13
Connections
IMPORTANT!
–The type plate is located at the rear of
the system.
– Before connecting the AC power cord
to the wall outlet, ensure that all other
connections have been made.
–Never make or change any
connections with the power switched on.
–High voltage! Do not open.You run the
risk of getting an electric shock.
–The machine does not contain any
user-serviceable parts.
–Modification of the product could
result in hazardous radiation of EMC or
other unsafe operation.
To avoid overheating of the system, a
safety circuit has been built in.Therefore,
your system may switch to Standby
mode automatically under extreme
conditions. If this happens, let the system
cool down before reusing it (not available
for all versions).
Step 1: Placing speakers
Place the front left and right speakers at equal
distances from the TV set and at an angle of
approximately 45 degrees from the listening
position.
Notes:
–To avoid magnetic interference, do not position
the front speakers too close to your TV set.
–Allow adequate ventilation around the DVD
System.
AUDIO
IN
S-VIDEO
IN
VIDEO IN
AUDIO
IN
S-VIDEO
IN
VIDEOIN
TVIN
Cr
Cb
Y
Speaker
(right)
Speaker
(left)
FM antenna
MW
antenna
AC power cord
Front
speaker
( left )
Front
speaker
( right )
VIEWING AREA
pg 001-039_FWD831-Eng 2007.6.15, 13:3513

14
English
FM Antenna
●For better FM stereo reception, connect an
outdoor FM antenna to the FM AERIAL (FM
ANTENNA) terminal.
Step 4: Connecting TV
IMPORTANT!
–You only need to make one video
connection from the following options,
depending on the capabilities of your TV
system.
–Connect the DVD system directly to
the TV.
Using component Video In jack (Cr CbY)
1
2
Connections
Step 2: Connecting speakers
12
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "RIGHT" and left
speaker to "LEFT", coloured (marked) wire to
"+" and black (unmarked) wire to "-". Fully insert
the stripped portion of the speaker wire into the
terminal as shown.
Notes:
– Ensure that the speaker cables are correctly
connected. Improper connections may damage the
system due to short-circuit.
–For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
Step 3: Antenna connection
Connect the supplied MW loop antenna and FM
antenna to the respective terminals. Adjust the
position of the antenna for optimal reception.
MW Antenna
●Position the antenna as far as possible from a TV,
VCR or other radiation source.
pg 001-039_FWD831-Eng 2007.6.15, 13:3514

English
15
1Use the component video cables (red/blue/
green) to connect the system’s Pr/Cr Cr/CbY
jacks to the corresponding Component video
input jacks on theTV set.
2To hear the sound of this DVD Player through
your TV, use the audio cables (white/red) to
connect LINE OUT (L/R) jacks of the DVD
Player to the corresponding AUDIO IN jacks on
theTV.
UsingVideo In jack (CVBS)
AUDIO
IN
2
1
1Use the composite video cable (yellow) to
connect the system's VIDEO OUT jack to the
video input jack (or labelled as A/V In,Video In,
Composite or Baseband) on theTV set.
2To hear the sound of this DVD Player through
your TV, use the audio cables (white/red) to
connect LINE OUT (L/R) jacks of the DVD
Player to the corresponding AUDIO IN jacks on
theTV.
Using S-Video In jack
1Use the S-Video cable (not supplied) to connect
the system's S-VIDEO OUT jack to the S-
Video input jack (or labelled asY/C or S-VHS)
on the TV set.
2To hear the sound of this DVD Player through
your TV, use the audio cables (white/red) to
connect LINE OUT (L/R) jacks of the DVD
Player to the corresponding AUDIO IN jacks on
theTV.
Connections
AUDIO
IN
1
2
pg 001-039_FWD831-Eng 2007.6.15, 13:3515

16
English
Using an accessory RF modulator
IMPORTANT!
–If your TV set only has a single
Antenna In jack (or labelled as 75 ohm or
RF In), you will need a RF modulator in
order to view the DVD playback via TV.
See your electronics retailer or contact
Philips for details on RF modulator
availability and operations.
1Use the composite cable (yellow) to connect the
system's VIDEO OUT jack to the video input
jack on the RF modulator.
2Use an RF coaxial cable (not supplied) to
connect the RF modulator to your TV's RF jack.
Connections
Step 5: Connecting the power
cord
IMPORTANT!
–Never make or change any connection
with the power switched on.
After everything is connected properly, plug in
the AC power cord to the power outlet.
Optional: Connecting additional
equipment
IMPORTANT!
–Some discs are copy-protected.You
cannot record the disc through a VCR or
digital recording device.
–When making connections, make sure
the colour of cables matches the colour
of jacks.
–Always refer to the owner's manual of
the other equipment for complete
connection and usage details.
AUDIO
INPUT
L
R
A
B
AUDIO IN
R L
VIDEO
IN
TO TVANT IN
CH3 CH4
2
1
RF coaxial cable to TV
Back of RF Modulator
(example only)
Antenna or
Cable TV signal
pg 001-039_FWD831-Eng 2007.6.15, 13:3516

English
17
Connections
Viewing and listening to the playback of
other equipment A
Connect the system's AUX/CDR IN (R/L)
jacks to the AUDIO OUT jacks on the other
audio/visual device (such as aTV,VCR, Laser Disc
player or cassette deck).
Before starting operation, press SOURCE on
the front panel to select AUX or press AUX on
the remote in order to activate the input source.
Connecting an active subwoofer B
Connect the DVD mini system's
SUBWOOFER OUT jack to the AUDIO
INPUT jack on an active subwoofer (not
supplied).
DIGITAL IN
D
AUDI O IN
L
R
VIDEO IN
C
Using the VCR for recording DVDs C
Connect one of the system's VIDEO OUT
jacks to the corresponding VIDEO IN jack and
LINE OUT (R/L) jacks to the AUDIO IN jacks
on theVCR.This will allow you to make analogue
stereo (two channel, right and left) recordings.
Recording (digital) D
Connect the system's DIGITAL OUT jack to
the DIGITAL IN jack on a digital recording
device (such as DTS-DigitalTheatre compatible,
with Dolby Digital decoder).
Before starting operation, set the DIGITAL OUT
according to the audio connection. (See “System
Menu Options-DIGITAL OUT”.)
pg 001-039_FWD831-Eng 2007.6.15, 13:3517

18
English
Controls (illustrations on page 3 &4)
Controls on the system
1STANDBY-ON/ECO POWER y
– to switch the system on or to Eco power/normal
standby mode.
2Display screen
– to view the current status of the system.
3SOURCE
–to select the respective sound source: DISC,
TUNER or AUX.
4DISPLAY/BAND
forTuner................. to select waveband : FM or
MW.
for DVD/VCD/CD/MP3-CD
................................. to display disc information on
theTV screen and system display
panel during playback.
5PRESET í/ë
forTuner ............. to select a preset radio station.
for DVD/VCD/CD/MP3 CD
................................. to select a desired track.
6SEARCH 22/33
*for DVD/VCD/CD.
................................. to fast reverse/forward the disc.
(It is impossible to fast reverse/
forward for MP3-CD.)
forTuner ............. to tune to a lower or higher
radio frequency.
for clock/timer. to adjust the hours and minutes.
7PLAY•PAUSE ÉÅ
for disc................. to start or interrupt playback.
forTuner ............. to activate plug and play function.
8STOP 9
for DVD/VCD/CD/MP3-CD…to stop playback
or to clear a program.
9OPEN/CLOSE ç
–to open the disc compartment.
0VOLUME -/+
–to increase or decrease the volume.
!CLOCK SET
*for Clock .......... (on the system only) to set the
clock function.
@iR sensor
–infrared sensor for remote control.
#n
–to connect headphones.
$MIC 1/2
–to connect microphone.
%MIC VOL -/+
–to adjust the mixing level for Karaoke.
Controls on the remote control
1y
– to switch the system on/off.
2Numeric Keypad (0-9)
– to input a track/title/chapter number of the disc.
3PROG/ANGLE
–DVD/VCD/CD/MP3-CD: to enter the program
menu.
–Tuner: to program preset radio stations.
–DVD: to select a DVD camera angle.
4 SOURCE
–to select the respective sound source: DISC,
TUNER or AUX.
5 SYSTEM MENU (disc mode only)
–to enter or exit the system menu bar.
6DISC MENU (disc mode only)
–DVD/VCD: to enter or exit the disc contents
menu.
–VCD2.0: in stop mode, to switch the playback
control mode on or off .
722/33
Tuner
–press to tune to a lower/higher radio frequency
gradually.
–press and hold, then release the key to start
automatic search for a radio frequency
downward/upward.
Disc
–(not for MP3 CD) to search backward/forward
in a disc at different speeds.
–In DISC mode, to select a movement direction in
the disc menu or system menu bar.
– to move an enlarged picture left/right.
–for picture CD, to rotate an image clockwise or
counterclockwise.
* = Press and hold the button for more than three seconds.
pg 001-039_FWD831-Eng 2007.6.15, 13:3518

English
19
* = Press and hold the button for more than three seconds.
Controls (illustrations on page 3 &4)
83/4
–In DISC mode, to select a movement direction in
the disc menu or system menu bar.
–moves an enlarged picture up/down.
–(4) selects different slow playback modes for a
VCD/SVCD/DVD disc.
–(3) starts frame-by-frame playback for DVD/
VCD/SVCD.
9OK
–to exit or confirm the selection.
0í/ë
–Disc: skips to the previous/next chapter/title/
track.
–Tuner: to select a preset radio station.
–to adjust the hours and minutes for the clock/
timer function.
!9
–In DISC mode, to stop playback or clear a
program.
@2;
–In DISC mode, to start or interrupt playback.
#VOL +/-
–adjusts the volume upward/downward.
– adjusts the echo/level or turns on/off the MIC in
the karaoke mode.
$SUBTITLE
–selects a subtitle language.
%AUDIO
for VCD
–sets Stereo, Mono-Left or Mono-Right sound
mode.
for DVD
–selects an audio language.
^ MUTE
– to interrupt or resume sound reproduction.
&DISPLAY (OSD)
– displays information on TV screen during
playback.
*SLEEP/TIMER
Standby mode
–sets a time for switching on the system
automatically.
Power-on mode
– sets the sleep timer function (auto-off).
(REPEAT A-B
–for VCD/CD: to repeat a specific section within
the same track.
–for DVD: to repeat a specific section in a disc.
) MODE
–to select various repeat modes or the shuffle
play mode for a disc.
¡ZOOM
–DVD/VCD/Picture CD: enlarges or reduces a
picture or active image on the TV screen.
™KEY/ECHO
– turns on/off microphone setting.
–turns on/off key setting.
£SOUND
– selects different types of preset sound equalizer
settings: OPTIMAL, ROCK, JAZZ or TECHNO
during CD/MP3/WMA playback; HALL, CINEMA
or CONCERT during DVD/VCD playback.
≤IS/DBB
– *to create a super-enhanced stereo effect.
–to select desired bass enhancement effect.
∞GOTO
–In DISC mode, to fast search in a disc by
entering a time, title, chapter or track.
Notes for remote control:
–First, select the source you wish to
control by pressing one of the source select
keys on the remote control (DISC or
TUNER, for example).
–Then select the desired function ( 2;, í,
ëfor example).
pg 001-039_FWD831-Eng 2007.6.15, 13:3519

20
English
Preparations
IMPORTANT!
– Make sure to complete the
preparation procedures before operating
the system.
Step 1: Using Remote Control
IMPORTANT!
–Before using the remote control,
remove the insulation plastic tab as
shown in the picture below.
–If the remote control does not
function correctly or the operating range
is reduced, replace the battery with a
new (CR2025) battery.
1
2
3
CR2025
1Push to open the battery tray.
2Replace a new battery according to the
indicated polarity.
3Push the battery tray back to close it.
Using the Remote Control to operate
the Player
1Aim the Remote Control
directly at the remote sensor
(IR) on the front panel.
2Select the source you wish to
control by pressing one of the
source select buttons on the
remote.
3Then select the desired function
(for example, ÉÅ, ¡or ™).
CAUTION!
–Remove the battery if it is exhausted
or if the Remote Control is not being
used for a long time.
–Batteries contain chemical substances,
so they should be disposed of properly.
Step 2: Setting the clock
1Go to Standby mode.
2Press and hold CLOCK SET on the front
panel.
➜“SET CLOCK” is displayed briefly.Then, the
hour digits flash on the display screen.
3Press SEARCH 22/33 ( ¡/™on the
remote) to set the hours.
4Press CLOCK SET again.
➜The minute digits flash on the display screen.
5Press SEARCH 22/33 ( ¡/™on the
remote) to set the minutes.
6Press CLOCK SET to confirm the clock
setting.
Notes:
–This system only supports 24-hour mode.
–The clock setting will be erased when the system
is disconnected from the power supply.
–The system will exit clock setting mode if no
button is pressed within 30 seconds.
SYSTEM MENU
SUBTITLE REPEAT A-B SHUFFLE
SLOWDISPLAY
OSD
DISC MENU
DISC AUX
pg 001-039_FWD831-Eng 2007.6.15, 13:3520
