Philips MC230E User manual

3140 115 xxxxx
1
Micro Hi-Fi System MC230E
user manual
manuel d'utilisation
manual del usario
benutzerhandbuch
manuale per l'utente
manual do usuário
Instrukcje obsługi
uživatelské příručky
používateľské príručky
felhasználói útmutatók

3140 115 xxxxx
2
Important notes for users in the
U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1Remove fuse cover and fuse.
2Fix new fuse which should be a BS1362 5 Amp,
A.S.T.A. or BSI approved type.
3Refit the fuse cover.
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board
should not be greater than 5 Amp.
Note: The severed plug must be disposed of to
avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N),
brown = live (L).
¶As these colours may not correspond with the
colour markings identifying the terminals in
your plug, proceed as follows:
–Connect the blue wire to the terminal
marked N or coloured black.
–Connect the brown wire to the terminal
marked L or coloured red.
–Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
Italia
DICHIARAZIONE DI CONFORMITA’
Si dichiara che l’apparecchio MC230E Philips
risponde alle prescrizioni dell’art. 2 comma 1
del D.M. 28 Agosto 1995 n. 548.
Fatto a Eindhoven
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven,The Netherlands
CAUTION
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous
radiation exposure or other unsafe
operation.

3140 115 xxxxx
33
1
!
7
0
8
*
%
@
3
#
$
&
^
(
5
1
3
4
6
7
8
9
5
!
0
2

3140 115 xxxxx
4
MAGYARORSZÁG
Minőségtanúsítás
A garanciajegyen feltüntetett forgalombahozó
vállalat a 2/1984. (III.10.) BkM-IpM együttes
rendelet értelmében tanúsítja, hogy ezen készülék
megfelel a műszaki adatokban megadott
értékeknek.
Figyelem! A meghibásodott készüléket –
beleértve a hálózati csatlakozót is – csak
szakember (szerviz) javíthatja. Ne tegye ki a
készüléket esőnek vagy nedvesség hatásának!
Garancia
A forgalombahozó vállalat a termékre 12 hónap
garanciát vállal.
Névleges feszültség ....................... 220-230 V /50 Hz
Elemes működéshez ................................. 1 x CR2025
Névleges frekvencia .......... 50 Hz (vagy 50-60 Hz)
Teljesítmény
maximális ...................................................................... 40 W
névleges ......................................................................... 10 W
készenléti állapotban ............................................ < 3 W
Érintésvédelmi osztály II.
Tömeg ............................................................................ 4.2 kg
Befoglaló méretek
szélesség ............................................................. 582 mm
magasság ............................................................. 245 mm
mélység ................................................................... 96 mm
Rádiórész vételi tartomány
URH .......................................................... 87,5 – 108 MHz
MW .......................................................... 531 – 1602 KHz
Erősítő rész
Kimeneti teljesítmény .......................... 200 W PMPO
........................................................................... 2 x 5 W RMS
ČESKA REPUBLIKÁ
Vystraha! Tento přístroj pracuje s laserovým
paprskem. Při nesprávné manipulaci s
přístrojem (v rozporu s tímto návodem) můņe
dojít k nebezpečnému ozáření. Proto přístroj
za chodu neotevírejte ani nesnímejte jeho
kryty. Jakoukoli opravu vždy svěřte
specializovanému servisu.
Nebezpečí! Při sejmutí krytů a odjištění
bezpečnostních spínačů hrozí nebezpečí
neviditelného laserového záření!
Chraňte se před přímým zásahem laserového
paprsku.
Záruka: Pokud byste z jakéhokoli důvodu
přístroj demontovali, vždy nejdříve vytáhněte
síťovou zástrčku.
Přístroj chraňte před jakoukoli vlhkostí i před
kapkami
SLOVAK REPUBLIC
Prístroj sa nesmie používať v mokrom a
vlhkom prostredí! Chránte pred striekajúcou a
kvapkajúcou vodou!

3140 115 xxxxx
5
English
Français
Português EspañolDeutschItaliano
PolskiČeskySlovensky
Magyar
Index
English ------------------------------------------------ 6
Français -------------------------------------------- 20
Español --------------------------------------------- 35
Deutsch --------------------------------------------- 49
Italiano ---------------------------------------------- 64
Português ------------------------------------------ 79
Česky ---------------------------------------------- 109
Slovensky ---------------------------------------- 124
Magyar -------------------------------------------- 139
Polski ------------------------------------------------ 94

3140 115 xxxxx
6
English
Contents
General Information
Environmental information ................................ 7
Supplied accessories ............................................ 7
Safety information ................................................ 7
Preparations
Rear connections .......................................... 8 – 9
Optional connection ........................................... 9
Before using the remote control ...................... 9
Replacing battery (lithium CR2025) into the
remote control ..................................................... 9
Controls
Controls on the system and remote
control .................................................................. 10
Basic Functions
Switching the system on ................................... 11
Switching the system to Standby mode ........ 11
Power Saving Automatic Standby .................... 11
Adjusting volume and sound............................ 11
CD Operation
Playing a disc ........................................................ 12
Selecting a different track ................................. 12
Finding a passage within a track ...................... 12
Different play modes: Shuffle and Repeat ..... 13
Programming track numbers ........................... 13
Reviewing the programme ............................... 13
Erasing the programme ..................................... 13
Radio Reception
Tuning to radio stations .................................... 14
Programming radio stations ............................. 14
Tuning to preset radio stations ....................... 14
RDS ....................................................................... 15
Setting the RDS clock ....................................... 15
Searching programme type (PTY) .................. 15
RDS News and Traffic Announcement (TA) . 16
Clock/Timer
Setting the clock ................................................. 17
Viewing the clock ............................................... 17
Setting the timer ................................................. 17
Activating and deactivating TIMER ................. 17
Activating and deactivating SLEEP .................. 17
Specifications ........................................... 18
Maintenance.............................................. 18
Troubleshooting .................................... 19

English
3140 115 xxxxx
7
General Information
This product complies with the radio
interference requirements of the European
Community.
Environmental Information
All unnecessary packaging has been omitted.We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Supplied accessories
–2speaker boxes
–remote control (with battery)
–MW loop antenna
–stand
–screw and plug assembly
Safety Information
●Before operating the system, check that the
operating voltage indicated on the typeplate (or
the voltage indication beside the voltage
selector) of your system is identical with the
voltage of your local power supply. If not, please
consult your dealer.
●Place the system on a flat, hard and stable
surface.
●Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
●The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
●Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
●No naked flame sources, such as lighted candles,
should be placed on the apparatus.
●No objects filled with liquids, such as vases, shall
be placed on the apparatus.
●If the system is brought directly from a cold to a
warm location, or is placed in a very damp room,
moisture may condense on the lens of the disc
unit inside the system. Should this occur, the CD
player would not operate normally. Leave the
power on for about one hour with no disc in the
system until normal playback is possible.
●The mechanical parts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
●When the system is switched to Standby
mode, it is still consuming some power.
To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.

3140 115 xxxxx
8
English
Preparations
Rear connections
The type plate is located at the rear of the
system.
For users in the U.K.: please follow the
instructions on page 2.
APower
Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
WARNING!
–For optimal performance, use only the
original power cable.
–Never make or change any connections
with the power switched on.
To avoid overheating of the system, a safety
circuit has been built in. Therefore, your
system may switch to Standby mode
automatically under extreme conditions. If
this happens, let the system cool down
before reusing it (not available for all versions).
BAntennas Connection
Connect the supplied MW loop antenna to the
respective terminals. Adjust the position of the
antenna for optimal reception.
MW Antenna
●Position the antenna as far as possible from a TV,
VCR or other radiation source.
MW loop 
antenna FM wire antenna
AC power cord
Speakers
(right) Speakers (left)

English
3140 115 xxxxx
9
FM Antenna
●Extend coil antenna at the back of the unit fully
for optimum reception.
CSpeakers Connection
Front Speakers
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "RIGHT" and left
speaker to "LEFT", coloured (marked) wire to
"+" and black (unmarked) wire to "-".
●Fully insert the stripped portion of the speaker
wire into the terminal as shown.
Notes:
–For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of + / - speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
Optional connection
The optional equipment and connecting cords
are not supplied. Refer to the operating
instructions of the connected equipment for
details.
Connecting other equipment to your
system
Connect the audio left and right OUT terminals
of a TV,VCR, Laser Disc player, DVD player or
CD Recorder to the AUX-IN terminals.
Note:
–If you are connecting equipment with a mono
output (a single audio out terminal), connect it to
the AUX left terminal. Alternatively, you can use a
“single to double” cinch cable (the output sound
still remain mono).
Before using the remote control
1Pull out the plastic protective sheet.
2Select the source you wish to control by
pressing one of the source select keys on the
remote control (for example CD,TUNER).
3Then select the desired function (for example
ÉÅ , í, ë).
plastic
protective
sheet
Replacing battery (lithium
CR2025) into the remote control
1Pull out the knob A slightly to the left.
2Pull out the battery compartment B .
3Replace a new battery and fully insert the
battery compartment back to the original
position.
CAUTION!
Batteries contain chemical substances, so
they should be disposed off properly.
Preparations

3140 115 xxxxx
10
English
Controls (illustrations on page 3)
Controls on the system and
remote control
1STANDBY-ON
– switches the system to standby/on.
2Display
–shows the status of the system.
3OPEN • CLOSEç
–opens/ closes the CD door.
4IR
–remote sensor
5VOLUME (3 /4 ) (+/-)
–adjusts the volume level.
6CD Door
7Mode Selection
SEARCH/ TUNE (à/á)
for TUNER ........ tunes to a station
for CD ................. fast searches back and forward
within a track/ CD.
STOP 9............ stops CD playback or erase a
CD programme.
PLAYÉÅ ...... starts or interrupts playback.
PRESET (¡/ ™)
for TUNER ........ selects a preset radio station.
for CD ................. skips to the beginning of a
current track/ previous/
subsequent track
8DBB (Dynamic Bass Boost)
– enhances the bass.
9BAND
–selects a waveband.
0PROGRAM
for CD ................. programmes tracks and reviews
the programme.
for TUNER ........ programmes tuner stations.
!SOURCE
– selects the respective sound source for CD/
TUNER/ AUX.
@CLOCK SET
–sets the clock function.
–views the clock.
#TIMER
– activates/ deactivates or sets the timer function
$SLEEP
– activates/deactivates or selects the sleeper time.
%DSC (Digital Sound Control)
–selects sound characteristics: ROCK/ JAZZ/
POP/ CLASSIC.
Notes for remote control:
– First select the source you wish to control
by pressing one of the source select keys on
the remote control (for example CD,
TUNER).
–Then select the desired function (for
example ÉÅ, ¡ , ™).
^RDS.NEWS
–activates RDS news and Traffic Announcement.
– for tuner, displays RDS information.
&MUTE
– interrupts and resumes sound reproduction.
*REPEAT
–repeats a track/ CD programme/ entire CD.
(SHUFFLE
–plays CD tracks in random order.

English
3140 115 xxxxx
11
Basic Functions
IMPORTANT!
Before you operate the system, complete
the preparation procedures.
Switching the system on
●Press STANDBY-ON / 2.
➜The system will switch to the last selected
source.
●Press SOURCE (or CD, TUNER or AUX on
the remote control).
➜The system will switch to the selected source.
Switching the system to Standby
mode
●Press STANDBY-ON / 2in the active mode.
●The volume level (up to a maximum volume
level of 20), interactive sound settings, last
selected mode, source and tuner presets will be
retained in the player's memory.
Power Saving Automatic Standby
As a power-saving feature, the system
automatically switches to Standby 15 minutes
after a CD has reached the end and no control
is operated.
Adjusting volume and sound
1Press the VOLUME 3 /4 (+/-)control to
decrease or increase the volume.
➜Display shows the volume level VOL and a
number from MIN1, 2, ...30, 31 MAX.
2Press DSC repeatedly to select the desired
sound effect: ROCK/JAZZ/POP/ CLASSIC.
3Press DBB to switch bass enhancement on or
off.
➜Display shows: DBB.
4Press MUTE on the remote control to
interrupt sound reproduction instantly.
➜Playback will continue without sound and the
display shows MUTE.
●To activate sound reproduction you can:
–press MUTE again;
–adjust the volume controls;
–change source.

3140 115 xxxxx
12
English
4Press ÉÅ to start playback.
➜Current track number and elapsed playing
time of the track are displayed during disc
playback.
5To interrupt playback pressÉÅ. Press ÉÅ
again to resume play.
6To stop disc playback, press STOP 9.
Note: CD play will also stop when;
– the CD door is opened.
– the disc has reached the end.
– you select another source: TUNER or AUX.
Selecting a different track
●Press íor ëonce or repeatedly until the
desired track number appears in the display.
●If you have selected a track number shortly after
loading a disc or in the PAUSE position, you will
need to press ÉÅto start playback.
Finding a passage within a track
1Press and hold down on àor á.
➜The disc is played at high speed and low
volume.
2When you recognise the passage you want,
release àor á.
➜Normal playback continues.
IMPORTANT!
The lens of the CD player should never be
touched.
Playing a disc
●CD-ROM, CD-I, CDV, VCD, MP3, DVD or
computer CDs, however, are not possible.
1Press SOURCE to select CD.
2Press OPEN • CLOSEçon the front panel
of the system to open the CD compartment.
➜OPEN is displayed when the compartment
cover slides up.
3Insert a disc with the printed side facing up.
Press OPEN • CLOSEçagain to close the
compartment.
➜READING is displayed as the CD player scans
the contents of the disc.
➜The total playing time and the total number
of tracks are displayed.
CD Operation

English
3140 115 xxxxx
13
CD Operation
Different play modes: SHUFFLE
and REPEAT
You can select and change the various play
modes before or during playback.The REPEAT
modes can also be combined with PROGRAM.
SHUFFLE ......... tracks of the entire disc are
played in random order
SHUFFLE and REPEAT ALL…to repeat the
entire disc continuously in
random order
REPEAT ALL ... repeats the entire disc/ program
REPEAT ............ plays the current track
continuously
1To select your play mode, press the SHUFFLE
or REPEAT on the remote control before or
during playback until the display shows the
desired function. (SHUFFLE, REPEAT, REPEAT
ALL)
2PressÉÅto start playback if in the STOP
position.
➜If you have selected SHUFFLE, playback starts
automatically.
3To return to normal playback, press the
respective SHUFFLE or REPEAT button until
the various SHUFFLE / REPEAT modes are no
longer displayed.
●You can also press STOP 9to cancel your play
mode.
Programming track numbers
Program in the STOP position to select and
store your disc tracks in the desired sequence. If
you like, store any track more than once. Up to
40 tracks can be stored in the memory.
1Press PROGRAM to enter the programming
mode.
➜A track number is shown and PROGRAM
flashes.
2Use the íor ëto select your desired track
number.
3Press PROGRAM to confirm the track number
to be stored.
➜The number of tracks programmed and the
total playing time of the programme are show
briefly, then the selected track and PROG.
4Repeat steps 2-3 to select and store all desired
tracks.
➜FULL is displayed if you attempt to program
more than 40 tracks.
5To start playback of your disc program, press
STOP 9followed by ÉÅor press ÉÅdirectly.
Reviewing the program
In STOP mode, press and hold PROGRAM.
Until the display shows all your stored track
number in sequence.
Erasing the program
You can erase the program by:
●pressing STOP 9once in the STOP mode;
●pressing STOP 9twice during playback;
●opening the CD compartment;
➜PROGRAM disappears.
➜CLEAR is displayed briefly.

3140 115 xxxxx
14
English
Radio Reception
Tuning to radio stations
1Press SOURCE to select TUNER.
➜TUNER is displayed briefly.
2Press BAND (or TUNER on the remote
control) once or more to select your waveband
(FM/ MW).
3Press and hold TUNE àor á.
➜The radio automatically tunes to a station
with sufficient reception. Display indication during
automatic tuning: SEARCH.
4Repeat step 3if necessary until you find the
desired station.
●To tune to a weak station, press TUNE àor
ábriefly and repeatedly until you have found
optimal reception.
Programming radio stations
You can store up to a total of 40 radio stations
in the memory.
Automatic programming
Automatic programming will start with a chosen
preset number. From this preset number
upwards, former programmed radio stations will
be overridden.The system will only program
stations which are not in the memory already.
1Press PRESET ¡or ™to select the preset
number where programming should start.
Note:
– If no preset number is selected, default is preset
(1) and all your presets will be overridden.
2Press PROGRAM for more than 2 seconds to
activate programming.
➜AUTO is displayed and available stations are
programmed in order of waveband reception
strength: RDS, FM followed by MW. The last
preset automatically stored will then be played.
Manual programming
1Tune to your desired station (see “Tuning to
radio stations”).
2Press PROGRAM to activate programming.
3Press PRESET ¡or ™to allocate a number
from 1 to 40 to this station.
4Press PROGRAM again to confirm the setting.
➜The preset number and the frequency of the
preset station are shown.
5Repeat the above four steps to store other
stations.
●You can override a preset station by storing
another frequency in its place.
Tuning to preset radio stations
●Press PRESET ¡or ™until the desired preset
station is displayed.

English
3140 115 xxxxx
15
Radio Reception
RDS
Radio Data System is a service that allows
FM stations to show additional information. If
you are receiving a RDS station, and the
station name are displayed.
When automatic programming is used, RDS
stations will be programmed first.
Scrolling through different RDS
information
●Press RDS • NEWS briefly and repeatedly to
scroll through the following information (if
available):
–Station name
–Programme type such as NEWS, SPORT,
POP M ...
–Radio text messages
–Frequency
Note:
–If you press RDS and the RDS signal is not
available NO RDS is displayed.
Setting the RDS clock
Some RDS radio station may be transmitting a
real clock time at an interval of every minute. It
is possible to set the clock by using a time signal
which is broadcast together with the RDS signal.
1Tuned to a RDS station from FM band (refer to
“Tuning to radio stations”).
2Press and hold CLOCK SET until "SET
CLOCK" is displayed.
3Press RDS • NEWS.
➜"SEARCH RDS TIME" appears.
➜When RDS time is read, the current time will
be stored.
➜If the RDS station does not transmit RDS
time within 90 seconds, "NO RDS TIME"
appears.
Note:
– Some RDS radio station may be transmitting a
real time clock at a minute interval. The accuracy
of the transmitted time depends on the
transmitting RDS radio station.
Searching programme type
(PTY)
PTY helps you find a desired programme type.
To enable PTY, first programme RDS stations
into the tuner memory (see Programming radio
stations)
1While receiving an RDS station, press RDS •
NEWS briefly until the programme type is
displayed.
2Press PRESET ¡or ™ until the desired
programme type is displayed.
3Press and hold down on TUNE àor áto
start searching.
➜The radio tunes to a RDS station
broadcasting this programme type. If the
programme type is not available TYPE NOT
FOUND is displayed.
RDS Programme types
NO TYPE .......... No RDS programme type
NEWS .................... News services
AFFAIRS .......... Politics and current affairs
INFO .................... Special information programmes
SPORT ................ Sports
EDUCATE .......... Education and advanced training
DRAMA ................ Radio plays and literature
CULTURE .......... Culture, religion and society
SCIENCE .......... Science
VARIED ............. Entertainment programmes
POP M ................. Pop music
ROCK M .............. Rock music
MOR M ................. Light music
LIGHT M .......... Light classical music
CLASSICS ...... Classical music
OTHER M .......... Special music programmes
WEATHER .......... Weather
FINANCE .......... Finance
CHILDREN ...... Children’s programmes
SOCIAL ............. Social Affairs
RELIGION ...... Religion
PHONE IN ....... Phone In
TRAVEL ............. Travel
LEISURE .......... Leisure
JAZZ .................... Jazz Music
COUNTRY .......... Country Music
NATION M ....... National Music
OLDIES ............. Oldies Music
FOLK M .............. Folk Music
DOCUMENT ...... Documentary
TEST .................... Alarm Test
ALARM ................ Alarm

3140 115 xxxxx
16
English
Radio Reception
RDS News and Traffic
Announcement (TA)
You may set up the tuner in such a way that
listening to CD/AUX is interrupted by the
NEWS on traffic announcement of a RDS
station.This only works if the RDS station
broadcasts a NEWS signal while sending the
news.
1Tune to the desired RDS station.
2In CD, AUX or Standby mode, press RDS •
NEWS once or more on the remote control to
select the NEWS option.
➜NEWS ON, TA ON or OFF is displayed briefly.
➜NEWS is displayed if you have activated the
NEWS or TA option. Changing listening source
will not disarm the function.
Notes:
– When you receive RDS news or traffic
announcements during CD playback, playback will
pause and you will be able to hear the news/TA.
Playback resumes after the broadcast has finished.
–If you are using the RDS NEWS announcement,
the whole network is searched for the respective
news.
Disarming RDS News andTraffic
Announcement
There are a number of ways to
disarm the news feature:
●Press RDS • NEWS on the
remote control during
reception of the news option.

English
3140 115 xxxxx
17
Clock/Timer
Setting the clock
1In standby mode or system on, press and hold
CLOCK SET on the remote control for more
than 3 seconds.
➜SET CLOCK scrolls on the display.
➜The clock digits for the hours flash.
2Press VOLUME +/-to set the hours.
3Press CLOCK SET again.
➜The clock digits for the minutes flash.
4Press VOLUME +/-to set the minutes.
5Press CLOCK SET to confirm the time.
Viewing the clock
Press CLOCK SET
➜The clock time is displayed.
Setting the timer
●The system can be used as an alarm clock,
whereby the CD,TUNER is switched on at a set
time.The clock time needs to be set first before
the timer can be used.
●During setting, if no button is pressed within 90
seconds, the system will exit timer setting mode
automatically.
1In standby mode or system on, press and hold
TIMER on the remote control for more than 3
seconds.
➜SET TIMER and SELECT SOURCE scrolls
on the display.
2Press SOURCE or VOLUME +/-to select
sound source.
➜Display sequence shows CD, TUNER.
➜flashes.
3Press TIMER to confirm your desired mode.
4Press VOLUME +/-to set the hours.
5Press TIMER again.
➜The clock digits for the minutes flash.
6Press VOLUME +/-to set the minutes.
7Press TIMER to confirm the time.
➜The timer is now set and activated.
Activating and deactivating
TIMER
●Press TIMER on the remote to turn off the
timer or turn on to the last setting again.
➜If activated, the timer information will display
for a few seconds, then the system resumes to
the last active source or stays in standby mode.
➜If deactivated,“OFF” appears.
Note:
–The system will exit timer setting mode if no
button is pressed within 90 seconds.
Activating and deactivating
SLEEP
The sleep timer enables the system to switch off
by itself after a set period of time.
●Press SLEEP on the remote control once or
more.
➜Display shows SLEEP and
one of the sleep time options
in sequence: 90, 75, 60,...,
45,30,15, OFF, 90. if you have
selected a time. Once SLEEP is
activated, SLEEP is display.
●To deactivate, press SLEEP on the remote
control once or more until OFF is shown, or
press STANDBY-ON on the system or
remote control.

3140 115 xxxxx
18
English
Cleaning the Cabinet
●Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning Discs
●When a disc becomes dirty,
clean it with a cleaning cloth.
Wipe the disc from the centre
out.
●Do not use solvents such as
benzene, thinner, commercially
available cleaners, or antistatic
spray intended for analogue records.
Cleaning the disc lens
●After prolonged use, dirt or dust may
accumulate at the disc lens.To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
Maintenance
Specifications
AMPLIFIER
Output power .......................................... 2 x 5 W RMS
............................................................ 10 W + 10 W MPO
Signal-to-noise ratio ....................................... ≥62 dBA
Frequency response ......... 63 – 16000 Hz, ± 3 dB
Input sensitivity AUX ....................... 0.5 V (max. 2 V)
Impedance loudspeakers ......................................... 4 Ω
CD PLAYER
Frequency range .................................. 30 – 16000 Hz
Signal-to-noise ratio ............................................ 75 dBA
TUNER
FM wave range ................................... 87.5 – 108 MHz
MW wave range ................................ 531 – 1602 kHz
Sensitivity
– mono, 26 dB signal-to-noise ratio ............ 2.8 µV
– stereo, 46 dB signal-to-noise ratio ........ 61.4 µV
Selectivity ................................................................. ≥28 dB
Total harmonic distortion ..................................... ≤5%
Frequency response ..... 63 – 12500 Hz (± 3 dB)
Signal-to-noise-ratio ...................................... ≥50 dBA
SPEAKERS
Bass reflex system
Dimensions (w x h x d) .... 166 x 245 x 90 (mm)
GENERAL INFORMATION
AC Power ..................................... 220 – 240 V / 50 Hz
Dimensions (w x h x d) ..... 250 x 245 x 96 (mm)
Weight(with/without speakers) ........... 4.2 / 2.3 kg
Standby power consumption ............................ <3 W
Specifications and external appearance are
subject to change without notice.

English
3140 115 xxxxx
19
WARNING
Under no circumstances should you try to repair the system yourself, as this will invalidate the
warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If you
are unable to remedy a problem by following these hints, consult your dealer or Philips for help.
Problem Solution
CD OPERATION
“NO DISC”is displayed. –Insert a disc.
–Check if the disc is inserted upside down.
–Wait until the moisture condensation at the lens
has cleared.
–Replace or clean the disc, see “Maintenance”.
– Use a finalised CD-RW or CD-R.
RADIO RECEPTION
Radio reception is poor. –If the signal is too weak, adjust the antenna for
better reception.
–Increase the distance between the Micro HiFi
System and your TV or VCR.
GENERAL
The system does not react when buttons –Remove and reconnect the AC power plug and
are pressed. switch on the system again.
Sound cannot be heard or is of poor –Adjust the volume.
quality. – Check that the speakers are connected correctly.
–Check if the stripped speaker wire is clamped.
The left and right sound outputs are –Check the speaker connections and location.
reversed.
The remote control does not function –Select the source (CD or TUNER, for example)
properly. before pressing the function button (ÉÅ,í,
ë).
–Reduce the distance between the remote control
and the system.
–Insert the battery with its polarities
(+/– signs) aligned as indicated.
–Replace the battery.
–Point the remote control directly toward
IR sensor on the front of the system.
The timer is not working. – Set the clock correctly.
–Press TIMER to switch on the timer.
The Clock/Timer setting is erased. –Power has been interrupted or the power cord
has been disconnected. Reset the clock/timer.
Troubleshooting
