Philips MC-70 User manual

• 2 x 50 watts RMS Stereo
• wOOx Technology Speaker System for deeper bass
• Incredible Surround™
• Bass & Treble Control
• 2-way Bass Reflex Speaker System with wOOx Speaker Technology
• Flat Metal Cone Woofers for greater sound clarity
• Plays CD, CD-R and CD-RW discs
• Logic Tape Deck with Auto Reverse
• One Touch CD Synchro Recording
• Digital Out for perfect CD Recording
• Subwoofer Ready
• Plug & Play for easy installation of radio stations
• 35-key Remote Control
• 4-Color Packaging
Micro Hi-Fi System with 3CD Changer,
100 watts Total Power, Logic Deck and
wOOx Technology Speaker System
100 w
MC-70
MC-70

2
21 3
TAPE AUX/CDRTUNERCD 123
MUTE
CLOCKCD RESUME
SNOOZEDIM SLEEP
AUTO REV. TIMER TIMER ON/OFF
CD DIRECT
VOLUME
REPEAT PROGRAM
BASS TREBLE
WOOX WOOX LEVEL
-+-+
á
à
ë
í
Ç
SHUFFLE
IS
Å
É
Sound Enhancement
2 x 50Watts RMS Stereo
50 watts continuous RMS power output per channel, at 8
ohms, from 120Hz to 15kHz, with no more than 10%
Total Harmonic Distortion (THD).
wOOxTechnology
Philips patented wOOxTechonolgy ensures superior bass
results. The dual suspension bass radiator, together with
dedicated amplifier circuitry, is especially designed to
produce and handle high dynamic sound signals at very
low frequencies. Because of the dual suspension, the
excursion of the membrane can be extreme (see
illustration). This is in combination with the symmetrical
sandwich construction, provides for very low and precise
bass without noticeable distortion. The net effect of using
wOOx Technology is a tight bass sound that is
significantly "lower and louder" than conventional mini
shelf systems.
3-Step wOOx Level Control
As the human ear does not perceive low frequencies at
the same level as higher frequencies (though at the same
"volume"), the bass sound needs to be enhanced to
achieve maximum impact. The wOOx is progressively
driven at different optimization levels in setting wOOx 1,
2 and 3.
Bass &Treble Control
Bass & Treble control allows sound adjustment of high
and low frequencies to personal preferences.
Incredible Surround™
An exciting, new, psycho-acoustic method of widening
the stereo spatial image especially suited for applications
with limited separation of left and right speakers.
2-Way Bass Reflex Speaker System
Equipped with one 51/4" woofer and one Cone Dome
Tweeter for crisp high tones.
Flat Metal ConeWoofers
The lightweight and strong metal cone woofer enables
greater sound clarity.
AM/FM Stereo DigitalTuner
State-of-the-art precision tuning system insures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Design
Contemporary Design
A striking glass and aluminum look coupled with Hi-Fi
design reference loudspeaker boxes complete with wood
finishing to match and blend with the modern home.
FTD Display
This large display is easy to read at any distance with no
distortion nor distraction makes it easy to recognize
different functions at a glance.
Ergonomic Control Layout
Convenient grouping of related functions along with a
positive tactile feedback from front mounted controls
tilted at an angle optimize this model for comfort and
convenience.
Detachable Cloth Speaker Grilles
Detachable cloth covered grilles protect delicate speaker
components in a rich high-tech styling.
Convenience
Change while Play
Flexibility of changing 2 discs while still listening to the
third disc being played.
Plays CD,CD-R and CD-RW discs
The player offers 100% playback guarantee of CD, CD-
Recordable and CD Rewritable CD's over the entire
lifetime of the player. Even CD-RW audio recordings on
computers can be used.
Dual LogicTape Deck
Offers the ability to switch from one function, such as
fast forward, to another function, such as play by remote
control.
Auto Reverse
The feature employs an auto revere mechanism to sense
the end of the tape and automatically reverse the
direction of tape travel in the PLAY mode providing an
uninterrupted, continuous flow of music without manually
flipping the cassette tape.
35-key Remote Control
This infrared remote control operates volume +/–, all
CD functions (POWER, NEXT, PREVIOUS, PLAY, STOP,
PAUSE, SHUFFLE, REPEAT, PROGRAM, CD123, CD
DIRECT 1, 2, 3, CD RESUME, F and G) AUX/CDR
select,TUNER select,TAPE select, MUTE, CLOCK, DIM,
SLEEP, SNOOZE, AUTO REVERSE, TIMER, TIMER
ON/OFF and sound enhancement features including,
Incredible Surround, Bass/Treble, wOOx on/off and
wOOx level.
Plug & Play
Press play button for 5 secs to automatically program 40
tuner presets (FM only).
40-Random Channel Presets
Random memory presets allow pre-programming of up
to 40 AM and FM station frequencies into the tuner
memory.
40-Track CD Random Program
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Shuffle Disc
Plays all selections on a particular disc in random order,
ignoring the sequential order in which they were
originally recorded.
Repeat
Repeat your favorite track.
Pause
Interrupts playback of a CD without returning to the
beginning of the disc, so when play resumes, the music
begins exactly where it stopped.
UPC Code: 0 3784990 9393
Product Dimensions:
10.4"W x 12.2" H x 13.4" D (electronics)
8.3"W x 12.2" H x 9.4" D (speakers)
Package Dimensions:
24.6"W x 16.1" H x 18.7" D
Product weight: 31 lbs.
Carton contains: 3CD Changer Micro System, Multi-Function Remote
Control,Batteries, Operating instructions,Warranty information
Printed in Singapore
Date printed : Sep 2000
©2000 Royal Philips Electronics N.V.
All rights reserved.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Incredible Surround™ is a Trademark of Philips Consumer Electronics
Company
MC-70
MC-70
Next/Previous Skip
This two button feature offers you the opportunity to
skip back to the previous track or skip up to the next
track instantly.
Digital Out for perfect CD Recording
The digital out connection provides a hook up to any
digital recording system (e.g. CDR).
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start
of a recording on an analog audio cassette deck with the
start of a CD or a CD program.
Clock/Alarm & Sleeptimer
Set the alarm portion of a built-in digital clock to wake
you to music from your favorite CD or an AM/FM radio
station at any desired time of the day. Sleep timer settings
of 60,45,30 or 15 minutes.
3 Dim Display modes (including nite mode)
2 different display options showing different amounts of
display activity can be selected and 1 nite mode display
which shows minimal display activity and turns most of
the lights off.
suspension 1suspension 2
excursion 1
excursion 2
excursion 2
excursion 1
wOOxTechnology
double suspension = double excursion
